SDV-FTX/FRX
Ultra-HDMI (4K/60) over Fiber extender
OPERATION MANUAL
3
DISCLAIMERS
The information in this manual has been carefully checked and is
believed to be accurate. CYP (UK) Ltd assumes no responsibility for any
infringements of patents or other rights of third parties which may result
from its use.
CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be
contained in this document. CYP (UK) Ltd also makes no commitment to
update or to keep current the information contained in this document.
CYP (UK) Ltd reserves the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer file, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express
written permission and consent from CYP (UK) Ltd.
© Copyright 2011 by CYP (UK) Ltd.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
4
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of fire,
electrical shock and injury to persons.
• To prevent fire or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts inside
the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if
it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufficient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE SUMMARY OF CHANGE
v1.00 11/05/2018 First release
5
CONTENTS
1. Introduction...........................................6
2. Applications ...........................................6
3. Package Contents ..................................7
4. System Requirements ...........................7
5. Features..................................................8
6. Operation Controls and Functions .......9
6.1 Transmitter's Front Panel ........................ 9
6.2 Transmitter's Rear Panel ........................10
6.3 Receiver's Front Panel ............................11
6.4 Receiver's Rear Panel..............................12
6.5 Basic AV Extension ..................................13
6.6 Advanced AV Extension ........................14
7. Connection Diagram .......................... 18
8. Specifications...................................... 19
8.1 Transmitter's Technical Specifications ...19
8.2 Receiver's Technical Specifications ...21
9. Acronyms............................................. 23
6
1. INTRODUCTION
This Transmitter and Receiver set is designed for high-quality, IP routable,
AV extension with minimum latency. By using a sophisticated ultra-
light compression scheme (lossless for most content) it’s a great solution
for extending 4K audio/video streams (HDMI or DisplayPort) and data.
Advanced HDMI content such as HDR (High Dynamic Range), 10-bit
colour and multi-channel HD Bitstream audio can be transmitted in
pass-through mode. The use of interchangeable, field replaceable, SFP+
modules allows for transmission distances of up to 30km (Maximum
transmission distance depends on the SFP+ modules used.). Multiple
control and data signals may also be transmitted along with the audio
and video, including IR, RS-232, USB (for KVM) and Ethernet.
When combined with the optional control center or control software,
the functionality of the extenders expands exponentially. Multiple
Transmitters and Receivers may be combined with one or more 10Gb
fiber Ethernet switch and the units can be used together to form a
distributed video matrix, a multi-viewer system, or a video wall system
adding to their flexibility in large event installations.
2. APPLICATIONS
Video, USB, Audio, LAN, IR, and RS-232 over fiber extension
Hotel or convention center display multi-monitor broadcast
Long distance data and video transmission immune to RF interference
Distributed video matrix system
Distributed video wall system
Remote KVM control of a system
7
3. PACKAGE CONTENTS
Transmitter
1×HDMI/DP over Fiber Transmitter
1×12V/3A DC Power Adaptor
1×Power Cord
1×Operation Manual
Receiver
1×HDMI/DP over Fiber Receiver
1×12V/3A DC Power Adaptor
1×Power Cord
1×Operation Manual
4. SYSTEM REQUIREMENTS
HDMI or DisplayPort source equipment such as media players, video
game consoles PCs or set-top boxes.
HDMI receiving equipment such as HDTVs, monitors or audio
amplifiers.
Analogue audio receiving equipment such as headphones, audio
amplifiers or powered speakers.
A 10 Gigabit fiber Ethernet network switch with jumbo frame and
IGMP snooping support is required for distributed video systems.
PC control software or control system hardware to configure
distributed matrix, video wall or multi-view systems. (Optional)
8
5. FEATURES
HDMI 2.0 and DVI 1.0 compatible
HDCP 2.2 and HDCP 1.x compliant
IP switchable with minimum latency (requires optional control center/
software)
Ultra-light compression, lossless for most content
Extension up to 30km (depending on the fiber module used)
Independent breakaway A/V matrix switching (requires optional
control center/software)
Video wall generation (requires optional control center/software)
Multi-view compositing (requires optional control center/software)
Supports pass-through of 10/12-bit HDR sources (Point-to-Point and
Genlock mode only)
Supports pass-through of audio formats including LPCM 2.0/5.1/7.1,
Bitstream and HD Bitstream from HDMI or DisplayPort sources
Analogue stereo audio extension, insertion and extraction (insertion
and extraction requires optional control center/software)
Bi-directional RS-232, IR, & USB 2.0 extension
Data Transmission interfaces with 10 gigabit Ethernet via XFI, IEEE
802.3ae, compatible SFP+ fiber modules
Supports the use of an external control center or control software to
provide expanded functionality (Contact your authorised dealer for
more information)
9
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Transmitter's Front Panel
POWER GbE VIDEO TX
LINK
RX USB VIDEO SWITCH
SDV-FTX
1 2 3 4 5 6 7 8
1POWER LED: This LED will illuminate to indicate the unit is on and
receiving power.
2GbE LED: This LED illuminates and blinks to indicate activity on the
gigabit Ethernet port.
3VIDEO LED: This LED will illuminate when the currently selected input
is live. When no source is detected the LED will remain off.
4LINK LEDs: These LEDs illuminate to indicate the fiber network
connection’s status.
TX: This LED blinks to indicate data transmission activity.
RX: This LED blinks to indicate data reception activity.
5USB LED: This LED will illuminate when the USB port is actively paired
with a Receiver’s USB port.
6BLANK BUTTON: Currently no assigned function.
7VIDEO SWITCH BUTTON: Press this button to switch between the
HDMI and DisplayPort inputs.
Note: Press and hold the Video Switch button for 30 seconds when
powering the unit on to reset the unit to the factory defaults.
8RESET: Press and hold this button for 3 seconds to soft-reboot the
unit.
10
6.2 Transmitter's Rear Panel
DC 12V
LAN USB
RS232
AUDIO IR OUT IR IN
DP IN
HDMI IN SFP+
21 3 8
456 7
9 10
1DP IN: Connect to DisplayPort source equipment such as a PC or
laptop.
2HDMI IN: Connect to HDMI source equipment such as a media player,
game console or set-top box.
3SFP+: Connect a standard SFP+ module to allow data transmission
over optical fiber to a compatible Receiver.
Note: The SFP+ module must support a dual-optical fiber connection
style, such as LC, or be pre-terminated dual-optical fiber cables. Single-
mode and multi-mode support is dependent on the SFP+ modules used.
4AUDIO IN: Connect to the stereo analogue output of a device such as
a CD player or PC.
5IR OUT: Connect to the provided IR Blaster to transmit IR signals to
devices within direct line-of-sight of the IR Blaster.
6IR IN: Connect to the provided IR Extender to extend the IR control
range of remotely located devices. Ensure that the remote being used
is within direct line-of-sight of the IR Extender.
7RS232: Connect to a PC, laptop or a serial controllable device for the
extension of RS-232 signals.
8LAN: Connect to an Ethernet supporting device or to your local
network as appropriate to extend the network between the
Transmitter and Receiver.
9USB: Connect directly to a PC to extend its USB functionality to the
port on the connected Receiver.
10 DC 12V: Plug the 12V DC power adapter into this port and connect it
to an AC wall outlet for power.
