USER’S MANUAL

mini PRO

mini PRO-50 (50 x 0.001g)

mini PRO-100 (100 x 0.001g)

American Weigh Scales, Inc.

Portable Milligram Scale

American Weigh

mini PRO User’s Manual

Thank you for purchasing the mini PRO Portable Precision Balance.

With normal care and proper treatment, it will provide you with years of

reliable service. Please read all operating instructions carefully before

using the scale.

•Avoid any exposure to extreme heat or cold. Your scale will work

better when operating in normal room temperature. Always allow the

scale to acclimate to normal room temperature for at least an hour

before use.

•Give the scale sufcient warm up time before use. Usually 30 to 60

seconds to give the internal components time to stablize.

•Keep your scale in a clean environment. Dust, dirt, moisture, vibra-

tion, air currents, or a close proximity to other electronic equipment can

cause an adverse effect on the reliability and accuracy of your scale.

• Handle with care. Gently apply all items to be weighed onto the

weighing surface. Although this scale is designed to be quite durable,

avoid rough treatment as this may permanently damage the internal

sensor.

• Do not shake, drop, or otherwise shock the scale. This is a precision

instrument and must be handled with extreme care.

• Only operate the scale on a stable, vibration free surface.

• Always store in a dry place to avoid moisture accumulation on

internal components.

I. Parts Description

1. Bubble level- insures scale is level

2. Weighing Platform.

3. On/Off - Turns scale on or off

4. Fn- Adjust backlight and other set-

tings (explained in this manual)

5. LCD Display

6. Tare- Resets scale to zero

7. Units- Changes weighing units

8. Adjustable feet- help keep scale

level

9. Draft Shield- Keeps wind from

interfering with weighing

10. Weighing Tray

11. Calibration Weight

*Carrying case and AC adapter

included (not shown)

II. Operation

This scale operates using either 4 AAA batteries or an included

AC Adapter. Insure the scale is plugged into a wall outlet, or

has battery power before use. To operate, set the balance

on a at / stable surface away from interference from wind,

vibration, and radio waves. If needed, you may adjust the

scales feet to insure that the scale is level. Press the “On/Off”

key to begin weighing. Once the scale reads “0.000”, you may

place the item to be weighed onto the center of the platform.

III. Weighing Units

This scale can weigh in either grams, ounces, troy ounces,

pennyweights, grains, or carats. To change the active weighing

unit, press the “Units” key. The scale also remembers the last

unit used. Therefore, the next time the scale is turned on, it will

revert to the previously used weighing unit. You may change

weighing units in the middle of weighing as well.

IV. Tare Feature

Tare allows you to subtract the weight of a container (ie. the

included weighing tray) in order to obtain the weight of objects

in the container (net weight). To use the scales “Tare” button,

turn the scale on in normal weighing mode and wait for the

screen to show “0.000”. Place the container you wish to use

on the scale then press the “Tare” button. The weight of the

container is now subtracted and the scale should read 0.000

again. If you now remove the container, a negative value will

be shown. If you wish to clear the negative value, press “Tare”

again.

V. Backlight

This scale has a backlight with adjustable settings. To change

the backlight’s parameters, press the “Fn” key two times. The

scale will display F1, meaning the backlight will come on when

weight is on the scale. To cycle through the different modes,

press the “Unit” key. Press the “Tare” key to conrm your

selection.

F1: Backlight will come on when weight is on the scale.

F2: Backlight is always on.

F3: Backlight is always off.

VI. Auto-Off Feature

This scale has an Auto-Off feature that can help extend battery

life by turning the scale off when not in use for a set amount

of time (1-9 minutes). To change the Auto-Off timer, press the

“Menu” button three times. The scale will show the current

Auto-Off setting (OFF, 60, 120, 180, 240, 300, 360, 420, 480,

or 540)

Press the “Unit” button to cycle through until you nd the

desired timer duration (in seconds). Press “Tare” to conrm

your selection.

VII. Calibration

This scale is calibrated at the factory, but frequent use or

slight shock can sometimes affect the calibration. In such

cases you may need to recalibrate the scale. Typically, the

Standard Calibration method is sufcient for the average

user to recalibrate their scale. Advanced calibration is already

performed at the factory and should not be attempted unless

you have two calibration weights. Before starting calibration,

insure that the area you are working on is free of any drafts,

vibrations, and you are using a at level surface

• Standard Calibration (Span):

**MiniPRO-50 calibrates with a 20g or 50g weight.

**MiniPRO-100 calibrates with a 50g or 100g weight.

Press the “Menu” button one time, “SCALE” will be displayed

on the LCD; Press the “Tare” button to continue. The scale will

display the required calibration weight. You can press “Unit”

to change between the two available calibration weights (see

above). Press “Tare” to conrm. The value on the display will

ash. Place your calibration weight onto the weighing platform.

• Advanced Calibration (Linear):

You will need two weights to perform Advanced Calibration:

**MiniPRO-50 takes a 20g and a 50g weight.

**MiniPRO-100 takes a 50g and a 100g weight.

Press the “Menu” button one time, “SCALE” will be displayed

on the LCD; Press the “Units” button once to change to “LINE”

mode, then press “Tare” to conrm. The scale will display

the rst required weight. Press “Tare” again to conrm. The

value will ash on the display. Place the rst required weight

onto the weighing platform. In a few seconds, the display will

show the second required calibration weight. Add the second

weight to the platform. After a few more seconds, the weight

will be accepted and the scale will return to normal weighing.

Calibration is complete!

Model MiniPRO-50 MiniPRO-100

Capacity 50g / 1.7637oz / 1.6075ozt /

32.15dwt / 771.62gn / 250ct

100g / 3.5273oz / 3.2150ozt /

64.3dwt / 1543.25gn / 500ct

Resolution 0.001g / 0.0001oz / 0.0001ozt

/ 0.001dwt / 0.02gn / 0.005ct

0.002g / 0.0001oz / 0.0001ozt

/ 0.002dwt / 0.05gn / 0.01ct

Display 5 - Digit Backlit LCD

Calibration Weight

(not Included) 20g, 50g 50g, 100g

Platform Dimensions

(inches) 2.7” Diameter

Scale Dimensions

(inches) 5.2 x 3.7 x 2.3 ”

Power 4 x AAA Alkaline Batteries or

6V 100mA Adapter (included)

In a few seconds, the display will stop ashing, and return to

normal weighing. Calibration is complete!
