Baumatic BW18BL Manuel utilisateur

BW18BL 18 Bottle wine cooler

BW28BL 28 Bottle wine cooler

USER MANUAL FOR YOUR BAUMATIC

BW18BL 18 Bottle wine cooler

BW28BL 28 Bottle wine cooler

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference, for

you or any person not familiar with the operation of the appliance.

DD 06/07/09

Contents

Environmentalnote 4

Important safety information 5 – 6

Specifications of your wine cooler 7-10

BW18BL 7

BW28BL 8

Descriptionoftheappliance 9

Description of the product features 10

Using your Baumatic wine cooler 11-13

Beforeswitchingon 11

Duringfirstuse 11

Setting the temperature 12

Interiorlight 13

Loading the wine cooler 13

Removingashelf 13

Replacingashelf 13

Storingyourwines 14-15

Winestorageproblems 16

Cleaning and maintenance 17

Defrosting 18

Installation 18-20

Electricalconnection 19

Positioning 20

Troubleshooting 21-22

Contactdetails 23

Environmental note

Note: Before discarding an old appliance, switch off and

disconnect it from the power supply. Cut off and render any plug

useless. Cut the cable off directly behind the appliance to prevent

misuse. This should be undertaken by a competent person. Disable

the door lock to make sure that children cannot get stuck inside

the appliance.

oThe packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

oPlease discard all packaging material with due regard for the

environment.

Important safety information

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If

you are unsure of any of the information contained in

this booklet, please contact the Baumatic Advice Line.

IMPORTANT: Any installation work must be

carried out by a qualified electrician or

competent person.

Use of the appliance

oYour appliance is only designed to be used in the

home. It is suitable for storing and chilling wine.

NO food stuffs must be stored in the appliance. If it

is used for any other purpose or it is not used

correctly, then Baumatic Ltd. will accept no liability

for any damage that is caused.

oAltering the specification of the appliance must not be attempted

for reasons of safety.

oDo not place any objects on top of the appliance, as

this may damage the table top.

Before using your appliance

oCheck the appliance for any signs of transport damage. If you

notice any damage, then you should not connect your appliance

to your mains supply and should contact your retailer.

Child safety

oPackaging material should be kept away from

children.

oChildren should not be allowed to touch the

controls or play with the appliance.

General safety

oDo not pull on the power supply cable to remove the plug from

your mains supply socket.

oDo not pull out or insert the plug with wet hands.

oDo not attempt to use your appliance outdoors or

any place where it is likely to come into contact

with the elements.

oBefore cleaning the appliance or performing

maintenance work, ensure that the appliance has been

disconnected from your mains supply.

oAlways ensure that the location where you are installing your

appliance is free of stored items such as papers and other

flammable materials.

oNever block the ventilation openings of the appliance, either on

the inside or its exterior.

oIt is vital to keep your appliance well ventilated,

so that there is proper air flow between the

bottom of the unit and the plinth/kick plate

which it is sitting on.

oDo not place electrical devices inside of the appliance, such as

mixers or ice cream makers.

Service

You should not attempt to repair the appliance

yourself, as this could cause injury or a more serious

malfunction. If you require a service call then please

contact the Baumatic Customer Care Department.

Specifications of your wine cooler

BW18BL

oGross capacity: 60 litres

oNet capacity: 48 litres

oBottle capacity: 18 x 1 litre wine bottles

oFan assisted operation

oAbsorption 'Peltier' system

oQuiet operation

oNo compressor (vibration free)

o5 waved chrome shelves

oAdjustable temperature

oInternal light

oTempered door glass

oDesigned to store wine at its optimum temperature between

10°C - 18 ºC

oAdjustable feet

oSmoked door glass

oBlack door frame

oBlack interior and exterior

Optional extra: BW18KIT- Wooden wine rack kit.

Dimensions of appliance*

Height: 645 mm

Width: 355 mm

Depth: 500 mm

* Please refer to the installation instructions for more specific

information on the size of aperture that you will require.

BW28BL

oGross capacity: 78 litres

oNet capacity: 65 litres

oBottle capacity: 28 x 1 litre wine bottles

oFan assisted operation

oAbsorption 'Peltier' system

oQuiet operation

oNo compressor, vibration free

o6 wire shelves

oAdjustable temperature

oInternal light

oTempered door glass

oDesigned to store wine at its optimum temperature between 10 -

18 ºC

oAdjustable feet

oSmoked door glass

oBlack door frame

oBlack interior and exterior

Optional extra: BW24KIT Wooden Wine Rack Kit

Dimensions of appliance*

Height: 735 mm

Width: 460 mm

Depth: 540 mm

* Please refer to the installation instructions for more specific

information on the size of aperture that you will require.

IMPORTANT: When you install your appliance it is important to bear

in mind its climatic rating.

In order to find out the climatic rating of your appliance, you should

check the rating plate. The rating plate is located inside the appliance,

on the top left front corner. The rating plate will indicate the ambient

temperature range that your appliance will function correctly within.

It is also advisable to make a note of the model number and the serial

number of the appliance before installing it.

Model number ………………………………………………

Serial number ………………………………………………

Date of purchase ……………………………………………..

Description of the appliance (BW18BL)

1) Temperature control dial

2) Light ON/OFF switch

3) Adjustable shelves (x 5)

4) Adjustable feet (x 4)

5) Hinge cover

6) Door seal

7) Door glass

8) Door

Description of the appliance (BW28BL)

1) Temperature control dial

2) Light ON/OFF switch

3) Adjustable shelves (x 6)

4) Adjustable feet (x 4)

5) Hinge cover

6) Door seal

7) Door glass

8) Door

Description of the product features

1) Temperature control dial

oThe temperature control dial is located at the top right hand

corner of the appliance, behind the glass door. It should be

turned to set the temperature that the wine cooler is chilling at.

oOn the BW18BL, the temperature control dial is located at the

front of the wine cooler, in the top right hand corner.

oOn the BW28BL, the temperature control dial is located at the

rear of the wine cooler, in the top right hand corner.

2) One cooling zone

oThere is one cooling zone inside of your wine cooler.

oThe cooling zone can hold up to 18 x 1 litre wine bottles

(BW18BL).

oThe cooling zone can hold up to 28 x 1 litre wine bottles

(BW28BL).

oIMPORTANT: The temperature of the appliance will be warmer

at the top of the cooling zone and cooler at the bottom.

oIf you are trying to store a mixture of wine types in the

appliance, we would recommend that red wines are stored at the

top of the cooling zone, white wines in the middle of the cooling

zone and sparkling wines at the bottom of the cooling zone.

3) Interior light

oThe cooling zone has an interior light. The light can be switched

on and off by using the light ON/OFF switch (2).

4) The wine cooler shelves

oAny of the shelves can be removed, to accommodate larger

bottles of wine.
