User Manual

F7D7501v1 • 8820-01467 Rev. C00

MIRACAST VIDEO

ADAPTER

TABLE OF CONTENTS

Introduction .............................................. 1

Placement for Optimal Performance ............................. 2

Overview................................................. 4

Product Features ............................................ 4

Product Specifications ........................................ 5

Status LED Behavior .......................................... 6

Multipurpose Button .......................................... 7

System Requirements......................................... 8

Package Contents ............................................ 8

Installing and Setting Up the Adapter ....................... 9

Navigating the Miracast Adapter’s Home Screen

with Your Remote ............................................ 19

Miracast Video Adapter’s Interfaces........................ 20

The Miracast Adapter’s User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Advanced Web Interface ..................................... 22

Troubleshooting ......................................... 31

Information.............................................. 34

INTRODUCTION

Thank you for purchasing the Belkin Miracast Video Adapter. Now you can take advantage of this great new technology that

lets you watch anything and everything from your mobile device or computer on your big, beautiful, HDTV screen.

Benefits of the Miracast Video Adapter

Your Belkin Home Network will allow you to:

• Share pictures that are saved or taken with your smart device with friends and family

• Play games made for your Android™ device directly on your TV and eliminate strained eyes

• Watch movies and videos on your TV that are saved on your smart device directly

• Browse the Internet on your TV without the need for a smart TV

INTRODUCTION

Placement for Optimal Performance

Your wireless connection will be stronger the closer your smart device is to the Miracast Video Adapter. Typical indoor operating

range for your Miracast Video Adapter is up to 50 feet if no obstructions are in the way. In the same way, your connection and

performance will degrade somewhat as the distance between your Miracast Video Adapter and connected device increases. This

may or may not be noticeable to you. As you move farther from your Miracast Video Adapter, performance may decrease. Factors that

can weaken signals simply by getting in the way of your Adapter’s radio waves are metal appliances or obstructions, and walls.

If you have concerns about your Miracast Video Adapter’s performance that might be related to range or obstruction factors,

try moving the connected device to a position between 5 and 10 feet from the Miracast Video Adapter in order to see if

distance is the problem. If difficulties persist, even at close range, please contact Belkin Technical Support.

Note: While some of the items listed below can affect network performance, they will not prohibit your wireless network from

functioning; if you are concerned that your network is not operating at its maximum effectiveness, this checklist may help.

INTRODUCTION

1. Placement of your Wireless Router (or Access Point)

Your wireless router may cause interference with the Miracast

Video Adapter, especially if it is a dual-band router.

For optimal performance of the Miracast Adapter, if possible,

try to place it away from your home Wi-Fi® network.

To achieve the best connection for your smart

devices with the Miracast Adapter:

• Your router transmits radio waves that may interfere with

the performance of the Miracast Video Adapter. If possible,

ensure that your Miracast Video Adapter is located on

or close to the outskirts of your Wi-Fi network.

• Try not to place the Miracast Video Adapter (or

smart device) near a cordless 2.4GHz phone.

• Disconnecting your smart device from your Wi-Fi network

can also improve the video performance where possible.

2. Cordless Phone Placement

If the performance of your Miracast Video Adapter is impaired after

attending to the above issues, and you have a cordless phone:

• Try moving cordless phones away from the

Miracast Video Adapter (or smart device).

• Unplug and remove the battery from any cordless phone that

operates on the 2.4GHz band (check manufacturer’s information).

If this fixes the problem, your phone may be interfering.

• If necessary, consider switching to a 900MHz cordless phone.

Product Features

The Adapter complies with the Wi-Fi Miracast specification

to communicate with other Wi-Fi Miracast wireless

devices. The Adapter can operate on the 2.4GHz or

5GHz frequency band as 802.11n Wi-Fi products.

• 2.4GHz or 5GHz band operation

• Micro USB 2.0 port to power the Miracast Video Adapter

• WPS™ button for pairing with your smart device

• HDCP 1.0, 2.0 and 2.1

• Easy installation and use

• LED status indicator

OVERVIEW

Product Specifications

Host Interface: HDMI®

Operating Temperature: 32–131 degrees F (0–40 degrees C)

Storage Temperature: -4–149 degrees F (-20–65 degrees C)

Humidity: Max. 85% (non-condensing)

Maximum Operating Range: Up to 50 ft.*

*Wireless performance may vary depending

on the networking environment.

(a) Power/Status LED

Lights when the Adapter is powered on and flashes when it is active.

(b) Multipurpose Button

Used for Wi-Fi Protected Setup™ handshaking with smart devices.

Used to supply power to the Miracast Video Adapter.

(d) HDMI Connector

Part of the Adapter that fits into your TV’s HDMI port.

(a)

(b)

(d)

(c)

OVERVIEW

LED Behavior What’s on the TV Screen Indicates

Blinking Green Loading screen Adapter is starting up

Steady Green Instructions to pair device Ready to pair with a smart device

Blinking Green with pause after 2nd blink Instructions to press button Waiting for user to press Multipurpose

button

Blinking Green with pause after 5th blink “Connection in progress” message Attempting to pair with smart device

Steady Green Smart device is being mirrored onto the TV Adapter and smart device have

paired successfully

Status LED Behavior

The LED on the Miracast Video Adapter gives you the status on the current state of the Adapter.

Please consult the table below for a guide to what the different LED behaviors indicate:

OVERVIEW

Multipurpose Button

The only button on the Miracast Video Adapter can be used for a variety of purposes. Please consult the table below for each application:

Adapter State Action Duration of Action Result

Adapter is unpowered

(then powered on) Press and hold button Until Firmware Update

page appears

Access to Advanced

Web Interface

Adapter is asking user to press

button during pairing Press button 0–5 seconds Adapter will attempt to pair with

smart device

Adapter is on its home screen Press and hold button 10+ seconds Restore factory defaults and

restart Adapter

OVERVIEW

System Requirements:

• TV with available HDMI port

USB power available (5V 500mA)

• Device with Miracast, Allshare Cast, Screen

Mirroring, or Android Wireless Display support

• HDMI-CEC compatible TV required to

interact with the User Interface

Package Contents:

Miracast Video Adapter

USB Power Cable

HDMI Extension Cable

Quick Installation Guide
