BestScope BS-2043 Series Manuel utilisateur

Version No.: V1.0

Biological Microscope

BS-2043 Series

Instruction Manual

BS-2043B BS-2043T

This instruction manual is for the operation guide, troubleshooting and

maintenance to the BS-2043 series biological microscope. Please study this manual

thoroughly before operating, and keep it with the instrument. The manufacturer

reserves the rights to the modifications by technology development. On the basis

of operation ensured, technical specifications may be subject to changes without

notice.

BestScope International Limited

Contents BS-2043 Series

Before Use

1.Components………………………………..…………..………………..………..………………………..1

2. Assembling………………..……………………..……………..………..…………………………………3

2-1Assembling Scheme…………………………..…..……..……………………….……………...3

2-2Assembling Steps ...……………………..……..………………..……………………………....4

3. Operations……………….…………………………..……….….………………..………………………….6

3-1Set Illumination………….………….…………..………..………………………………………..6

3-2 Place the Specimen Slide ..……….…………..………..……….…………………………....6

3-3 Adjust the Focus …………………………………………..………. ….……………………....6

3-4 Adjust the Focusing Tension …………………………..………..……………………..….7

3-5 Adjust the Interpupillary Distance…….………………..………..……………………….….7

3-6 Aperture Diaphragm……...…………………………………..………..……..…………………….7

3-7Use the Oil Objective (100X)….……………………………..………..………………………..….8

3-8 Use the Filter ………………………………………..………..………..…………………………..….8

3-9 Assembling and using of the TV Device..……………………..………..……………….....8

3-10 Assembling of the Photography Device……………………..………..……………….....9

3-11 Use the Storage Box ………………………………………..………..………..…………….....9

4. Troubleshooting….…………………………………..………..………..……………………………………10

BestScope International Limited

Before Use BS-2043 Series

1. Operation Notice

1. As the microscope is a high precision

instrument, always operate it with care, and avoid

physical vibrations.

2. Do not expose the microscope in the sun

directly, either not in the high temperature, damp,

dust or acute shake. Make sure the worktable is

flat and horizontal.

3. When moving the microscope, keep holding the

rear cover hand clasp①and the front end of

microscope body②with each hand. Handle with

care. (See Fig. 1)

★It will damage the microscope by holding the

stage, focusing knob or head when moving.

4. Connect the microscope to the ground to avoid

lightning strike.

5. For safety, make sure the power switch ③is at

“O” (off) and power it off before replacing the

bulb, and wait until the bulb and base cool down

completely (see Fig. 2).

★Bulb selected only: single 3W LED

6. Wide voltage range is supported as 100~240V.

Additional transformer is not necessary. Make

sure the power supply voltage is in this range.

7. Use the special power adapter supplied by our

company.

Fig.1

Fig.2

BestScope International Limited

BS-2043 Series

2. Maintenance

1. Wipe the lens gently with a soft tissue. Carefully wipe off the oil marks and fingerprints

on the lens surfaces with a tissue moistened with a small amount of 3:7 mixture of alcohol and

ether or dimethylbenzene.

★As the alcohol and ether is flammable, don’t place these chemicals near to fire or fire

source. For example, when turning on or turning off the electrical device, please use these

chemicals in a ventilated place.

2. Don’t use organic solution to wipe the surfaces of the other components. Please use the

neutral detergent if necessary.

3. If the microscope is damped by liquid when using, please power it off immediately and

wipe it dry.

4. Never disassemble the microscope, otherwise the performance will be affected or the

instrument will be damaged.

5. After using, cover the microscope with a dust cover.

3. Safety Sign

Sign

Signification

Study the instructions before use. Unsuitable operation would lead to

person hurt or instrument faulty.

Main switch ON

Main switch OFF

BestScope International Limited

1. Components BS-2043 Series

Eyepiece

Objective

Stage

Condenser

Fixed Koehler

Illuminator

Condenser

Up-down Knob

Fine

Focusing

Knob

Coarse

Focusing

Knob

Body Group

Binocular Head

FocusArm

Tension

Adjustment

Ring

BestScope International Limited

BS-2043 Series

Eyepiece

Trinocular Head

Fine

Focusing

Knob

Coarse

Focusing

Knob

FocusArm

Body Group

Lock Screw

Light

Adjustment

Knob

Power

Switch

Nosepiece

Vertical

Adjustment

Knob

Horizontal

Adjustment Knob

Condenser

Stage

Objective

BestScope International Limited

2. Assembling BS-2043 Series

2-1 Assembling Scheme

Following is the Assembling Scheme, and the numbers denote the assembling order.

★Before assembling, make sure there is no dust, dirt or other materials which will disturb it.

Assemble carefully and do not scrap any part or touch the glass surface.

Eyepiece

Objective

Condenser

Power Cord

BestScope International Limited

BS-2043 Series

2-2 Assembling Steps

2-2-1 Assemble the Condenser

1. Rotate the coarse focusing knob①according

to the direction shown in the figure, to raise the

stage to the highest position (see Fig.3).

2. Fully loosen the condenser lock-screw②.

3. Insert the condenser into the hole of base

according to the arrowhead pointed, until the

condenser is aligned with the base, and rotate the

condenser to make the handle face forward.

4. Tighten the condenser lock-screw②of

condenser, then raise the condenser with the

up-down knob to the highest position.

2-2-2 Assemble the Objective

1. Rotate the coarse focusing knob①to lower

the stage to a suitable position (see Fig. 4).

2. Then install the objectives into the

nosepiece②from the lowest magnification to

the highest in clockwisedirection.

★When operating, first use the low

magnification objective (4X or 10X) to search for

specimen and focus, and then replace with high

magnification objective to observe.

★When replacing the objective, rotate the

objective nosepiece until it sounds “ka-da”, to

make sure the objective wanted is in the center

of optical path.

2-2-3 Assemble the Eyepiece

1. Take down the cover of eyepiece tube①.

2. Insert the eyepiece② into the eyepiece tube,

until it touches the surface.

3. Tighten eyepiece with M2.5 inner hexagon

lock-screw③(see Fig.5).

Fig.5

Fig.4

Fig.3

BestScope International Limited

BS-2043 Series

2-2-4 Connect the Power Cord

★Don’t use strong force when the power cord is

bended or twisted, otherwise it will be damaged.

1. Make sure the power switch is at “O”(OFF)

before connecting the power cord.

2. Insert the connector①of power cord into the

power socket②, and make sure it connects well

(see Fig.6).

3. Insert the other connector into the socket of

power supply, and make sure it connects well.

★Use the special wire supplied by our company.

If it’s lost or damaged, choose one in the same

specifications.

★Wide voltage range is supported as 100~240V.

★Connect the power cord appropriately to

make sure the instrument is connected to

ground.

Fig.6

BestScope International Limited

3. Operations BS-2043 Series

3-1 Set Illumination

1. Put through the power and turn on the main

power switch to “—”(turn on) on the side.

2. Adjust the light adjustment knob②until the

illumination is comfortable for observation.

Rotate the light adjustment knob in clockwise to

raise the voltage and brightness. Rotate the light

adjustment knob in counterclockwise to lower the

voltage and brightness (see Fig.7).

3-2 Place the Specimen Slide

1. Push the wrench①of the specimen holder

backwards.

2. Place the cover glass of slide②faced upwards

into the clip, loosen the wrench①and clamp the

slide (see Fig. 8).

3. Rotate the X and Y-axis knob③of the stage,

and move the specimen to the center (aligned

with the center of objective).

3-3 Adjust the Focus

1.Rotate the condenser up-down knob①

according to the direction shown in the figure, to

raise it to the highest position.

2. Move the objective 4X into the optical path.

3. Observe the right eyepiece with right eye,

rotate the coarse focusing knob②until the

specimen outline appears in the view field (see

Fig. 9).

4. Rotate the fine focusing knob③ for clear

details.

★The position screw ④can avoid the

objective touching the clips.

Fig.8

Fig.7

Fig. 9
