Bushnell Elite 1600 Rangefinder Manuel utilisateur

Model: 205110

Lit. #: 98-2003/07-11 ENGLISH

CONTENTS

English

Français

Español

Deutsch

Italiano

Português

4 - 26

27 - 52

53 - 78

79 - 104

105 - 130

131 - 156

Elite™1600 ARC™- Laser Rangeﬁnder

205110

e ultimate in innovation, the NEW ELITE  ARC, combines the best of a compact monocular with the

new Vivid Display Technology™. Every range is displayed with rich contrast and stunning clarity no matter what

the lighting conditions are. At the push of a button, it displays the exact distance to your target from  to ,

yards. With built-in Angle Range Compensation, BOW Mode delivers Line-of-sight, degree of angle, and true

horizontal distance and RIFLE Mode provides line-of-sight, degree of angle, and bullet-drop / holdover data. With

new RainGuard® HD anti-fog coating and a fully waterproof design to ensure reliability and clarity in all conditions,

it’s the best of all worlds.

is booklet will help you achieve optimum performance by explaining its adjustments and features as well as how to

care for this device. To ensure optimal performance and longevity, please read these instructions before using you’re

Elite  ARC laser rangender.

HOW OUR DIGITAL TECHNOLOGY WORKS

e Elite™  ARC™ emits invisible, eye safe, infrared energy pulses. e Elite  ARC‘s Advanced Digital

microprocessor and ASIC chip (Application-Specic Integrated Circuit) results in instantaneous and accurate

readings every time. Sophisticated digital technology instantaneously calculates distances by measuring the time it

takes for each pulse to travel from the rangender, to the target, and back.

RANGING ACCURACY

e ranging accuracy of the Elite  ARC is plus or minus one yard / meter under most circumstances. e

maximum range of the instrument depends on the reectivity of the target. e maximum distance for most objects

is  yards /  meters while for highly reective objects the maximum is  yards /  meters. Note: You will

get both longer and shorter maximum distances depending on the reective properties of the particular target and the

environmental conditions at the time the distance of an object is being measured.

e color, surface nish, size and shape of the target all aect reectivity and range. e brighter the color, the longer

the range. White is highly reective, for example, and allows longer ranges than the color black, which is the least

reective color. A shiny nish provides more range than a dull one. A small target is more dicult to range than a

larger target. e angle to the target also has an eect. Shooting to a target at a  degree angle (where the target

surface is perpendicular to the ight path of the emitted energy pulses) provides good range while a steep angle on

the other hand, provides limited ranging. In addition, lighting conditions (e.g. the amount of sunlight) will aect

the ranging capabilities of the unit. e less light (e.g. overcast skies) the farther the unit’s maximum range will be.

Conversely, very sunny days will decrease the unit’s maximum range.

GETTING STARTED

OPERATIONAL SUMMARY

While looking through the Elite™  ARC™, depress the power button once to activate the Vivid Display. Place the

aiming circle (located in the center of the eld of view) upon a target at least  yards away, depress and hold the power

button down until the range reading is displayed near the bottom of the in-view display. Crosshairs surrounding the

aiming circle indicate that the laser is being transmitted. Once a range has been acquired, you can release the power

button. e crosshairs surrounding the aiming circle will disappear once the power button has been released (i.e. the

laser is no longer being transmitted). Note: Once activated, the display will remain active and display the last distance

measurement for  seconds. You can depress the power button again at any time to distance to a new target. As with

any laser device, it is not recommended to directly view the emissions for long periods of time with magnied lenses.

e maximum time the laser is transmitted (red) is  seconds. To re-re, press the button down again.

VIVID DISPLAY INDICATORS

Your Elite  ARC Vivid Display™ incorporates the following illuminated indicators:

Angle Range Compensation Modes

Rie Mode ()

Bow Mode ()

Battery Life Indicator ()

Aiming Circle ()

Active Laser ()

Targeting Modes

BullsEye Mode ()

Brush Mode ()

Primary Numeric Display displays Line-of-sight Distance ()

Holdover / Bullet-drop measure for Riﬂe Mode

MOA ()

CM ()

IN ()

SD = Variable Sight-In Distance ()

Secondary Numeric Display ()

(Toggles from Degree of Angle to Holdover / bullet drop for Rie mode)

(Toggles from Degree of Angle to True Horizontal Distance for Bow Mode)

910

ANGLE RANGE COMPENSATION

e Elite™ ARC™is an advanced premium laser rangender monocular featuring a built-in accelerometer-based

inclinometer that digitally displays the exact angle from - to + degrees of elevation and is +/- . degree accurate.

e Bushnell® Elite  ARC solves a problem hunters have been faced with for years. e problem: Bow and rie

hunters have struggled with extreme uphill and downhill angles because of how these angles alter true horizontal

distance to your target. e Solution: ARC’s integrated inclinometer provides elevation angle to allow for distance

compensation when targeting objects that are either uphill or downhill. is data is then combined with internal

algorithmic ballistic formulas.

ARC (ANGLE RANGE COMPENSATION) MODES

Bow Mode ( ): Displays line of sight distance, degree of elevation, and true horizontal distance from - yards /

meters and a maximum inclination of +/- °.

Riﬂe Mode ( ): Calculates and displays the amount of bullet drop, at the target in inches, centimeters or

MOA. e amount of bullet drop is determined by the line of sight distance to the target, degree of elevation,

along with the specic ballistic characteristics of the caliber and ammunition load. When you range your target,

the line of sight, degree of elevation, and bullet-drop/holdover in inches, centimeters, or MOA will be displayed

from  to  yards/meters with a maximum inclination of +/- °. One of eight ballistic groups (identied as

A, B, C, D, E, F, G, and H) for center re ries and two ballistic groups (Identied as I and J) for Black Powder /

Muzzleloaders can be selected by the user, with each formula representing a given combination of caliber and loads.

e ballistic groups are selected by the user in the SET-UP menu.

Regular Mode ( ): is mode does not provide any degree of elevation or compensated distance, but instead,

line of sight distance only.

BATTERY LIFE INDICATOR

Battery Indicator:

Full charge

/ battery life remaining

/ battery Life remaining

Battery Indicator Blinks - Battery needs to be replaced and unit will not be operable.

INSERTING THE BATTERY

Remove the battery cap by lifting the battery door tab and then rotating counter clockwise. Insert a CR123 3-volt

lithium battery into the compartment negative end ﬁrst, then replace the battery cap.

NOTE: It is recommended that the battery be replaced at least once every 12 months.

UNIT OF MEASURE OPTIONS

e Elite  ARC can be used to measure distances in yards or meters. e unit of measure indicators are located

in the lower right portion of the LCD.

ACTIVE LASER

Crosshairs surrounding the aiming circle indicate that the laser is being transmitted. Once a range has been acquired,

you can release the power button. e crosshairs surrounding the circle will disappear once the power button has been

released (i.e. the laser is no longer being transmitted).

SELECTIVE TARGETING™ MODES

e Elite™ ARC™was especially designed with hunters in mind. e selective targeting modes allow you to

adjust the performance parameters of the unit to suit your specic situation and environment. To move from one

mode to another, press the POWER button once to turn on the unit. While looking through the eyepiece, press the

MODE button and quickly release. e dierent targeting modes available and mode indicators are listed below:

Standard with Automatic SCAN (LCD Indicator – none) is setting allows most targets to be distanced up to 

yards. Used for moderately reective targets that are typical of most distancing situations. e minimum distance in

the standard mode is  yards. To use the Automatic SCAN feature, simply hold down on the POWER button for

approximately  seconds and move the rangender from object to object while leaving the POWER button depressed.

Automatic SCAN will allow the range to be continuously updated as multiple objects are targeted.

BullsEye™(LCD Indicator - )is advanced mode allows easy acquisition of small targets and game without

inadvertently getting distances to background targets that have stronger signal strength. When more than one object

has been acquired, distance of the closer object will be displayed and a crosshair will surround the BullsEye™ indicator

informing the user that distance to the closer object is being displayed in the LCD.

Once in this mode, press the POWER button to turn the unit on. Next, align the aiming circle

onto the object (i.e. deer) that you want distance to. Next, press and hold the POWER button

and move the laser slowly over the deer until crosshairs surround the BullsEye indicator. If the

laser beam recognized more than one object (i.e. deer and background trees), distance of the

closer object (i.e. deer) will be displayed and crosshairs will surround the BullsEye indicator

informing the user that distance to the closer object is being displayed in the LCD (Figure ).

ere may be times when only the laser beam only sees one object in its path. In this case,

218

Figure 
