Anviz W 1 Manuel utilisateur
Color Screen Fingerprint & Card
Time Aendance and Access Control
W Series
W 1 W 2
- 1 -
W1 & W2 Features
* Standard 2.8-inch TFT LCD, 512MB Flash, industrial high speed CPU
* Touch keypad & touch active sensor
* Identification mode: Fingerprint, Password, Card (optional)
* Cloud management systerm support
* Support webserver: basic setting, personnel inquiry and management, records inquiry
* DDNS: Support dynamic domain name server which offers a persistent domain name for
non-static IP devices
* Support TCP/IP network communication, the access control data and events will push to the
access control management software by real time.
* With 32 customize access control time zone and 16 permission groups make access control
more easy (W2 access control)
* Communication: TCP/IP, Mini USB, USB Host,RS485 (RS485 is for W2 access control)
* W2 In/Out: 1 relay output, wiegand input/output, door switch, door sensor, tamper alarm
* Registration capacity: 3000 Fingerprints and 100000 Records
2. Mount the Device to Wall
* Install the mounting panel on th wall
* Plug in the Ethernet cable,charger or extended function connector cable
* Slide the W1 or W2 down onto the panel and secure with the screw on the bottom of device
1. What’s in the package?
Accessory PackageDevice
Card
Instruction Package
Color Screen Fingerprint & Card Time Aendance and Access Control
W Series
W 1 W 2
*Card is optional
W1 or W2
*Power adapter
is only for W1
*Two extended function connector
cables are only for W2
1 2 3
- 2 -
Wiring Instruction
TCP/IP
W 1 W 2
W 1
Mini USB
Power DC input port
RJ45 Network interface
Important notice: Please follow the wiring diagram as it is displayed. Damaged products diagram as
it is displayed. Damaged products due to improper wiring are not covered under the product warranty.
DC12V
GND
WI0
WO0
GND
BELL-
485A
BELL+
485B
PWR
DM
OPEN
GND
NO
WI1
WO1
COM
NC
Mini USB
Extended function interface
TCP/IP
RJ45 Network interface
J12J1
J12 Extended function interface：
- 3 -
Organge
Wiegand
DATA1 Input
Wiegand
DATA1 Output
Yellow
Wiegand
DATA0 Output
Wiegand
DATA0 Input
Door Bell-
RS485A RS485B
Door Bell+
Door
Magnetic
①
②
③
④
⑤
⑥
⑦
⑧
⑨
No.
Funcition
No.
Funcition
Cable Color
Cable Color
⑩
13
14
15
16
Wiegand 26 Output
Wiegand 26 Input
Brown
Blue
White
Green Black
Red Gray
Purple
White
Red Blue
Brown Red
Black
GND GND
COM
NCNO
Exit Button
Active doorbell
Passive
doorbell
Relay Output
RS485 Door Magnetic
DC12V
GND
W2 & Switching Power Supply
W2 & Anviz SC011
J1
J12
- 4 -
SC011 can work with W2 by Anviz encrypt Wiegand code authorized to
set up a distributed access control system. Wiegand mode must be set to
‘AnvizWiegand’ by PC software. You can buy SC011 from our sales.
④② ⑥ ⑧
Active doorbell
+5V
Passive doorbell
WI0
WO0
GND
BELL-
485A
BELL+
485B
PWR
DM
OPEN
GND
NO
WI1
WO1
COM
NC
Door Open Sensor
Exit button
Wiegand Card Reader
W0
W1
GND
DC12V
GND
J1
J12
WI0
WO0
GND
BELL-
485A
BELL+
485B
PWR
DM
OPEN
GND
NO
WI1
WO1
COM
NC
1311
1 3 5
10 12 14 16
- 5 -
Wiegand 26 date output format (W2 & other access control):
Card user: Output card number.(Decimal)
Fingerprint user: Output ID number.
Anviz Wiegand date output format：
ALL registered users output devieces’ last eight serial number.
(For example, SN of one device is 1050000014470004, then
Anviz Wiegand output 14470004.)
W2 & Access Control Power Supply
DC12V
GND
J1
J12
WI0
WO0
GND
BELL-
485A
BELL+
485B
PWR
DM
OPEN
GND
NO
WI1
WO1
COM
NC
Exit button
Door Open Sensor
⑥ ⑧
Active doorbell
+5V
1311
- 6 -
0
Set
1. Turn on the Device
Plug in the power supply and wait for the device
boot up.
2. Add Users to Device
Scan the same finger three times to enroll the
fingerprint.
* RFID Card is the optional feature. If you have the card option and want to enroll the card, use the up & down key to move the cursor
to card number field. Swipe the card in the field of card module. The card number will be displayed.
- 7 -
or close Ehernet
5. Setup the Device Communication
- 8 -
- 9 -
W1 or W2
Device
Device
Device
Device Device
2. Enable Commucation between Device and the Management Software CrossChex
Local Area Network (TCP/IP)
Right click on the device icon
and choose ‘Set the IP configuration’
to set correct network enviroment
parameters such as above window.
1
2
Loose the screw on the bottom of device, then
pull up the front case, seperate from back
panel
Connect USB cable between with device and
PC which has installed software
How to connect the Device with Software?
