Bushnell Neo+ Handheld Manuel utilisateur
User
Manual
Model # 368150 Lit # 98-1958/10-10
®
®
3
Table of Contents
Page Title Page #
Welcome 4
Important Info / Our Website 5
iGolf.com Registration 6
Battery Information 7
Package Contents / Computer Requirements 8
Controls/Parts Reference 9
Button Functions 10
Power On/O and Backlight 11
Getting Started/Main Menu 12
Play Golf Mode 13-14
Shot Distance Feature 15
Play Golf Menu 16
Options Menu 17-20
Options Menu (Settings Submenu) 19
Troubleshooting 21-22
Warranty 23
FCC Statement 24
4
Welcome
Introduction
Important Information
Congratulations on your purchase of the Bushnell neo+ Golf GPS. We sincerely hope
you will nd your Bushnell product both enjoyable and easy to use. Knowing the exact
distance for each shot will assist you in lowering your score and enhance your overall
golng experience.
This User Manual was created for you to get the most out of your new device and
assist with the initial setup. It only takes a few minutes to read, after which you can
immediately begin using your new neo+and enjoying its many features.
The Bushnell neo+is preloaded with over 16,000 golf courses and ready to use out of the
box without downloading any additional software. After you’ve had a chance to begin
to get familiar with the capabilities of the neo+, please be sure go to iGolf.com to set up
your free user account within 45 days. This will let you make sure the internally stored
GPS data includes any newly added courses.
Thank you for choosing Bushnell.
5
Introduction
Legal Disclaimer
By using this product, you agree that Bushnell Outdoor Products will not be held legally
responsible for any injury or damage to you or any person or property caused by the
user’s improper operation and/or poor judgment while using this product.
Note: See Limited Warranty for other limitations to our liability.
Additional Information
The Global Positioning System (GPS), a network of 32 satellites orbiting Earth, is operated
and maintained by the U.S. government. This GPS device requires at least 3 satellites to
be acquired to accurately determine your position. Any change made to the system by
the government could aect the accuracy and performance of this product.
Important Information
Our Website: www.bushnellgolf.com
Bushnell Golf GPS Website
www.bushnellgolf.com is an online
resource for all our Golf GPS product
owners, including product support,
FAQs, and instruction manuals.
6
Introduction
iGolf.com Registration
Within 45 days of purchase, go to iGolf.com to register your neo+, which will update the
preloaded GPS course data and load any new courses that have been recently added to
the iGolf database. Registration is free and will only take a few minutes.
If a unit that has not been registered is powered on 45 days or more after the rst GPS
x, it will not function and display a prompt to register online (which will restore it to
normal operation).
1. Using the provided cable, connect one end to the mini USB port on the front of
your neo+and attach the other end to a USB port on your computer. The display
will indicate “USB Mode”and your computer will recognize it as a standard USB
mass storage device (no driver is required).
2. Go to http://www.igolf.com, select ‘Join Now’, enter the requested information
and select the ‘Join Now’ button to continue. Create your iGolf.com prole and
select the ‘Save’ button. While on the My Prole page, select the ‘Sync Device’
button to register your neo+.
Once your neo+has been registered, you may have occasions in the future when you
want to update the GPS data for an existing course, or download a brand new course.
This can be done easily at anytime. First make sure your neo+is connected to the
computer, and that you are logged in to your iGolf.com account. Then, simply click the
‘Sync Device’ button-this will download all updated and new course data to your neo+.
7
Introduction
Battery Charging
This product contains an internal rechargeable lithium-ion battery. Under normal
operating conditions, a new battery will last 14 -16 hours on a full charge. However,
battery life may be reduced due to a variety of factors (external temperature, etc). All
rechargeable batteries lose their eective charge length over time.
The internal battery can be charged by connecting the included USB cable to the device
and a computer. Alternatively, the battery can be charged by connecting the USB cable
to the device and using the included adapter to plug the charger into a standard 110V
wall outlet. If the battery is new or has been totally drained, allow six to eight hours for
a full charge.
WARNING
• Do not attempt to access, disassemble or service the battery. Battery must be
replaced by qualied technician.
• Do not crush, puncture or short external contacts. Do not expose to temperatures
above 140oF (60oC).
• Properly recycle or dispose of battery. Do not dispose in re or water.
Product Updates
Please check www.bushnellgolf.com for the latest product updates and information.
Battery Information
8
Introduction
Package Contents
1 - Bushnell neo+
1 - Belt Clip
1 - USB Cable
1 - AC/DC 5V Adapter
1 - Quick Start Guide
Computer Requirements*
USB (1.1 or 2.0) Port
OS: Windows 7/Vista/XP, or Mac OSX **
*Required to transfer course data les.
**Windows is a registered trademark of Microsoft Corporation in the United States and
other countries. Mac and Mac OS are trademarks of Apple Inc., registered in the U.S. and
other countries.
Note: earlier versions of the neo also included a CD-Rom containing a Sync App and
Drivers. This CD is no longer included or necessary, as the new neo+ comes preloaded
with golf courses, ready to use. Your computer will recognize it automatically (no driver
or software is necessary) when you connect to the iGolf.com website to set up your
account and download the latest updated course data.
Package Contents / Computer Requirements
9
USB Port
Distance to the Center
Distance to
the Front
Distance to
the Back
Power Button / Backlight ESC / MENU Button
SCREEN Button OK / SHOT Button
Up / Down Buttons
Hole #
Controls and Parts Reference
Parts / Controls
10
Power Button ESC / MENU Button
SCREEN Button OK / SHOT Button
Up / Down Buttons
Power Button
•Turnsthedeviceon&o
•Turnsthebacklighton&o
SCREEN Button
•Displaysdistancestoadditionalpointsofinterest
Up Button
•Scrollsup
•Changesholenumber(+)
Down Button
•Scrollsdown
•Changesholenumber(-)
OK/SHOT Button
•Selectshighlightedoption
•ActivatesShotDistance
ESC/MENU Button
•Cancelscurrentoperation
•Returnstopreviousstep/screen/menu
Button Functions
Control Functions
