Avalue Technology APC-1733 Manuel utilisateur

Part No. E2017A731A0R

APC-1733

17.3” PCAP EMX-APLP Apollo Lake N4200 / HDMI/ 2xDP/ 4x

USB 3.0/ 2 x LAN/ FANLESS Panel PC

Quick Reference Guide

1st Ed –28 June 2018

APC-1733

2 APC-1733 Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

Quick Reference Guide

APC-1733 Quick Reference Guide

Content

1. Getting Started ........................................................................................................4

1.1 Safety Precautions....................................................................................................4

1.2 Packing List...............................................................................................................4

1.3 System Specifications...............................................................................................5

1.4 System Overview......................................................................................................8

1.4.1 Front View................................................................................................................................ 8

1.4.2 Rear View................................................................................................................................ 9

1.5 System Dimensions ................................................................................................10

2. Hardware Configuration .......................................................................................11

APC-1733

4 APC-1733 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x APC-1733 17.3” PCAP EMX-APLP Apollo Lake N4200 / HDMI/

2xDP/ 4x USB 3.0/ 2 x LAN/ FANLESS Panel PC

1 x AC/DC adapter 12V/5A 90 Plug Type

1 x Power cord

Quick Reference Guide

APC-1733 Quick Reference Guide

1.3 System Specifications

Component

Mother Board

EMX-APLP

CPU

Intel® Apollo Lake N4200 Processor

CPU Cooler (Type)

Fanless Heatsink

Memory

2 x 204-pin DDR3L 1600 MHz SO-DIMM supports up to 16GB(MAX)

Power Supply

External power adapter

Adapter

AC/DC Adapter 100~240V 50~60Hz, 12V/5A

System Fan

Fanless

Speaker

2 x 8Ω/2W speaker (E175X201304R)

Camera

ACC-NBCAM-05R

2.0M CMOS,1600*1200,USB2.0,60*8*4.5mm

Wireless LAN

(Optional) M.2 Type A 2230 WiFi, ACC-M2-WIFIBT-03R

Operating System

Windows 10

Other Component

NFC: ACC-NFC-USB-03R

(Optional) E971XAP173302R, Handset module with 2D Barcode Scanner

ACC-BARCODE-004R, 2D Barcode scanner reader N3680SR-W1-USB

Storage

Other Storage Device

mSATA

Panel

LCD Panel

17.3 CHIMEI INNOLUX N173HGE-E11 FHD eDP Panel

Touch Screen

17.3” PCAP Touch

Touch Controller

EETI

External I/O

USB Port

4 x USB3.0

Video Port

1 x HDMI/DP, 1 x DP++

LAN Port

1 x RJ-45 Intel® i211AT Gigabit Ethernet

Wireless LAN Antenna

(Optional)

E199TN00012R x 1

E199TN00013R x 1

Expansion Slots

1 x full size Mini PCI-e support mSATA

Mechanical

Power Type

+12V ~ 24V ATX, ACC-ADP-060N-02R

Power Connector

Type

12V ~ 24VDC Input, Screw type

Dimension

445 (L) x 281 (H) x 45 (D) mm

APC-1733

6 APC-1733 Quick Reference Guide

Weight

4.7kg

Color

White

Fanless

Yes

Reliability

EMC

CE FCC Class A

Dust and Rain Test

IP-65 on Front Panel

Vibration Test

Random Vibration Operation

1 PSD: 0.00454G²/Hz, 1.5 Grms

2 Operation mode

3 Test Frequency : 5-500Hz

4 Test Axis : X,Y and Z axis

5 30 min. per each axis

6 IEC 60068-2-64 Test:Fh

Sine Vibration test (Non-operation)

1 Test Acceleration : 2G

2 Test frequency : 5~500 Hz

3 Sweep：1 Oct/ per one minute. (logarithmic)

4 Test Axis : X,Y and Z axis

5 Test time :30 min. each axis

6 System condition : Non-Operating mode

7. Reference IEC 60068-2-6 Testing procedures

Package vibration test

1. PSD: 0.026G²/Hz , 2.16 Grms

2. Non-operation mode

3. Test Frequency : 5-500Hz

4. Test Axis : X,Y and Z axis

5. 30 min. per each axis

6. IEC 60068-2-64 Test:Fh

Mechanical Shock

Test

Standard, With CF/SSD : 10Grms, IEC 60068-2-27, Half Sine, 11ms

Drop Test

1 One corner , three edges, six faces

2 ISTA 2A, IEC-60068-2-32 (96.5cm) Test:Ed

Operating

Temperature

Normal Temperature: 0°C ~ 35°C (32°F ~ 95°F)

Operating Humidity

10% ~ 90% Relative Humidity, Non-condensing

Storage Temperature

Normal Temperature: -20°C ~ 60°C (14°F ~ 122°F)

Quick Reference Guide

APC-1733 Quick Reference Guide

Note: Specifications are subject to change without notice.

APC-1733

8 APC-1733 Quick Reference Guide

1.4 System Overview

1.4.1 Front View

Power on/off

Brightness

Up/down

NFC

Notepad

Browser

Quick Reference Guide

APC-1733 Quick Reference Guide

1.4.2 Rear View

Connectors

Label

Function

Note

DC Jack

DC-in power connector

HDMI

HDMI connector

DP connector

DP++

DP++ connector

USB3.0

4 x USB 3.0 connector

LAN

RJ-45 Ethernet

APC-1733

10 APC-1733 Quick Reference Guide

1.5 System Dimensions

(Unit: mm)
