Cabletron Systems 9G421-02 Document technique

9032332-01

SmartSwitch 9000

9G421-02/9G429-02

Local Management Appendix

Appendix

9G421-02/9G429-02 Module Speciﬁc

Information

Introduction

This appendix contains local management information that is speciﬁc to the

9G421-02 and 9G429-02 Ethernet Modules.

The 9G421-02 and 9G429-02 modules are 3-port Ethernet switching modules with:

• 2 front-panel gigabit Ethernet ports

• 1 Internal Network Bus (INB) backplane port

Modifying Fields and User Privileges

To modify ﬁelds on this module, you must have read-write or super-user

privileges. If you have read-only privileges, you can view information; however,

you cannot modify any ﬁelds. For more information about user privileges and

community names, see the

SmartSwitch 9000 Module Local Management User’s

Guide.

9G421-02/9G429-02 Module Speciﬁc Information

Module Interface Codes

The 9G421-02 and 9G429-02 modules have 7 interfaces each. Table 1 lists the

identifying number, name, and description of each interface.

Use the numbers listed in Table 1 to conﬁgure the module’s default interface (see

the Figure 1, the General Conﬁguration Screen).

Table 1. 9G421-02/9G429-02 Module Interface Codes

Interface

Number

Interface

Name

Interface

Description

1 SMB1 1 Mbps System Management Bus

2 SMB10 10 Mbps System Management Bus

3 HOST i960 Host

4 LOCAL i960 Controller

5 INB Internal Network Bus

6 ENET1 Gigabit Ethernet Front Panel Port 1

7 ENET2 Gigabit Ethernet Front Panel Port 2

9G421-02/9G429-02 Module Speciﬁc Information

General Conﬁguration Screen

The General Conﬁguration Screen (Figure 1), displays information about the

selected module and allows you to set the following general parameters:

• Module Date and Time

• Screen Refresh and Lockout Time

• Host IP Address

• Subnet Mask

• Default Gateway and Interface

• TFTP Gateway IP Address

Figure 1. General Conﬁguration Screen

SmartSwitch 9000 Local Management

General Configuration

Module Name: 9G421-02 Firmware Revision: 01.00.00

Slot Number: 8 BOOTPROM Revision: 01.01.01

Module Serial #: Module Date: 08/11/1997

Module Board Revision: Module Time: 10:18:31

Screen Refresh Time: 03 sec

Screen Lockout Time: 15 min

FLASH Memory: 4 MB

Host IP Address: XXX.XXX.XXX.XXX

Subnet Mask: 255.255.0.0

Default Gateway: NONE DEFINED

Default Interface: NONE DEFINED

Base MAC Address: 00-00-1D-00-00-00

TFTP Gateway IP: 0.0.0.0

SAVE EXIT RETURN

9G421-02/9G429-02 Module Speciﬁc Information

General Conﬁguration Screen Fields

The following information brieﬂy explains each General Conﬁguration Screen

ﬁeld.

Module Serial #

Displays the serial number of the selected module.

Module Board Revision

Displays the version number of the selected module.

FLASH Memory

Displays the amount (megabytes) of ﬂash memory in the selected module.

Module Date

Contains a value that the module recognizes as the current date. To enter a new

date, highlight the ﬁeld and enter the date in MM/DD/YYYY format. The month

and day portion of the date must include two digits. Therefore, enter a leading

zero for months January through September, and for dates less than 10. For

example, for June 4, 1996, enter 06/04/1996 (slashes are optional). If you do not

enter slashes to separate the month, day, and year values, the ﬁrst eight digits you

enter in this ﬁeld represent an entry (i.e., 06041996).

ModuleTime

Contains a value that the module recognizes as the current time. To enter a new

time, highlight the ﬁeld and enter the time in HH:MM:SS format. Notice that

there is no AM/PM indicator. Time should be entered based upon a 24-hour

clock. For 4:07 p.m., enter 16:07:00 (colons are optional). If you do not enter colons

to separate the hours, minutes, and seconds values, the ﬁrst six digits you enter in

this ﬁeld represent an entry (i.e., 160700). For 6:12 a.m., enter 6:12:00 or 061200.

Screen RefreshTime

Contains the rate at which the module’s screens are updated. This setting

determines how frequently (in seconds) information is updated on the screen. To

enter a new refresh rate, highlight the ﬁeld and enter a number. The

default

refresh rate is 3 seconds. The

range

is 3 - 99 seconds.

The module’s default date and time settings are indeterminate. The internal

calendar and clock begin running as soon as you install the module.

NOTE

9G421-02/9G429-02 Module Speciﬁc Information

Screen LockoutTime

Contains the maximum number of minutes that the Local Management

application will display a module’s screen while pending input or action from a

user. For example, if you enter 5 in this ﬁeld, users will have up to ﬁve minutes to

respond in some fashion to each of the speciﬁed module’s Local Management

screens. In our example, after ﬁve minutes of “idleness” (no input or action), the

Local Management application terminates the session on the selected module and

the Slot Selection Screen reappears. To enter a new lockout time, highlight the

ﬁeld and enter a number. The

default

lockout time is 15 minutes. The

range

1 - 30 minutes.

Host IP Address

Contains the Internet Protocol address currently assigned to the selected module.

Set this ﬁeld according to your network requirements. Highlight the Host IP

Address ﬁeld and enter the desired IP address using dotted decimal notation (4

decimal values between 1 and 255 separated by periods). For example,

255.255.255.255.

The maximum number that you can enter in any of the four segments is 255. The

default

is 0.0.0.0 . Any of the system interfaces on the module can use this

address.

Subnet Mask

Contains the subnet mask for the selected module. A subnet mask “masks out”

the network bits of the IP address by setting the bits in the mask to 1 when the

network treats the corresponding bits in the IP address as part of the network or

subnetwork address, or to 0 if the corresponding bit identiﬁes the host. The

default

subnet mask uses the ﬁrst two portions of the IP address to identify the

network id, leaving the rest of the IP address to identify speciﬁc nodes. To enter a

new subnet mask, highlight the ﬁeld and enter a new value using dotted decimal

notation (4 decimal values between 1 and 255 separated by periods). For example,

255.255.255.255.

(The Subnet Mask ﬁeld defaults to the natural mask value, based on the IP

Address that you entered for the device.)

Default Gateway

Contains the IP Address of the device to which all packets addressed to an

unknown network or host are sent. If you do not conﬁgure a Default Gateway,

any packets that are addressed to an unknown network or host will be dropped.

This ﬁeld is not deﬁned until you enter an appropriate value using dotted

decimal notation (4 decimal values between 1 and 255 separated by periods). The

default

is NONE DEFINED, meaning no default gateway selected.

9G421-02/9G429-02 Module Speciﬁc Information

Default Interface

Contains the number that represents the interface that is connected to the

module’s Default Gateway. In some instances, dissimilar modules have different

corresponding interface numbers. For example, if you are assigning a default

interface to a 9E133-36 module and you enter a 3, then the default interface is the

Flexible Network Bus. However, if you are assigning a default interface to a

9F310-02 module and you enter a 3, then the default interface is the Internal

Network Bus. See Table 1 for module-speciﬁc interface information. The

default

is NONE DEFINED, meaning no default interface selected.

Base MAC Address

Displays the MAC Address of the selected module. This is the MAC Address of

the SMB-10 interface.

TFTP Gateway IP

The IP address of the router that connects to or is closest to the module. Conﬁgure

this address when you are performing TFTP downloads in a routed environment

(if proxy ARP is disabled on the router).

Exiting the General Conﬁguration Screen

To exit the General Conﬁguration Screen, use the arrow keys to highlight

RETURN, then press the Return key.

The Default Interface ﬁeld becomes active after you enter an IP address in the

Default Gateway ﬁeld.

NOTE

9G421-02/9G429-02 Module Speciﬁc Information

Port Statistics Screen

The Port Statistics Screen (Figure 2), displays information and statistics about the

module’s Ethernet ports.

Figure 2. Port Statistics Screen

SmartSwitch 9000 Local Management

Port Statistics

Module Name: 9G421-02 Firmware Revision: 01.00.00

Slot Number: 8 BOOTPROM Revision: 01.01.01

PORT #: 1

OCTETS: 471908210 LINK STATUS: Link

PACKETS: 1047459244

TOTAL ERRORS: 0 PORT TYPE: MMF SC

COLLISIONS: 0

CRC/ALIGNMENT ERRORS: 0 PORT STATUS: ENABLED

UNDERSIZE PACKETS: 0

OVERSIZE PACKETS: 0 APPLICATION: BRIDGING

FRAGMENTS: 0

JABBERS: 0 OPERATION MODE: FULL DUPLEX

BROADCASTS: 0

MULTICASTS: 14929292

PORT #:[ 1] EXIT RETURN

9G421-02/9G429-02 Module Speciﬁc Information

Port Statistics Screen Fields

The following information brieﬂy explains each Port Statistics Screen ﬁeld.

PORT #

Indicates the current port for which statistics are displayed.

OCTETS

Displays the number of octets transmitted and received on the port.

PACKETS

Displays the number of packets transmitted and received on the port.

TOTAL ERRORS

Displays the total number of errors on the port.

COLLISIONS

Displays the total number of collisions detected on this port.

CRC/ALIGNMENT ERRORS

Displays the number of packets with bad Cyclic Redundancy Checks (CRC) that

have been received from the network. The CRC is a 4-byte ﬁeld in the data packet

that ensures that the data received is the same as the data that was originally sent.

Alignment errors are due to misaligned packets.

UNDERSIZE PACKETS

Displays the number of packets received whose size was less than the minimum

Ethernet frame size of 64 bytes, not including preamble.

OVERSIZE PACKETS

Displays the number of packets received whose size exceeded 1518 data bytes,

not including preamble.

FRAGMENTS

Displays the total number of packets received that were not an integral number of

octets in length or that had a bad Frame Check Sequence (FCS), and were less

than 64 octets in length (excluding framing bits but including FCS octets).

JABBERS

Displays the total number of packets received that were longer than 1518 octets

(excluding framing bits, but including Frame Check Sequence (FCS) octets), and

were not an integral number of octets in length or had a bad Frame Check

Sequence.

BROADCASTS

Displays the number of broadcasts received.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Cabletron Systems Changer

Cabletron Systems

Cabletron Systems FN10 Manuel utilisateur

Cabletron Systems

Cabletron Systems SPECTRUM 1800 Manuel utilisateur

Cabletron Systems

Cabletron Systems SmartCell 6A000 Instructions de montage

Cabletron Systems

Cabletron Systems FlowPoint 2100 12 Manuel utilisateur

Cabletron Systems

Cabletron Systems SEH-24 Manuel utilisateur

Cabletron Systems

Cabletron Systems MMAC-Plus 9H531-18 Manuel utilisateur

Cabletron Systems

Cabletron Systems ATX Manuel utilisateur

Cabletron Systems

Cabletron Systems 2H23-50R Manuel utilisateur

Cabletron Systems

Cabletron Systems FN100 Manuel utilisateur

Cabletron Systems

Cabletron Systems CyberSWITCH CSX150 Manuel utilisateur

Cabletron Systems

Cabletron Systems Cabletron CyberSWITCH CSX5500 Mode d’emploi

Cabletron Systems

Cabletron Systems SmartSTACK ELS10-27MDU Instructions d'installation et d'utilisation

Cabletron Systems

Cabletron Systems SmartSTACK ELH100 Manuel utilisateur

Cabletron Systems

Cabletron Systems HubSTACK SEHI-34 Manuel utilisateur

Cabletron Systems

Cabletron Systems KBU 64 Manuel utilisateur

Cabletron Systems

Cabletron Systems Cabletron CyberSWITCH CSX5500 Manuel utilisateur

Cabletron Systems

Cabletron Systems SEH-22 Manuel utilisateur

Cabletron Systems

Cabletron Systems 6A000/ZX-250 Manuel utilisateur

Cabletron Systems

Cabletron Systems SmartSTACK 100 ELS100-16TX Manuel utilisateur

Cabletron Systems

Cabletron Systems MMAC-Plus 9E312-12 Document technique

Cabletron Systems

Cabletron Systems MMAC-Plus 9E312-12 Manuel utilisateur

Cabletron Systems

Cabletron Systems ATX Manuel utilisateur

Cabletron Systems

Cabletron Systems Cyber SWITCH 1000 Manuel utilisateur

Cabletron Systems

Cabletron Systems SmartSTACK 100 ELS100-24TX Instructions d'installation et d'utilisation

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
