AWS MDI-20 Manuel utilisateur
MDI-20 (44lb x 0.1oz)
User Manual
Baby Scale
MDI-20
Copyright © 2011 American Weigh Scales, Inc.
All rights reserved. Rev. 1.0
MDI-20
Thank you for purchasing the American Weigh MDI-20
baby scale. Please read all operating instructions carefully before
use. Scales are precision measuring devices and should always
be handled with proper care. To ensure years of reliable service,
keep these simple tips in mind:
• Do not exceed the scale’s maximum capacity. Overloading
your scale can permanently damage it!
• Avoid exposure to extreme heat or cold. Scales perform
best at normal room temperature. If temperatures have
changed dramatically, calibration and adjustment may be
necessary.
• Allow your scale to warm up for 30-60 seconds before
performing calibration and adjustment(if available).
• Store your scale in a clean, dry location. Dust, dirt, and
moisture can accumulate on the weighing sensors and
electronics causing inaccuracy or malfunction.
• Avoid using your scale in close proximity to strong radio
wave emitting devices such as computers, cash registers,
and cordless phones.
• Alwaysweighonaatandlevelsurface,freefrom
vibrations and drafts. The corner of a room is usually the
most stable.
• Gently apply all items to be weighed. Do not drop items
onto the weighing platform.
• Avoid dropping your scale. The warranty does not cover
damage due to rough treatment or overload.
• Checkthebatteriesrstifyouarehavinganytrouble
with your scale. This simple step can remedy most scale
issues.
• Do not disassemble your scale. This product contains no
user serviceable parts.
UNIT SET
Max: 44lb
d: 0.1oz
MDI-20
TARE
I. Part List
1. Scale
2. AA Batteries (x4)
II. Key Description
III. Battery Installation
1. Beforeusingthescaleforthersttime,checkthebattery
compartment and remove any plastic insulation strips or
packaging that may be in place to prevent battery drainage
during shipping/storage.
2. If you are replacing the batteries, make sure the positive
and negative contacts are properly aligned.
SET Key
UNIT Key
ON/OFF
TARE Key
MDI-20
IV. Scale Operation
1. Placethescaleonaat,levelsurface.
2. Press the /TARE key to turn the scale on and weight for
the display to show “0.0”.
3. You may now place your baby onto the scale.
4. Whenyouarenishedweighing,holdthe /TARE key to
turn the scale off.
V. Zeroing The Scale
If you wish to zero out the weight of an item such as a blanket,
follow these steps:
1. Place the blanket on the center of the weighing platform.
2. Wait for the weight to stabilize then tap the /TARE key
briey.Thedisplaywillresettozero.
3. Now place the baby on the scale. Only the baby’s weight
will be displayed.
4. When the blanket and baby are removed, a negative
number will be displayed. Tap /TARE to reset the display
back to zero again.
VI. Changing the Unit of Measure
1. Press and hold the UNIT key for 3~4 seconds to change
the scale’s displayed unit of measure.
2. If the scale is turned off then back on, it will default to the
last unit used.
• MDI-20 Units: kg (Kilogram) lb:oz (Pound:Ounce)
VII. Memory Function
1. Place an item to be weighed on the scale platform.
2. Oncetheweighthasstabilized,thedisplaywillash,show
weight value until the /TARE key is pressed again.
3. Press the SET key to recall the last weight result.
4. Press the SET key repeatedly to continue cycling through
the past 9 weighing results.
5. The display will return to normal weighing mode after 3
seconds of inactivity.
VIII. Using The Built-In Measuring Tape
1. Locate and open the door on the left side of the scale.
2. Extend the measuring tape out to
the desired length.
3. Whennishedmeasuring,youcan
press the button on the underside
of the scale to retract the measuring
tape. To keep the tape from lashing
as you retract it, hold one end and
guide it back in slowly.
IX. Error Codes
1. Lo -Batteries are low. Replace the batteries.
2. O-ld - Maximum capacity exceeded. This scale cannot be
used to give measurements over 44lbs.
X. Specications
MDI-20
Max. Capacity 20kg / 44lb
Readability 0.005kg / 0.1oz
Min. Capacity 0.1kg / 3.5oz
Power 4 x AA
Dimensions 3.3 x 16.5 x 25.7”
Display Size 1.0 x 3.3”
Warranty 10 Year Limited Warranty
Bottom View
Push to Retract
Measuring Tape
MDI-20
American Weigh Scales, Inc.
Norcross, GA 30092, U.S.A
MadeinChinatoourexactspecicationsandqualitycontrol.
