CA 610 Owners Manual

CAUTION!

Be certain that the vehicle is outdoors before using this or any re-

motevehiclestartingdevice. Arunningengineproducesdangerous

carbon monoxide fumes which can be harmful or fatal if prolonged

exposure occurs. DO NOT remote start the vehicle if the car is

garaged

128-6530

2 of 10

Page 2

Your Remote Start Alarm System has many features and available options

some of which are selected at time of installation. Consult your installing

dealer for options that may have been installed and are not listed.

ARMING THE SYSTEM:

1. Turn the engine OFF, exit the vehicle, and close all doors, hood and trunk.

2. Press and release the Arm button of your key chain transmitter one time.

The parking lights will flash once, the siren will chirp once, and the dash

mounted LED will begin to flash slowly confirming the system is armed. If you

have the optional door lock/unlock circuit installed, the doors will lock.

NOTE: If the siren/horn sounds 3 chirps, then you have left a door, trunk, or

hood lid ajar. Simply close the opened entry point to provide full protection. If

the siren "chirped" 3 times, sometime after arming, the exclusive delayed

dome light learn circuit has been programmed and the system detected a

open entry point after the learned delay expired. Again, closing the hood,

trunk, or doors will correct the problem and you do not need to disarm the

system to make the correction. If the siren/horn did not sound when arming,

then the chirps have been turned off and you should refer to the section titled

"ELIMINATING THE ARM/DISARM CHIRPS" in this manual.

SILENT ARMING:

1. Turn the engine OFF, exit the vehicle, and close all doors, hood and trunk.

2. Press and hold the Arm button of your key chain transmitter for 2 seconds.

The parking lights will flash once, and the dash mounted LED will begin to

flash slowly confirming the system is armed. The siren will not chirp. If you

have the optional door lock/unlock circuit installed, the doors will lock.

NOTE: If the siren/horn sounds 3 chirps, then you have left a door, trunk, or

hood lid ajar. Simply close the opened entry point to provide full protection. If

the siren "chirped" three times, sometime after arming, the exclusive delayed

dome light learn circuit has been programmed and the system detected a

open entry point after the learned delay expired. Again, closing the hood,

trunk, or doors will correct the problem and you do not need to disarm the

system to make the correction. If the siren/horn did not sound when arming,

then the chirps have been turned off and you should refer to the section titled

"ELIMINATING THE ARM/DISARM CHIRPS" in this manual.

128-6530

3 of 10

ARMING THE SYSTEM:

If the passive arming feature has been selected:

1. Turn the engine OFF, exit the vehicle, and close all doors, hood and trunk.

The dash mounted LED will begin to flash rapidly indicating that the 30

second passive arming timer has begun. If the LED does not begin to flash

rapidly, then you have left a door, hood, or trunk ajar. Closing this entry point

will allow the arming cycle will begin. If any entry point is opened during the

30 second arming cycle, arming will be suspended. When all entry points are

closed, the arming cycle will begin again.

At the end of the 30 seconds, the parking lights will flash once, the siren will

chirp once, and the dash mounted LED will begin to flash slowly confirming

the system is armed. If the siren did not sound when arming, then the chirps

have been turned off. Refer to the section on "Eliminating the Arm/Disarm

Chirps" shown later in this manual. Passive door locking is a selectable

feature. If you have the optional door lock/unlock circuit installed, the doors

may or may not lock passively depending upon the setup during installation.

PROTECTION WHILE THE SYSTEM IS ARMED:

Opening any protected entry point, hood, trunk, or doors will cause the alarm

to trigger immediately. The siren will sound and the parking lights will flash

for 30 seconds, then stop and continue to monitor all protected entry points. If

the thief left the door opened, the System will sound for six 30 second cycles

then shut down, isolate the triggered zone and continue to protect all other

zones.

Whenever the system is armed, the dash mounted LED will slowly flash. This

serves as a visual deterrent to a potential thief. This LED is a very low current

light emitting diode, and will not cause the battery to drain even if left

unattended for long periods of time.

Whenever the system is triggered, the vehicle's parking lights will flash for the

full siren sounding period. Optional - whenever the system is triggered, the

interior courtesy light will flash for the full siren sounding period.

Whenever the system is armed, the vehicle starter circuit is disabled, and the

vehicle will not start with the ignition key.

Whenever the system is armed, any strong impact to the vehicle will cause

the shock detector to trigger the alarm. Any lesser impact will cause the pre-

detect stage of the shock sensor to emit a few short series of warning tones

from the siren.

Page 3

128-6530

4 of 10

Page 4

DISARMING THE SYSTEM:

As you approach the vehicle, press and release the Disarm button on the

keychain transmitter. The parking lights will flash 2 times, the siren will chirp 2

times, and the dash mounted LED will turn off.

If you have the optional door lock/unlock circuit installed, the doors will unlock.

If you have the optional entry illumination circuit installed, the interior light will

turn on for 30 seconds or until the ignition key is switched on.

NOTE: If the passive arming mode was selected at time of installation, the

dash mounted LED will start flashing rapidly indicating that the system is

rearming. Opening any door will suspend the automatic arming.

If the parking lights flashed 3 times, and the siren chirps 4 times, this

indicates that the alarm system was triggered during your absence. Before

turning on the ignition key, examine the dash mounted LED's flash pattern.

The number of flashes identifies the triggered zone. For additional

information, refer to INTRUSION WARNING SIGNALS found later in this

manual.

If the siren did not sound upon disarm, then the chirps have been turned off.

Refer to the section titled ELIMINATING THE ARM/DISARM CHIRPS.

NOTE: If the optional 2 step door unlock circuit is installed, when the unlock

transmitter button is activated, the drivers door only will unlock, pressing the

unlock button a second time will cause all doors to unlock. If your transmitter

has a sperate lock unlock buttons, pressing the unlock button anytime after

the first unlock command will cause all the vehicle doors to unlock.

SILENT DISARMING:

1. As you approach the vehicle, press and hold the disarm button of your key

chain transmitter for 2 seconds.

The parking lights will flash 2 times, and the dash mounted LED will turn off

confirming that the system is disarmed. The siren will not chirp. If you have the

optional door lock/unlock circuit installed, the doors will unlock. If you have the

optional entry illumination circuit installed, the interior light will turn on for 30

seconds or until the ignition key is switched on.

NOTE: If the passive arming mode was selected at time of installation, the

dash mounted LED will start flashing rapidly indicating that the system is

rearming. Opening any door will suspend the automatic arming.If the parking

lights flashed 3 times, and the siren chirps 4 times, this indicates that the

128-6530

5 of 10

Page 5

alarm system had been triggered in your absence. Before turning on the

ignition key, examine the dash mounted LED's flash pattern. The number of

flashes identifies the triggered zone. For additional information, refer to

INTRUSION WARNING SIGNALS found later in this manual.

NOTE: If the optional 2 step door unlock circuit is installed, when the unlock

transmitter button is activated, the drivers door only will unlock, pressing the

unlock button a second time will cause all doors to unlock. If your transmitter

has a sperate lock unlock buttons, pressing the unlock button anytime after

the first unlock command will cause all the vehicle doors to unlock.

WHILE THE SYSTEM IS SOUNDING:

If during a triggered state, you wish to shut off the siren without disarming your

security system, simply press and release any transmitter button other than

the disarm button. This action will turn off the siren yet leave the vehicle fully

armed and protected. This feature is particularly useful if you are aware of

children playing near your vehicle that may accidently trigger your security

system. In this case you can cancel the siren sounding.

INTRUSION WARNING SIGNAL:

This system will inform you if an intrusion attempt has occurred while you

were away from the vehicle. Upon disarm, the siren will chirp 4 times and the

parking lights will flash 3 times. Enter the vehicle and before turning on the

ignition switch, observe the LED flash pattern.

If the LED flashes 1 time...pause, 1 time...pause etc., then an intrusion

attempt was made by impact or a strong vibration that the shock sensor

detected. Check the vehicle for possible damage to the glass or body panels.

If the LED flashes 2 times...pause, 2 times...pause etc., then an intrusion

attempt was made to open the hood, trunk, or by an accessory triggering

device. Check the vehicle for indications of forced entry to these openings.

If the LED flashes 3 times...pause, 3 times...pause etc., then an intrusion

attempt was made to the vehicle doors. Check all doors for indications of

forced entry.

NOTE: The LED intrusion warning indications are stored in the system's

memory and will be erased when the ignition switch is turned on.

128-6530

6 of 10

Page 6

VALET SWITCH:

The valet switch allows you to temporarily bypass all alarm functions,

eliminating the need to hand your transmitter to parking attendants or garage

mechanics. When the system is in valet mode, all alarm functions are

bypassed, however the remote panic feature and remote door locks will

remain operational.

1. Enter the vehicle, and turn the ignition key to the ON position.

2. Press and hold the valet pushbutton switch until the dash mounted LED

turns on solid. The system will remain in the valet mode.

3. To return to normal operation, press and release the pushbutton switch

any time the ignition is on.

NOTE: Always remember to return the vehicle to the valet OFF position. This

will ensure that the vehicle remains protected at all times.

MANUALLY OVERRIDING YOUR SYSTEM:

USING THE VALET SWITCH MANUAL OVERRIDE

Your Security system can be disarmed without the use of the keychain

transmitter. This is necessary, since you will need the ability to operate your

vehicle if the transmitter is lost or its battery fails. If your system has been

selected for Valet Switch manual override as indicated on the last page of this

manual, to by-pass the alarm system;

1. Open the vehicle door. The alarm will sound.

2. Turn the ignition key to the ON position.

3. Within 5 seconds, press and release the valet pushbutton switch.

The alarm system will stop sounding and enter the (by-passed) mode. You

can now start and operate the vehicle normally.

Typically this override mode is used only if the transmitter has become

inoperative.

Programming Your Custom Override Code:

Unlike override switches easily found, and defeated, this security system

allows the consumer to program a personal override code, offering a higher

level of security. To take advantage of this option, programmable feature # 10

must be selected for the Custom Code Option. Consult your installation

128-6530

7 of 10

Page 7

center for programming details. The system comes from the factory with a

pre-programmed override code of 11.To change this default override code, do

the following:

1. Disarm the system by use of the transmitter, or by use of the emergency

override sequence. Turn the ignition switch to the ON position.

2. Within 10 seconds, press and release the valet/override switch, 3 times.

3. Within 10 seconds turn the ignition switch OFF, ON, OFF, ON, OFF, ON.

(The siren or horn will beep and the lights will flash one time.)

4. Within 10 seconds, begin to enter your chosen 10ths digit by pressing

and releasing the pushbutton switch from 1up to 9 times.

5. Within 10 seconds of the last entered 10ths digit, turn the ignition switch

OFF then ON.

6. Within 10 seconds, begin to enter your chosen units digit by pressing and

releasing the pushbutton switch from 1 up to 9 times.

7. Finish by turning the ignition switch to the OFF position.

If the new code was accepted, the system will report back the newly entered

code, by flashing the LED, first indicating the 10ths digit, pause and then the

units digit. The system will report the new code three times with a one second

pause between each code, then the system will begin arming. If the LED flash

pattern reports the previously stored code, the new code was not entered

correctly. Please repeat steps 1 through 7 above considering the following.

NOTE: Acceptable digits 10ths or units are 1 through 9. The system will not

recognize a 0 (Zero), or no digit entered in any place, units or tenths.

NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for

more then 5 seconds during any of the above steps, the system will revert

back to the last successfully stored code.

MANUALLY OVERRIDING YOUR SYSTEM:

USING THE CUSTOM CODE OVERRIDE:

Assuming the override code programmed has not been changed, and the

default override code of 11 is in the system's memory.

1. Enter the vehicle and turn the ignition switch to the ON position.

NOTE: The siren will sound.

128-6530

8 of 10

2. Within 5 seconds, press and release the pushbutton switch 1 time.

3. Within 5 seconds, turn the ignition switch OFF then ON.

4. Within 5 seconds, press and release the pushbutton switch 1 time.

5. Turn the ignition switch OFF then ON and start the vehicle.

NOTE:If you have changed the programmed override code then substitute your

new code tenths for step 2 above, and units for step 5 above.

ELIMINATING THE NORMAL ARM/DISARM CHIRPS

You can selectively eliminate the normal arm & disarm chirps by holding the

transmitter button slightly longer when arming or disarming. This will prevent

the siren chirps for one arm or disarm cycle. If you find this inconvenient and

wish to eliminate these chirps permanently,

1. Start with the valet switch in the OFF position.

2. Turn the ignition switch ON then OFF.

3. Within 10 seconds of turning OFF the ignition, move the valet switch ON,

OFF,ON,OFF, ON, OFF.

4. If the chirps were on before you started, the siren will emit 2 short chirps

indicating that the chirps are now off. If the chirps were off before you started,

the siren will emit one short chirp indicating that the chirps are now on.

NOTE: If the vehicle battery is disconnected then reconnected, the system will

return to the default setting of chirps ON. Repeat the above procedure to

eliminate the arm/disarm chirps.

REMOTE PANIC OPERATION:

The Lock or Unlock button on your keychain transmitter also functions as a

panic switch for use in emergency situations. To use remote panic,

1. Press and hold the Lock or Unlock button on the keychain transmitter for 3

or more seconds. The alarm will immediately sound.

2. To stop the alarm, press and hold the Lock or Unlock button on the

transmitter again for 3 seconds. If the button is not pressed, the alarm will

automatically stop after 30 seconds. Also if any transmitter button other than

the Lock or Unlock button is pressed and released, the Panic mode will be

turned off immediately. The normal function of this transmitter button will be

suspended during the Panic sounding period.

NOTE: While in the Panic mode, pressing and releasing the Lock, or the

Page 8

128-6530

9 of 10

Unlock buttons will, if the option is installed, lock and unlock the doors

respectively. While in the panic mode, anytime the unlock button is pressed,

the panic feature will continue for the allotted 30 seconds, however, the

security system will be disarmed allowing the vehicle to start.

SAFETY (Red Handled ) CONTROL SWITCH:

The control switch allows you to temporarily disable the remote starting function

of your Remote Start system. To disable the system, move the red handled

control switch to the OFF position.

RREMOTE STARTINGTHEVEHICLE:

Press and release the trunk/key button of your keychain transmitter two times

within 2 secondsto activate the remote start system. The vehicle will start and

remain running for the pre-programmed 10 or 15 minutes. As a visual indica-

tion, the parking lights will flash or turn on depending on the programming set up

by your installation center.

When you arrive at your vehicle, unlock the vehicle by pressing and releasing the

unlock button of your keychain transmitter or by use of the vehicle key. Enter the

vehicle and turn the ignition key to the ON position.

The system WILL NOT start the vehicle if any one of the following conditions exist:

1.The vehicle's hood Is opened.

2.The gear shift selector is in any gear other than park.

3.The brake is depressed.

4.The safety control switch is in the OFF position.

CAUTION! Be certain that the vehicle is outdoors before using this or any remote

vehicle starting device. A running engine produces dangerous carbon monoxide

fumes which can be harmful or fatal if prolonged exposure occurs. DO NOT

remote start the vehicle if the car is garaged.

Page 9

128-6530

10 of 10

NOTE: The engine will stop running before the expiration of the pre-

programmed run timer if you complete any of the following:

1. Press and release trunk/key button of your keychain transmitter two times

within 2 seconds.

2. Depress the brake pedal.

3. Open the hood.

4. Move the red handled control switch to the OFF position.

5. Race the engine to above 4000 RPM.

TO BEGIN THE AUTOMATIC START UP TIMER:

1. Turn the ignition key ON then OFF.

2. Within 10 seconds, Push the trunk/key button of your keychain transmitter

4 times.

The parking lights will flash and the siren will chirp 4 times indicating the

timed start mode is activated. The vehicle, on a 2 or 4 hour interval basis,

will automatically start, run for the pre-programmed time (5,10,15 or 20

minutes), and then shut OFF. This will continue for 48 hours.

ADJUSTING THE START TIMER FROM 2 TO 4 HOURS:

The SAFETY (Red Handled ) CONTROL SWITCH also allows you to select be-

tween automatic 2 hour start or 4 hour start when using the automatic start

timer mode. The factory preset start up time for this mode is every 4 hours. To

select between 2 or 4 hour start timer:

1.Begin with the saftey control switch in the ON position.

2.Turn the ignition switch ON then OFF.

3.Within10seconds, move thecontrolswitchOFF,ON,OFF,ON(2 switch cycles)

to select a 2 hour start timer. After 10 seconds expire, the parking lights will

flash 2 times confirming that the 2 hour start cycle is set. Or, within 10 seconds

move the control switch OFF,ON,OFF,ON,OFF,ON,OFF,ON (4 switch cycles) to

select a 4 hour start timer. The parking lights will flash 4 times confirming that

the 4 hour start timer is set.

Table des matières

Autres manuels Code Alarm Alarme de voiture

Code Alarm

Code Alarm CA 420 Manuel utilisateur

Code Alarm

Code Alarm CA-330 Manuel utilisateur

Code Alarm

Code Alarm CA611 Manuel utilisateur

Code Alarm

Code Alarm ca 2051 Manuel utilisateur

Code Alarm

Code Alarm CATX120 Mode d'emploi

Code Alarm

Code Alarm CATX510 Mode d'emploi

Code Alarm

Code Alarm CA-160 Manuel utilisateur

Code Alarm

Code Alarm Professional ca6153 Manuel utilisateur

Code Alarm

Code Alarm ca 1552 Professional Series Manuel utilisateur

Code Alarm

Code Alarm CATX110 Mode d'emploi

Code Alarm

Code Alarm Elite CA6155e Manuel utilisateur

Code Alarm

Code Alarm CA 1550 Manuel utilisateur

Code Alarm

Code Alarm PowerCode PC 6100 Manuel utilisateur

Code Alarm

Code Alarm ca1554 Manuel utilisateur

Code Alarm

Code Alarm CSI-300 Manuel utilisateur

Code Alarm

Code Alarm CA-640 Manuel utilisateur

Code Alarm

Code Alarm 2000 Manuel utilisateur

Code Alarm

Code Alarm Ca 1053 Manuel utilisateur

Code Alarm

Code Alarm ca 1552 Professional Series Manuel utilisateur

Code Alarm

Code Alarm CA 6151 Manuel utilisateur

Code Alarm

Code Alarm CA 110 Manuel utilisateur

Code Alarm

Code Alarm PRO 3500 Caractéristiques techniques

Code Alarm

Code Alarm CA 6151 Manuel utilisateur

Code Alarm

Code Alarm ca 1051 Manuel utilisateur

Manuels Alarme de voiture populaires d'autres marques

Clifford

Clifford 3606X Manuel utilisateur

Ultra Start

Ultra Start 2500M SERIES Manuel utilisateur

Ultra Start

Ultra Start 650 Series Manuel utilisateur

Audiovox

Audiovox Prestige Platinum+ APS-511C Manuel utilisateur

Sparkrite

Sparkrite SRA8 Manuel utilisateur

Viper

Viper 4708V Manuel utilisateur

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuel

Falcon

Falcon Predator XL3 Guide de l'utilisateur

Audiovox

Audiovox Auto Security XR91 Mode d'emploi

Clifford

Clifford Sabre II Manuel utilisateur

CrimeStopper

CrimeStopper CS-8717 Guide de démarrage rapide

Ultra Start

Ultra Start 450 SERIES Manuel utilisateur

Scytek electronic

Scytek electronic Vectra X3 Manuel utilisateur

Excalibur

Excalibur AL-1860-EDPB Manuel utilisateur

Clifford

Clifford CYBER 2 Manuel utilisateur

Gemini

Gemini 7057 Manuel utilisateur

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuel utilisateur

Magicar

Magicar FAI-440 Manuel utilisateur
