BestScope BS-6020DRF Manuel utilisateur

Metallurgical Motorized Microscope

With Auto-Focus System

BS-6020DRF/DTRF

User Manual

It is recommended strongly that you study this manual thoroughly before using the microscope. Retain

this manual in an easily accessible place near the work desk for future reference.

Contents

User Notice ………………………………………………………… 2

1. Components …………………………………………………… 4

2. Assembly ……………………………………………………… 6

3. Adjustment ……………………………………………………… 1 5

4. O bservation Steps ……………………………………………… 1 6

5. Adjustment Operation ………………………………………… 1 7

6. Control Box Menu Setting ……………………………………… 2 4

7. Observation Methods ………………………………………… 2 7

8. Specification …………………………………………………… 2 9

9. Troubleshooting Guide …………………………………………… 30

Contents

User Notice

Ⅰ.

. Safety

Safety

Safety note

note

Ⅱ.

. Maintenance

Maintenance

User

User Notice

Notice

1. Carefully open the box, avoid the accessories, like lens, dropping to ground and being

damaged.

2. Do keep the instrument out of direct sunlight, high temperature or humidity, dusty and

easy shaking environment. Make sure the stage is smooth, horizontal and firm enough.

3. When moving the instrument, please use two hands to grip with the two sides of the

microscope body.

4. When running, the lamp house and nearby parts will be very hot. Please ensure there is

enough cooling room for them.

5. Make sure the instrument is earthed, to avoid lighting strike.

6. For safety, be sure the main switch is in “ O ” (off) state before replace the halogen lamp or

the fuse, then cut off the power, and do the operation after the lamp bulb and the lamp

house completely cool.

7. Use the factory supplied power cord, please.

The microscope has been adjusted at the factory according to the standard slide,

and all components are in the right initial position. If you want to use non-standard slide,

please refer to Chapter 6, "Control Box Menu setting ", and section 6-2-6 to re-adjust.

Otherwise, it will have serious consequences.

1. All the lenses have been well checked and adjusted. It is forbidden to disassemble them

yourself.

2. The nosepiece and coarse/fine focus unit have a compact and precise frame, please

don ’ t disassemble them as possible as you can.

3. Keep the instrument clean, wipe dust regularly, and be attention to avoid

contaminating the optical elements especially.

4. The contaminations on the prism, as finger mark and oil, could be gently wiped with a

piece of soft cloth or tissue paper, gauze which has been immersed in pure alcohol or

xylene. (

(

( N

N ote

ote

ote that

that

that the

the

the alcohol

alcohol

alcohol and

and

and the

the

the xylene

xylene

xylene are

are

are all

all

all burned

burned

burned easily,

easily,

easily, do

do not

not

not let

let

let them

them

near

near the

the

the fire,

fire,

fire, and

and

and use

use

use them

them

them in

in a

a drafty

drafty

drafty room

room

room as

as possible

possible

possible as

as you

you

you can.)

can.)

5. Don ’ t use organic solvent to wipe the non-optical elements, when you need to clean,

use the soft detergent, please.

Ⅲ

. Warning

Warning

Warning symbols

symbols

s ymbols

ymbols

ymbols meaning

meaning

S urface is hot, not touch with bare hands

C arefully read the user manual b efore use . Improper use may cause personal

injury or microscope damage .

M ain Switch on

Main Switch off

6. When using, if the microscope is splash by liquid, cut off the power at once, and wipe

up the moisture.

7. Do not disassemble any parts of the microscope. That will affect the function or decline

the performance of the microscope.

8. Place the instrument in a cool, dry position. After using the microscope, remember to

cover it with dust helmet. Do wait for the lamp house cooling completely before cover.

1. Components

. Name Of Components

滤色片插槽

（从左侧插入）

目镜

ND 滤色片拉杆

显微镜主体

Lead

电动转换器

电源开关

聚光器

反光镜选择杆

Front View

Camera

Video Adapter

E yepiece(Ocular)

ND Filter Lever

Mirror Selector Lever

Motorized Nosepiece

Lead Screw Stage

Condenser

MainBoday

Lamp House

Light Path Selector Lever

Filter Insertion Slot (The filter

should be inserted from the

left)

Aperture Diaphragm Lever

Field Diaphragm Lever

Ploarizer Insertion Slot

Analyzer Insertion Slot

Control Box

Main Switch

1. Components

Components

视频接口 (另一接口在

Video Inter

灯室

电源接口

Communication Interface(Serial port)

Communication Interface( Parallel Port )

P latform Communication Interface

Computer

Communication

Interface

Power Outlet

Power Switch

Communication Interface(Serial port)

Communication Interface(Parallel Port)

Platform Communication Interface

Lamp House

Lamp Connector

Power Outlet

Video Interface(RCA)

Video Interface (Another

Interface on the side)

Lamp House

Rear View

1. Name

Name

Name Of

Of Components

Components

①Display Panel: Displays the current status of the platform and the information ofthe

microscope System , the current platform position, lens position and the system brightness.

When insert the system setting status, it displays system setup parameters.

②Z-axis Lift Wheel: roll the wheel to control the Lead screw platform toup and down

(Z-axis Movement).

③Platform Control TouchPad: Use your fingertip moving on the Touchpad. Simultaneously,

the Microscope stage will be moving as your fingertip do ing (X-axis and Y - axis movement).

④Brightness A djust Button: Adjust the brightness.

⑤Z-axis Lift button: Z-axis's up and down .

⑥Objectives Change Button: C hange the objectives at clockwise or counter clockwise

⑦Auto-Focus Button: Focus automatically once.

⑧Real-time Focus Button: Control the real-time focus control function ON or OFF. I f ON ,

when m oving specimens, microscope automatically focuses the specimens all the whole

time.

⑨RTF Status Indicator: Displays the current state of real-time focus function.

⑩Function Buttons: Menu settings buttons.

Control Panel

①Display Panel

②Z-axis Lift Wheel

③Platform Control

TouchPad

④Brightness

Adjust Button

⑩Function Buttons

⑧Real-Focus Button

⑨RTF Status Indicator

⑦Auto-Focus Button

⑤Z-axis Lift Button

⑥Objectives Chage Button

LUM

LUM ZAxis

ZAxis

ZAxis ObJ

ObJ

OK Cancel

Cancel

RTF

○

RTF OFF

●RTF ON

2. Assembly

Assembly

2.1 Assembly Diagram

2 .

. Assembly

Assembly

2.1 Assembly Diagram

Stage Support Device

Main Body

Lamp House 2

Lamp House1

Specimen(Slice)

Holder

Lead Screw Platform

(Stage)

Objectives

Eyepieces

Camera

Video Adapter

Trinocular

Viewing

Unit

The following figure shows the installation sequence of the components. The number in the

figure shows the assembly steps.

�

Before installing, be sure every components is clean, do not score any parts or glass

surface.

�

Keep well with hexagon wrench provided. When replacing the components, you will need it

again.

2. 2 Assembly Step

Fig.1

F ig.2

2 .

. Assembly

Assembly

2. 2 Assembly Step

2.2.1 Installing Stage Support Device

Before installing the device, be sure to adjust

the coarse focus knob. Make the guide board

(see figure 1)down to the limit position, so you

can install the mechanical stage support device

easily.

Hold on the stage support device (figure 2),

place it from the top of the guide board (figure 1),

let the device (figure2) falling free until it reach

the limit position. Use the hexagon wrench to

screw down the screw and locking block , make

the stage support device (figure1) and the guide

board fixed together. (See figure 3)

Fig.3

Attention

Attention ：The

The

The stage

stage

stage support

support

support device

device

must

must be

be installed

installed

installed to

to the

the

the limit

limit

limit position,

position,

otherwise,

otherwise, when

when

when the

the

the controller

controller

controller initializing,the

initializing,the

objectives

objectives will

will

will hit

hit

hit the

the

the device

device

device and

and

and be

be damaged

damaged

badly.

Attention:

Attention: The

The

The lead

lead

lead Screw

Screw

Screw platform

platform

and

and the

the

the stage

stage

stage support

support

support device

device

device have

have

have been

been

adjusted

adjusted horizontally

horizontally

horizontally and

and

and fixed

fixed

fixed together

together

before

before leaving

leaving

leaving factory.

factory.

factory. Please

Please

Please don

don

don ’

’

’ t

disassembly

disassembly it

it unless

unless

unless necessary,

necessary,

necessary, otherwse,

otherwse,

otherwse, it

will

will affect

affect

affect the

the

the observation

observation

observation precision

precision

precision of

of the

the

microscopy.

2 .

. Assembly

Assembly

F ig.4

Fig.5

F ig.6

2. 2 Assembly Step

2.2. 2 Installing the reflected light brightfield /

darkfield illuminatior

⑥

2.2. 3 Installing the Trinoclar Viewing Unit

⑧

⑦

Installing the reflected light illuminator (fig.4)

on the head of microscope body (fig.5), and turn

to a proper position, then screw down the bolt ⑥

to fix it .

1. Loosen the fixed bolt ⑦on the microscope

main body, but do not let it ⑦fall out.

2. Insert the trinocular viewing unit into the

microscope head(fig.6), turn to a proper position,

let the two eyepiece tubes toward the front, then

use the hexagon wrench screw down the fixed

bolt ⑦to fix( See fig.6).

2 .

. Assembly

Assembly

F ig.9

F ig.8

F ig.7

2. 2 Assembly Step

2.2. 4 Installing the Lamp House

①

②

④③

Installing

Installing the

the

the Lamp

Lamp

Lamp House

House

House 1

1 (indecent

(indecent

(indecent light

light

illuminator)

1. 1. Pushing the lamp holder (Fig.7)into the

illumination kits(Fig. 6) gently until they are

against each other, turn to a proper position, then

screw down the bolt (Fig.6 ⑧) to fix it.

2. Insert the power plug (Fig.7 ①) into the power

jack of the microscope (F i g.9 ③) , and screw

down the bolt to fix it. The result in show in Fig.

10 .

Installing

Installing the

the

the Lamp

Lamp

Lamp House

House

House 2

2 (transmitted

(transmitted

(transmitted light

light

illuminator)

2. 1. Pushing the lamp holder (Fig. 8 ②)into the

illumination kits , gently until they are against each

other, turn to a proper position, then screw down

the bolt to fix it.

2. Insert the power plug ( Fig. 8 ②) into the power

jack of the microscope (F i g.9 ④) , and screw

down the bolt to fix it. The result in show in Fig.

10 .
