USER INSTRUCTIONS

GC0414

HOT AIR GUN

MODEL NO: CHG1500D

PART NO: 3400757

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

INTRODUCTION

Thank you for purchasing this CLARKE Hot Air Gun.

Before attempting to use this product, please read this manual thoroughly and

follow the instructions carefully. In doing so you will ensure the safety of yourself

and that of others around you, and you can look forward to your purchase

giving you long and satisfactory service.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt which will be

required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or

tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission. This guarantee does not effect your

statutory rights.

IMPORTANT

Please read all of the safety and operating instructions carefully before using

this product. The following safety symbols may be found on the product.

Keep these instructions in a safe place for future reference.

Read this instruction

booklet carefully

before use.

Wear protective gloves

Wear eye protection Wear dust mask.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

GENERAL SAFETY RULES

GENERAL SAFETY IN THE WORKPLACE

1. Always ensure that air can circulate around the hot air gun and that the air

vents are unobstructed.

2. Always keep work area clean & tidy. Cluttered work areas and benches

invite accidents.

3. Never over-reach. Keep proper footing and balance at all times.

4. Never store equipment in a wet/damp environment or expose to rain.

5. Always ensure the workplace is well lit. Ensure that lighting is placed so that

you will not be working in your own shadow.

6. Keep other persons away. Do not let persons, especially children, not

involved in the work, touch the tool or extension cable and keep them

away from the work area.

7. Never operate a power tool when under the influence of alcohol, drugs or

medication.

8. Do not use power tools in the presence of flammable liquids or gasses.

9. Stay alert, watch what you are doing, use common sense and do not

operate the power tool when you are tired.

CARE OF POWER TOOLS

1. Read this manual carefully. Learn the tool’s applications and limitations, as

well as the specific potential hazards peculiar to it.

2. Always keep guards in place and in working order. A guard or other part

that is damaged should be properly repaired or replaced by an authorised

service centre, unless otherwise indicated in this instruction manual.

3. Don’t force the tool and use the correct attachment. It will do the job

better and safer, at the rate for which it was intended.

4. Always disconnect the power tool from the power supply before carrying

out any repairs or changing of accessories.

WARNING: WHEN USING ELECTRIC TOOLS, BASIC SAFETY PRECAUTIONS

SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK AND PERSONAL INJURY INCLUDING THE FOLLOWING. READ ALL

THESE INSTRUCTIONS BEFORE ATTEMPTING TO OPERATE THIS PRODUCT

AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

5. Before further use of the tool, it should be carefully checked to determine

that it will operate properly and perform its intended function. Check for

alignment of moving parts, binding of moving parts, breakage of parts,

mountings or other condition that may affect its operation.

6. Have defective switches repaired by an authorised service centre. Do not

use a power tool if the switch does not turn it on and off.

7. Always check for any damage or any condition that could affect the

operation of the tool. Damaged parts should be properly repaired.

8. Have your tool repaired by a qualified person. This tool complies with the

relevant safety rules. Repairs should only be carried out by qualified

persons using original spare parts, otherwise this may result in considerable

danger to the user.

9. Never use this product for any other purpose than that described in this

booklet.

10. Never abuse the power cable by yanking the cable to disconnect it from

the socket. Keep the cable away from heat, oil or sharp edges.

11. Guard against electric shock. Avoid body contact with earthed or

grounded surfaces.

12. If the tool should be used outdoors, use only extension cables intended for

outdoor use and marked accordingly.

13. Avoid accidental starting by making sure the power switch is off before

plugging in the power cable.

ADDITIONAL SAFETY RULES FOR HOT AIR GUNS

1. Always keep the mains cable well away from the hot air gun, particularly if

laying it down temporarily during use.

2. Always switch the hot air gun OFF after use and allow it to cool before

storing. Support on its stand with the nozzle pointing upwards.

3. Never leave the hot air gun unattended when it is switched on.

4. Always wear safety gloves and never touch the hot nozzle.

5. Never point the hot air gun at any person or animal.

6. Never use in a flammable atmosphere, e.g. where solvent vapours are

present.

CAUTION: WITH ALL MACHINES, THERE ARE CERTAIN HAZARDS

INVOLVED WITH THEIR OPERATION AND USE. EXERCISING RESPECT AND

CAUTION WILL CONSIDERABLY LESSEN THE RISK OF PERSONAL INJURY.

HOWEVER, IF NORMAL SAFETY PRECAUTIONS ARE OVERLOOKED, OR

IGNORED, PERSONAL INJURY TO THE OPERATOR, OR DAMAGE TO

PROPERTY MAY RESULT.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

7. Never use the hot air gun as a hair dryer.

8. Be aware that heat generated by the gun could cause nearby materials

to ignite - particularly in confined spaces. Take all necessary precautions -

have a fire extinguisher, or means to extinguish a fire to hand.

9. Be aware that fumes given off by paint etc., could be toxic. Take all

necessary precautions - consult paint manufacturer etc where necessary.

10. When finished take great care to place the gun where it cannot cause

damage to property or other equipment, and cannot be accidentally

touched by persons in the area. Stand upright while it cools.

11. Do not stand on a soft surface. The air gun could topple over or the air

intakes become blocked.

12. Do not apply heat to the same place for a long time.

13. Be aware that heat may be conducted to combustible materials that are

out of sight.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

ELECTRICAL CONNECTIONS

Before switching the product on, make sure that the voltage of your electricity supply is

the same as that indicated on the rating plate. This product is designed to operate on

230VAC 50Hz. Connecting it to any other power source may cause damage.

This product may be fitted with a non-rewireable plug. If it is necessary to change the

fuse in the plug, the fuse cover must be refitted. If the fuse cover becomes lost or

damaged, the plug must not be used until a suitable replacement is obtained.

If the plug has to be changed because it is not suitable for your socket, or due to

damage, it should be cut off and a replacement fitted, following the wiring instructions

shown below. The old plug must be disposed of safely, as insertion into a mains socket

could cause an electrical hazard.

If the colours of the wires in the power cable of this product do not correspond with the

markings on the terminals of your plug, proceed as follows.

• The wire which is coloured Blue must be connected to the terminal which is

marked Nor coloured Black.

• The wire which is coloured Brown must be connected to the terminal which is

marked Lor coloured Red.

We strongly recommend that this machine is connected to the mains supply via a

Residual Current Device (RCD)

If in any doubt, consult a qualified electrician. DO NOT attempt any repairs yourself.

This symbol indicates that this is a Class II product, and does not require an earth

connection.

WARNING! Read these electrical safety instructions thoroughly

before connecting the product to the mains supply.

WARNING! The wires in the power cable of this product are

coloured in accordance with the following code:

Blue = Neutral Brown = Live

Plug must be BS1363/A approved.

Always fit a 13 Amp fuse.

Ensure that the outer sheath of the cable is firmly held by the clamp

Neutral

(Blue)

Live

(Brown)

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

OVERVIEW

The CHG1500D hot air gun provides two temperatures/air speeds for varying

applications.

A protection nozzle is supplied for use when stripping window frames or similar,

where hot air is prevented from being trained directly onto the glass.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

OPERATION

Before starting work it is recommended that you heat a test piece to ensure

you have the correct heat setting. In addition you should always take steps to

protect sensitive or delicate areas where the effect of heat could cause

damage (i.e. glass and plastics). Do not apply heat to the same place for a

long time.

After the work has been completed, switch the gun OFF, disconnect from the

mains supply and allow to cool in a safe place.

Take care not to drop the gun as this could seriously damage the heating

element.

REMOVING PAINT AND DISSOLVING ADHESIVES

The gun can be used in conjuction with a shavehook to remove paint.

1. With the switch in the ‘0’ (OFF) position plug the hot air gun into the mains

supply.

2. Set the switch to either position I

or II according to how much heat

is required. (see Specification on

page 10).

• Ensure the nozzle is pointing

away from you.

3. Bring the nozzle of the hot air gun

to the work piece approximately 3

cm from the surface.

• The exact distance between

the nozzle and the work piece will be dependent on the material

being worked on.

• Paint will rapidly become soft and blister, at which point it can be

removed with a suitable scraper. Do not allow paint to burn as this

will make the removal process more difficult.

• Some adhesives soften when heated and the joint can then be

separated, taking care to avoid damage to jointed parts.

4. Clean your shavehook quickly if paint/glue becomes stuck to it.

• Profiled parts may be cleaned with a suitable wire brush once paint

is softened.

• Normally only one pass is required to remove both thick and thin

layers of paint.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

REMOVING PAINT FROM WINDOW FRAMES

DO NOT point the gun directly at

glass and always ensure it is

adequately protected. A glass

protection nozzle is provided for use

when stripping window frames etc.

1. Fit the glass protection nozzle to

the front of the hot air gun and

angle it so that the gun can be

placed up against the window,

with the cowl of the nozzle, flat

against the glass as shown.

2. It will be necessary to change the position of the protection nozzle as you

work around the window pane. Ensure you wear adequate hand

protection when doing so.

3. The protection nozzle must be kept in contact with the work at all times, but

do not spend too much time in one area.

GENERAL USE

To prevent the gun from overheating, maintain a minimum distance of 3 cm

between the end of the nozzle and the work piece.

IMPORTANT: In continuous operation, never exceed the duty cycle for the

unit as stated in the specification.

FORMING AND WELDING PLASTIC PARTS

When bending or forming plastic parts, work slowly and with great care

observing the effects of heat on such materials.

NOTE: With plastics, the temperature range between solid, pliable and

liquid states is narrow, therefore great care should be taken.

DE-FREEZING WATER PIPES

The gun is ideal for speeding up the defrosting of water pipes.

1. Always heat frozen areas inwards from the edge to the centre.

2. Take special care when defrosting plastic pipes.

3. Provide protection against heat damage to nearby paint and wall

coverings where necessary.

4. Be aware that copper gas pipes can be difficult to distinguish from copper

water pipes. Always check first.

5. Copper pipes are often soldered together, therefore should not be heated

above 200oC.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

MAINTENANCE

This hot air gun is maintenance free, except always ensure that the air intake

vents are kept clean. If used in a dusty environment clean the tool with low

pressure compressed air.

ENVIRONMENTAL PROTECTION

Through the purchase of this product, the customer is taking on the

obligation to deal with any waste electrical/electronic equipment in

accordance with the WEEE Regulations in relation to the treatment,

recycling, recovery and environmentally sound disposal of the WEEE.

In effect, this means that this product must not be disposed of with general

household waste. It must be disposed of according to the laws governing

Waste Electrical and Electronic Equipment (WEEE) at a rcognised disposal

facility.

SPECIFICATION

Dimensions (D x W x H) 228 x 77 x 220 mm

Product Weight 0.7 kg

Operating Voltage/Frequency 230 V - 50 Hz

Input Power 1500 W

Electrical Insulation Class II

Operating Temperature Min: -10oC, max 50oC

Duty Cycle 10 minutes on and 3 minutes off, as one cycle.

Temperature Settings:

Setting 1:

Setting 2:

300oC

500oC

Air Flow Settings:

Setting 1:

Setting 2:

280 litres/min

450 litres/min

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Clarke Outils électriques

Clarke

Clarke CAT22B Manuel d'installation et d'exploitation

Clarke

Clarke CHG1600 Manuel utilisateur

Clarke

Clarke CPSB200 Mode d’emploi

Clarke

Clarke CAT210 Manuel d'installation et d'exploitation

Clarke

Clarke CONTRACTOR CON800 Manuel d'installation et d'exploitation

Clarke

Clarke STRONG-ARM CSA50FP Guide de dépannage

Clarke

Clarke ZX-R Pro Series Mode d’emploi

Clarke

Clarke Woodworker CJS1-C Manuel d'installation et d'exploitation

Clarke

Clarke Strong-Arm GC0915 Mode d’emploi

Clarke

Clarke CAT171 Manuel utilisateur

Clarke

Clarke Contractor CON15 Manuel d'installation et d'exploitation

Clarke

Clarke MetalWorker CDP151B Manuel d'installation et d'exploitation

Clarke

Clarke STRONG-ARM CSA4B Mode d’emploi

Clarke

Clarke X-Pro CAT202 Manuel d'installation et d'exploitation

Clarke

Clarke CPT1000 Mode d’emploi

Clarke

Clarke Strong-Arm AP500B Manuel utilisateur

Clarke

Clarke Metalworker CDP501F Manuel d'installation et d'exploitation

Clarke

Clarke Air 25C Manuel d'installation et d'exploitation

Clarke

Clarke FP18 Manuel utilisateur

Clarke

Clarke Woodworker CPT600 Manuel d'installation et d'exploitation

Clarke

Clarke CCRT266 Mode d’emploi

Clarke

Clarke X-Pro CAT213 Manuel d'installation et d'exploitation

Clarke

Clarke Metalworker CDP502F Mode d’emploi

Clarke

Clarke Air CSG3KC Manuel d'installation et d'exploitation

Manuels Outils électriques populaires d'autres marques

AEG

AEG OMNI-JS Manuel utilisateur

SIP

SIP 01533 Manuel utilisateur

Ribimex

Ribimex PRS499 Manuel utilisateur

3M Fiber Optic Connector Crimp Tool Manuel utilisateur

Ryobi

Ryobi P524 Manuel utilisateur

ROJEK

ROJEK FSN 300A Manuel utilisateur

Kemper

Kemper 1740PRO Manuel utilisateur

WABCO

WABCO OptiTire Manuel utilisateur

EINHELL

EINHELL TE-MS 18/210 Li Manuel utilisateur

Orgapack

Orgapack OR-T 85 Guide rapide

TOUGHCUT

TOUGHCUT Diamond 400 Manuel utilisateur

Yaros

Yaros PB-3603 Manuel utilisateur

Fein

Fein BSS 2.0 E Guide de configuration

Baileigh Industrial

Baileigh Industrial SS-2725 Manuel utilisateur

Milwaukee

Milwaukee 2674-20 Manuel utilisateur

Fein

Fein BLs 1.6 Manuel utilisateur

Princess

Princess Electric Multi Sharpener Manuel utilisateur

FOREDOM

FOREDOM K.1050 Manuel
