Bosch Video Management System

en Operator's Manual

Bosch Video Management System Table of Contents | en 3

Bosch Sicherheitssysteme GmbH Operator's Manual Operator Client | V3 | 2010.07

Table of Contents

1 Using the Help 6

1.1 Finding information 6

1.2 Printing the Help 6

2 Introduction 8

3Systemoverview 9

3.1 Hardware requirements 9

3.2 Software requirements 9

3.3 License requirements 9

4 Getting started 10

4.1 Installing the software modules 10

4.2 Installing Bosch VMS Archive Player 10

4.3 Starting Operator Client 10

5 Displaying camera images 12

5.1 Displaying a camera in an Image pane 12

5.2 Finding an item in the Logical Tree 12

5.3 Arranging Image panes 12

5.4 Displaying the Alarm Image window 13

5.5 Starting manual recording 13

5.6 Starting a pre-configured camera sequence 13

5.7 Starting an automatic camera sequence 14

5.8 Using one channel audio mode 15

5.9 Using multichannel audio mode 15

5.10 Using digital zoom 15

5.11 Saving a single image 16

5.12 Printing a single image 16

5.13 Switching to full-screen mode 16

5.14 Displaying or hiding the Image pane bars 16

5.15 Displaying information on a camera 16

5.16 Starting instant playback 17

5.17 Assigning a camera to a monitor 17

5.18 Using audio mode 17

5.19 Displaying metadata (for NVR recordings only) 17

5.20 Using the Intercom functionality 18

5.21 Locking the control of a PTZ camera 18

5.22 Updating the reference image 19

6 Using maps and the PTZ cameras 20

6.1 Displaying a map 20

6.2 Controlling PTZ cameras 20

6.3 Using in-window control of a camera 20

4en | Table of Contents Bosch Video Management System

Operator Client | V3 | 2010.07 Operator's Manual Bosch Sicherheitssysteme GmbH

7Usingfavorites 22

7.1 Adding items to the Favorites Tree 22

7.2 Creating/editing views 22

8 Managing recorded videos 24

8.1 Using the Timeline 24

8.2 Playing a specific recording mode 24

8.3 Playing recorded videos 24

8.4 Authenticating video data (for NVR recordings only) 25

8.5 Changing the playback speed 25

8.6 Protecting video 25

8.7 Deleting video data 25

8.8 Exporting video data 26

8.9 Importing video data 27

8.10 Performing a Forensic Search (only VRM recordings) 27

8.11 Finding motion (only NVR recordings) 28

8.12 Finding Logbook entries 28

8.13 Finding recorded video data 29

9 Handling alarms 30

9.1 Accepting an alarm 30

9.2 Adding comments to an alarm 30

9.3 Clearing an alarm 31

9.4 Customizing the Alarm List window 31

9.5 Displaying the Live Image window 32

9.6 Starting a workflow 32

9.7 Un-accepting an alarm 32

10 Using a CCTV keyboard 33

10.1 CCTV keyboard user interface 33

10.1.1 Status display 34

10.2 Using a keyboard connected to a workstation 34

10.2.1 Starting the keyboard 35

10.2.2 Entering operation modes 35

10.2.3 Displaying cameras 35

10.2.4 Using the joystick 36

10.2.5 Using softkeys 36

10.3 Using a keyboard connected to a decoder 39

10.3.1 Starting the keyboard 39

10.3.2 Displaying cameras 39

10.3.3 Using the joystick 40

10.3.4 Using softkeys 40

11 Reference information 41

11.1 Live Mode (Normal Display) 41

11.2 Playback Mode 43

11.3 Alarm Mode (Alarm Display) 45

11.4 Menu commands 47

Bosch Video Management System Table of Contents | en 5

Bosch Sicherheitssysteme GmbH Operator's Manual Operator Client | V3 | 2010.07

11.5 Reference Image dialog box 49

11.6 Select Search Parameters dialog box 49

11.7 ATM/POS Options dialog box 50

11.8 Select Virtual Inputs Filter Settings dialog box 51

11.9 Device Selection dialog box 51

11.10 Event Selection dialog box 51

11.11 Logbook Results: dialog box 51

11.12 Options dialog box 51

11.13 Logical Tree window 52

11.14 Search dialog box 52

11.15 Favorites Tree window 53

11.16 Export Tree window 53

11.17 Map window 53

11.18 PTZ Control window 53

11.19 Monitors window 54

11.20 Image window 54

11.21 Image pane 55

11.22 Timeline window 56

11.23 Motion Search dialog box 58

11.24 Export Video dialog box 59

11.25 Delete Video dialog box 60

11.26 Forensic Search dialog box (only VRM recordings) 60

11.27 Protect Video dialog box 61

11.28 Unprotect Video dialog box 61

11.29 Motion Search Results window 61

11.30 Video Search Results window 61

11.31 Alarm List window 62

11.32 Event List window 62

11.33 Used icons 63

12 Keyboard shortcuts 65

12.1 General controls 65

12.2 Playback controls 65

12.3 Image window controls 65

13 Concepts 66

13.1 Alarm handling 66

14 Troubleshooting 68

14.1 Updating an old Bosch VMS Archive Player version 68

14.2 Fixing the recording setting for Intercom functionality 69

Glossary 70

Index 83

6en | Using the Help Bosch Video Management System

Operator Client | V3 | 2010.07 Operator's Manual Bosch Sicherheitssysteme GmbH

1 Using the Help

To find out more about how to do something in Bosch Video Management System, access the

online Help using any of the following methods.

To use the Contents, Index, or Search:

On the Help menu, click Help. Use the buttons and links to navigate.

To get Help on a window or dialog:

On the toolbar, click .

Press F1 for help on any program window or dialog.

1.1 Finding information

You can find information in the Help in several ways.

To find information in the Online Help:

1. On the Help menu, click Help.

2. If the left-hand pane is not visible, click the Show button.

3. In the Help window, do the following:

Texts of the user interface are marked bold.

The arrow invites you to click on the underlined text or to click an item in the application.

Click to get step-by-step instructions

Related Topics

Click to display a topic with information on the application window you currently use.

This topic provides information on the application window controls.

Section 13 Concepts provides background information on selected issues.

1.2 Printing the Help

While using the Online Help, you can print topics and information right from the browser

window.

Click: To:

Contents Display the table of contents for the Online Help. Click each book to

display pages that link to topics, and click each page to display the

corresponding topic in the right-hand pane.

Index Search for specific words or phrases or select from a list of index

keywords. Double-click the keyword to display the corresponding topic in

the right-hand pane.

Search Locate words or phrases within the content of your topics. Type the word

or phrase in the text field, press ENTER, and select the topic you want

from the list of topics.

CAUTION!

Medium risk (without safety alert symbol): Indicates a potentially hazardous situation.

If not avoided, this may result in property damage or risk of damage to the unit.

Cautionary messages should be heeded to help you avoid data loss or damaging the system.

NOTICE!

This symbol indicates information or a company policy that relates directly or indirectly to the

safety of personnel or protection of property.

Bosch Video Management System Using the Help | en 7

Bosch Sicherheitssysteme GmbH Operator's Manual Operator Client | V3 | 2010.07

To print a Help topic:

1. Right-click in the right pane and select Print.

The Print dialog box opens.

2. Click Print. The topic is printed to the specified printer.

8en | Introduction Bosch Video Management System

Operator Client | V3 | 2010.07 Operator's Manual Bosch Sicherheitssysteme GmbH

2 Introduction

Bosch Video Management System integrates digital video, audio and data across any IP

network.

The system consists of the following software modules:

– Central Server

–NVR (Network Video Recorder)

– Operator Client (Bosch VMS NVRs / DiBos 8 DVRs / VRM recording / iSCSI recording /

VIDOS NVRs / local recording)

– Configuration Client

To achieve a running system, you must perform the following tasks:

– Install services (Central Server and NVR / VRM)

– Install Operator Client and Configuration Client

– Connect to network

– Connect devices to network

– Basic configuration:

– Add devices (e.g. by device scan)

– Build logical structure

– Configure schedules, cameras, events, and alarms

–Configureuser groups

– Basic operation

Bosch VMS Archive Player displays exported recordings.

Bosch Video Management System System overview | en 9

Bosch Sicherheitssysteme GmbH Operator's Manual Operator Client | V3 | 2010.07

3 System overview

See data sheets on Bosch workstations and servers for information on computers where

Bosch Video management System can be installed.

All these software modules can optionally be installed on one PC.

Tasks of the software modules

–Central Server: Stream management, alarm management, priority management, central

logbook, user management

–NVR: Collecting the stream data from IP cameras, administering data on the connected

hard disk drives, distributing events from connected cameras. Manages MPEG-4 SH++

streams.

–VRM: Distributing storage capacities on iSCSI devices to the encoders, while handling

load balancing between multiple iSCSI devices.

Streaming playback video and audio data from iSCSI to Operator Clients.

Manages MPEG-4 SH++ and H.264 streams.

–Configuration Client: System configuration and administration for Operator Client.

–Operator Client: Live monitoring, storage retrieval and playback, alarm.

3.1 Hardware requirements

See the data sheet for Bosch Video Management System. Data sheets for platform PCs are

also available.

3.2 Software requirements

See the data sheet for Bosch Video Management System.

Bosch Video Management System must not be installed on a computer where you want to

install Bosch VMS Archive Player.

3.3 License requirements

See the data sheet for Bosch Video Management System for the available licenses.

10 en | Getting started Bosch Video Management System

Operator Client | V3 | 2010.07 Operator's Manual Bosch Sicherheitssysteme GmbH

4 Getting started

This chapter provides information on how to get started with Bosch Video Management

System and with Bosch VMS Archive Player.

4.1 Installing the software modules

Install every software module on the computer that is supposed to be used for this module.

To install:

1. Insert the product CD-ROM.

2. Start setup.exe or start the Bosch Video Management System Setup on the Welcome

screen.

3. In the next dialog box, select the modules to be installed on this computer.

4. Follow the instructions on the screen.

4.2 Installing Bosch VMS Archive Player

You can include the setup for Bosch VMS Archive Player in an export you create with

Bosch VMS Operator Client.

If there is no setup available with the export, you can find it on a computer where Bosch VMS

is installed: C:\<Installation

directory>\Bosch\VMS\Update\NvrArchivePlayer\NvrArchivePlayerSetup.exe

To install:

1. Copy the Setup program file on a computer where Bosch VMS is not installed.

2. Start NVRArchivePlayerSetup.exe.

3. Follow the instructions on the screen.

4.3 Starting Operator Client

Note:

– Before using the system, activate the licenses that you have ordered. The Configuration

Manual or the Configuration Client Online Help describe how to activate the licenses.

– To be sure that your Bosch Video Management System uses the language that you need,

please configure this language in your Configuration Client. See the Online Help for

details.

If a newer version of the application is stored on the Central Server, this version is installed

automatically by no-touch deployment when you log on.

To start Operator Client:

1. From the Start menu, select Programs > Bosch VMS > Operator Client.

The dialog box for logging on is displayed.

2. In the User Name: field, type your user name.

When you start the application for the first time, type Admin as user name, no password

required.

CAUTION!

Do not install DiBos Web client on any Bosch VMS computer. Otherwise Operator Client on

each computer with the web client crashes after the Web client is started.

CAUTION!

Install Bosch VMS Archive Player only on a computer where Bosch Video Management is not

installed.

Autres manuels pour LTC 1311/20 FlexiDome I

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Bosch Système de sécurité

Bosch

Bosch FMM-100 Series Manuel utilisateur

Bosch

Bosch PRAESENSA PRA-SCL Feuille d'instructions

Bosch

Bosch Praesideo Manuel utilisateur

Bosch

Bosch SOLUTION 6000 Manuel utilisateur

Bosch

Bosch HSG9483 Series Manuel utilisateur

Bosch

Bosch Security System Manuel utilisateur

Bosch

Bosch 120 Series Manuel utilisateur

Bosch

Bosch Security Systems Manuel utilisateur

Bosch

Bosch DIP-3040-00N Manuel utilisateur

Bosch

Bosch D220 Manuel utilisateur

Bosch

Bosch DIVAR IP all-in-one 7000 3U Manuel utilisateur

Bosch

Bosch Radion Specialty RFBT Manuel utilisateur

Bosch

Bosch Divar Manuel utilisateur

Bosch

Bosch PRAESENSA Comment utiliser

Bosch

Bosch D621 Series Manuel utilisateur

Bosch

Bosch B Series Manuel utilisateur

Bosch

Bosch FMC-300RW-GSGRD Manuel utilisateur

Bosch

Bosch ISW-BHB1-WX Manuel de service

Bosch

Bosch Fire System Manuel utilisateur

Bosch

Bosch Solution 16i Manuel utilisateur

Bosch

Bosch Plena Power Amplifier Manuel utilisateur

Bosch

Bosch AMAX 2100 Manuel d'instructions

Bosch

Bosch FNM-320 Series Manuel utilisateur

Bosch

Bosch CC610PB Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
