Asus AAEON BOXER-6406-ADN Manuel utilisateur

Last Updated: August 7, 2023

BOXER-6406-ADN

Fanless Embedded Box PC

User’s Manual 1st Ed

Preface II

Fanless Embedded Box PC BOXER-6406-ADN

This document is copyrighted, 2023. All rights are reserved. The original manufacturer

reserves the right to make improvements to the products described in this manual at

any time without notice.

No part of this manual may be reproduced, copied, translated, or transmitted in any

form or by any means without the prior written permission of the original manufacturer.

Information provided in this manual is intended to be accurate and reliable. However,

the original manufacturer assumes no responsibility for its use, or for any infringements

upon the rights of third parties that may result from its use.

The material in this document is for product information only and is subject to change

without notice. While reasonable efforts have been made in the preparation of this

document to assure its accuracy, AAEON assumes no liabilities resulting from errors or

omissions in this document, or from the use of the information contained herein.

AAEON reserves the right to make changes in the product design without notice to its

users.

Preface III

Fanless Embedded Box PC BOXER-6406-ADN

Acknowledgement

All other product name or trademarks are properties of their respective owners.

⚫Microsoft Windows®, Windows® 10, and Windows® 11 are registered

trademarks of Microsoft Corp.

⚫Intel® and Atom® are registered trademarks of Intel Corporation.

⚫Linux® is a registered trademark of Linus Torvalds in the U.S. and other

countries.

⚫Ubuntu and Canonical are registered trademarks of Canonical Ltd.

All other product names or trademarks are properties of their respective owners. The

publisher of this document does not assume nor imply ownership of any trademarked

product not listed herein.

Preface IV

Fanless Embedded Box PC BOXER-6406-ADN

Packing List

Before setting up your product, please make sure the following items have been

shipped:

Item

Quantity

⚫BOXER-6406-ADN

⚫Wallmount Bracket

⚫3 Pin DC-in Power Connector

⚫Screw Pack

If any of these items are missing or damaged, please contact your distributor or sales

representative immediately.

Preface V

Fanless Embedded Box PC BOXER-6406-ADN

About this Document

This User’s Manual contains all the essential information, such as detailed descriptions

and explanations on the product’s hardware and software features (if any), its

specifications, dimensions, jumper/connector settings/definitions, and driver

installation instructions (if any), to facilitate users in setting up their product.

Users may refer to the product page at AAEON.com for the latest version of this

document.

Preface VI

Fanless Embedded Box PC BOXER-6406-ADN

Safety Precautions

Please read the following safety instructions carefully. It is advised that you keep this

manual for future references

1. All cautions and warnings on the device should be noted.

2. Make sure the power source matches the power rating of the device.

3. Position the power cord so that people cannot step on it. Do not place anything

over the power cord.

4. Always completely disconnect the power before working on the system’s

hardware.

5. No connections should be made when the system is powered as a sudden rush

of power may damage sensitive electronic components.

6. If the device is not to be used for a long time, disconnect it from the power

supply to avoid damage by transient over-voltage.

7. Always disconnect this device from any power supply before cleaning.

8. While cleaning, use a damp cloth instead of liquid or spray detergents.

9. Make sure the device is installed near a power outlet and is easily accessible.

10. Keep this device away from humidity.

11. Place the device on a solid surface during installation to prevent falls.

12. Do not cover the openings on the device to ensure optimal heat dissipation.

13. Watch out for high temperatures when the system is running.

14. Do not touch the heat sink or heat spreader when the system is running

15. Never pour any liquid into the openings. This could cause fire or electric shock.

16. As most electronic components are sensitive to static electrical charge, be sure

to ground yourself to prevent static charge when installing the internal

components. Use a grounding wrist strap and contain all electronic components

in any static-shielded containers.

Preface VII

Fanless Embedded Box PC BOXER-6406-ADN

17. If any of the following situations arises, please the contact our service personnel:

i. Damaged power cord or plug

ii. Liquid intrusion to the device

iii. Exposure to moisture

iv. Device is not working as expected or in a manner as described in

this manual

v. The device is dropped or damaged

vi. Any obvious signs of damage displayed on the device

18. Do not leave this device in an uncontrolled environment with temperatures

beyond the device’s permitted storage temperatures (see chapter 1) to prevent

damage.

19. Do NOT disassemble the motherboard so as not to damage the system or void

your warranty.

20. If the thermal pad had been damaged, please contact AAEON's salesperson to

purchase a new one. Do NOT use those of other brands.

21. The Hex Cylinder Coppers on the front panel are not removable.

22. Repeatedly assemble and disassemble the system may cause damages to the

exterior paint and surface and screw holes.

23. Use the right size screwdriver.

24. Use the screwdriver correctly to remove screws from the system.

Preface VIII

Fanless Embedded Box PC BOXER-6406-ADN

FCC Statement

This device complies with Part 15 FCC Rules. Operation is

subject to the following two conditions: (1) this device may not

cause harmful interference, and (2) this device must accept

any interference received including interference that may

cause undesired operation.

Caution:

There is a danger of explosion if the battery is incorrectly replaced. Replace only with the

same or equivalent type recommended by the manufacturer. Dispose of used batteries

according to the manufacturer’s instructions and your local government’s recycling or

disposal directives.

Attention:

Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.

Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le

constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et

les directives gouvernementales de recyclage.

Preface IX

Fanless Embedded Box PC BOXER-6406-ADN

China RoHS Requirements (CN)

产品中有毒有害物质或元素名称及含量

AAEON System QO4-381 Rev.A0

部件名称

有毒有害物质或元素

铅

(Pb)

汞

(Hg)

镉

(Cd)

六价铬

(Cr(VI))

多溴联苯

(PBB)

多溴二苯

醚(PBDE)

印刷电路板

及其电子组件

○

外部信号

连接器及线材

○

外壳

○

中央处理器

与内存

○

硬盘

○

液晶模块

○

光驱

○

触控模块

○

电源

○

电池

○

本表格依据 SJ/T 11364 的规定编制。

○

：表示该有毒有害物质在该部件所有均质材料中的含量均在

GB/T 26572标准规定的限量要求以下。

×：表示该有害物质的某一均质材料超出了GB/T 26572的限量要求，然而该

部件

仍符合欧盟指令2011/65/EU 的规范。

备注：

一、此产品所标示之环保使用期限，系指在一般正常使用状况下。

二、上述部件物质中央处理器、内存、硬盘、光驱、电源为选购品。

三、上述部件物质液晶模块、触控模块仅一体机产品适用。

Preface X

Fanless Embedded Box PC BOXER-6406-ADN

China RoHS Requirement (EN)

Hazardous and Toxic Materials List

AAEON System QO4-381 Rev.A0

Component

Name

Hazardous or Toxic Materials or Elements

Lead

(Pb)

Mercury

(Hg)

Cadmium

(Cd)

Hexavalent

Chromium

(Cr(VI))

Polybrominat

ed biphenyls

(PBBs)

Polybrominat

ed diphenyl

ethers

(PBDEs)

PCB and

Components

Wires &

Connectors for

Ext.Connections

Chassis

CPU & RAM

HDD Drive

LCD Module

Optical Drive

Touch Control

Module

PSU

Battery

This form is prepared in compliance with the provisions of SJ/T 11364.

O: The level of toxic or hazardous materials present in this component and its parts is below the

limit specified by GB/T 26572.

X: The level of toxic of hazardous materials present in the component exceed the limits specified

by GB/T 26572, but is still in compliance with EU Directive 2011/65/EU (RoHS 2).

Notes:

1. The Environment Friendly Use Period indicated by labelling on this product is applicable only

to use under normal conditions.

2. Individual components including the CPU, RAM/memory, HDD, optical drive, and PSU are

optional.

3. LCD Module and Touch Control Module only applies to certain products which feature these

components.
