AA-14FBS Full User Manual

Device description

wiki.bas-ip.com

ENTRANCE PANEL

Main features

• Panel type: Multi-apartment.

• Display: 10’’ IPS, color with backlight and heated.

• Display angle: 176° (horizontal) / 178° (vertical).

• Keyboard: Touch screen.

• Camera: 1/3”.

• Resolution: 2 Мp.

• Сamera angle: 110° (horizontal).

• Output video: Full HD (1920 × 1080), H.264 Main Proﬁle.

• Night backlight: 6 LEDs.

• Light sensitivity: 0,01 LuX.

• Protection class: IP65.

• IK-Code: IK06.

• Working temperature: -40 — +65 °С.

• Power consumption: 6,5 W, in standby — 3,6 W.

• Power supply: +12 V DC.

• Body: Aluminum.

• Colors: Silver, Gold, Black.

• Dimensions for installation: 172 × 373 × 58 mm.

• Size of the panel: 185 × 400 × 45 mm.

• Installation: Flush, surface with BR-AA14 bracket.

Appearance

Multi-apartment entrance panel with 10" IPS screen with backlight and heated,

with face recognition and support for mobile access BAS-IP UKEY.

The panel has a unique feature – face recognition. This identifying technology

is integrated into the BAS-IP panels and uses the camera of the outdoor panel

and infrared sensors for its operation.

10’’ Display.

Reader.

Microphone.

Backlight.

Camera.

Loudspeaker.

Completeness check of the product

Before installation of the outdoor panel, it is necessary to check that

it is complete and all components are available.

Outdoor panel kit includes:

Outdoor panel

Manual

Flush mount bracket

Set of wires with connectors for connection of power supply,

lock, and additional modules

Set of screws with a wrench

1 pc

After verifying the device's completeness, you can switch to the outdoor panel

connection.

For connection you will need:

Electrical connection

An Ethernet UTP CAT5 or higher cable connected to a PoE network switch

or regular switch/router.

Cable length recommendations

The maximum length of the UTP CAT5 cable segment should not exceed 100 meters,

according to the IEEE 802.3 standard.

Power supply at +12 V, 2 amps.

EAN: 5060514914670 (BLACK)

EAN: 5060514914687 (GOLD)

EAN: 5060514914694 (SILVER)

123

VBUS DM DP

Power

+12 V

Opening

lock time

adjustment

Exit

button

Less

N.C.

N.O.

GND

Contact

Fire alarm

input

Switching

contact type:

normally open

or normally closed

1. +12V

2. Ground

3. Lock

4. COM

5. N.C./N.O.

6. Unused

Output to connect

electromechanical lock

LAN

SYS Interface Supply / Relay Outputs

Wiegand output

123

+5V D0

GND D1

RS485 / Exit / Door / Fire

123

485+

GND

Connection scheme of electromagnetic

lock using third-party power supply

for the lock

+12V

Electromagnetic Lock -+

GND

123

+12V NC

GND COM

5 6 7 8

+12V 485- Exit DS1 FIN DS2

SH-42

(optional)

+12V

GND

GND S

SH-45

Exit Button

Door Sensor Fire Equipment Additional

button

or sensor

123

VBUS DM DP

Power

+12 V

Opening

lock time

adjustment

Exit

button

Less

N.C.

N.O.

GND

Contact

Fire alarm

input

Switching

contact type:

normally open

or normally closed

1. +12V

2. Ground

3. Lock

4. COM

5. N.C./N.O.

6. Unused

Output to connect

electromechanical lock

LAN

SYS Interface Supply / Relay Outputs

Wiegand output

123

+5V D0

GND D1

RS485 / Exit / Door / Fire

123

485+

GND

Connection scheme of electromechanical

lock using third party power supply

for the lock

+12V

Electromechanical lock

GND

123

+12V NC

GND COM

5 6 7 8

+12V 485- Exit DS1 FIN DS2

SH-42

(optional)

+12V

GND

GND S

SH-45

Exit Button

Door Sensor Fire Equipment Additional

button

or sensor

Flush mounting using complete brachet

Check the availability of all components required for installation,

connection and fastening.

fastening

screws

fastening

anchor

dowels

ﬂush

mount

bracket

panel

fastening

bolts

connection

cords

185 mm

400 mm

45 mm 172 mm

373 mm

58 mm

Measure the bracket dimensions required for carving out a niche

for further bracket mounting.

On the wall, draw a rectangle

according to the dimensions

done in the previous step.

3Make a niche in the wall by

hollowing the wall or any other

appropriate way.

174 mm

375 mm

1090-1300 mm

EAN: 5060514914670 (BLACK)

EAN: 5060514914687 (GOLD)

EAN: 5060514914694 (SILVER)

Place ﬂush mount bracket in the

niche and outline places for

anchor dowels mount opposite

the holes in the bracket.

Attention: the hole at the bottom is designed to drain the water.

Do not intentionally close it. Also it is necessary to make a drain for water

at the bottom of the niche which will serve to divert water out.

Remove the bracket and make

holes in the outlined places with

a perforator.

7Hammer the anchor dowels into

the resulting holes.

Place the ﬂush mount bracket

in the hollowed-out niche and

fasten it with screws through

the mounting holes.

Wire all the necessary cables

for panel connection and

switching (for Ethernet, an exit

button, a lock, panel power,

a door sensor, a ﬁre alarm,

RS485, and Wiegand interfaces)

into the niche.

Cut out a rectangle of 80x40 mm

from foamed polyurethane or

rubber and make holes opposite

the required outgoing connectors

on the back side of the panel.

80 mm

40 mm

Pass all the protruding from the

wall wires through the made

earlier holes in the insulating

rectangle.

EAN: 5060514914670 (BLACK)

EAN: 5060514914687 (GOLD)

EAN: 5060514914694 (SILVER)

Apply a thin layer of silicone

sealant along the perimeter

of the niche with the connectors

оn the panel rear side and place

the protective rectangle in a niche

(where all connectors are)

on the panel rear side.

Silicon

sealant

Apply a 3-4 mm layer of silicone

sealant around the niche with

the placed insulating rectangle,

so that the sealant falls precisely

on the joint of the rectangle

and the back plastic cover

of the panel.

Silicon

sealant

Switch and connect the

protruding from the wall

and passing through the

insulating rectangle wires to the

necessary connection cords from

the panel kit.

13Join all the resulting connectors

at the ends of the wires to their

corresponding response parts

on the panel rear side.

Tape

Put all connected to the panel

wires on the bottom of the ﬂush

mount bracket.

All the protruding from the wall

and connected to the panel wires

must be carefully bent in

a semicircle in so that the upper

part of the wiring bundle is higher

than the hole for inserting cables

from the wall into the inside

of the bracket.

Apply a 3-4 mm layer of silicone

sealant around all wires coming

out of the slots in the insulating

rectangle.

The sealant must be applied

to the top of the joint between

the wire and the insulating

rectangle.

Silicon

sealant

EAN: 5060514914670 (BLACK)

EAN: 5060514914687 (GOLD)

EAN: 5060514914694 (SILVER)

Install the entrance panel inside

the ﬂush mount bracket.

Important!

Hold the wiring bundle

on the bottom of the bracket

so that some wires do not fall

on the sharp edges and are not

pressed by the panel.

Fasten the entrance panel

to the bracket with the fastening

bolts from the kit.
