DRUM BRAKE TOOL KIT

MODEL No: CHT 455

Part No: 1801455

GUARANTEE

This CLARKE product is guaranteed against faulty manufacture for a period of

12 months from the date of purchase. Please keep your receipt as proof of

purchase. This guarantee is invalid if the product is found to have been abused

or tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission.

This guarantee does not effect your statutory rights.

COMPONENTS

Part No.

1. Shoe Return Spring Remover ZHCHT45501

2. Brake Cable Tool ZHCHT4502

3. Hose Clamp ZHCHT45503

4. Piston Retainer ZHCHT45504

5. Shoe Clearance Adjuster. ZHCHT45505

6. Shoe Retaining Pin, Cap Remover ZHCHT45506

Parts & Service: Tel: 020 8988 7400

METHOD OF USE

Slide the tongue of the tool into the

end of the spring as shown then

position the serated cup on the

surface of the brake shoe.

Bring the handles together to extend

the spring, sufficienrtly for it to be

prised from the hole in the shoe.

Assemble in reverse.

ALWAYS wear safety goggles when

using the tool

Shoe Spring Remover

Slide the claws of the tool between the

head of the brake cable and the spring.

Close the handles to lock them, thereby

allowing the brake shoe to be

manouvered off the cable.

Brake Cable Tool

Hose Clamp

Piston Retainer

Shoe Clearance Adjuster

Before operating on the

hydraulic system, where

hydraulic lines are opened,

clamp the flexible hose as

near as possible to the

union with the back plate.

With the shoes removed, ensure the

pistons are maintained in place by

clamping them as shown.

Shoe Retaining Pin, Cap Remover

Push the tool firmly on to the Spring

Retaining Plate, then turn through 90

degrees before releasing pressure.

Remove the plate and spring followed by

the retaining pin from behind the back

plate.

Remove the dust proof cover at the back

plate, and insert the tool into the hole,

engaging with the serrations of the adjuster.

Lever the tool to turn the adjuster.
