Enhanced High Density (EHD) Panel

TECP-91-008 • Rev C • January 2019

Page 2

3.3 Grounding the Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

4 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . 11

4.1 Loading Adapter Packs or Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4.2 Accessing Connectors on Back of Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4.3 Closing Blade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4.4 Removing Blade from Front (if Required) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4.5 Installing Trunk Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

5 ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . 22

5.1 Channel Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . 22

5.2 Cabinet Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

5.3 UMB Brackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

6 CONNECTING AND ROUTING PATCH CORDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

7 CONTACT INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . 26

INTRODUCTION

This user manual describes the Enhanced High density (EHD) Panel. Included in this

user manual are all procedures required in installing the EHD Panel as well as

operation procedures.

Revision History

Trademark Information

CommScope (logo), CommScope, and Enhanced High Density Panel are trademarks

Applicable Standards

UL 60950-1, 2nd Edition, 2007-03-27 (Information Technology Equipment - Safety -

Part 1: General Requirements

CSA C22.2 No. 60950-1-07, 2nd Edition, 2007-03 (Information Technology Equipment

-Safety - Part 1: General Requirements)

Admonishments

Important safety admonishments are used throughout this manual to warn of possible

hazards to persons or equipment. An admonishment identifies a possible hazard and

then explains what may happen if the hazard is not avoided. The admonishments — in

the form of Dangers, Warnings, and Cautions — must be followed at all times.

Content Page

REV DATEREASON FOR CHANGE

Rev C January 2019 Added new information on shipment (product stacking).

TECP-91-008 • Rev C • January 2019

Page 3

General Safety Precautions

1 PRODUCT DESCRIPTION

1.1 General Description

The Enhanced High density (EHD) Panel is a fiber optic connector panel intended for

use in large data centers in a direct connect or interconnect environment. The EHD

Panel mounts in a 19-inch (48.26 cm) or 23-inch (58.42 cm) equipment rack with a 3-

inch or 6-inch channel. The EHD Panel will also mount in 19-inch or 23-inch cabinet.

The EHD Panel is available in 1RU, 2RU, or 4RU size. In each 1RU of rack space, a

fully loaded panel provides 144 LC (72 Duplex) terminations and/or 72 MPO ports. The

panel features slide out blades (three per 1.75 inches (4.44 cm) of rack space)

accessible from front or rear and providing full hand access to adapters and

connectors. Each blade can accommodate two adapter packs or modules.

1.2 Major Components

Figure 2 shows the main components of the EHD Panel. They are as follows:

•Blade—holds two LC-MPO modules or two MPO adapter packs; slides out toward

front or rear of the panel. There are three blades per 1RU of rack space. The

blade has a first and second position. The first position is used to plug in

connectors to the front of an adapter pack or module. The second position (further

removed from the front of the panel) is used install adapter packs and modules,

and for access to clean the rear connectors when using adapter packs.

Danger: Danger is used to indicate the presence of a hazard that will cause severe personal

injury, death, or substantial property damage if the hazard is not avoided.

Warning: Warning is used to indicate the presence of a hazard that can cause severe personal

injury, death, or substantial property damage if the hazard is not avoided.

Caution: Caution is used to indicate the presence of a hazard that will or can cause minor

personal injury or property damage if the hazard is not avoided.

Caution: When mounting equipment in the rack make sure mechanical loading is even to avoid

a hazardous condition, such as loading heavy equipment in the rack unevenly. The rack should

safely support the combined weight of all equipment it supports.

Caution: This equipment is to be installed only in Restricted Access Areas (dedicated

equipment rooms, equipment closets, etc.).

Note: In this figure, the 2RU panel is shown. Main components are analogous for

other RU sizes. For comparative views of the three panel sizes, refer to Section

1.3 on Page 4.

TECP-91-008 • Rev C • January 2019

Page 4

Figure 1. EHD Panel Main Components (2U Model Shown)

•Rear Cover—can be removed to allow a blade to be removed from the rear of the

panel. It is also removed to route in and secure fiber cables on the rear of the

panel.

•Grounding Location—is where a two-hole lug (not provided) and ground wire

are attached to connect the panel ground PEM nuts to office ground. The two-hole

lug to be used requires a spacing between holes of 0.625 inch (1.59 cm).

•Mounting Brackets—can be flipped around to provide either front- or rear-facing

mounting on a channel rack. The mounting brackets can be mounted with a

recess of either 3 inches (7.62 cm) or 6 inches (15.24 cm).

•Front Door—swings down to provide access to the interior of the panel. The door

features a double-hinged design that allows users to open the door without

interfering with equipment below the panel on the same rack, or to move the door

into its lower position allowing the lowest blade to open freely.

•Designation Label—provides physical space for recording fiber designations.

1.3 Comparative View of 1RU, 2RU, and 4RU Panel

The figures below provide comparative views of the different sizes of the EHD Panel,

as follows: 1RU panel (Figure 2); 2RU panel (Figure 3); 4RU panel, front view

(Figure 4); 4RU panel, rear view (Figure 5). Figure 6 shows the rear of the 4RU panel

with rear cover removed. The 4RU panel has a removable mid-shelf, also shown in

Figure 6.

26418-A

MOUNTING

BRACKET (2X)

BLADE

(PARTLY REMOVED

FROM CHASSIS)

DESIGNATION LABEL FRONT

DOOR

GROUNDING

LOCATION

REAR

COVER

TECP-91-008 • Rev C • January 2019

Page 5

Figure 2. EHD 1RU Panel

Figure 3. EHD 2RU Panel

Figure 4. EHD 4RU Panel

TECP-91-008 • Rev C • January 2019

Page 6

Figure 5. EHD 4RU Panel, Rear View

Figure 6. EHD 4RU Panel, Rear View, Rear Cover Removed

1.4 Specifications

Table 1 lists specifications for the EHD Panel.

Note: The 4RU panel comes with a rear midshelf, shown in Figure 6. This

midshelf can be removed for easier access to the bottom blades when cabling or

for high count cables that will be terminated on both lower and upper blades. The

midshelf should be used when many trunks are terminated in the panel. The

midshelf prevents the weight of the trunks terminated on the top blades from

weighing down on the trunks terminated at the bottom of the panel thus impeding

their movement.

26426-A

MIDSHELF

TO REMOVE THE MIDSHELF,

REMOVE THESETWO SCREWS

TECP-91-008 • Rev C • January 2019

Page 7

*between mounting holes

1.5 Transportation and Storage

Products packaged in cartons may be stacked two high in transportation and storage.

Some products packaged in spools may be stacked two high in transportation and

storage. See product packaging labels for designation.

2 UNPACKING AND INSPECTION

1. Inspect the exterior of the shipping container(s) for evidence of rough handling

that may have damaged the components in the container.

2. Unpack each container while carefully checking the contents for damage and

verify with the packing slip.

3. If damage is found or parts are missing, file a claim with the commercial carrier

and notify CommScope Customer Service. Save the damaged cartons for

inspection by the carrier.

4. Refer to Section 7 on Page 26 if you need to contact CommScope.

Table 1. EHD Panel Specifications

PARAMETER SPECIFICATION REMARKS

Operating conditions −14°F to +140°F (−10°C to +60C)

Humidity 10% to 95% RH No condensation

Storage conditions −40°F to +158°F (−40°C to +70°C)

Panel Dimensions and Weight

1RU panel Dimensions:

21.17 in. (53.76 cm) D

x 17.24 in. (43.78 cm) W

x 1.72 in. (4.37 cm) H

Weight without packaging:

14.0 lb. (6.4 Kg);

Weight with packaging:

19.5 lb. (8.9 Kg)

2 RU panel Dimensions:

21.17 in. (53.76 cm) D

x 17.24 in. (43.78 cm) W

x 3.44 in. (8.74 cm) H

Weight without packaging:

19.4 lb. (8.8 Kg);

Weight with packaging:

25.6 lb. (11.6 Kg)

4 RU panel Dimensions:

21.17 in. (53.76 cm) D

x 17.24 in. (43.78 cm) W

x 6.94 in. (17.63 cm) H

Weight without packaging:

32.4 lb. (14.7 Kg);

Weight with packaging:

42.0 lb. (19.1 Kg)

All panel Width with 19-inch brackets* 18.31 in. (46.51 cm);

Note: There will be cardboard and/or plastic inserts inside of the panel to prevent

damage during shipping. Panel front door and rear cover will need to be opened

to remove them.

TECP-91-008 • Rev C • January 2019

Page 8

5. Save all shipping containers for use if the equipment requires shipment at a future

date.

3 PANEL INSTALLATION

3.1 Overview

The EHD Panel, shown in Figure 7, is mounted in a 19 inch (48.26 cm) channel rack or

cabinet. When mounting into a cabinet, it is recommended that the rear mounting rails

be 24 inches back (60.96 cm) from the front mounting rails. Trunk breakouts are

intended to come into the rear right or left side of the panel. CommScope trunks with

standard breakouts and gland adapters are the preferred method.

If required per local standards, the panel can be grounded as described in Section 3.3

on Page 10. Ground lugs and ground cables are not provided with the panel.

Figure 7. Mounting Options

Caution: This equipment is to be installed only in Restricted Access Areas (dedicated

equipment rooms, equipment closets, etc.).

26405-B

3.0 IN.

(76.2 CM) 6.0 IN.

(152.5 CM)

RIGHT SIDE VIEW

OF CHASSIS

FRONT OBLIQUE VIEW

OF CHASSIS

MOUNTING POSITION FOR FRONT OF 3-INCH CHANNEL

MOUNTING POSITION FOR BACK OF 3-INCH CHANNEL

MOUNTING POSITION FOR BACK OF 6-INCH CHANNEL

MOUNTING POSITION

FOR FRONT OF

3-INCH CHANNEL

MOUNTING POSITION FOR

BACK OF 3-INCH CHANNEL

MOUNTING POSITION

FOR BACK OF

6-INCH CHANNEL

MOUNTING LOCATION

FOR GROUND LUG

(OPTIONAL)

TECP-91-008 • Rev C • January 2019

Page 9

3.2 Mounting the Panel

The panel can be installed in a 19-inch (48.26 cm) or 23-inch (58.42 cm) equipment

rack with a 3-inch or 5-inch channel, as shown in Figure 7. Use the following procedure

to mount the panel:

1. Obtain the following tools and equipment:

• Phillips #2 screwdriver;

• Mounting hardware provided.

Figure 8. EHD Panel as Shipped

2. Select the mounting position to be used referring to Figure 7, and if required

remove and re-install the mounting brackets on the panel using the screws

holding the brackets when shipped.

3. Once the mounting brackets are located in the correct position (Figure 10):

a. Select two mounting screws from the accessory pack, and screw the two

screws into the rack bottom mounting position on each rail approximately 1.5

turns (so most of the screw shank is still out).

b. Place the open slots on the bottom of the mounting brackets onto these

screws.

c. Secure the brackets with mounting screws at higher points on the bracket.

Use the first full mounting hole for the top screw.

d. Tighten the bottom screws.

Note: The panel is shipped with the 19-inch mounting brackets at the 3-inch

recess position, as shown in Figure 8. The two 23-inch mounting/shipping

brackets mounted further back can be removed and discarded. To ease

installation, the back cover and side plate/gland adapters assemblies should also

be removed. See Section 4.5 on Page 16.

26531-A

BACK

COVER

19-IN.

MOUNTING BRACKET (2X)

23-IN. SHIPPING/

MOUNTING

BRACKET (2X)

SIDE PLATE/

GLAND

ADAPTERS

ASSEMBLY (4X)

TECP-91-008 • Rev C • January 2019

Page 10

Figure 9. EHD Panel as Shipped

3.3 Grounding the Panel

A termination (for an M4 screw) is provided on the panel for a frame ground

connection, if required. The connection must be made in accordance with local and

national electrical codes.

Use the following procedure, referring to Figure 10.

1. Locate the ground location on the panel.

Figure 10. Grounding Location

26419-A

SUPPORT CHASSIS

ON SCREW SHANKS

26420-A

RIGHT SIDE VIEW

OF CHASSIS

GROUNDING

LOCATION

Autres manuels pour EHD

Table des matières

Autres manuels CommScope Matériel réseau

CommScope

CommScope NETCONNECT 1479542-1 Manuel utilisateur

CommScope

CommScope AMP NETCONNECT MRJ21 Manuel utilisateur

CommScope

CommScope Mini-OTE 300 Manuel utilisateur

CommScope

CommScope NG4access ODF Platform Value-Added Module Manuel utilisateur

CommScope

CommScope SYSTIMAX AirSPEED AP542 Manuel utilisateur

CommScope

CommScope ION-U EU H 7P/80-85P/17P/19P Manuel utilisateur

CommScope

CommScope ION-M7P Manuel utilisateur

CommScope

CommScope SYSTIMAX 360 iPatch G2 MPO Manuel utilisateur

CommScope

CommScope SCIL-B Manuel utilisateur

CommScope

CommScope ONECELL RP5200 Manuel

CommScope

CommScope TC-96370-IP Manuel utilisateur

CommScope

CommScope SYSTIMAX EHD Manuel utilisateur

CommScope

CommScope Uniprise Solutions HFTP-HD6B-1U-24 Manuel utilisateur

CommScope

CommScope FPX Series Manuel utilisateur

CommScope

CommScope NG4access ODF Platform Value-Added Module Manuel utilisateur

CommScope

CommScope FPX Series Manuel utilisateur

CommScope

CommScope RUCKUS SmartZone 100 Manuel utilisateur

CommScope

CommScope OneCell RP5000 Series Mode d’emploi

CommScope

CommScope RUCKUS SmartZone 300 Manuel utilisateur

CommScope

CommScope SD-4U-SPLICE PANEL Manuel utilisateur

CommScope

CommScope ION-U EU H 23/23 Manuel utilisateur

CommScope

CommScope FOSC-OC-6 Manuel utilisateur

CommScope

CommScope LSX Manuel utilisateur

CommScope

CommScope ION-U EU H 7P/80-85P/17P/19P Manuel utilisateur

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

ADC

ADC DSX-1 Manuel

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur
