Bushnell 202208 Manuel utilisateur

SER RANGEFINDERS

Model: 202208/202208C

01-14

Features/Display

Battery Life Indicator

Aiming Reticle

Distance Displayed

in Yards/Meters

LCD INDICATORS

4x Magnification

Simple One Button

Operation

In-view LCD

Vertical

Configuration

Rainproof

Housing

Congratulations on your purchase of the Bushnell Bone Collector Laser Rangefinder. Your Bushnell

Laser Rangefinder is designed to provide many years of enjoyment. This booklet will help you achieve

optimum performance by explaining its adjustments and features as well as how to care for this

precise laser rangefinding instrument. To ensure optimal performance and longevity, please read these

instructions before using your Bushnell Bone Collector Laser Rangefinder.

INTRODUCTION

The Bushnell Bone Collector Laser Rangefinder delivers accurate range performance to +/- one yard.

Range to a deer as far as 200 yards/182 meters out, or to a tree 400 yards/366 meters away for a

reference point. The single button operation allows outdoor enthusiasts to easily measure distance with

confidence. The Bushnell Bone Collector Laser Rangefinder emits invisible, eyesafe, infrared energy

pulses. Digital technology instantaneously calculates distances by measuring the time it takes for each

pulse to travel from the rangefinder, to the target, and back.

ACCURACY

The ranging accuracy of the Bushnell Bone Collector Laser Rangefinder is plus or minus one yard under

most circumstances. The maximum range of the instrument depends on the reflectivity of the target.

The maximum distance for most objects is 400 yards/366 meters while for highly reflective objects the

maximum is 600 yards/549 meters.

Note: You will get both longer and shorter maximum distances depending on the reflective properties of the

particular target and the environmental conditions at the time the distance of an object is being measured.

The color, surface finish, size and shape of the target all affect reflectivity and range. The brighter the color, the

longer the range. Red is highly reflective, for example, and allows longer ranges than the color black, which is

the least reflective color. A shiny finish provides more range than a dull one. A small target is more difficult to

range than a larger target. The angle to the target also has an effect. Shooting to a target at a 90 degree angle

(where the target surface is perpendicular to the flight path of the emitted energy pulses) provides good range

while a steep angle on the other hand, provides limited ranging. In addition, lighting conditions (e.g. the

amount of sunlight) will affect the ranging capabilities of the unit. The less light (e.g. overcast skies) the farther

the unit’s maximum range will be. Conversely, very sunny days will decrease the unit’s maximum range.

INSERTING THE BATTERY

Remove the battery cap by rotating the screw counter clockwise lifting the battery door. Insert an

Alkaline 9 volt battery into the compartment and attach battery connectors.

Note: It is recommended that the battery be replaced at least once every 12 months.

OPERATIONAL SUMMARY

While looking through the monocular, depress the power button once to activate the inview display

system (LCD). Aim the rangefinder at a target at least 10 yards away, depress and hold the power button

down until range reading is displayed. Release the power button.

Note: Once activated, the Bushnell Bone Collector Laser Rangefinder’s LCD will remain active and display

the last distance measurement for 30 seconds.

You can depress the power button again at any time to distance to a new target. As with any laser device,

it is not recommended to directly view the emissions for long periods of time with magnified lenses.

FEATURES

Your Bushnell Bone Collector Laser Rangefinder’s LCD incorporates illuminated indicators that advise

you unit of measure, when the laser is active, the battery charge is low, and when a target has been 3

acquired. A summary of these features is presented below:

BATTERY LIFE INDICATOR

Battery Indicator: Within the display is a battery icon

Full charge

2/3 battery life remaining

1/3 battery Life remaining

Battery Indicator Blinks – Battery needs to be replaced and unit will not be operable.

UNIT OF MEASURE OPTIONS

The rangefinder can be used to measure distances in yards or meters. The unit of measure indicators are

located in the lower right portion of the LCD. To select between yards and meters, the unit should be

off. While looking through the eyepiece, press and hold the POWER button down for approximately

5 seconds. During this time all liquid crystal segments and icons will be displayed. As you continue to

depress the power button, the display will toggle back and forth between Yards and Meters. Once the

unit of measure desired is displayed, simply release the power button. The device will return to the last

unit of measure setting used each time the unit is turned on.

OPTICAL DESIGN

The Bushnell Bone Collector Laser Rangefinder features a fixed focus monocular optical system for

viewing your target. A liquid crystal display (LCD) is mounted within the optical system and when

activated, displays a reticle for targeting, yards, and low battery indicators. Inherent in the manufacturing

process are small black spots that appear in the optical system. These are a natural characteristic of the

LCD and cannot be fully eliminated in the manufacturing process. They do not affect the distancing

performance of the unit.

CLEANING

Gently blow away any dust or debris on the lenses (or use a soft lens brush). To remove dirt or

fingerprints, clean with a soft cotton cloth, rubbing in a circular motion. Use of a coarse cloth or

unnecessary rubbing may scratch the lens surface and eventually cause permanent damage. For a more

thorough cleaning, photographic lens tissue and photographic-type lens cleaning fluid or isopropyl

alcohol may be used. Always apply the fluid to the cleaning cloth – never directly on the lens.

SPECIFICATIONS:

•Dimensions: Pocket Size, measuring 4.2 x 3.6 x 1.9 inches

•Weight: 7.7 oz.

•Accuracy: +/- 1 yard

•Magnification: 4x

•Display: LCD (even and odd numbers)

•Power Source: 9 volt alkaline battery

•FOV: 320 ft. @ 1000 yards

•Total Eye Relief: 20mm

•Exit Pupil: 4 mm

•Single Button Operation

•10-yard minimum, 600 yards to a reflective target, 400 yards to a tree, 200 yards to a deer

•Includes case 5

TROUBLE SHOOTING TABLE

Before returning your laser rangefinder for repair, consult the Trouble Shooting Table below.

If unit does not turn on – LCD does not illuminate :

•Depress power button.

•Check and if necessary, replace battery.

If unit powers down (display goes blank when attempting to power the laser) :

•The battery is either weak or low quality. Replace the battery with a good quality alkaline battery.

"Heavy Duty" or other non-alkaline batteries are NOT recommended.

There is no reset button to clear last range reading before ranging another target :

•The last range reading does not need to be cleared before ranging another target. Simply aim at the

new target using the LCD’s reticle, depress the power button and hold until new range reading is

displayed. If target range cannot be obtained:

•Make sure LCD is illuminated.

•Make sure that the power button is being depressed

•Make sure that nothing, such as your hand or finger, is blocking the objective lenses (lenses closest to

the target) that emit and receive the laser pulses.

•Make sure unit is held steady while depressing power button.
