Belden HIRSCHMANN SPIDER II 16TX EEC Manuel utilisateur

Installation SPIDER II 16TX

Release

12/2014

Technical Support

https://hirschmann-support.belden.eu.com

User Manual

Installation

Industrial Ethernet Rail Switch

SPIDER II 16TX EEC, SPIDER II 16TX/2DS-S EEC

SPIDER II 16TX EEC SPIDER II 16TX/2DS-S EEC

The naming of copyrighted trademarks in this manual, even when not specially indicated, should

not be taken to mean that these names may be considered as free in the sense of the trademark

and tradename protection law and hence that they may be freely used by anyone.

translation, conversion into any electronic medium or machine scannable form is not permitted,

either in whole or in part. An exception is the preparation of a backup copy of the software for

your own use. For devices with embedded software, the end-user license agreement on the

enclosed CD/DVD applies.

The performance features described here are binding only if they have been expressly agreed

when the contract was made. This document was produced by Hirschmann Automation and

Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right

to change the contents of this document without prior notice. Hirschmann can give no guarantee

in respect of the correctness or accuracy of the information in this document.

Hirschmann can accept no responsibility for damages, resulting from the use of the network

components or the associated operating software. In addition, we refer to the conditions of use

specified in the license contract.

You can get the latest version of this manual on the Internet at the Hirschmann product site

(www.hirschmann.com).

Hirschmann Automation and Control GmbH

Stuttgarter Str. 45-51

72654 Neckartenzlingen

Germany

Tel.: +49 1805 141538

InstallationSPIDER II 16TX

Installation SPIDER II 16TX

Release

12/2014 3

Contents

Safety instructions 5

About this Manual 10

Legend 10

1 Description 11

1.1 General device description 11

1.2 Description of the device variants 11

1.3 Ethernet ports 12

1.3.1 10/100 Mbit/s twisted pair port 12

1.3.2 100/1000 Mbit/s F/O port (optional) 13

1.4 Display elements 14

2 Installation 15

2.1 Checking the package contents 15

2.2 Installing and grounding the device 15

2.2.1 Installing the device onto the DIN rail 15

2.2.2 Grounding the device 16

2.3 Wiring the terminal block for the supply voltage and the

grounding 17

2.4 Operating the device 18

2.5 Connecting data cables 18

2.6 Installing an SFP transceiver (optional) 19

2.7 Removing the SFP transceivers 19

3 Maintenance and service 20

4 Disassembly 21

4.1 Removing the device from the DIN rail 21

5 Technical data 22

A Further Support 29

4Installation SPIDER II 16TX

Release

12/2014

Installation SPIDER II 16TX

Release

12/2014 5

Safety instructions

General safety instructions

You operate this device with electricity. Improper usage of the device

entails the risk of physical injury or significant property damage. The

proper and safe operation of this device depends on proper handling

during transportation, proper storage and installation, and careful opera-

tion and maintenance procedures.

Before connecting any cable, read this document, and the safety

instructions and warnings.

Operate the device with undamaged components exclusively.

The device is free of any service components. In case of a damaged

or malfunctioning the device, turn off the supply voltage and return the

device to Hirschmann for inspection.

Qualification requirements for personnel

Only allow qualified personnel to work on the device.

Qualified personnel have the following characteristics:

Qualified personnel are properly trained. Training as well as practical

knowledge and experience make up their qualifications. This is the

prerequisite for grounding and labeling circuits, devices, and systems

in accordance with current standards in safety technology.

Qualified personnel are aware of the dangers that exist in their work.

Qualified personnel are familiar with appropriate measures against

these hazards in order to reduce the risk for themselves and others.

Qualified personnel receive training on a regular basis.

Intended usage

Use the product only for the application cases described in the

Hirschmann product information, including this manual.

Operate the product only according to the technical specifications.

See “Technical data” on page 22.

Connect to the product only components suitable for the requirements

of the specific application case.

National and international safety regulations

Verify that the electrical installation meets local or nationally applicable

safety regulations.

6Installation SPIDER II 16TX

Release

12/2014

Supply voltage

The supply voltage is electrically isolated from the housing.

Ground the device before connecting any other cables.

Connect only a supply voltage that corresponds to the type plate of

your device.

Every time you connect the electrical conductors, make sure that the

following requirements are met:

The voltage supply conforms to overvoltage category I.

The power supply has an easily accessible disconnecting device

(e.g., a switch or a plug). This disconnecting device is clearly iden-

tified. So in the case of an emergency, it is clear which discon-

necting device belongs to which power supply cable.

The electrical wires are voltage-free.

Relevant for North America:

The power supply is Class 2 compliant.

The supply voltage inputs are designed for operation with safety

extra-low voltage. Connect only SELV circuits with voltage restric-

tions in line with IEC/EN 60950-1 to the supply voltage connec-

tions.

A fuse suitable for DC voltage is located in the plus conductor of the

power supply.

Regarding the properties of this fuse: See “General technical data”

on page 22.

The wire diameter of the power supply cable is at least 1 mm²

(North America: AWG16) on the supply voltage input.

The power supply cables used are permitted for the temperature

range required by the application case.

Relevant for North America: For use in Class 2 circuits

Use copper wire/conductors of class 1 60/75 °C or 75 °C or 90 °C

exclusively.

Installation site requirements

Verify that there is at least 4 in (10 cm) of space above and below the

device.

Verify that there is at least 0.8 in (2 cm) of space on the right and left

sides of the device.

Only install the device in “operating sites with restricted access” based

on EN 60950-1.

Installation SPIDER II 16TX

Release

12/2014 7

Housing

Only technicians authorized by the manufacturer are permitted to open

the housing.

Never insert pointed objects (narrow screwdrivers, wires, etc.) into the

device or into the connection terminals for electric conductors. Do not

touch the connection terminals.

Verify that the electrical installation meets locally or nationally appli-

cable safety regulations.

Keep the ventilation slits free to ensure good air circulation.

Install the device in the vertical position.

At ambient temperatures > 140 °F (60 °C):

The surfaces of the device housing may become hot. Avoid touching

the device while it is operating.

LED or laser components

Relevant for SPIDER II 16TX/2DS-S EEC:

LED or LASER components according to IEC 60825-1 (2007):

CLASS 1 LASER PRODUCT

CLASS 1 LED PRODUCT

Only use SFP transceiver which are limited to the laser class 1.

CE marking

The labeled devices comply with the regulations contained in the following

European directive(s):

2011/65/EU (RoHS)

Directive of the European Parliament and of the Council on the restriction

of the use of certain hazardous substances in electrical and electronic

equipment.

2004/108/EC (EMC)

Directive of the European Parliament and the council for standardizing the

regulations of member states with regard to electromagnetic compati-

bility.

In accordance with the above-named EU directive(s), the EU conformity

declaration will be at the disposal of the relevant authorities at the

following address:

Hirschmann Automation and Control GmbH

Stuttgarter Str. 45-51

72654 Neckartenzlingen

Germany

Tel.: +49 1805 141538

8Installation SPIDER II 16TX

Release

12/2014

The device can be used in the industrial sector.

Interference immunity: EN 61000-6-2

Emitted interference: EN 55022

Warning! This is a class A device. This device can cause interference in

living areas, and in this case the operator may be required to take appro-

priate measures.

Note: The assembly guidelines provided in these instructions must be

strictly adhered to in order to observe the EMC threshold values.

Relevant for Use in Hazardous Locations Class I Div. 2

Groups A, B ,C and D (according to the Standards

ANSI/ISA12.12.01-2013 / CSA C22.2 No.213-M1987)

These devices are open-type devices that are to be installed in an enclo-

sure with tool removable cover/door that is suitable for the environment..

This equipment is suitable for use in Class I, Division 2, Groups A, B, C,

and D or non-hazardous locations only.

WARNING - EXPLOSION HAZARD – Do not connect or disconnect

equipment unless power has been removed or the area is known to be

non-hazardous.

WARNING - EXPLOSION HAZARD – Substitution of any components

may impair suitability for Class I, Division 2.

Relevant for use in Ex Zone 2 according to ATEX 95

(European directive 94/9/EC)

Any unauthorized modifications to or use of this equipment outside its

specified mechanical, electrical, or other operating limits may cause

personal injury and/or property damage, including damage to the equip-

ment.

Any such unauthorized modifications: (1) constitute “misuse” and/or

“negligence” within the meaning of the product warranty, thereby

excluding warranty coverage for any resulting damage; and (2) invalidate

product certifications or listings.

Conditions of Safe Use

Equipment intended for use in potentially explosive atmosphere directive

94/9/EC.

Compliance with the essential health and safety requirements has been

assured by compliance with the following standards: EN 60079-0:2012,

EN 60079-15:2010.

This product should be installed by personnel trained in installation of

equipment in Hazardous Locations and meet the representative National

Electrical Code of the according country.

Installation only in Zone 2 for gas group IIC.

Installation SPIDER II 16TX

Release

12/2014 9

Subject devices are to be installed in an ATEX Certified IP54 (as defined

in EN 60079-0 and EN 60079-15) enclosure and accessible only by the

use of a tool.

Subject devices are for use in an area of not more than pollution degree

2 in accordance with IEC 60664-1.

Provision shall be made to prevent the rated voltage being exceeded by

the transient disturbances of more than 140 % of the peak rated voltage.

When end users are providing Optical SFP Communications modules,

these must be limited to Laser Class I only.

FCC note:

This device complies with part 15 of the FCC rules. Operation is subject

to the following two conditions: (1) this device may not cause harmful

interference; (2) this device must accept any interference received,

including interference that may cause undesired operation.

Appropriate testing has established that this device fulfills the require-

ments of a class A digital device in line with part 15 of the FCC regula-

tions.

These requirements are designed to provide sufficient protection against

interference when the device is being used in a business environment.

The device creates and uses high frequencies and can also radiate these

frequencies. If it is not installed and used in accordance with this oper-

ating manual, it can cause radio transmission interference. The use of this

device in a residential area can also cause interference, and in this case

the user is obliged to cover the costs of removing the interference.

Recycling note

After usage, this device must be disposed of properly as electronic waste,

in accordance with the current disposal regulations of your county, state,

and country.

10 Installation SPIDER II 16TX

Release

12/2014

About this Manual

The “Installation User Manual” document contains a device description,

safety instructions, a display description and other information that you

require to install the device before starting with the configuration of the

device.

Legend

The symbols used in this manual have the following meanings:

Listing

Work step

Subheading

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Belden Changer

Belden

Belden HIRSCHMANN IT MAMMUTHUS MTM8000 Series Manuel utilisateur

Belden

Belden HIRSCHMANN Octopus II Manuel utilisateur

Belden

Belden Hirschmann SPIDER II 8TX Manuel utilisateur

Belden

Belden HIRSCHMANN MACH4002-48+4G Manuel utilisateur

Belden

Belden ThinkLogical TLX12 Manuel utilisateur

Belden

Belden Hirschmann GREYHOUND GRS1042 Manuel utilisateur

Belden

Belden HIRSCHMANN PTN-CSM310-A Manuel utilisateur

Belden

Belden Hirschmann MACH4002 Series Manuel utilisateur

Belden

Belden HIRSCHMANN IT MAMMUTHUS MTS2948X-6Q-A Manuel utilisateur

Belden

Belden Hirschmann SPIDER-SL-20-01T1S29999SZ9HHHH Manuel utilisateur

Belden

Belden Hirschmann RS20 U Series Manuel utilisateur

Belden

Belden grass valley SIRIUS 800 Series Guide de l'utilisateur

Belden

Belden Hirschmann DRAGON MACH Series Manuel utilisateur

Belden

Belden HIRSCHMANN OCTOPUS OS20 Series Manuel utilisateur

Belden

Belden HIRSCHMANN Dragon PTN CSM310-A Manuel utilisateur

Belden

Belden HIRSCHMANN SPIDER II Manuel utilisateur

Belden

Belden Hirschmann IT MAMMUTHUS MTS26 Series Manuel utilisateur

Belden

Belden grass valley MASTERPIECE 12G-SDI Manuel utilisateur

Belden

Belden Hirschmann MACH102 Series Manuel utilisateur

Belden

Belden HIRSCHMANN EESX Series Guide de configuration rapide

Belden

Belden Hirschmann MACH104-PoEP Series Manuel utilisateur

Belden

Belden Hirschmann SPIDER-SL-20-08T1999999SY9HHHH Manuel utilisateur

Belden

Belden HIRSCHMANN OCTOPUS OS24 Series Manuel utilisateur

Belden

Belden Hirschmann SPIDER 8TX EEC Manuel

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
