Cabletron Systems TRMIM 24A TRMIM-24A Manuel utilisateur

TRXI-22A, TRXI-24A, TRXI-42A,

AND TRXI-44A ACTIVE

TOKEN RING INTELLIGENT HUB

USER’S GUIDE

CABLETRON SYSTEMS, P. O. Box 5005, Rochester, NH 03867-0505

NOTICE

Cabletron Systems reserves the right to make changes in specifications and other

information contained in this document without prior notice. The reader should in all

cases consult Cabletron Systems to determine whether any such changes have been

made.

The hardware, firmware, or software described in this manual is subject to change

without notice.

INNOEVENTSHALLCABLETRONSYSTEMSBELIABLEFORANYINCIDENTAL,

INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER

(INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR

RELATED TO THIS MANUAL OR THE INFORMATION CONTAINED IN IT, EVEN

IF CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR SHOULD HAVE

KNOWN, THE POSSIBILITY OF SUCH DAMAGES.

Cabletron Systems, Inc.

P.O. Box 5005, Rochester, NH 03867-0505

Printed in the United States of America

Order Number: 9031079 May 94

TRXI-22A

TRXI-24A

TRXI-42A

TRXI-44A,

and

TPIM

are trademarks of Cabletron

Systems, Inc.

SPECTRUM, LANVIEW

, and

Remote LANVIEW

are registered trademarks of

Cabletron Systems, Inc.

IBM

is a registered trademark of International Business Machines Corporation.

DEC

VT200

, and

VT300

are trademarks of Digital Equipment Corporation.

CompuServe

is a trademark of Compuserve, Inc.

Printed On Recycled Pape

NOTICE

FCC NOTICE

This device complies with Part 15 of the FCC rules. Operation is subject to the following

two conditions: (1) this device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment uses, generates, and can radiate

radio frequency energy and if not installed in accordance with the operator’s manual,

may cause harmful interference to radio communications. Operation of this equipment

in a residential area is likely to cause interference in which case the user will be required

to correct the interference at his own expense.

WARNING: Changes or modifications made to this device which are not expressly

approved by the party responsible for compliance could void the user’s authority to

operate the equipment.

DOC NOTICE

This digital apparatus does not exceed the Class A limits for radio noise emissions from

digital apparatus set out in the Radio Interference Regulations of the Canadian

Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les

limites applicables aux appareils numériques de la class A prescrites dans le Règlement

sur le brouillage radioélectrique édicté par le ministère des Communications du Canada.

CABLETRON SYSTEMS, INC. PROGRAM LICENSE AGREEMENT

IMPORTANT: Before utilizing this product, carefully read this License Agreement.

This document is an agreement between you, the end user, and Cabletron Systems, Inc.

(“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron

software program (the “Program”) contained in this package. The Program may be

contained in firmware, chips or other media. BY UTILIZING THE ENCLOSED

PRODUCT, YOU ARE AGREEING TO BECOME BOUND BY THE TERMS OF THIS

AGREEMENT, WHICH INCLUDES THE LICENSE AND THE LIMITATION OF

WARRANTY AND DISCLAIMER OF LIABILITY. IF YOU DO NOT AGREE TO THE

TERMSOFTHISAGREEMENT,PROMPTLYRETURNTHEUNUSEDPRODUCTTO

THE PLACE OF PURCHASE FOR A FULL REFUND.

CABLETRON SOFTWARE PROGRAM LICENSE

1. LICENSE. Youhavetherighttouseonly the one (1)copyof the Program provided

in this package subject to the terms and conditions of this License Agreement.

You may not copy, reproduce or transmit any part of the Program except as

permitted by the Copyright Act of the United States or as authorized in writing by

Cabletron.

NOTICE

iii

2. OTHER RESTRICTIONS. You may not reverse engineer, decompile, or

disassemble the Program.

3. APPLICABLE LAW. This License Agreement shall be interpreted and governed

under the laws and in the state and federal courts of New Hampshire. You accept

the personal jurisdiction and venue of the New Hampshire courts.

EXCLUSION OF WARRANTY AND DISCLAIMER OF LIABILITY

1. EXCLUSION OF WARRANTY. Except as may be specifically provided by

Cabletron in writing, Cabletron makes no warranty, expressed or implied,

concerning the Program (including Its documentation and media).

CABLETRON DISCLAIMS ALL WARRANTIES, OTHER THAN THOSE

SUPPLIED TO YOU BY CABLETRON IN WRITING, EITHER EXPRESS OR

IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF

MERCHANTABLITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH

RESPECTTO THE PROGRAM, THE ACCOMPANYING WRITTEN MATERIALS,

AND ANY ACCOMPANYING HARDWARE.

2. NO LIABILITY FOR CONSEQUENTIAL DAMAGES. IN NO EVENT SHALL

CABLETRON OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES

WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS

OF BUSINESS, PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS

INFORMATION, SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR RELIANCE

DAMAGES, OR OTHER LOSS) ARISING OUT OF THE USE OR INABILITY TO

USE THIS CABLETRON PRODUCT, EVEN IF CABLETRON HAS BEEN

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME

STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY

FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, OR ON THE DURATION

OR LIMITATION OF IMPLIED WARRANTEES IN SOME INSTANCES THE

ABOVE LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO YOU.

UNITED STATES GOVERNMENT RESTRICTED RIGHTS

The enclosed product (a) was developed solely at private expense; (b) contains “restricted

computer software” submitted with restricted rights in accordance with Section 52227-

19 (a) through (d) of the Commercial Computer Software - Restricted Rights Clause and

its successors, and (c) in all respects is proprietary data belonging to Cabletron and/or its

suppliers.

For Department of Defense units, the product is licensed with “Restricted Rights” as

defined in the DoD Supplement to the Federal Acquisition Regulations, Section 52.227-

7013 (c) (1) (ii) and its successors, and use, duplication, disclosure by the Government is

subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in Technical

Data and Computer Software clause at 252.227-7013. Cabletron Systems, Inc., 35

Industrial Way. Rochester, New Hampshire 03867

CONTENTS

TABLE OF CONTENTS

CHAPTER 1 INTRODUCTION

1.1 USING THIS MANUAL............................................................1-1

1.2 GETTING HELP........................................................................1-2

1.3 TRXI ACTIVE CONCENTRATOR OVERVIEW......................1-2

1.4 TRXI FEATURES......................................................................1-3

1.5 REMOTE NETWORK MANAGEMENT CAPABILITIES ......1-6

1.6 RECOMMENDED READING...................................................1-6

CHAPTER 2 REQUIREMENTS/SPECIFICATIONS

2.1 CABLE SPECIFICATIONS.......................................................2-1

2.1.1 UTP Cable Specifications for the TRXI-22A/24A

Lobe Ports and TPIM-T2..............................................2-2

2.1.2 STP Cable Specifications For The TRXI-42A/44A

Lobe Ports and TPIM-T1/T4.........................................2-4

2.1.3 Mixed Cable Types........................................................2-6

2.1.4 Multimode Fiber Optic Cable Specifications for

the TPIM-F2..................................................................2-7

2.1.5 Single Mode Fiber Optic Cable Specifications for

the TPIM-F3..................................................................2-8

2.2 CABLE RECOMMENDATIONS/TROUBLESHOOTING.......2-9

2.3 COM 1/COM 2 PORT SPECIFICATIONS..............................2-11

2.4 TPIM SPECIFICATIONS........................................................2-12

2.5 GENERAL SPECIFICATIONS...............................................2-17

CHAPTER 3 INSTALLATION

3.1 UNPACKING THE TRXI..........................................................3-1

3.2 ATTACHING THE STRAIN RELIEF BRACKET ...................3-1

3.3 INSTALLING THE TRXI..........................................................3-2

3.3.1 Rack Mounting the TRXI..............................................3-3

3.3.2 Wall Mounting the TRXI..............................................3-4

3.3.3 Free-Standing Installation...........................................3-5

3.4 SETTING THE RING SPEED SWITCH..................................3-6

3.5 SETTING THE NVRAM SWITCH ...........................................3-7

3.6 CONNECTING THE TRXI TO THE POWER SOURCE.........3-8

3.7 CONNECTING THE NETWORK LOBE PORT CABLING....3-8

3.8 INSTALLING THE TPIM RI/RO MODULES........................3-11

CONTENTS

3.8.1 Setting the TPIM’s Phantom Switch and

RI/RO Switch...............................................................3-12

3.8.2 Installing a TPIM to the TRXI....................................3-13

3.8.3 Connecting a Twisted Pair Segment to

the TPIM-T1 ................................................................3-14

3.8.4 Connecting a Twisted Pair Segment to

the TPIM-T2 or TPIM-T4............................................3-15

3.8.5 Connecting a Fiber Optic Link Segment to

the TPIM-F2 or TPIM-F3............................................3-16

3.9 FINISHING THE INSTALLATION........................................3-18

CHAPTER 4 TESTING AND TROUBLESHOOTING

4.1 CHECKING THE INSTALLATION..........................................4-1

4.2 USING LANVIEW LEDs...........................................................4-2

4.3 USING THE LCD DISPLAY .....................................................4-3

4.3.1 Static System Messages................................................4-4

4.3.2 Alarm Messages.............................................................4-5

4.3.3 Unsaved Initialization Messages..................................4-6

4.3.4 Saved System Messages................................................4-7

CHAPTER 5 LOCAL MANAGEMENT

5.1 MANAGEMENT TERMINAL REQUIREMENTS...................5-2

5.1.1 Attaching the Management Terminal..........................5-2

5.1.2 Setting the Management Terminal Setup

Parameters.....................................................................5-3

5.1.3 Modem Cable Configuration and Setup.......................5-4

5.2 ACCESSING LOCAL MANAGEMENT....................................5-5

5.3 USING LOCAL MANAGEMENT..............................................5-6

5.3.1 The System Level Screen..............................................5-8

5.3.2 The SNMP Community Names Screen......................5-13

5.3.3 The SNMP Traps Screen.............................................5-15

5.3.4 The Ring Security Screen............................................5-17

5.3.5 The Device Statistics Screen.......................................5-22

5.3.6 The Chassis Status View Screen................................5-28

5.3.7 The Component Status View Screen..........................5-30

5.3.8 The SNMP Tools Screen..............................................5-31

INTRODUCTION

Page 1-1

CHAPTER 1

INTRODUCTION

Welcome to the Cabletron Systems

TRXI-22A, TRXI-24A, TRXI-42A,

and TRXI-44A Active Token Ring Intelligent Hub User’s Guide

This manual provides installation instructions, network

requirements, and reference information for the TRXI Active

stand-alone concentrator.You should have an understanding of Token

Ring (IEEE 802.5) type data communications networks and their

physical layer components before installing the TRXI.

Note

: This manual uses the term TRXI to describe the TRXI -22A, 24A,

42A, and 44A unless otherwise specified.

1.1 USING THIS MANUAL

The following summary provides information about each chapter in

this manual. Read through the summary to familiarize yourself with

this manual’s organization and content.

Chapter 1,

Introduction

, outlines the contents of this manual and

describes features of the TRXI. It also lists recommended reading for

implementing a Token Ring network.

Chapter 2,

Requirements/Speciﬁcations

, describes cabling

requirements, network guidelines, and TRXI operating speciﬁcations.

Chapter 3,

Installation

, contains instructions for installing your

TRXI and connecting it to the network using the various media types.

This chapter includes instructions for setting the Ring Speed Switch,

setting the NVRAM Switch, installing the TPIMs, and setting the

TPIM Phantom Switch.

Chapter 4,

Testing and Troubleshooting

contains procedures for

testing the TRXI after installation, a description of the LANVIEW®

LEDs, and explains the front panel LCD display.

Chapter 5,

Local Management

describes how to access Local

Management. It also describes each of the Local Management screens

and the available commands.

INTRODUCTION

Page 1-2

1.2 GETTING HELP

If you need additional support related to the Cabletron Systems TRXI,

or if you have any questions,comments,or suggestions concerning this

manual, contact Cabletron Systems Technical Support:

By phone......................... (603) 332-9400

Monday-Friday; 8am - 8pm EST

By CompuServe

............ GO CTRON from any ! prompt

By Internet mail............. [email protected]

1.3 TRXI ACTIVE CONCENTRATOR OVERVIEW

The TRXI stand-alone concentrator provides 12 or 24 RJ45 active

Trunk Coupling Units (TCUs) for Shielded Twisted Pair (STP) or

Unshielded Twisted Pair (UTP) network lobe connections. The

TRXI-22A, 24A, 42A, and 44A are functionally identical with the

exception of the TCU lobe ports. Cabletron offers the following TRXI

conﬁgurations:

•

TRXI-22A

, twelve active RJ45 TCU lobe ports that support

category 3, 4, and 5 UTP cabling.

•

TRXI-24A

, twenty-four active RJ45 TCU lobe ports that

support category 3, 4, and 5 UTP cabling.

•

TRXI-42A

, twelve active RJ45 TCU lobe ports that support

IBM Type 1, 2, 6, and 9 STP cabling.

•

TRXI-44A

, twenty-four active RJ45 TCU lobe ports that

support IBM Type 1, 2, 6, and 9 STP cabling.

Figure 1-1. The TRXI-24A

DISPLAY

TRXI-24A TOKEN RING HUB WITH LANVIEW®

24 23 22 21 20 19 18 17 16 15 14 13

12 11 10 9 8 7 6 5 4 3 2 1

COM 2 COM 1

18 17 16 15 14 13

6 5 4 3 2 1

24 23 22 21 20 19

12 11 10 9 8 7 RO

PWR

CPU ACT

MGMT16 Mb/s

RESET

DISPLAY

INTRODUCTION

Page 1-3

You can upgrade the TRXI-22A and TRXI-42A to twenty-four ports

using a twelve port upgrade kit available from Cabletron Systems

(Cabletron Part Number TRXI-24A-UGKIT or TRXI-44A-UGKIT).

The TRXI provides two additional ports for Ring In and Ring Out

(RI/RO) connections.These ports support Cabletron’s Token Ring Port

Interface Modules (TPIMs).TPIMs provide full repeater functionality.

They are not included with the TRXI, but can be ordered separately

from Cabletron.Table 1-1 lists each TPIM.

1.4 TRXI FEATURES

Active TCU Ports

The active TCU ports regenerate, reshape and ﬁlter the incoming

signal permitting UTP lobe cable lengths of up to

100 meters

and STP

lobe cable lengths up to

150 meters

at 16 Mbps ring speed.

Cable Signal Polarity

Differential Manchester encoding is utilized for each of the

concentrator module TCU ports.This permits passing data regardless

of receive link polarity.

Note

: If a reversed polarity condition is discovered,the segment should

be removed from the network and wired correctly (according to the

connector wiring shown in Chapter 2, Requirements / Speciﬁcations).

This will avoid the potential for future compatibility problems.

Speed Fault Protection

If a station attempts to insert into the ring at a ring speed

(4 or 16 Mbps) different from what is set on the TRXI, that port is

automatically bypassed to prevent the ring from beaconing.The Lobe

Port Status LED blinks indicating the port with the speed fault is

bypassed.

Local Management

Local Management provides the tools to manage the TRXI and all of

its attached segments.You access Local Management by connecting a

Digital Equipment Corporation VT™ 320 series terminal or a PC

using VT320 emulation software to the TRXI’s COM 1 port.

INTRODUCTION

Page 1-4

Token Ring Port Interface Modules

TPIMs are optional features that let you expand your trunk

connections using different media types.TPIMs have embedded

repeaters and retime all data. Cabletron offers a variety of TPIMs for

trunk Ring In or Ring Out connections.Table 1-2 lists each TPIM.

Ring Speed Switch

The Ring Speed Switch lets you select ring speeds of either 4 Mbps or

16 Mbps.The factory default setting is 16 Mbps.

Flash EEPROMs

The TRXI uses Flash EEPROMs that allow you to download new and

updated ﬁrmware using Cabletron System’s Remote LANVIEW/

Windows, version 2.3 or later or any device using BOOTP or TFTP

protocols.

LANVIEW LEDs

Cabletron Systems’ LANVIEW LED Status Monitoring and

Diagnostics System is a convenient troubleshooting tool that helps you

diagnose power failures, RI/RO status, cable faults, ring speed, link

problems, and network activity.

Cabletron’s Distributed LAN Monitor

Cabletron Systems’ Distributed LAN Monitor (DLM) is a software

option for the TRXI. DLM provides a method for locally polling and

monitoring devices on a local area network to minimize network

management trafﬁc on an enterprise, campus, or wide area network.

Table 1-1. TPIMs

TPIM Media Type Connector

TPIM-T1 Shielded Twisted Pair DB9

TPIM-T2 Unshielded Twisted Pair RJ45

TPIM-T4 Shielded Twisted Pair RJ45

TPIM-F2 Multimode Fiber Optic ST

TPIM-F3 Single mode Fiber Optic ST
