Anviz M-Bio Manuel utilisateur
PortableBluetoothEnabled
Fingerprint&RFIDDevice
M-Bio
Quick Guide v1.1
www.anviz.com
RFID Card
X4
USB Cable Quick GuideDevice
Notification:
Package List
1
POWERING A SMARTER WORLD
POWERING A SMARTER WORLD
1. Please check if the package contains all the
items listed above. Contact the distributor if
there is any problem.
2. Please keep the product away from the
magnetic field, and avoid causing any damage
to the device.
3. Please use the original power supply or refer
to the instruction to get the right power supply.
4. Please strictly follow the instructions to install
the product. Any damage to it caused by
incorrect operation and wiring are not under
warranty.
PortableBluetoothEnabled
Fingerprint&RFIDDevice
M-Bio
QuickGuide v1.1
Illustration for Placing Finger
Try to place your finger
covers the entire sensor.
Correct Method
Incorrect Method
DO NOT place finger
at an angle.
DO NOT place finger away
from the center of the sensor.
DO NOT place the finger
over an excessive angle.
DO NOT
take off finger during
the verification process.
( Straighten your finger and then place it on the sensor
Ensure the finger is flat and covers the entire sensor)
Always place finger in the
center of the sensor.
2
DO NOT slide your finger
during the fingerpint
verification process.
DO NOT just use
your fingertip.
Appearance
3
OLED Screen
Fingerprint Sensor
RFID Reader
Area
4
Power Over USB Port
Power
Button
192.168.2.23 4
AP
2021 01 10
14:20:33
Date and Time BluetoothWIFI AP Mode Battery
5
Operation Guide
5. Swipe Enroll
Card to end
the enrollment.
IMPORTANT:
Register User:
M-Bio is suitable for USB 5V power supply only. Plug in the
power the device will automatic power on.
Add One Fingerprint per User Only:
1. Swipe
Enroll
Card
2. Place finger
4. Continue to register another user
3. Place
finger
again
Green &
Blue LEDs
light up
Blue LED
and Sensor
lights up
Green LED lights
up and display
Save Successed
1. After finish enrolling current user, the device will
continue to register another user.
2. After finish enrollment, please swipe enroll card
to exit enroll status.
6
Add Card Only:
Notice:
During the device in the regsiter mode without
any operation for 3 sec the M-bio will back to the
normal mode.
Operation Guide
1. Swipe
Enroll
Card
2. Swipe
User Card
4. Continue to register another user
3. Swipe
User Card
again
Green &
Blue LEDs
light up
Blue LED
and Sensor
light up
Green LED lights
up and display
Save Successed
5. Swipe Enroll
Card to end
the enrollment.
5. Swipe Delete
Card to end
the process
Operation Guide
7
Delete User:
Delete Fingerprint or Card
1. Swipe
Delete
Card
2. Place finger
4. Continue to delete user
3. Place
finger
again
Red and Blue
LEDs Light
Up
Blue LED and
FingerPrint sensor
lights up
Green LED lights
up and display
delete success
After delete one user, you can continue to delete
another user or swipe Delete Card to exit delete mode.
Notice:
During the device in the delete mode
without any operation for 3 sec the M-bio
will back to the normal mode.
8
Notice:
Operation Guide
After delete one user, you can continue to delete
another user or swipe Delete Card to exit delete mode.
1. Swipe
Delete
Card
2. Swipe
User Card
4. Continue to delete user
3. Swipe
User Card
again
5. Swipe Delete
Card to end
the process
Red and Blue
LED Light
Up
Blue LED and
FingerPrint sensor
lights up
Green LED lights
up and display
delete success
When you swipe card on M-Bio, Red LED
flashing with long beeps means the card does
not exist in the device.
Delete Card:
Login WebServer
9
192.168.2.1
AP
2021 01 10
14:20:33
Login to M-bio Webserver to
manage the device.
M-bio is default with WIFI AP
funciton.
Please connect M-Bio WIFI AP
WIFI SSID: M-bio
Default Password: 123456789
Please input the default address (192.168.2.234)
in the browser to login Webserver.
Account: admin
Default Password: 12345
Login Web Server
Login Reset
User Name
Password
