Avalue Technology BFC-1508 Manuel utilisateur

Part No. E2017B580A1R

BFC-1508

15” Multifunctional Full Flat

Multi-Touch Panel Computer

Quick Reference Guide

2nd Ed –01 August 2016

BFC-1508

2 BFC-1508 Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

Quick Reference Guide

BFC-1508 Quick Reference Guide

Content

1. Getting Started............................................................................................................4

1.1 Safety Precautions ................................................................................................4

1.2 Packing List...........................................................................................................4

1.3 System Specifications ...........................................................................................5

1.4 System Overview...................................................................................................7

1.4.1 Rear View..................................................................................................................................... 7

1.5 System Dimensions...............................................................................................8

1.5.1 Front, rear and side view ............................................................................................................. 8

2. Hardware Configuration.............................................................................................9

2.1 BFC-1508 connector mapping.............................................................................10

2.1.1 External Serial Port connector (COM) ....................................................................................... 10

2.2 Installing Hard Disk & Memory (BFC-1508).........................................................11

BFC-1508

4 BFC-1508 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x BFC-1508 15” Multifunctional Full Flat Multi-Touch Panel Computer

1 x DVD-ROM contains the followings:

—User’s Manual (this manual in PDF file)

—Ethernet driver and utilities

—VGA drivers and utilities

—Audio drivers and utilities

—Chipset drivers

Other major components include the followings:

—60W adapter and power cord

—4 x M3*4mm screw for HDD bracket

—4 x M4*6mm screw for VESA mount

Quick Reference Guide

BFC-1508 Quick Reference Guide

1.3 System Specifications

Panel

LCD Size

15", 4:3

Resolution

1024 x 768

Pixel Pitch

0.297mm (H) x 0.297mm (V)

Luminance

CMI G150XGE-L05 250 cd/m2

Contrast Ratio

700

Viewing Angle

70 (U), 70 (D), 80 (L), 80 (R)

Response Time

16ms

Backlight

LED

Touch Type

Projected Capacitive Touch

Light Transmission

88%

Touch Interface

USB (EETI)

System

Board

EBM-QM87U

CPU

Onboard Intel® 4th Generation Core i5 4300U

Processor (2 Die MCP, 15W)

BIOS

AMI uEFI BIOS, 64/128Mbit SPI Flash ROM

System Chipset

2 Die MCP; Integrated in Processor

I/O Chip

E/C IT8528E

System Memory

2 x 204-pin SODIMM Socket Supports Up to 16GB DDR3L

1333/1600 SDRAM

SSD

One CompactFlash Type I/II Socket

Hard Driver Bay

Optional One 2.5” HDD or SSD

WiFi

Optional Mini PCIe WiFi 802.11b/g/n

Watchdog Timer

Reset: 1sec. ~ 255min. and 1sec. or 1min./step

H/W Status Monitor

Monitoring System Temperature and Voltage with Auto Throttling

Control

Expansion

2 x Mini PCIe (One Supports mSATA, One Supports SIM Card Slot)

Rear Panel I/O

Serial Port

1 x RS-232/422/485 (Selected by BIOS; additional setting for

RS-485 mode by SW2)

Ethernet

2 x RJ-45

HDMI

1 x HDMI

Audio Port

Line-out

USB

2 x USB 3.0

Speaker

2 x 1W

BFC-1508

6 BFC-1508 Quick Reference Guide

Display

Chipset

2 Die MCP; Integrated in Processor

Resolution

LVDS Through eDP: 1920 x 1200 @ 60Hz

Dual Display

HDMI + LVDS (Clone Mode)

Audio

Audio Codec

Realtek ALC892 Supports 5.1-CH Audio

Audio Interface

Line-out (Audio Jack), AMP Line-in, Line-out, Mic-in (in Header)

Ethernet

LAN Chip

1 x Intel® I210 Gigabit Ethernet Controller,

1 x Intel® I218LM Gigabit Ethernet PHY

Ethernet Interface

10/100/1000 Base-Tx Gigabit Ethernet Compatible

Mechanical & Environment

Color

Front Bezel Silver & Rear Black

Mounting

Wall/Stand/VESA 75mm x 75mm/100mm x 100mm

Adapter

Input: 100 ~ 240Vac/50 ~ 60Hz Output: 60W Adapter (12V @ 5A

Adapter)

Power Requirement

+12V ~ +26V

Power Type

AT/ATX

Operating Temperature

0 ~ 40°C (32 ~ 104°F)

Storage Temperature

-10 ~ 50°C (14 ~ 122°F)

Operating Humidity

5% ~ 90% Relative Humidity, Non-condensing

Dimensions (W x D x H)

350 x 273.9 x 53 mm

Weight

4.5kg

Note: Specifications are subject to change without notice.

Quick Reference Guide

BFC-1508 Quick Reference Guide

1.4 System Overview

1.4.1 Rear View

Connectors

Label

Function

Note

COM

External Serial Port connector

DB-9 male connector

HDMI

HDMI connector

LAN1/2

RJ-45 Ethernet 1/2

Power

System power switch

USB

USB 3.0 connector x 2

BFC-1508

8 BFC-1508 Quick Reference Guide

1.5 System Dimensions

1.5.1 Front, rear and side view

(Unit: mm)

Quick Reference Guide

BFC-1508 Quick Reference Guide

2.Hardware

Configuration

For advanced information, please refer to:

1- EBM-QM87U Quick Installation Guide or User’s Manual

Note: If you need more information, please visit our website:

http://www.avalue.com.tw

BFC-1508

10 BFC-1508 Quick Reference Guide

2.1 BFC-1508 connector mapping

2.1.1 External Serial Port connector (COM)

Note:

RS-232/422/485 can be selected by BIOS, but additional

setting for RS-485 mode by SW2.

RS-232 Mode

Signal

NRXDA

NDCDA#

NDTRA#

NTXDA

NDSRA#

GND

NCTSA#

NRTSA#

NRIA#

RS-422 Mode

Signal

485TXP

485TXN

485RXN

485RXP

GND

RS-485 Mode

Signal

485TXP

485TXN

GND
