Bushnell 202204 Manuel utilisateur

Model: 202204

Lit. #: 98-1355/01-09

CONTENTS

English

Français

Español

Deutsch

Italiano

Português

2 - 12

13 - 24

25 - 36

37 - 48

49 - 60

61 - 73

Congratulations on a laser rangeﬁnder that is tested, proven and endorsed by the world’s most successful bowhunter.

When the world leader in laser rangeﬁnder technology and the world’s most successful bowhunter put their heads

together on a project, it’s all about putting heads on the wall. Enter the ﬁnest archery-speciﬁc specimen on the planet.

Extremely lightweight and compact, the new Bushnell®BowHunter™Chuck Adams Edition laser rangeﬁnder excels

from tree stands and steep terrain thanks to Angle Range Compensation (ARC). Hit the FIRE button and it calculates

the “shoots-like” distance based on the angle of your shot. Featuring Bow Mode, this unit simultaneously displays

line-of-sight, angle, and true horizontal distance from 5-99 yards so you always know what pin. And if by chance you

also riﬂe hunt, the BowHunter will accurately provide line of sight distance from 5-800 yards.

INTRODUCTION

Your BUSHNELL®BOWHUNTER™CHUCK ADAMS EDITION laser rangeﬁnder is a precision instrument

designed to provide many years of enjoyment. is booklet will help you achieve optimum performance by explaining

its adjustments and features as well as how to care for this precise laser rangeﬁnding instrument. To ensure optimal

performance and longevity, please read these instructions before using your BowHunter laser rangeﬁnder.

HOW IT WORKS

e BowHunter™emits invisible, eye safe, infrared energy pulses. e Advanced Digital microprocessor and ASIC

chip (Application-Speciﬁc Integrated Circuit) results in instantaneous and accurate readings every time. Sophisticated

digital technology instantaneously calculates distances by measuring the time it takes for each pulse to travel from the

rangeﬁnder, to the target, and back.

RANGING ACCURACY

erangingaccuracyoftheBowHunter is plus or minus one yard/meterundermostcircumstances.emaximumrange

of the instrument depends on the reﬂectivity of the target. e maximum distance for most objects is 600 yards/549

meters while for highly reﬂective objects the maximum is 800 yards 732 meters, and 200 yards/183 meters to a deer

sized animal. Note: You will get both longer and shorter maximum distances depending on the reﬂective properties of

the particular target and the environmental conditions at the time the distance of an object is being measured.

e color, surface ﬁnish, size and shape of the target all aﬀect reﬂectivity and range. e brighter the color, the longer

the range. White is highly reﬂective, for example, and allows longer ranges than the color black, which is the least

reﬂective color. A shiny ﬁnish provides more range than a dull one. A small target is more diﬃcult to range than a

larger target. e angle to the target also has an eﬀect. Shooting to a target at a 90 degree angle (where the target

surface is perpendicular to the ﬂight path of the emitted energy pulses) provides good range while a steep angle on

the other hand, provides limited ranging. In addition, lighting conditions (e.g. the amount of sunlight) will aﬀect

the ranging capabilities of the unit. e less light (e.g. overcast skies) the farther the unit’s maximum range will be.

Conversely, very sunny days will decrease the unit’s maximum range.

GETTING STARTED

INSERTING THE BATTERY

Remove the battery cap by lifting the battery door tab and then rotating counter clockwise. Insert a CR-2 3-volt

lithium battery into the compartment positive end ﬁrst, then replace the battery cap.

NOTE: It is recommended that the battery be replaced at least once every 12 months.

OPERATIONAL SUMMARY

While looking through the 4x eyepiece, depress the power button once to activate the in-view Liquid Crystal

Display (LCD). Place the aiming circle (located in the center of the ﬁeld of view) upon a target at least 5 yards away,

depress and hold the power button down until the range reading is displayed near the bottom of the in-view display.

Crosshairs surrounding the aiming circle indicate that the laser is being transmitted. Once a range has been acquired,

you can release the power button. e crosshairs surrounding the aiming circle will disappear once the power button

has been released or a distance has been displayed (i.e. the laser is no longer being transmitted). Note: Once activated,

the LCD will remain active and display the last distance measurement for 30 seconds. You can depress the power

button again at any time to distance to a new target. As with any laser device, it is not recommended to directly view

the emissions for long periods of time with magniﬁed lenses. e maximum time the laser is transmitted (ﬁred) is 10

seconds. To re-ﬁre, press the button down again.

LIQUID CRYSTAL DISPLAY (LCD) INDICATORS

e BowHunter™features a Perma Focus monocular optical system for viewing your target. A liquid crystal display

(LCD) is mounted within the optical system and when activated, displays unit of measure, a reticle for targeting, when

the laser is actively ﬁring, when a target has been acquired, battery life indicator and Bow mode indicator. Inherent in

the manufacturing process are small black spots that appear in the optical system. ese are a natural characteristic of

the LCD and cannot be fully eliminated in the manufacturing process. ey do not aﬀect the distancing performance

of the unit. A summary of these features is presented below.

UNIT OF MEASURE OPTIONS

e BowHunter™can be used to measure distances in yards or meters. e unit of measure indicators are located

in the lower right portion of the LCD. To select between yards and meters, the unit should be oﬀ. While looking

through the eyepiece, press and hold the POWER button down for approximately 5 seconds. During this time all

liquid crystal segments and icons will be displayed. As you continue to depress the power button, the display will

toggle back and forth between Yards and Meters. Once the unit of measure desired is displayed, simply release the

power button. e device will return to the last unit of measure setting used each time the unit is turned on.

RETICLE FOR TARGETING OBJECTS

Place the aiming circle (located in the center of the ﬁeld of view) upon a target at least 5 yards away, depress and hold

the power button down until the range reading is displayed near the bottom of the in-view display.

ACTIVE LASER

Crosshairs surrounding the aiming circle indicate that the laser is being transmitted. Once a range has been acquired,

you can release the power button. e crosshairs surrounding the circle will disappear once the power button has been

released or a distance has been displayed (i.e. the laser is no longer being transmitted).

BATTERY LIFE INDICATOR

Battery Indicator: Within the display is a battery icon.

Full charge

2/3 battery life remaining

1/3 battery Life remaining

Battery Indicator Blinks - Battery needs to be replaced and unit will not be operable.

ARC (Angle Range Compensation): In addition to all of the features described above, the BowHunter is an advanced

premium laser rangeﬁnder featuring a built-in accelerometer-based inclinometer that digitally displays the exact angle

from -90 to +90 degrees of elevation and is +/- 1.0 degree accurate.

e BowHunter™solves a problem bow-hunters have been faced with for years. e problem: Bow-hunters have

struggled with extreme uphill and downhill angles because of how these angles alter true horizontal distance to your

target. e Solution: ARC’s integrated inclinometer provides elevation angle to allow for distance compensation when

targeting objects that are either uphill or downhill.

Bow Mode ( ): Displays line of sight distance, degree of elevation, and true distance range from 5-99 yards / meters

and a maximum inclination of +/- 90°.

Once the range is displayed, continue to hold the POWER button down for approximately

2 seconds while holding the aiming circle on the object and keeping the unit as steady

as possible so as to allow the inclinometer enough time to measure angle. en release

the POWER button. Once you have released the power button, a degree of angle and

compensated range will be displayed beneath the line of sight distance as seen in the

images below.

When line of sight distances from 5-99 yards are displayed, the Bow mode indicator will automatically be displayed

along with angle and a compensated distance. If distances greater than 99 yards are displayed, the Bow mode Indicator

will automatically turn oﬀ along with compensated distances.

BOW MODE EXAMPLE

Line of sight is 32 yards, angle is -44 degrees, and the Angle Range Compensated distance is 23 yards. e “ ”

means “play” or “shoot as,” so instead of shooting as 32 yards, shoot as 23 yards. If you were to shoot as if 32 yards,

you would shoot over the top of the deer because of the severe angle.

e line of sight distance will display in the primary numeric display and the inclination and horizontal distance will

display in the secondary numeric displays. Bushnell®determined through extensive testing and interviews with high-

proﬁle bow hunting experts that multiple bow ballistic groups were not necessary. Bow-hunters want to know true

horizontal distance because that is how they practice shooting, and once they conﬁdently know that, they can make

any necessary adjustments. Giving the bow-hunter anything else other than horizontal distance creates additional

confusion and uncertainty.

Many people mistakenly believe that uphill shots perform diﬀerently from downhill shots because of gravity. However,

it is not due to gravity, but more of an aberration of the sighting system used on bows. e sighting pin on a bow

resides several inches above the mechanical axis of the arrow. For example, when one is aiming 23 degrees up an

incline, the arrow is at a diﬀerent angle.

NOTE: We took the most commonly used features and included them all in a simple to use, one button operation

device. is laser rangeﬁnder always functions in Bow mode from 5-99 yards. e device will provide line of sight

distance only when objects greater than 99 yards are acquired.

SPECIFICATIONS

Dimensions: Pocket Size Vertical Design, measuring 1.4 x 2.4 x 3.8 inches

Weight: 5.2 oz.

Accuracy: +/- 1 yard

Magniﬁcation: 4x

Built-In Inclinometer

ARC provides bow-hunters true horizontal distance from 5-99 yards

Power Source: 3- volt lithium battery included

FOV: 430 ft. @ 1000 yards

Total Eye Relief: 20mm

Exit Pupil: 5 mm

RainProof

5-yard minimum, 800 yards to a reﬂective target, 200 yards to a deer, 600 yards to a tree

CLEANING

Gently blow away any dust or debris on the lenses (or use a soft lens brush). To remove dirt or ﬁngerprints, clean

with a soft cotton cloth, rubbing in a circular motion. Use of a coarse cloth or unnecessary rubbing may scratch the

lens surface and eventually cause permanent damage. For a more thorough cleaning, photographic lens tissue and

photographic-type lens cleaning ﬂuid or isopropyl alcohol may be used. Always apply the ﬂuid to the cleaning cloth

- never directly on the lens.

TROUBLE SHOOTING TABLE

If unit does not turn on - LCD does not illuminate:

• DepressPOWERbutton.

• Checkandifnecessary,replacebattery.
