BestScope BS-6020RF Manuel utilisateur

METALLURGICAL

MICROSCOPE

Model：BS-6020RF⁄TRF

User Manual

It is recommended strongly that you study this manual thoroughly before using the

microscope. Retain this manual in an easily accessible place near the work desk for future.

reference.

BestScope International Limited

Contents BS-6020RF∕TRF

USER NOTICE…………………………………………………………… 2

1. Components………………………………………………………………3

2. Installation…………………………………………………………………5

3. Operation………………………………………………………………… 10

4. Observation Methods ……………………………………………… 17

5. Specification …………………………………………………………… 19

6. Troubleshooting ……………………………………………………… 20

BestScope International Limited

Use Notices BS-6020RF⁄TRF

I、Safety note

1. Carefully open the box, avoid the accessories, like lens, dropping to ground and being

damaged.

2. Do keep the instrument out of direct sunlight, high temperature or humidity, dusty and easy

shaking environment. Make sure the stage is smooth, horizontal and firm enough.

3. When moving the instrument, please use two hands to grip with the two sides of the

microscope body.

4. When running, the lamp house and nearby parts will be very hot. Please ensure there is enough

cooling room for them.

5. Make sure the instrument is earthed, to avoid lighting strike.

6. For safety, be sure the main switch is in “O”(off) state before replace the halogen lamp or the

fuse, then cut off the power, and do the operation after the lamp bulb and the lamp house

completely cool.

7. Use the factory supplied power cord, please.

II、Maintenance

1. All the lenses have been well checked and adjusted. It is forbidden to disassemble them

yourself.

2. The nosepiece and coarse/fine focus unit have a compact and precise frame, please don’t

disassemble them as possible as you can.

3. Keep the instrument clean, wipe dust regularly, and be attention to avoid contaminating the

optical elements especially.

4. The contaminations on the prism, as finger mark and oil, could be gently wiped with a piece of

soft cloth or tissue paper, gauze which has been immersed in pure alcohol or xylene. (note that

the alcohol and the xylene are all burned easily, do not let them near the fire, and use them

in a drafty room as possible as you can.)

5. Don’t use organic solvent to wipe the non-optical elements, when you need to clean, use the

soft detergent, please.

6. When using, if the microscope is splash by liquid, cut off the power at once, and wipe up the

moisture.

7. Do not disassemble any parts of the microscope. That will affect the function or decline the

performance of the microscope.

8. Place the instrument in a cool, dry position. After using the microscope, remember to cover it

with dust helmet. Do wait for the lamp house cooling completely before cover.

BestScope International Limited

1. Name of Components BS-6020RF⁄TRF

Mirror Selector Lever

ht Path Selector Leve

Analyzer Insertion Slot

ND Filter Lever

Polarizer Insertion Slot

Aperture Diaphragm Lever

Field Dia

hra

m Leve

Main Switch

Brightness Adjustment Knob

Right Fine Focus Knob

Mechanical Stage

Portrait Adjustment

Knob

Lateral Adjustment

Knob

Lamp housing

Trinoclular Viewing

Filter Insertion Slot (The

filter should be inserted

from the left

)

Right Coarse Focus Knob

Components name of BS-6020TRF

BestScope International Limited

BS-6020RF⁄TRF

Components name of BS-6020RF

Trinoclular Viewing

Mirror Selector Lever

ND Filter Lever

Mechanical Stage

Main Switch Lateral Adjustment

Knob

Portrait Adjustment

Knob

ht Path Selector Leve

Analyzer Insertion Slot

Lamp housing

Filter Insertion Slot (The

filter should be inserted

from the left

)

Aperture Diaphragm Lever

Field Dia

hra

m Leve

Polarizer Insertion Slot

Right Coarse Focus Knob

Brightness Adjustment Knob

Right Fine Focus Knob

BestScope International Limited

2．Installation BS-6020RF⁄TRF

2-1 Installation Diagram

The following figure shows the installation sequence of the components. The number in the figure

show the installation steps.

Before installing, be sure every components is clean, do not score any parts or glass surface.

Keep well with the supplied hexagon wrench. When changing the components, you will need

it again.

Video Port

Trinocular Viewing Unit

10 ×Wide Field

Eyepiece

Lamp

housing

Reflected Light Brightfield/Darkfield

Illuminator

Infinite Plan Objective

Mechanical Stage Support

Device

Microscope Body

①

⑤

⑥

③

⑦

④

②

BestScope International Limited

2-2InstallationSteps BS-6020RF⁄TRF

2-2-1 Installing the Mechanical

Stage Support Device

1. Before installing the device, be sure to

adjust the coarse focus knob①. Make

the guide board ②down to the lowest

position, so you can install the

mechanical stage support device easily.

2. Hold on the mechanical stage support

device (Fig. 2), place it from the top of

the guide board (Fig.1), let the device

(Fig.2) falling free until it reach the limit

position. Use the hexagon wrench screw

down the locking block ③, make the

stage support device and the guide board

fixed together(Fig.3).

The mechanical stage⑤have been

adjusted horizontally and fixed

together before leaving factory. Do

not disassembly unless necessary,

that may affect the observation

precision of the instrument.

Fig.1

②

①

Fig.2

⑤③

④

Fig. 3

BestScope International Limited

BS-6020RF⁄TRF

2-2-2 Installing the reflected light

brightfield/darkfield illuminator

1. Installing the reflected light illuminator

(Fig.4) on the head of

microscope body(Fig. 5), and turn to a

proper position, then screw down the bolt

⑥to fix it.

2-2-3 Installing the Video Port

1. Insert the video port (Fig.6) into the

illuminator (Fig. 4), then screw down

the bolt to fix it.

2-2-4 Installing the Objective

1. Adjusting the coarse focus knob until the

support device of the mechanical stage

reach its low limit position.

2. Wresting the lowest magnification

objective onto the nosepiece from the

left or the right side, then push the

nosepiece clockwise, then place other

objectives by the sequence of low to

high magnification (Fig.7).

Installing objective this way will make

the change of magnification to be easier

while in using.

Clean the objective regularly, the

objective of the inversed microscope

is very sensitive to dust.

When replacing the objective, slowly

turning the nosepiece until you hear

“clicked”, that means the objective

enter the required position--the light

path center.

Fig.4

⑦

⑧

Fig.5

⑥

Fig.6

⑨

Fig.7

BestScope International Limited

BS-6020RF⁄TRF

2-2-5 Installing the Video Port

(optional)

Insert the video port (Fig. 8) into the

trinocular unit (Fig. 6), then screw down

the bolt ⑨to fix it.

2-2-6 Installing the Eyepiece

Insert the eyepiece (Fig.9) into the

eyepiece tube until they are against each

other.

2-2-7 Installing the Lamp Housing

1. Pushing the lamp holder (Fig.10)into the

illumination kits(Fig. 4) gently until they are

against each other, turn to a proper position,

then screw down the bolt ⑧to fix it.

2. Insert the power plug①into the power jack

of the microscope②, and screw down the bolt

to fix it. The result in show in Fig. 12.

◎When using transmitted light illuminator,

remove the dust cap first, then pushing the

lamp holder (Fig.10)into the jack on the back

of the microscope (Fig.11) gently and turn to a

proper position, then screw down the bolt ④.

Insert the power plug①into the power jack

of the microscope③, and screw down the bolt

to fix it.

Fig.8

Fig.9

Fig.10

①

Fig.11

②

③

④

.12

BestScope International Limited

BS-6020RF⁄TRF

Fig.13

①

②

Fig.14

③④

Fig.15

2-2-8 Attaching the Halogen Bulb

The applicable lamp bulb is the

24V100WHAL.

1. Fully loosen the clamping screw ①at the

top of the lamp housing using the provided

hexagon wrench.

2. Remove the lamp housing ②by lifting it

up.

3. Tilt the bulb socket by 90°(Fig. 14)

4. While pushing down the bulb clamping

levers, hold the halogen bulb with gloves or

a piece of gauze, insert the bulb pins into

the sections as far as they will go.

Then return the lamp clamping lever gently

back to the original position to clamp the

bulb.

Caution for Bulb Replacement Durig or

Right After Use

When using, or soon after it is turned off

the lamp, the lamp house and nearby parts

will be very hot and will cause serious burns.

Please turn the main switch on “O” (off),

pull out power plug, and make sure the bulb,

the lamp room and periphery are all cool.

Then, you can do your replacing.

Please insert the lamp gently, or it will

be damaged by excessive extrusion.

Do not touch the Halogen bulb with

your bare hands. It will shorten the

service life or cause it to burst. If you

leave finger marks on the surface

carelessly, clean it with a dry soft cloth.

When using, the temperature of the

lamp housing surface will be very hot,

please pay attention to the warning

written on the Warning board.
