BestScope BS-6022RF Manuel utilisateur

Metallurgical Microscope

Model: BS-6022RF/TRF

User Manual

It is recommended strongly that you study this manual thoroughly before using the microscope.

Retain this manual in an easily accessible place near the work desk for future reference.

BestScope International Limited

Contents BS-6022RF/TRF

USER NOTICE…………………………………………………………… 2

1. Components………………………………………………………………3

2. Assembly……………………………………………………………………5

3. Operation………………………………………………………………… 10

4. Observation Methods ……………………………………………… 17

5. Specification …………………………………………………………… 19

6. Troubleshooting ……………………………………………………… 20

BestScope International Limited

User Notices BS-6022RF/TRF

I. Safety note

1. Carefully open the box, avoid the accessories, like lens, dropping to ground and being

damaged.

2. Do keep the instrument out of direct sunlight, high temperature or humidity, dusty and easy

shaking environment. Make sure the stage is smooth, horizontal and firm enough.

3. When moving the instrument, please use two hands to grip with the two sidesofthe

microscope body.

4. When running, the lamp house and nearby parts will be very hot. Please ensure there is enough

cooling room for them.

5. Always ensure that the grounding terminal of the microscope and that of the wall outlet are

properly connected. If the proper power cord is not used, product safety performance cannot be

warranted.

6. For safety, be sure the main switch is in “O”(off) state before replace the halogen lamp or the

fuse, then cut off the power, and do the operation after the lamp bulb and the lamp house

completely cool.(Specified Lamp: G6.35 24V100W halogen lamp)

7. Use the factory supplied power cord, please.

II. Maintenance

1. All the lenses have been well checked and adjusted. It is forbidden to disassemble them

yourself.

2. The nosepiece and coarse/fine focus unit have a compact and precise frame, please don’t

disassemble them as possible as you can.

3. Keep the instrument clean, wipe dust regularly, and be attention to avoid contaminating the

optical elements especially.

4. The contaminations on the prism, as finger mark and oil, could be gently wiped with a piece of

soft cloth or tissue paper, gauze which has been immersed in pure alcohol or xylene. (note that

the alcohol and the xylene are all burned easily, do not let them near the fire, and use them

in a drafty room as possible as you can.)

5. Don’t use organic solvent to wipe the non-optical elements, when you needtoclean,usethe

soft detergent, please.

6. When using, if the microscope is splash by liquid, cut off the power at once, and wipe up the

moisture.

7. Do not disassemble any parts of the microscope. That will affect the function or decline the

performance of the microscope.

8. Place the instrument in a cool, dry position. After using the microscope, remember to cover it

BestScope International Limited

with dust helmet. Do wait for the lamp house cooling completely before cover.

III. Electrical Parameters:

1. Voltage Rating: 100-240V AC, 50/60HZ

2. Power Rating: 200VA

3. Fuse specs.50T T5AL250V

4. Lamp: 24V100W

BestScope International Limited

1. Name of Components BS-6022RF/TRF

Components Name of BS-6022TRF

Mirror Selector Lever

ht Path Selecto

Leve

Analyzer Insertion Slot

ND Filter Lever

Polarizer Insertion Slot

Aperture Diaphragm Lever

Field Dia

hra

Leve

Main Switch

Brightness Adjustment Knob

Right Fine

Focus Knob

Mechanical Stage

Portrait Adjustment Knob

Lateral Adjustment

Knob

Lamp housing

Trinocular Viewing Unit

Filter Insertion Slot (The

filter should be inserted

fro

the left

)

Right Coarse

Focus Knob

BestScope International Limited

BS-6022RF/TRF

Components Name of BS-6022RF

Trinocular Viewing Unit

ht Path Selecto

Leve

Aperture Diaphragm Lever

Filter Insertion Slot (The

filter should be inserted

fro

the left

)

Analyzer Insertion Slot

Lamp housing

Mechanical Stage

ND Filter Lever

Mirror Selector Lever

Field Dia

hra

Leve

Main Switch

Polarizer Insertion Slot

Lateral Adjustment

Knob Brightness Adjustment KnobPortrait Adjustment

Knob

Right Fine Focus Knob

Right Coarse Focus Knob

BestScope International Limited

2．Installation BS-6022RF/TRF

2-1 Installation Diagram

The following figure shows the installation sequence of the components take BS-6022TRF for

example. The number in the figure show the installation steps.

Before installing, be sure every components is clean, do not score any parts or glass surface.

Keep well with the supplied hexagon wrench. When changing the components, you will need

it again.

Video Port

Trinocular Viewing Unit

10 ×Wide Field

Eyepiece

Lamp

housing

Reflected Light Brightfield/Darkfield

Illuminator

Infinite Plan Objective

Mechanical Stage Support

Device Microscope Body

①

⑤

⑥

③

⑦

④

②

⑧

Lamp

housing

BestScope International Limited

2-2 Installation Steps BS-6022RF/TRF

2-2-1 Installing the Mechanical Stage

Support Device

1. Before installing the device, be sure to adjust

the coarse focus knob ①.Maketheguide

board ②down to the lowest position, so you

can install the mechanical stage support

device easily.

2. Hold on the mechanical stage support device

(Fig. 2), place it from the top of the guide

board (Fig.1), let the device (Fig.2) falling

free until it reach the limit bolt. Use the

hexagon wrench screw down the locking

block③, make the stage support device and

the guide board fixed together(Fig.3).

Fig.1, Fig.2 show the installation sequence

of the components which take

BS-6022TRF for example. For

BS-6022RF, there are two limit bolt

holes with different height on the guide

board ②to meet with sample which

have different thickness: the upside hole

is for sample with 0 ～30mm thickness,

the underside hole is for sample with

20～50mm thickness.

The mechanical stage ⑤have been

adjusted horizontally and fixed together

before leaving factory. Do not

disassembly unless necessary, that may

affect the observation precision of the

instrument.

Fig.1

②

①

Fig.2

⑤③

④

limit

bolt

BestScope International Limited

BS-6022RF/TRF

2-2-2 Installing the reflected light

brightfield/darkfield illuminator

1. Installing the reflected light illuminator

(Fig.4) on the head of

microscope body(Fig. 5), and turn to a

proper position, then screw down the bolt

⑥to fix it.

2-2-3 Installing the Video Port

1. Insert the video port (Fig.6) into the

illuminator (Fig. 4), then screw down

the bolt to fix it.

2-2-4 Installing the Objective

1. Adjusting the coarse focus knob until the

support device of the mechanical stage

reach its low limit position.

2. Wresting the lowest magnification

objective onto the nosepiece from the

left or the right side, then push the

nosepiece clockwise, then place other

objectives by the sequence of low to

high magnification (Fig.7).

Installing objective this way will make

the change of magnification to be easier

while in using.

Clean the objective regularly, the

objective of the inversed microscope

is very sensitive to dust.

When replacing the objective, slowly

turning the nosepiece until you hear

“clicked”, that means the objective

enter the required position--the light

path center.

Fig.4

⑦

⑧

Fig.6

⑨

Fig.7

BestScope International Limited

BS-6022RF/TRF

2-2-5 Installing the Video Port (optional)

Insert the video port (Fig. 8) into the trinocular

unit (Fig. 6), then screw down the bolt ⑨to

fix it.

2-2-6 Installing the Eyepiece

Insert the eyepiece (Fig.9) into the eyepiece

tube until they are against each other.

2-2-7 Installing the Lamp Housing

1. Pushing the lamp holder (Fig.10)into the

illumination kits(Fig. 4) gently until they are

against each other, turn to a proper position, then

screw down the bolt ⑧to fix it.

2. Insert the power plug①into the power jack of

the microscope②, and screw down the bolt to fix

it. The result in show in Fig. 12.

◎When using transmitted light illuminator,

remove the dust cap first, then pushing the lamp

holder (Fig.10)into the jack on the back of the

microscope (Fig.11) gently and turn to a proper

position, then screw down the bolt ④. Insert the

power plug ①into the power jack of the

microscope③, and screw down the bolt to fix it.

Fig.8

Fig.9

Fig.10

①

Fig.11

②

③

④

Fig.12
