Creality HALOT-ONE PLUS Manuel utilisateur
3D Printer User Manual
V1.0
HALOT-ONE PLUS
Create reality，achieve dreams
HALOT-ONE PLUS
Dear Consumers,
Thank you for choosing our products.For the best experience,please read the instructions before operating the Printer. Our
teams are always ready to render you the best services. Please contact us via the phone number or e-mail address provided
at the end when you encounter any problem with the Printer.
For a better experience in using our product, you can also access how to use the printer in the following ways:
View the accompanied instructions and videos in the U disk.
Visit our official website www.creality.com to find relevant software/hardware information,contact details and operation and
maintenance instructions.
Firmware/Software Downloads and Upgrades
The product has access to both LycheeSlicer and CHITUBOX. WIFI printing and access to the Creative Cloud are under development.
Download the firmware and HALOT BOX slicing software at: https://www.creality.com
Download the CHITUBOX slicing software at: https://www.chitubox.com
Download the LycheeSlicer slicing software at: https://lychee.mango3d.io
Slicing software supported：
NOTES
1
2
3
4
5
6
7
8
9
10
Do not use the printer any way other than described to avoid personal injury or property damage.
Do not place the printer near any heat source or flammable or explosive objects. We suggest placing it in a well-ventilated, low-dust environment.
Do not expose the printer to violent vibration or any unstable environment, as this may cause poor print quality.
Please use recommended resin in case damage to machine.
Do not use any other power cable except the one supplied. Always use a grounded three-prong power outlet.
Please do not open the plastic cover during usage, otherwise the printing will be interrupted.
Do not wear cotton gloves when operating the printer. Such cloths may become tangled in the printers moving parts leading to burns, possible bodily injury, or printer damage.
Please wait after the print is finished. please wear gloves to take out the print tools.
Children under 10 years should not use the printer without supervision.
11
12
Tips Do not plug or unplug the power cord when power on.
Clean the printer frequently. Always turn the power off when cleaning, and wipe with a dry cloth to remove dust, adhered printing plastics or any other material off the frame,
guide rails, or wheels. Use glass cleaner or isopropyl alcohol to clean the print surface.
Users should comply with the laws and regulations of the corresponding countries and regions where the equipment is located (used), abide by professional ethics, pay attention to safety
obligations, and strictly prohibit the use of our products or equipment for any illegal purposes. Creality will not be responsible for any violators' legal liability under any.
Contents
Equipment Introduction 01-01
Equipment Parameters 02-02
Parts List 03-03
04-05
11-16
06-10
17-17
18-18
Assemble the 3D Printer
Use the 3D Printer
Troubleshooting
Print Method
Wiring Connection
19-19
FCC Statement
20-20
IC Cautiont
01
1. Equipment Introduction
Hexalobular socket screw
Leveling screw
Platform plate
Resin vat
Air filter
Power receptacle
Power switch
USB port
Touch screen
Limit sensor
9
7
8
10
11
Resin vat fixing screw
02
Model Name HALOT-ONE PLUS
172*102*160mm (length*width * height)
4320*2560
0.04mm
1-4S/ layer
0.01-0.2mm
236*243*418 mm
310*300*530mm
8.6KG
USB Disk，Creality Cloud App, Creality Cloud Online, WiFi Print
中文(简/繁)/ English/ Español/ Deutsche/ Français/ Pусский/ Português/ Italiano/ Türk/Nederlands/Polskie/日本語/한국어
Win7/Win8/Win 10 64bit, Mac system(32-bit is not supported)
Common rigid photosensitive ,Standard resin ,High hardness ,High toughness ,Dental model resin
Integral Light Source(wavelength 405nm)
100-240V~,50/60Hz
100WRated Power
Machine Size
Package Size
Net Weight
Compatible Resin
Machine Language
Gross Weight
Print Method
Slicing Software Operation System
Build Size
XY Axis Resolution
Touch Screen
Light Source Type
Rated Voltage
XY Axis Accuracy
Print Speed
Layer Thickness
Basic Parameters
5 inch touch screen
6.8KG
2. Equipment parameters
03
3. Parts Content List
Tool list
Print platform x 1 Resin vat x 1 3D printer x 1
Tips: the above accessories are for reference only lease refer to the physical accessories!
4
3
U disk x 1 Paper funnel x 2
Power cable x 1
Release film x 1
6
5Metal blade x 1
Screwdrivers x 1set
7Plastic blade x 1 8Calibration card x 1
9Tray fixing screw x 2
04
4. Assemble the 3D Printer
Take out the resin vovt align the two tray fixing screws with the corresponding holes and tighten them to fix. (as the picture shows)
Resin vat x 1
9
10
10
Tray fixing screw x 2
05
4. Assemble the 3D Printer
Machine body x 1
Plastic Upper cover x 1
Note: put the upper cover on the machine body and the installation is completed.
06
5. Interface Information
Note: Check whether the light source is normal The UI interfaceis only for reference , the actual UI.
Settings
