ASROCK P45TS - V1.0 Manuel utilisateur

P45TS-R /

P45TS

User Manual

Version 1.0

Published July 2008

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identification or explanation and to the owners’ benefit, without intent to infringe.

Disclaimer:Disclaimer:

Disclaimer:

Specifications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or fitness for a particular purpose.

In no event shall ASRock, its directors, officers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of profits, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in

California, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

ContentsContents

Contents

1 Introduction1 Introduction

1 Introduction ......................................................................................................

......................................................................................................

................................................... 55

1.1 Package Contents .......................................................... 5

1.2 Specifications ................................................................. 6

1.3 Minimum Hardware Requirement Table for Windows®

VistaTM Premium 2008 and Basic Logo......................... 10

1.4 Motherboard Layout (P45TS-R) .................................... 11

1.5 Motherboard Layout (P45TS) ........................................ 12

1.6 ASRock 1394_SPDIF I/O (P45TS-R) .............................. 13

1.7 ASRock SPDIF I/O (P45TS) ............................................ 14

2 Installation2 Installation

2 Installation............................................................................................................

............................................................................................................

...................................................... 1515

1515

2.1 Screw Holes ................................................................. 15

2.2 Pre-installation Precautions ........................................... 15

2.3 CPU Installation .............................................................. 16

2.4 Installation of Heatsink and CPU fan ............................. 18

2.5 Installation of Memory Modules (DIMM) ......................... 19

2.6 Expansion Slots (PCI and PCI Express Slots) ..................... 21

2.7 Jumpers Setup .............................................................. 22

2.8 Onboard Headers and Connectors .............................. 23

2.9 HDMI_SPDIF Header Connection Guide ......................... 29

2.10 eSATAII Interface Introduction ....................................... 30

2.11 SATAII Hard Disk Setup Guide ........................................ 33

2.12 Serial ATA (SATA) / Serial ATAII (SATAII) Hard Disks

Installation ...................................................................... 34

2.13 Hot Plug and Hot Swap Functions for SATA / SATAII

HDDs and eSATAII Devices ......................................... 35

2.14 SATA / SATAII HDD Hot Plug Feature and Operation

Guide .............................................................................. 36

2.15 Driver Installation Guide ................................................. 38

2.16 Installing Windows®XP / XP 64-bit / VistaTM / VistaTM

64-bit With RAID Functions (For P45TS-R Only) ........... 38

2.16.1 Installing Windows®XP / XP 64-bit With RAID

Functions ............................................................ 38

2.16.2 Setting Up a “RAID Ready” System ................... 39

2.16.3 Migrating a “RAID Ready” System to RAID 0,

RAID 1 or RAID 5 ................................................. 40

2.16.4 Installing Windows®VistaTM / VistaTM 64-bit With

RAID Functions ................................................... 41

2.17 Installing Windows®2000 / XP / XP 64-bit / VistaTM /

VistaTM 64-bit Without RAID Functions .......................... 42

2.17.1 Installing Windows®2000 / XP / XP 64-bit Without

RAID Functions ................................................... 42

2.17.2 Installing Windows®VistaTM / VistaTM 64-bit Without

RAID Functions ................................................... 43

2.18 Untied Overclocking Technology ................................... 44

3 BIOS S3 BIOS S

3 BIOS SETUP UTILITYETUP UTILITY

ETUP UTILITYETUP UTILITY

ETUP UTILITY......................................................................................

......................................................................................

........................................... 4545

4545

3.1 Introduction .................................................................... 45

3.1.1 BIOS Menu Bar .................................................... 45

3.1.2 Navigation Keys ................................................... 46

3.2 Main Screen ................................................................... 46

3.3 Smart Screen ................................................................ 47

3.4 Advanced Screen ......................................................... 48

3.4.1 Overclock Configuration ...................................... 49

3.4.2 CPU Configuration ................................................ 52

3.4.3 Chipset Configuration .......................................... 54

3.4.4 ACPI Configuration ............................................... 57

3.4.5 IDE Configuration ................................................. 58

3.4.6 PCIPnP Configuration ........................................... 61

3.4.7 Floppy Configuration ........................................... 61

3.4.8 Super IO Configuration ........................................ 62

3.4.9 USB Configuration ............................................... 63

3.5 Hardware Health Event Monitoring Screen .................. 64

3.6 Boot Screen ................................................................... 65

3.6.1 Boot Settings Configuration .................................. 65

3.7 Security Screen ............................................................ 66

3.8 Exit Screen .................................................................... 67

4 Software Support4 Software Support

4 Software Support ......................................................................................

......................................................................................

........................................... 6868

6868

4.1 Install Operating System ............................................... 68

4.2 Support CD Information ................................................. 68

4.2.1 Running Support CD ............................................ 68

4.2.2 Drivers Menu ........................................................ 68

4.2.3 Utilities Menu ........................................................ 68

4.2.4 Contact Information .............................................. 68

Chapter 1: IntroductionChapter 1: Introduction

Chapter 1: Introduction

Thank you for purchasing ASRock P45RTS-R / P45TS motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control. It de-

livers excellent performance with robust design conforming to ASRock’s commit-

ment to quality and endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-by-step

guide to the hardware installation. Chapter 3 and 4 contain the configuration guide to

BIOS setup and information of the Support CD.

Because the motherboard specifications and the BIOS software might

be updated, the content of this manual will be subject to change without

notice. In case any modifications of this manual occur, the updated

version will be available on ASRock website without further notice. You

may find the latest VGA cards and CPU support lists on ASRock website

as well. ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specific information about the model you are using.

www.asrock.com/support/index.asp

1.1 P1.1 P

1.1 Packack

ackack

ackage Contentsage Contents

age Contentsage Contents

age Contents

ASRock P45RTS-R / P45TS Motherboard

(ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm)

ASRock P45RTS-R / P45TS Quick Installation Guide

ASRock P45RTS-R / P45TS Support CD

One 80-conductor Ultra ATA 66/100/133 IDE Ribbon Cable

One Ribbon Cable for a 3.5-in Floppy Drive

Two Serial ATA (SATA) Data Cables (Optional)

One Serial ATA (SATA) HDD Power Cable (Optional)

One “ASRock 1394_SPDIF I/O” I/O Panel Shield (P45TS-R)

One “ASRock SPDIF I/O” I/O Panel Shield (P45TS)

1.21.2

1.2 SpecificationsSpecifications

SpecificationsSpecifications

Specifications

Platform - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm

- All Solid Capacitor design (100% Japan-made high-quality

Conductive Polymer Capacitors) (P45TS-R)

- Solid Capacitor for CPU power (P45TS)

CPU - LGA 775 for Intel®CoreTM 2 Extreme / CoreTM 2 Quad / CoreTM

2 Duo / Pentium®Dual Core / Celeron®Dual Core / Celeron®,

supporting Penryn Quad Core Yorkfield and Dual Core

Wolfdale processors

- Compatible with FSB2000/1600/1333/1066/800 MHz

(see CAUTION 1)

- Supports Hyper-Threading Technology (see CAUTION 2)

- Supports Untied Overclocking Technology (see CAUTION 3)

- Supports EM64T CPU

Chipset - Northbridge: Intel®P45

- Southbridge: Intel®ICH10R (P45TS-R)

- Southbridge: Intel®ICH10 (P45TS)

Memory - Dual Channel DDR3/DDR2 Memory Technology

(see CAUTION 4)

- 2 x DDR3 DIMM slots

- Support DDR3 1333/1066 non-ECC, un-buffered memory

(see CAUTION 5)

- Max. capacity of system memory: 4GB (see CAUTION 6)

- 4 x DDR2 DIMM slots

- Support DDR2 1066/800/667 non-ECC, un-buffered memory

(see CAUTION 5)

- Max. capacity of system memory: 16GB (see CAUTION 6)

Expansion Slot - 1 x PCI Express 2.0 x16 slot (green @ x16 mode)

- 3 x PCI Express x1 slots

- 3 x PCI slots

Audio P45TS-R

- 7.1 CH Windows® VistaTM Premium Level HD Audio with

Content Protection

- DAC with 110dB dynamic range (ALC890 Audio Codec)

P45TS

- 7.1 CH Windows® VistaTM Premium Level HD Audio

(ALC888 Audio Codec)

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111B/RTL8111C

- Supports Wake-On-LAN

Rear Panel I/O P45TS-R

ASRock 1394_SPDIF I/O

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x Coaxial SPDIF Out Port

- 1 x Optical SPDIF Out Port

- 6 x Ready-to-Use USB 2.0 Ports

- 1 x eSATAII Port

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)

- 1 x IEEE 1394 Port

- HD Audio Jack: Side Speaker/Rear Speaker/Central/Bass/

Line in/Front Speaker/Microphone (see CAUTION 7)

P45TS

ASRock SPDIF I/O

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x Coaxial SPDIF Out Port

- 1 x Optical SPDIF Out Port

- 6 x Ready-to-Use USB 2.0 Ports

- 1 x eSATAII Port

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)

- HD Audio Jack: Side Speaker/Rear Speaker/Central/Bass/

Line in/Front Speaker/Microphone (see CAUTION 7)

Connector - 6 x SATAII 3.0Gb/s connectors, support RAID (RAID 0,

RAID 1, RAID 10, RAID 5 and Intel Matrix Storage), NCQ,

AHCI and “Hot Plug” functions (see CAUTION 8)

* RAID functions are for P45TS-R only

- 1 x eSATAII 3.0Gb/s connector (shared with 1 SATAII port)

(see CAUTION 9)

- 1 x ATA133 IDE connector (supports 2 x IDE devices)

- 1 x Floppy connector

- 1 x IR header

- 1 x COM port header

- 1 x HDMI_SPDIF header

- 1 x IEEE 1394 header (P45TS-R)

- CPU/Chassis FAN connector

- 24 pin ATX power connector

- 8 pin 12V power connector

- CD in header

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

(see CAUTION 10)

WARNING

Please realize that there is a certain risk involved with overclocking, including adjusting

the setting in the BIOS, applying Untied Overclocking Technology, or using the third-

party overclocking tools. Overclocking may affect your system stability, or even

cause damage to the components and devices of your system. It should be done at

your own risk and expense. We are not responsible for possible damage caused by

overclocking.

- 1 x WiFi/E header (see CAUTION 11)

BIOS Feature - 8Mb AMI BIOS

- AMI Legal BIOS

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- AMBIOS 2.3.1 Support

- CPU, DRAM, NB, SB, VTT Voltage Multi-adjustment

- Supports I. O. T. (Intelligent Overclocking Technology)

- Supports Smart BIOS

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version)

Unique Feature - ASRock OC Tuner (see CAUTION 12)

- Hybrid Booster:

- CPU Frequency Stepless Control (see CAUTION 13)

- ASRock U-COP (see CAUTION 14)

- Boot Failure Guard (B.F.G.)

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

- CPU Fan Tachometer

- Chassis Fan Tachometer

- CPU Quiet Fan

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

OS - Microsoft® Windows® 2000 / XP / XP 64-bit / VistaTM /

VistaTM 64-bit compliant (see CAUTION 15)

Certifications - FCC, CE, WHQL

* For detailed product information, please visit our website: http://www.asrock.com

CAUTION!

1. Some CPU you adopt may be overclocked to FSB2000 MHz, in this

situation, please adopt DDR3 1333 memory modules on this

motherboard. This motherboard supports native FSB1600/1333/1066/800

MHz. For normal operation, you do no need to adjust the jumper settings.

For special overclocking mode, please refer to page 22 for proper jumper

settings.

2. About the setting of “Hyper Threading Technology”, please check page 53.

3. This motherboard supports Untied Overclocking Technology. Please read

“Untied Overclocking Technology” on page 44 for details.

4. This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read

the installation guide of memory modules on page 19 for proper installation.

5. Please check the table below for the CPU FSB frequency and its

corresponding memory support frequency.

CPU FSB Frequency Memory Support Frequency

1600 DDR2 800, DDR2 1066,

DDR3 1066, DDR3 1333

1333 DDR2 667, DDR2 800, DDR2 1066,

DDR3 1066, DDR3 1333

1066 DDR2 667, DDR2 800, DDR2 1066,

DDR3 1066

800 DDR2 667, DDR2 800

6. Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows®XP

and Windows®VistaTM. For Windows®XP 64-bit and Windows®VistaTM

64-bit with 64-bit CPU, there is no such limitation.

7. For microphone input, this motherboard supports both stereo and mono

modes. For audio output, this motherboard supports 2-channel, 4-

channel, 6-channel, and 8-channel modes. Please check the table on

page 13 and 14 for proper connection.

8. Before installing SATAII hard disk to SATAII connector, please read the

“SATAII Hard Disk Setup Guide” on page 33 to adjust your SATAII hard disk

drive to SATAII mode. You can also connect SATA hard disk to SATAII

connector directly.

9. This motherboard supports eSATAII interface, the external SATAII

specification. Please read “eSATAII Interface Introduction” on page 30 for

details about eSATAII and eSATAII installation procedures.

10. Power Management for USB 2.0 works fine under Microsoft®Windows®

VistaTM 64-bit / VistaTM / XP 64-bit / XP SP1 or SP2 / 2000 SP4.

11. WiFi/E header supports WiFi+AP function with ASRock WiFi-802.11g or

WiFi-802.11n module, an easy-to-use wireless local area network (WLAN)

adapter. It allows you to create a wireless environment and enjoy the

convenience of wireless network connectivity. Please visit our website for

the availability of ASRock WiFi-802.11g or WiFi-802.11n

module. ASRock website http://www.asrock.com

1010

1.31.3

1.3 Minimum Hardware RMinimum Hardware R

Minimum Hardware RMinimum Hardware R

Minimum Hardware Requirement Tequirement T

equirement Tequirement T

equirement Table forable for

able forable for

able for

WindowsWindows

Windows®®

®®

® VistaVista

VistaVista

VistaTMTM

TMTM

TM Premium 2008 and Basic LogoPremium 2008 and Basic Logo

Premium 2008 and Basic LogoPremium 2008 and Basic Logo

Premium 2008 and Basic Logo

For system integrators and users who purchase this motherboard and

plan to submit Windows®VistaTM Premium 2008 and Basic logo, please

follow below table for minimum hardware requirements.

CPU Celeron 420

Memory 1GB system memory (Premium)

512MB Single Channel (Basic)

VGA DX10 with WDDM Driver

with 128bit VGA memory (Premium)

with 64bit VGA memory (Basic)

* After June 1, 2008, all Windows®VistaTM systems are required to meet above

minimum hardware requirements in order to qualify for Windows®VistaTM

Premium 2008 logo.

12. It is a user-friendly ASRock overclocking tool which allows you to surveil

your system by hardware monitor function and overclock your hardware

devices to get the best system performance under Windows® environment.

Please visit our website for the operation procedures of ASRock OC

Tuner. ASRock website: http://www.asrock.com

13. Although this motherboard offers stepless control, it is not recommended

to perform over-clocking. Frequencies other than the recommended CPU

bus frequencies may cause the instability of the system or damage the

CPU.

14. While CPU overheat is detected, the system will automatically shutdown.

Before you resume the system, please check if the CPU fan on the

motherboard functions properly and unplug the power cord, then plug it

back again. To improve heat dissipation, remember to spray thermal

grease between the CPU and the heatsink when you install the PC system.

15. RAID / AHCI functions are not supported under Windows® 2000 OS. It is

recommended to use IDE mode under Windows® 2000. Please refer to

page 58 for detailed setup.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK H97M-ITX/ac Manuel utilisateur

ASROCK

ASROCK H170 Combo Manuel utilisateur

ASROCK

ASROCK X570 AQUA Manuel utilisateur

ASROCK

ASROCK X79 Extreme4-M Manuel utilisateur

ASROCK

ASROCK ALIVENF5SLI-1394 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

ASROCK

ASROCK IMB-151N Manuel utilisateur

ASROCK

ASROCK H110M-DVP Manuel utilisateur

ASROCK

ASROCK IMB-A160 Manuel de service

ASROCK

ASROCK Profess1onal Series Manuel utilisateur

ASROCK

ASROCK 880G EXTREME3 - LIST Manuel utilisateur

ASROCK

ASROCK G41MH USB3 Manuel utilisateur

ASROCK

ASROCK P55 PRO/USB3 - Manuel utilisateur

ASROCK

ASROCK EP2C612D16FM Manuel utilisateur

ASROCK

ASROCK 785G Pro Manuel utilisateur

ASROCK

ASROCK iBOX-155 Manuel utilisateur

ASROCK

ASROCK Z270 SUPERCARRIER Manuel utilisateur

ASROCK

ASROCK H55ICAFE Manuel utilisateur

ASROCK

ASROCK J3160DC-ITX Manuel utilisateur

ASROCK

ASROCK IMB-385 Instructions d'utilisation

ASROCK

ASROCK X99 Extreme4 Manuel utilisateur

ASROCK

ASROCK P55 EXTREME4 - Manuel utilisateur

ASROCK

ASROCK H370M-HDV/M.2 Manuel utilisateur

ASROCK

ASROCK SP2C741D16HM3 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
