Baumatic BW38BL Manuel utilisateur

BW38BL 38 Bottle

electronic wine

cabinet

USER MANUAL FOR YOUR BAUMATIC

BW38BL

38 Bottle electronic wine

cabinet

NOTE

This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance Please keep it

in a safe place so that it is easily available for future reference, for

you or any person not familiar with the operation of the appliance

GS 04/05/12

Contents

En ironmental note 4

Important safety information 5 – 6

Specifications of your wine cabinet 7 -10

Description of the appliance 8

Control panel 9

Description of the prod ct feat res 9-10

Using your Baumatic wine cabinet 11-15

Before switching on 11

D ring first se 11

Switching on the appliance and setting the temperat re 12

Changing between Fahrenheit and Celsi s 12

Interior light 12

The safety lock 13

Loading the wine cabinet 13

Storing yo r wines 13-14

Wine storage problems 15

Cleaning and maintenance 16-18

Defrosting 17

Reversing the door 17-18

Installation 19-20

Electrical connection 19-20

Positioning 20

Troubleshooting 21-22

Baumatic consumables 23

Technical data 24

Contact details 25

En ironmental note

Note

: Before discarding an old appliance, switch off and

disconnect it from the power supply. Cut off and render any plug

useless. Cut the cable off directly behind the appliance to prevent

misuse. This should be undertaken by a competent person. Disable

the door lock to make sure that children cannot get stuck inside

the appliance.

oThe packaging materials that Ba matic ses are environmentally

friendly and can be recycled.

oPlease discard all packaging material with d e regard for the

environment.

Important safety information

Yo r safety is of the tmost importance to Ba matic.

Please make s re that yo read this instr ction booklet

before attempting to install or se the appliance. If

yo are ns re of any of the information contained in

this booklet, please contact the Ba matic Advice Line.

IMPORTANT: Any installation work must be

carried out by a qualified electrician or

competent person

Use of the appliance

oYo r appliance is only designed to be sed in the

home. It is s itable for storing and chilling wine.

NO food st ffs m st be stored in the appliance. If it

is sed for any other p rpose or it is not sed

correctly, then Ba matic Ltd. will accept no liability

for any damage that is ca sed.

oAltering the specification of the appliance m st not be attempted

for reasons of safety.

Before using your appliance

oCheck the appliance for any signs of transport damage. If yo

notice any damage, then yo sho ld not connect yo r appliance

to yo r mains s pply and sho ld contact yo r retailer.

Refrigerant

oYo r appliance contains R600a refrigerant, which is a nat ral gas

that does not contain CFCs that can damage the environment.

However it is a flammable s bstance, therefore care sho ld be

taken:

D ring the transportation and installation of the

appliance, make s re that the refrigeration pipework

does not get damaged.

If it does become damaged then so rces of ignition

and open flames sho ld be avoided. Also the room

that the appliance is sit ated in sho ld be thoro ghly

ventilated.

oDo not place any objects on top of the appliance,

as this may damage the table top.

Child safety

oPackaging material sho ld be kept away from

children.

oChildren sho ld not be allowed to to ch the

controls or play with the appliance.

General safety

oDo not p ll on the power s pply cable to remove the pl g from

yo r mains s pply socket.

oDo not p ll o t or insert the pl g with wet hands.

oDo not attempt to se yo r appliance o tdoors or

any place where it is likely to come into contact

with the elements.

oBefore cleaning the appliance or performing

maintenance work, ens re that the appliance has been

disconnected from yo r mains s pply.

oNever allow the back coils of the appliance to come into contact

with the wall s rface.

oAlways ens re that the location where yo are installing yo r

appliance is free of stored items s ch as papers and other

flammable materials.

oNever block the ventilation openings of the appliance, either on

the inside or its exterior.

oIt is vital to keep yo r appliance well ventilated,

so that there is proper air flow between the

bottom of the nit and the plinth/kick plate

which it is sitting on.

oDo not place electrical devices inside of the appliance, s ch as

mixers or ice cream makers.

Ser ice

Yo sho ld not attempt to repair the appliance

yo rself, as this co ld ca se inj ry or a more serio s

malf nction. If yo req ire a service call then please

contact the Ba matic Service Department.

Specifications of your wine cabinet

oGross capacity: 120 litres

oNet capacity: 110 litres

oBottle capacity: 38 x 0.75 litre Bordea x wine bottles

oEnergy efficiency class: B

oNoise level: 39 dB

oElectronic control operation

oLED display

oCelsi s and Fahrenheit switch

oTempered door glass

oWater drainage

oAdj stable temperat re

oInterior light

o8 chrome shelves

oAdj stable feet

oReversible door

oBlack door frame

oBlack interior and exterior

oSmoked door glass

oDesigned to store wine at its optim m temperat re between +

7°C - 18°C

Dimensions of appliance

Height: 865 mm

Width: 490 mm

Depth: 500 mm

IMPORTANT: When you install your appliance it is important to bear

in mind its climatic rating.

In order to find o t the climatic rating of yo r appliance, yo sho ld

check the rating plate. The rating plate is located on the rear of the

appliance. The rating plate will indicate the ambient temperat re range

that yo r appliance will f nction correctly within.

It is also advisable to make a note of the model n mber and the serial

n mber of the appliance before installing it.

Model number ………………………………………………

Serial number ………………………………………………

Date of purchase ……………………………………………..

Description of the appliance

1) Control panel and LED display

2) Cabinet

3) Temperat re sensor

4) Adj stable feet

5) Chrome racks (x2)

6) Door seal

7) Waved chrome shelves (x6)

8) Door

9) Interior light

Please note that the above image shows the correct

config ration of the shelving inside of the wine cabinet.

Control panel

The control panel is located at the top of the appliance, behind the

glass door.

A) Temperat re increase b tton

B) Temperat re decrease b tton

C) Light ON/OFF b tton

D) LED display

E) Celsi s/Fahrenheit indicator neons

F) Power b tton

Description of the product features

1) Control panel

oThe control panel is located at the top of the appliance, behind

the glass door. This means it is easy to set the temperat re of

the appliance and see what temperat re the appliance is set to.

2) One cooling zone

oThere is one cooling zone inside of yo r wine cabinet.

oThe cooling zone has a temperat re control and temperat re

LED display.

oThe cooling zone can hold p to 38 x 0.75 litre Bordea x wine

bottles.

oIMPORTANT: The temperature of the appliance will be

warmer at the top of the cooling zone and cooler at the

bottom

oIf yo are trying to store a mixt re of wine types in the

appliance, we wo ld recommend that red wines are stored at the

top of the cooling zone, white wines in the middle of the cooling

zone and sparkling wines at the bottom of the cooling zone.

3) Interior light

oThe cooling zone has an interior light. The light can be switched

on and off by sing the light ON/OFF b tton (C).

4) The wine cabinet shel es

oAll of the f ll depth shelves have tabs that lock into both sides of

the cabinet.

oAny of the shelves can be removed, to accommodate larger

bottles of wine.

Remo ing a shelf

oRemove all of the bottles from the shelf that yo want to

remove.

oLift the shelf pwards and then gently p ll the shelf away from

the wine cabinet.

Replacing a shelf

oPlace the shelf back into a s pporting g ide slot and p sh it back

ntil the shelf tabs slide into place.

oIMPORTANT: You must not store any bottles on a shelf until the

tabs are fully engaged.

5) Wine racks

oThere are additional wine racks at the bottom of the wine

cabinet.

oThe wine racks are removable for cleaning p rposes.
