BiPAC 8500/8520/8501

2.3Mb/4.6Mb SHDSL and 5.7Mb SHDSL.bis

Bridge/Router

VPN Firewall

4-Port Switching Hub

Quick Install Guide

LThis guide covers only the initial

Internet set-up and is based on

the 8500 model. Please refer to

the full User Manual on the CD-

ROM for more advanced

settings. Screen shots may vary

from the actual router.

www.billion.uk.com

This symbol on the product or in the instructions means that your electrical and electronic

equipment should be disposed at the end of its life separately from your household waste.

There are separate collection systems for recycling in the EU.

For more information, please contact the local authority or your retailer where you purchased

the product.

QUICK INSTALL GUIDE

Billion 8500/8520/8501 VPN Firewall Bridge/Router Installation

1.1 Starting out:

Before you can establish an Internet connection through your Billion 8500 VPN

Firewall Bridge/Router make sure you have the following:

1. A Computer or Notebook with an installed Network Adaptor (sometimes called

an Ethernet Adaptor, Network Card or NIC)

2. An SHDSL (sometimes called SDSL) service account and configuration

information provided by your Internet Service Provider (ISP). You should need

only a User Name and Password, but you can check with your ISP to see if you

require any of the other following configuration parameters to connect your

Billion 8500 VPN Firewall Bridge/Router to the Internet :

a. ISP User Name and Password

b. VPI/VCI parameters

c. Multiplexing Method

d. Host and Domain Names

e. ISP Domain Name Server ( DNS ) Address

f. Fixed or Static IPAddress.

1.2 Steps for Connection:

The following are the steps to properly connect your Billion 8500 VPN Firewall

Bridge/Router:

1. Turn off your computer.

2. Connect the supplied ADSL RJ-11 cable from your master SDSL socket or SDSL

enabled telephone socket to the LINE Port of your Billion 8500 VPN Firewall

Bridge/Router.

3. Connect the Ethernet cable (RJ-45) from one of the Ethernet ports of your Billion

8500 VPN Firewall Bridge/Router to the Network Adaptor in your computer.

4. Connect the Power adaptor to the Billion 8500 VPN Firewall Bridge/Router and

plug the other end into a Power outlet. Power up the unit.

5. Turn on your computer. Please allow up to 45 seconds for your Network Adaptor

to locate the Router.

6. Now you are ready to configure the Billion 8500 VPN Firewall Bridge/Router.

7. Please note that your router should be pre-configured for the UK*. All you need to

do is to follow the instructions that follow and enter your user name and password

as supplied by your Service Provider. No other changes should be necessary.

*Standard UK settings are VPI 0, VCI 38, Encapsulation PPPoA, and Annex B for

SHDSL. If the modem is not pre-configured for the UK, you will have to make

changes to the VPI and VCI settings and check the Encapsulation. This can be done at

Step 4 on the next page, and under Configuration. Please contact your Service

Provider to confirm their configuration parameters.

Screen shots in this QIG may vary slightly from the actual Router.

2.1 Configuration:

1. Open Internet Explorer or your default web browser and type

http://192.168.1.254 on the address bar (where you would normally enter the

web site address) as per the illustration below.

2. You will be presented with a user name and password prompt. Simply enter

user name as admin, password as admin and click OK. This will take you to

the modem’s Status Page.*

•If the user name and password prompt box does not appear make sure that any

firewall or anti-virus such as Zone Alarm or Norton is disabled. Also ensure that

your Internet settings are correct. (In Internet Explorer go to Tools/Internet

Options/Connections and make sure “Never dial a Connection” is checked. Then

Click on the LAN settings and ensure “Automatically detect settings” is checked

and all other fields are blank. Then go to Tools/Internet Options/Security and

return your Security settings to “default”. )

3. From the Menu on the left select Quick Start.

4. Under PPP add your user name and password as provided by your ISP (only

change VPI and VCI settings and Encapsulation if necessary) and click Apply.

5. Click OK.

6. Now click the blue Save Config button.

7. Confirm by clicking Apply.

8. Click OK.

9. Now restart the router by clicking the blue Restart button

10. Confirm restart of the router by clicking Restart.

11. Wait for the router to finish the restart process.

12. Go to the Status Page which should now show a WAN IP address and your

connection status under WAN.

13. This completes the initial configuration of the router and you can close down

your browser or Logout. You should now be connected to your Service

Provider. For advanced configuration please access the full manual on the CD

provided.

Telephone Support for Internet Access ONLY is available during office hours from

Mon-Fri 10am–5pm on 0870-8501528. If you are successfully connected to the

Internet and have a support query please contact www.billion.uk.com/esupport and

submit a ticket.
