PROFESSIONAL

SERIES

CA 1150

Owner’s Guide

IMPORTANT NOTE: TheoperationoftheSecurityandConvenienceSystem asdescribedinthismanualis

applicabletomostvehicles.However,due to the configuration of somevehicles,somefunctionsAND/OR

SAFETYPRECAUTIONSmaynotapply. Please see your installingdealer for more information.

Vehicle Security and Keyless Entry

System

Table of Contents

Using Your Remote Control ...............................................................3

Arming the Security System ............................................................3

Bypassing the Shock Sensor ..........................................................3

Disarming the Security System........................................................3

Two Stage Door Unlock (optional) ...................................................3

Valet Mode ........................................................................................3

Activating Trunk Release (optional) ................................................4

Activating Optional AUX 1 (optional) ...............................................4

Using the Car Finder Feature...........................................................4

Using the Personal Protection Alarm ...............................................4

Car Jack Mode ..................................................................................4

LED and Siren/Horn Indications ......................................................... 5

Transmitter Button Functions ........................................................... 6

Replacing Remote Control Batteries............................................... 6

Warranty Information...........................................................................7

Arming the Security System

To arm the system, exit the vehicle, close all doors, then press the button. The

parking lights will flash 2 times, indicating the system is armed, has locked the

doors (if equipped and connected) and activated the starter disable feature. The

LED status indicator will blink steadily, once per second.

NOTE: The system is defaulted with Silent Choice enabled, which requires a

second press of the button to activate an audible arming response from the

vehicle.

Bypassing The Shock Sensor

To arm the system and ignore the shock sensor press button, then within 5

seconds press + , the system will respond with 1 long chirp.

NOTE: The system will only change the shock sensor setting for one arm cycle

and will be defaulted back to normal operation the next time the system is armed.

Disarming the Security System

To disarm the system press the button. The parking lights will flash 1 time,

indicating the system is disarmed and has unlocked the doors (if equipped and

connected).

NOTE: The system is defaulted with Silent Choice enabled, which requires a

second press of the button to activate an audible arming response from the

vehicle.

*Throughout this manual, ‘press’ refers to pressing for less than 1 second; ‘press and hold’ refers to pressing for more

than2seconds.

Using Your Remote Control

Valet Mode

To engage valet mode:

1. Turn the ignition key to the ON position.

2. Press and hold the emergency override button.

3. The LED will light solid indicating that the system is in valet mode.

When valet mode is activated the status LED will light solid, and all security

functions will be disabled.

Two Stage Door Unlock (Optional)

If this feature is enabled on your system, pressing the button one time will

unlock only the driver’s door. Press again within 5 seconds to unlock the

remaining doors.

Activating the Trunk Release Feature (Optional)

If this feature is enabled on your system, pressing and holding the button for 3

seconds will open the vehicle’s trunk or hatch.

Activating Optional AUX 1 (Optional)

If this feature is enabled on your system, pressing the and buttons

simultaneously will activate an optional feature. This feature can be programmed

for a wide range of functions like power window or sunroof automation, please

consult your installing dealer to determine the functionality of your system.

Using the Progressive Car Finder Feature

Press the button to locate your vehicle. The system will sound 5 times at low

volume, increasing in volume each time the button is pressed.

Using the Personal Protection Alarm (Panic)

Press and hold the button for 3 seconds to activate the personal protection

alarm. During panic mode, the normal function of the transmitter buttons will be

suspended. The transmitter’s and buttons can be used to lock and unlock the

door (if the option is installed). To stop the alarm, press and hold the button on

the transmitter again for 3 seconds. The system will automatically stop after 30

seconds.

To disengage valet mode:

1. Turn the ignition key to the ON position.

2. Press and release the emergency override button.

3. The LED will turn off indicating that the system has exited valet mode.

Car Jack Mode

This feature must be turned on in system programming, please consult your

installing dealer.

Triggering Car Jack mode: While the ignition is ON and press and hold + for 2

seconds, the parking lights will flash 1 time and the system will act as follows;

1. 50 seconds after being triggered the siren will chirp for 15 seconds,

during this 15 seconds you will be alerted to push the valet button to turn

off Car Jack mode. If Car Jack mode is not turned off at this time it will

advance to the next step.

2. Following the 15 second chirps (total time now 65 seconds) the siren

will go into full sound and the parking lights will start flashing.

3. 90 seconds after trigger in, addition to the siren and parking lights, the

system will activate the starter kill. THE SYSTEM WILL REMAIN IN THIS

STATEUNTILTHEBATTERYISDEPLETED.

OVERRIDETHESYSTEM TO TURN OFFCAR JACK MODE:Turn the ignitionOFF

then On and press the valet button within 10 seconds.

LED and Siren/Horn Indications

LED Display Indications

LED Function

OFF DISARMED

SLOW FLASH ARMED

FAST FLASH PASSIVEARMING

ON(SOLID) VALETMODE

2 FLASH... PAUSE ZONE2TRIGGER,HOOD/TRUNK

3 FLASH... PAUSE ZONE3TRIGGER,DOOR

4 FLASH... PAUSE ZONE4TRIGGER,SHOCK

5 FLASH... PAUSE ZONE5TRIGGER,IGNITION

Siren/Horn Indications

Chirps Function

1 DISARM

2 ARM

3 DOORAJARUPONARMING

4 DISARM/TRIGGERED

5 CARLOCATOR

Parking Light Flash Indications

Flashes Function

1 DISARM

2 ARM

3 DISARM/TRIGGERED

5 CARLOCATOR

Transmitter Button Functions

Replacing Remote Control Batteries

1-Way 4 Button Remote Control:

The batteries (model CR2016) inside each remote control should last approximately

1 year under normal use. When the batteries become weak you will notice the

remote control range (the distance from the vehicle the remote control will work)

deteriorate and the small LED on the remote control will dim. To replace the remote

control batteries:

1. Remove 3 screws and disassemble the halves of the remote control.

2. Remove the old batteries, observing the +/- symbols on the batteries and

replace with new CR2016 batteries.

3. Reassemble the halves of the remote control and install the 3 screws.

4. Test operation of the remote control.

Code Systems, Inc. Limited Lifetime Warranty

Code Systems Inc. (“CODE”) warrants to the ORIGINAL PURCHASER of this CODE

vehicle security product (the “Product”), purchased from an authorized CODE dealer, that (except as

provided below) should this Product under normal use and conditions, be proven defective in

material or workmanship DURING THE LIFETIME OF THE VEHICLE IN WHICH IT WAS ORIGI-

NALLYINSTALLED, such defect(s) will be repaired or replaced (at CODE’s option) without charge for

parts directly related to repairs of the defect(s).

Switches, indicator lights, and transmitter cases are similarly warranted to the original

purchaser for a period of one (1) year from the date of purchase of the Product.

CODE accessories, sold separately, are covered by the applicable warranty accompa-

nying the accessory.

This warranty is non-transferable, non-assignable and is voided when: (1) the Product is

removed from the vehicle in which it was originally installed; or (2) the vehicle in which the Product

was originally installed is transferred to another party.

This warranty does not apply to any product damaged by accident, physical or electrical

abuse, improper installation, alteration, or use contrary to its intended function, fire, flood, or other

natural acts.

In order for the Product to be repaired or replaced under the terms of this warranty, the

defective Product must be returned to an authorized CODE dealer and accompanied by a copy of

the retail sales receipt. The date of purchase and year, make and model of the vehicle in which the

Product was originally installed must be clearly indicated on the sales receipt.

This warranty is exclusive and CODE MAKES NO OTHER WARRANTIES EXPRESSED

OR IMPLIED. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MER-

CHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE

DURATION OF THIS WRITTEN WARRANTY. IN NO CASE SHALL CODE BE LIABLE FOR ANY

CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WAR-

RANTY, EXPRESS OR IMPLIED, WHATSOEVER.

CODE does not warrant that the Product cannot be compromised or circumvented. THE EXTENT OF

CODE’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT

PROVIDED ABOVE AND, IN NO EVENT SHALL CODE’S LIABILITY EXCEED THE PURCHASE

PRICE PAID BY THE ORIGINAL PURCHASER OF THE PRODUCT WITHOUT INSTALLATION

LABOR.

Some states do not allow the exclusion or limitation of incidental or consequential

damages, so the above limitation may not apply to you. This warranty gives you specific legal

rights and you may also have other rights which vary from state to state

Audiovox Electronics Corporation.

Customer Service 1-800-421-3209

WWW.CODE-ALARM.COM

FCC COMPLIANCE

This device complies with Part 15 of the FCC rules and with RSS-210 of

Industry Canada. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including any interference

that may cause undesired operation.

Warning!

Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.
