Asus PEB-10G/57840-2S Manuel utilisateur

10 Gigabit/s Ethernet card

PEB-10G/57840-2S

PEB-10G Series

PEB-10G/57811-1S

User Guide

E9427

First Edition

June 2014

No part of this manual, including the products and software described in it, may be reproduced, transmitted,

transcribed, stored in a retrieval system, or translated into any language in any form or by any means,

except documentation kept by the purchaser for backup purposes, without the express written permission

of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless

such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the

owners’ benet, without intent to infringe.

iii

Contents

Contents...................................................................................................................... iii

About this guide......................................................................................................... iv

How this guide is organized ............................................................................iv

Where to nd more information.......................................................................iv

Conventions used in this guide ....................................................................... v

Typography ..................................................................................................... v

PEB-10G Series specifications summary ................................................................ vi

Chapter 1: Product introduction

1.1 Welcome! ....................................................................................................1-2

1.2 Package contents ...................................................................................... 1-2

1.3 System requirements.................................................................................1-2

1.4 Card layout .................................................................................................1-3

1.5 Replacing the card bracket .......................................................................1-4

Chapter 2: Boot Agent Configuration

2.1 Broadcom NetXtreme Ethernet Boot Agent ............................................2-2

2.1.1 Device Hardware Conguration Menu ........................................ 2-4

2.1.2 MBA Conguration Menu............................................................ 2-4

2.1.3 iSCSI Boot Conguration ............................................................ 2-6

2.1.4 NIC Partition Conguration Menu (PEB-10G/57840-2S only)... 2-10

Chapter 3: Driver installation

3.1 Windows®Server OS Driver Installation.................................................. 3-2

3.2 Linux OS Driver Installation...................................................................... 3-5

ASUS contact information.......................................................................................... 1

About this guide

This user guide contains the information you need when installing and conguring the server

management board.

How this guide is organized

This guide contains the following parts:

• Chapter1:Productintroduction

This chapter describes the PEB-10G Series Ethernet card features and the new

technologies it supports.

• Chapter2:BootAgentconfiguration

This chapter provides instructions on setting the Broadcom NetXtreme Ethernet Boot

Agent.

• Chapter3:Driverinstallation

This chapter provides instructions for installing the Ethernet card drivers on different

operating systems.

Where to find more information

Refer to the following sources for additional information and for product and software updates.

1. ASUS websites

The ASUS website provides updated information on ASUS hardware and software

products. Refer to the ASUS contact information.

2. Optional documentation

Your product package may include optional documentation, such as warranty yers,

that may have been added by your dealer. These documents are not part of the

standard package.

Typography

Bold text Indicates a menu or an item to select.

Italics

Used to emphasize a word or a phrase.

<Key> Keys enclosed in the less-than and greater-than sign means

that you must press the enclosed key.

Example: <Enter> means that you must press the Enter or

Return key.

<Key1>+<Key2>+<Key3> If you must press two or more keys simultaneously, the key

names are linked with a plus sign (+).

Example: <Ctrl>+<Alt>+<Del>

Command Means that you must type the command exactly as shown,

then supply the required item or value enclosed in

brackets.

Example: At the DOS prompt, type the command line:

format a:

DANGER/WARNING: Information to prevent injury to yourself

when trying to complete a task.

CAUTION: Information to prevent damage to the components

when trying to complete a task.

NOTE: Tips and additional information to help you complete a

task.

IMPORTANT: Instructions that you MUST follow to complete a

task.

Conventions used in this guide

To make sure that you perform certain tasks properly, take note of the following symbols

used throughout this manual.

PEB-10G Series specifications summary

* Please refer to ASUS website for Approved Vendor List (AVL).

** Specifications are subject to change without notice.

PEB-10G/57840-2S PEB-10G/57811-1S

Speed & Ports

10 Gigabit/s Ethernet

Fiber; Dual Port

10 Gigabit/s Ethernet

Fiber; Single Port

Ethernet

Controller

PHY

Broadcom 57840S Broadcom 57811S

Connector &

module type

LC Fiber Optic

Supports SFP+ SR Optical module, SFP+ LR Optical module, Direct

Attached Copper*

Host Interface PCI-E Gen3 x8 PCI-E Gen2 x8

Form factor 4.72 in. x 1.77 in. (lower than standard low prole)

Support Cable

Type

SMF up to 10km (LR)

MMF 62.5/50um up to 300m (SR)

Passive Twin-AX up to 5m (SFP+ Direct Attach)

Features

PXE boot

iSCSI boot

Product introduction

This chapter offers the PEB-10G Series Ethernet card features

and the new technologies it supports.

Chapter 1: Product introduction

1-2 Chapter 1: Product introduction

1.1 Welcome!

Thank you for buying an ASUS®PEB-10G Series 10 Gigabit/s Ethernet card!

Before you start installing the Ethernet card, check the items in your package with the list

below.

1.2 Package contents

Check your package for the following items.

PEB-10G/57840-2S

PEB-10G/57811-1S

1.3 System requirements

Before you install the PEB-10G Series Ethernet card, check if the system meets the following

requirements:

• Server or workstation motherboard with a PCI Express x8 or x16 card slot

• Supported operating system:

Windows®andLinuxoperatingsystems(refertothespecicationtableortheASUS

website for the latest updates).

Standard Gift Box Pack Standard Bulk Pack

Support DVD 1 1 (per carton)

Low profile bracket 1 1

Small bracket for node* 1 1

Screws 4 4

Packing Quantity 1 pc per carton 5 pcs per carton

Standard Gift Box Pack Standard Bulk Pack

Support DVD 1 1 (per carton)

Low profile bracket 1 1

Small bracket for node* 1 1

Screws 4 4

Packing Quantity 1 pc per carton 5 pcs per carton

If any of the above items is damaged or missing, contact your retailer.

* The bundled small bracket for node is a proprietray bracket that supports ASUS

Z10PH-D16 series, ES4000 G3 series, and RS720Q-E8 series models, etc. The supported

list of models are subject to change without prior notice.

ASUS PEB-10G Series 1-3

1.4 Card layout

1. LC Fiber Optic Connector 1

2. LC Fiber Optic Connector 2

3. PCI Express x8 interface

4. SFP2LED2 LED

5. SFP2LED1 LED

6. PCIELINK1 LED

LED indications

Speed/Link

Status Description

SFP2LED1 /

SFP2LED2

Green 10 Gbps link

Amber 1 Gbps link

Blinking Data Activity

Status Description

PCIELINK1 Green PCIE link

PEB-10G/57840-2S

Front view

Back view

1-4 Chapter 1: Product introduction

1.5 Replacing the card bracket

ThePEB-10GSeriesEthernetcardisbundledwithafull-lengthbracket,alow-prolebracket,

and an ASUS proprietary bracket. By default, the card is pre-installed with a full-length

bracket.

The proprietray bracket supports ASUS Z10PH-D16 series, ES4000 G3 series, and

RS720Q-E8 series models, etc. The supported list of models are subject to change without

prior notice.

To replace the card bracket:

1. Get the PEB-10GSeriesEthernetcardandplaceitonastableandatsurface.

Ensure that the printed circuit board (PCB) is facing down.

2. Remove the two screws that secures the PEB-10G Series Ethernet card to the card

bracket then remove the card bracket.

3. Get the replacement card bracket.

4. Align and insert the PEB-10G Series Ethernet card into the mounting hole of the card

bracket. Ensure that the screw holes on the PEB-10G Series Ethernet card matches

the screw holes of the card bracket.

5. Replace the screws that you removed earlier in step 2.

screw

replacement card bracket

default card bracket
