Asus AGP-V3100 Manuel utilisateur

AGP-V3100 Series

3D Multimedia Accelerator

USER’S MANUAL

Hardware & Video Drivers

AGP-V3100T

AGP-V3100TV

ASUS AGP-V3100 Series User’s Manual

USER’S NOTICE

Product Name: ASUS AGP-V3100 Series

Manual Revision: 1.00 E287

Release Date: October 1998

No part of this manual, including the products and software described in it, may be repro-

duced, transmitted, transcribed, stored in a retrieval system, or translated into any language

in any form or by any means, except documentation kept by the purchaser for backup pur-

poses, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND,

EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOTLIMITED TO THE IMPLIED

WARRANTIES OR CONDITIONS OF MERCHANTABILITYOR FITNESS FORAPAR-

TICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,

EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDEN-

TAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF

PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSI-

NESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY

OF SUCH DAMAGESARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL

OR PRODUCT.

Product warranty or service will not be extended if: (1) the product is repaired, modified or

altered, unless such repair, modification of alteration is authorized in writing by ASUS; or

(2) the serial number of the product is defaced or missing.

Products and corporate names appearing in this manual may or may not be registered trade-

marks or copyrights of their respective companies, and are used only for identification or

explanation and to the owners’ benefit, without intent to infringe.

• IBM and OS/2 are registered trademarks of International Business Machines.

• S3 and Savage3D are trademarks of S3 Incorporated.

• Windows and MS-DOS are registered trademarks of Microsoft Corporation.

• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.

The product name and revision number are both printed on the product itself. Manual revi-

sions are released for each product design represented by the digit before and after the period

of the manual revision number. Manual updates are represented by the third digit in the

manual revision number.

For previous or updated manuals, BIOS, drivers, or product release information, contactASUS

at http://www.asus.com.tw or through any of the means indicated on the following page.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUALARE FUR-

NISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT

ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COM-

MITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR

ANYERRORSORINACCURACIESTHAT MAYAPPEARINTHIS MANUAL, INCLUD-

ING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

ASUS AGP-V3100 Series User’s Manual 3

ASUS CONTACT INFORMATION

ASUSTeK COMPUTER INC.

Marketing

Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112

Telephone: +886-2-2894-3447

Fax: +886-2-2894-3449

Email: [email protected]

Technical Support

Fax: +886-2-2895-9254

BBS: +886-2-2896-4667

Email: [email protected]

WWW: www.asus.com.tw

FTP: ftp.asus.com.tw/pub/ASUS

ASUS COMPUTER INTERNATIONAL

Marketing

Address: 6737 Mowry Ave, Mowry Business Center, Building 2,

Newark, CA 94560, USA

Fax: +1-510-608-4555

Email: [email protected]

Technical Support

Fax: +1-510-608-4555

BBS: +1-510-739-3774

Email: [email protected]

WWW: www.asus.com

FTP: ftp.asus.com.tw/pub/ASUS

ASUS COMPUTER GmbH

Marketing

Address: Harkort Str. 25, 40880 Ratingen, BRD, Germany

Telephone: 49-2102-445011

Fax: 49-2102-442066

Email: [email protected]

Technical Support

Hotline: 49-2102-499712

BBS: 49-2102-448690

Email: [email protected]

WWW: www.asuscom.de

FTP: ftp.asuscom.de/pub/ASUSCOM

ASUS AGP-V3100 Series User’s Manual

(This page was intentionally left blank)

ASUS AGP-V3100 Series User’s Manual 5

CONTENTS

I. Introduction......................................................................................7

Item Checklist ..................................................................................7

Features ............................................................................................7

ASUS AGP-V3100 Series ...............................................................8

II. Hardware Installation ....................................................................9

AGP-V3100 Series Connection Examples ......................................9

Installation Procedures .............................................................10

New Systems ......................................................................10

Systems with Existing VGACard ......................................10

III. Windows 95/98 ............................................................................11

Operating System Requirements ...................................................11

Windows 95 OSR2.0 ................................................................11

Windows 98..............................................................................11

Installation Procedures...................................................................12

Install All Drivers and Utilities ......................................................12

Install VGARTD ............................................................................13

Install DirectX 6.............................................................................14

Install AGP-V3100 Display Driver................................................15

Install Video Player........................................................................16

Using Video Player...................................................................16

Change Resolution and Color ........................................................17

TV Setting ................................................................................17

Advance Setting..................................................................17

Refresh Rate .............................................................................18

To Adjust the Refresh Rates ...............................................18

Remove Display Driver .................................................................19

Using the Autorun Screen ........................................................19

Using Control Panel .................................................................19

IV. Windows NT 4.0...........................................................................20

Install NT4.0 Display Driver .........................................................20

Remove NT4.0 Display Driver ......................................................21

V. Display Information ......................................................................22

Resolution Table: 2D Video Modes ...............................................22

Resolution Table: Maximum 3D Video Modes .............................23

VI. Troubleshooting ...........................................................................24

Description.....................................................................................24

Recommended Action....................................................................24

ASUS AGP-V3100 Series User’s Manual

FCC & DOC COMPLIANCE

FederalCommunicationsCommission Statement

This device complies with FCC Rules Part 15. Operation is subject to the following

two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received, including interference that

may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installa-

tion. This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with manufacturer’s instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the inter-

ference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

WARNING! The use of shielded cables for connection of the monitor to the

graphics card is required to assure compliance with FCC regulations. Changes

or modifications to this unit not expressly approved by the party responsible for

compliance could void the user’s authority to operate this equipment.

CanadianDepartmentof CommunicationsStatement

This digital apparatus does not exceed the Class B limits for radio noise emissions

from digital apparatus set out in the Radio Interference Regulations of the Cana-

dian Department of Communications.

7ASUS AGP-V3100 Series User’s Manual

I. Introduction

Items/Features

Thank you for purchasing the ASUS AGP-V3100 Series Graphics & Video Accel-

erator. With S3 Inc.’s Savage3D

accelerator built in, the ASUS AGP-V3100 Se-

ries Graphics & Video Accelerator provides you with fast acceleration in both 2D/

3D graphics and high quality scalable video playback, which can fully support 3D

Gaming and Multimedia Applications.

Item Checklist

TheAGP-3100 Series graphics cards can only be installed in motherboards with an AGPslot.

Basic Model Advanced Model

ASUS AGP-V3100T ASUS AGP-V3100TV

This User’s Manual This User’s Manual

ASUS Driver & Utility CD ASUS Driver & Utility CD

(1) S-VHS Cable (2) S-VHS Cable

(1) Composite Cable (2) Composite Cable

Software DVD Player (optional) Software DVD Player (optional)

Features

• Built-in 128-bit Savage3D

Graphics Engine Accelerator

• 128-bit 2D, GUI, and DirectDraw Acceleration

• 8MB 125MHz SGRAM frame buffer

• X and Y up and down video scaling

• Software VCD Player (MPEG-1)

• Software DVD Player (MPEG-2) with motion compensation

• 250MHz Palette-DAC

• Built-in VIP Bus Connectors for TVTuner, Video Capture, MPEG-1, and MPEG-2

• Acceleration for Windows 95APIs, including Direct3D and DirectDraw (+VPE)

• User-friendly installation for Windows 95 and Windows 98

• Video-In (AGP-V3100TV only)

• Flicker-free TV-Out

• Video Capture Utility for Live Video/Still Image Capture (AGP-V3100TV only)

• Full AGP2X support (sideband addressing and AGP execute mode)

• High quality texture compression for 6 times the amount of texture storage and

AGP bandwidth

• Video Texture

ASUS AGP-V3100 Series User’s Manual8

ASUS AGP-V3100 Series

I. Introduction

Parts

8MB SGRAM

Onboard Memory

Savage3D

Graphics

Engine with

Heatsink

VIP-A

Connector

VIP-B

Connector

NOTE: Components enclosed in dotted boxes are available only in the AGP-

V3100TV models

Video-In

Controller

Video-In

TV-Out

VGA

Output

9ASUS AGP-V3100 Series User’s Manual

II. Hardware Installation

II. Installation

Connections

Composite

(RCA) Input

Video

Input

NOTES:

• ASUS Video cards come in either NTSC or PAL standards.

• You may not convert NTSC to PAL or vice versa.

• You must use the same standard for all devices.

VGA

Output

S-Video

Output

Composite

(RCA) Output

S-Video Plug

RCA Plug

S-Video or Tuner Box Plug

• Camcorder

• Video Cassette Recorder

• Television

• Other Video Displaying

or Recording Devices

15-Pin VGA Plug

• Camcorder

• Video Cassette Player

• Laser Disc Player

• Other Video Devices

With ASUS Tuner Box:

• TV / FM Tuner

• Computer Monitor

• Video Projector

• Other VGA

Compatible devices

CATV ASUS TV Box

AGP-V3100 Series Connection Examples

NOTE: Components enclosed in dotted boxes can only be used or are available

only in the AGP-V3100TV models

ASUS AGP-V3100 Series User’s Manual10

Installation Procedures

New Systems

1. Unplug all electrical cords on your computer.

2. Remove the system unit cover.

3. Locate the AGP bus expansion slot. Make sure this slot is unobstructed.

4. Remove the corresponding expansion slot cover from the computer chassis.

5. Ground yourself to an antistatic mat or other grounded source .

6. Pick up the board (still in its sleeve) by grasping the edge bracket with one hand

and then remove the plastic sleeve.

7. Position the card directly over the AGP slot and insert one end of the board in

the slot first. Firmly but gently press the bus connector on the bottom of the card

down into the slot. Be sure the metal contacts on the bottom of the host adapter

are securely seated in the slot.

8. Anchor the board’s mounting bracket to the computer chassis using the screw

from the slot cover that you set aside previously.

9. Replace the cover on the system unit.

10. Connect your analog monitor’s 15-pin VGAconnector to the card and fasten the

retaining screws (if any).

11. Connect other cables and devices if available -You are now ready to install the

software drivers and utilities.

Systems with Existing VGA Card

1. Change your display driver to Standard VGA.

2. Shut down your computer and unplug all electrical cords.

3. Replace the existingVGAcard with theASUSAGP-V3100 series graphics card.

4. Restart your computer.

5. Install the ASUS AGP-V3100 series display driver.

II. Hardware Installation

II. Installation

Procedures

NOTE:Your graphics card can only be installed in motherboards with anAGP slot.

WARNING!Computer boards and components contain very delicate Integrated

Circuit (IC) chips. To protect the computer board and other components against

damage from static electricity, you must follow some precautions.

1. Make sure that you unplug your power supply when adding or removing

expansion cards or other system components. Failure to do so may cause

severe damage to both your motherboard and expansion cards.

2. Keep all components such as the host adapter in its antistatic bag until you

are ready to install it.

3. Use a grounded wrist strap before handling computer components. If you do

not have one, touch both of your hands to a safely grounded object or to a

metal object, such as the power supply case. Hold components by the edges

and try not to touch the IC chips, leads, or circuitry.

4. Place components on agroundedantistaticpad or on the bag thatcamewiththe

component whenever the components are separated from the system.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Asus Matériel informatique

Asus

Asus AAEON UP Xtreme i12 Edge Manuel utilisateur

Asus

Asus USB 3.1 TYPE-C CARD Manuel utilisateur

Asus

Asus LSISAS RAID Card PIKE 1064E Manuel utilisateur

Asus

Asus M2N68-VM - Motherboard - Micro ATX Manuel utilisateur

Asus

Asus AAEON GENESYS-KBU6 Manuel utilisateur

Asus

Asus AAEON BOXER-8640AI Manuel utilisateur

Asus

Asus ROG STRIX LC RGB Series Manuel utilisateur

Asus

Asus AAEON BOXER-6652 Manuel utilisateur

Asus

Asus Aaeon BOXER-6641 Manuel utilisateur

Asus

Asus SpaceLink Manuel utilisateur

Asus

Asus HDAV1.3 - Xonar Slim Sound Card Manuel utilisateur

Asus

Asus ASMB6-IKVM Manuel utilisateur

Asus

Asus AAEON PER-T500 Manuel utilisateur

Asus

Asus LSISAS RAID Card PIKE 1064E Manuel utilisateur

Asus

Asus SpaceLink WL-100 Manuel utilisateur

Asus

Asus Triton 79 Manuel utilisateur

Asus

Asus Aaeon UPN Edge Pro Manuel utilisateur

Asus

Asus Q16328 Manuel utilisateur

Asus

Asus AGP-V2740 Manuel utilisateur

Asus

Asus Aaeon NanoCOM-EHL Manuel utilisateur

Asus

Asus LSISAS RAID Card PIKE 1064E Manuel utilisateur

Asus

Asus ThunderboltEX II Manuel utilisateur

Asus

Asus AAEON UP-AUDIO Manuel utilisateur

Asus

Asus PIKE 2008 IMR Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
