ASROCK Rack MT-C224 Manuel utilisateur

Version 1.0

Published August2014

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Rack Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished

for informational use only and subject to change without notice, and should not

be constructed as a commitment by ASRock Rack. ASRock Rack assumes no

responsibility for any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock Rack does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable

for any indirect, special, incidental, or consequential damages (including damages

for loss of prots, loss of business, loss of data, interruption of business and the

like), even if ASRock Rack has been advised of the possibility of such damages

arising from any defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Rack’s Website: www.ASRockRack.com

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 3

1.3 Unique Features 6

1.4 Motherboard Layout 7

1.5 I/O Panel 9

1.6 Block Diagram 11

Chapter 2 Installation 12

2.1 Screw Holes 12

2.2 Pre-installation Precautions 12

2.3 Installing the CPU 13

2.4 Installing the CPU Fan and Heatsink 15

2.5 Installation of Memory Modules (DIMM) 16

2.6 Expansion Slots (PCI and PCI Express Slots) 18

2.7 Jumper Setup 19

2.8 Onboard Headers and Connectors 20

2.9 Driver Installation Guide 25

2.10 Dual LAN and Teaming Operation Guide 26

Chapter 3 UEFI Setup Utility 27

3.1 Introduction 27

3.1.1 UEFI Menu Bar 27

3.1.2 Navigation Keys 28

3.2 Main Screen 29

3.3 Advanced Screen 30

3.3.1 CPU Conguration 31

3.3.2 North Bridge Conguration 34

3.3.3 South Bridge Conguration 35

3.3.4 Storage Conguration 36

3.3.5 Super IO Conguration 38

3.3.6 ACPI Conguration 39

3.3.7 USB Conguration 40

3.3.8 WHEA Conguration 41

3.3.9 Intel Server Platform Services 42

3.3.10 Serial Port Console Redirection 43

3.3.11 Voltage Control 45

3.3.12 Instant Flash 46

3.4 H/W Monitor Screen 47

3.5 Boot Screen 49

3.6 Security Screen 51

3.7 Event Logs 52

3.8 Server Mgmt (Server Management) 54

3.9 Exit Screen 56

Chapter 4 Software Support 57

4.1 Install Operating System 57

4.2 Support CD Information 57

4.2.1 Running The Support CD 57

4.2.2 Drivers Menu 57

4.2.3 Utilities Menu 57

4.2.4 Contact Information 57

Chapter 5 Troubleshooting 58

5.1 Troubleshooting Procedures 58

5.2 Technical Support Procedures 60

5.3 Returning Merchandise for Service 60

MT-C224

English

Chapter 1 Introduction

ank you for purchasing ASRock Rack MT-C224 motherboard, a reliable

motherboard produced under ASRock Rack’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock Rack’s

commitment to quality and endurance.

In this manual, chapter 1 and 2 contains introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration

guide to BIOS setup and information of the Support CD.

1.1 Package Contents

•ASRock Rack MT-C224 Motherboard

(Extended Mini ITX Form Factor: 7.8-in x 6.7-in, 19.8 cm x 17.0 cm)

•Support CD

•User Manual

•1 x I/O Shield

•4 x SATA3 cables (50cm)

•2 x SATA3 cables (60cm)

If any items are missing or appear damaged, contact your authorized dealer.

Because the motherboard specications and the BIOS soware might be updated, the con-

tent of this manual will be subject to change without notice. In case any modications of

this manual occur, the updated version will be available on ASRock Rack website without

further notice. You may nd the latest memory and CPU support lists on ASRock Rack

website as well. ASRock Rack’s Website: www.ASRockRack.com

If you require technical support related to this motherboard, please visit our website for

specic information about the model you are using.

www.asrock.com/support/index.asp

English

Contact Information

If you need to contact ASRock Rack or want to know more about ASRock Rack,

you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you

may contact your dealer for further information.

ASRock Rack Incorporation

6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,

Taipei City 112, Taiwan (R.O.C.)

MT-C224

English

1.2 Specications

MT-C224

MB Physical Status

Form Factor Extended mini ITX

Dimension 7.8'' × 6.7'' (19.8 cm x 17.0 cm)

Processor System

CPU - Single socket H3 (LGA 1150) supports Intel® Xeon processor

E3-1200 v3 series & Haswell i3 processors

- Supports Hyper-reading Technology

Socket Single Socket H3 (LGA1150)

Chipset Intel® C224

System Memory

Capacity - 4 x 240-pin DDR3 DIMM slots

- Support up to 32GB DDR3 ECC UDIMM

Type - Dual Channel DDR3 memory technology

- Supports DDR3 1600/1333 ECC DIMM

Voltage 1.5V, 1.35V

Expansion Slot

PCIe 3.0 x 8 1 slot

Storage

SATA Controller Intel® C224 : 4 x SATA3 6.0 Gb/s, 2 x SATA2 3.0 Gb/s, Support

RAID 0, 1, 5, 10 and Intel® Rapid Storage

Ethernet

Interface Gigabit LAN 10/100/1000 Mb/s

LAN Controller - 2 x Intel® i210

- Supports Wake-On-LAN

- Supports Energy Ecient Ethernet 802.3az

- Supports Dual LAN with Teaming function

- Supports PXE

Management

BMC Controller ASPEED AST2300 : IPMI (Intelligent Platform Management

Interface) 2.0 with iKVM support

IPMI Dedicated

GLAN

1 x Realtek RTL8211E for dedicated management GLAN

Gracphics

Controller ASPEED AST2300

VRAM DDR3 16MB

Rear Panel I/O

VGA Port 1 x D-Sub

USB 3.0 Port 2

English

Lan Port - 2 x RJ45 Gigabit Ethernet LAN ports

- 1 x RJ45 Dedicated IPMI LAN port

- LAN Ports with LED (ACT/LINK LED and SPEED LED)

UID Button/UID

LED

DC IN 1x ATX 8-pin connector

Internal Connector

Auxiliary Panel

Header

1 (includes chassis intrusion, location button & LED, front

LAN LED)

TPM Header 1

IPMB Header 1

BMC_SMBUS 2

SGPIO 1

Fan Header 5 x 4-pin

Power Connector 1 (18-pin, DC Input)+1 (4-pin, SATA power output)

USB 3.0 Header 1 (each supports 2 USB 3.0 ports)

USB 2.0 Header 1 (each supports 2 USB 2.0 ports)

PDB SMBUS 1 x 2.0mm 6-pin connector

NMI BTN 1

System BIOS

BIOS Ty pe 64Mb AMI UEFI Legal BIOS

BIOS Features - Plug and Play (PnP)

- ACPI 1.1 Compliance Wake Up Events

- SMBIOS 2.3.1 Support

- DRAM Voltage Multi-adjustment

- ASRock Instant Flash

Hardware Monitor

Temperature - CPU Temperature Sensing

- System Temperature Sensing

Fan - CPU/Rear/Front Fan Tachometer

- CPU Quiet Fan (Allow CPU Fan Speed Auto-Adjust by CPU

Temperature)

- CPU/Rear/Front Fan Multi-Speed Control

Voltage Voltage Monitoring:

SIO: +12V, +5V

BMC: +3.3V, CPU Vcore, DRAM, 1.05V_PCH, +BAT, 3VSB,

5VSB, DC_IN 12V

MT-C224

English

Support OS

OS Microso® Windows®

- Server 2008 R2 (64 bit)

- Server 2012 (64 bit)

- Server 2012 R2 (64 bit)

Linux®

- RedHat Enterprise Linux Server 5.9/6.4 (32 / 64 bit)

- CentOS 5.9 / 6.4 (32 / 64 bit)

- SUSE Enterprise Linux Server 11 SP3 (32 / 64 bit)

- FreeBSD 9.1 (32 / 64 bit)

- Fedora core 19 (64 bit)

- UBuntu 12.04.2 (64 bit) / 12.10 (64 bit)

Virtual

- VMWare® ESXi 5.5

Environment

Temperature Operation temperature: 10°C ~ 35°C / Non operation

temperature: -40°C ~ 70°C
