Anritsu MS2830A Manuel utilisateur

Document No.: M-W3338AE-4.0

ANRITSU CORPORATION

•For safety and warning information, please read this

manual before attempting to use the equipment.

•

Additional safety and warning information is provided

within the

MS2830A Signal Analyzer Operation Manual

(Mainframe Operation), MS2840A Signal Analyzer

Operation Manual (Mainframe Operation) and the

MS2830A/MS2840A Signal Analyzer Vector Signal

Generator Option Operation Manual (Operation).

Please also refer to these documents before using the

equipment.

•

Keep this manual with the equipment.

Fourth Edition

MS2830A/MS2840A

Signal Analyzer

Vector Signal Generator

Operation Manual

Remote Control

Safety Symbols

To prevent the risk of personal injury or loss related to equipment malfunction, Anritsu Corporation uses the

following safety symbols to indicate safety-related information. Ensure that you clearly understand the meanings of

the symbols BEFORE using the equipment. Some or all of the following symbols may be used on all Anritsu

equipment. In addition, there may be other labels attached to products that are not shown in the diagrams in this

manual.

Symbols used in manual

This indicates a very dangerous procedure that could result in serious injury or

death if not performed properly.

This indicates a hazardous procedure that could result in serious injury or death if

not performed properly.

This indicates a hazardous procedure or danger that could result in light-to-severe

injury, or loss related to equipment malfunction, if proper precautions are not taken.

Safety Symbols Used on Equipment and in Manual

The following safety symbols are used inside or on the equipment near operation locations to provide information

about safety items and operation precautions. Ensure that you clearly understand the meanings of the symbols and

take the necessary precautions BEFORE using the equipment.

This indicates a prohibited operation. The prohibited operation is indicated

symbolically in or near the barred circle.

This indicates an obligatory safety precaution. The obligatory operation is

indicated symbolically in or near the circle.

This indicates a warning or caution. The contents are indicated symbolically in or

near the triangle.

This indicates a note. The contents are described in the box.

These indicate that the marked part should be recycled.

MS2830A/MS2840A

Signal Analyzer Vector Signal Generator

Operation Manual Remote Control

15 December 2009 (First Edition)

13 May 2016 (Fourth Edition)

publisher.

The contents of this manual may be changed without prior notice.

Printed in Japan

DANGER

WARNING

CAUTION

iii

Notes On Export Management

This product and its manuals may require an Export License/Approval by

the Government of the product's country of origin for re

-export

from your

country.

Before re

exporting the product or manuals, please contact us to confirm

whet

her they are export-controlled items or not.

When you dispose of export

controlled items, the products/manuals need

to be broken/shredded so as not to be unlawfully used for military purpose.

About This Manual

Composition of Operation Manuals

The operation manuals for the MS2830A/MS284A Signal Analyzer are

comprised as shown in the figure below.

MS2830A/MS2840A Signal Analyzer Vector Signal Generator

Operation Manual (Operation)

MS2690A/MS2691A/MS2692A and MS2830A/MS2840A Signal Analyzer

Vector Signal Generator Operation Manual (Standard Waveform Pattern)

Communication System Supporting IQproducerTM

Operation Manual

MS2690A/MS2691A/MS2692A and MS2830A/MS2840A Signal Analyzer

Vector Signal Generator Operation Manual (IQproducer™)

MS2830A/MS2840A Signal Analyzer Vector Signal Generator

Operation Manual (Remote Control)

MS2840A Signal Analyzer

Operation Manual

(Main Frame Operation)

MS2690A/MS2691A/MS2692A and MS2830A/MS2840A

Signal Analyzer Operation Manual (Main Frame Remote Control)

MS2830A Signal Analyzer

Operation Manual

(Main Frame Operation)

Signal Analyzer Operation Manual (Mainframe Operation)

Signal Analyzer Operation Manual (Mainframe Remote Control)

These manuals describe basic operating methods, maintenance

procedures, common functions, and common remote control of the signal

analyzer mainframe.

Vector Signal Generator Operation Manual (Operation)

This manual describes functions, operating methods, and so on of the

vector signal generator (option).

Vector Signal Generator Operation Manual (Remote Control) (This

manual)

This manual describes remote control of the vector signal generator

(option).

Vector Signal Generator Operation Manual (IQproducerTM)

This manual describes functions, operating methods, and so on of the

IQproducer, which is application software used with the vector signal

generator (option).

Vector Signal Generator Operation Manual (Standard Waveform

Pattern)

This manual describes details on the standard waveform pattern data

used with the vector signal generator (option).

III

Table of Contents

About This Manual........................................ I

Chapter 1 Overview.................................... 1-1

1.1 Overview ....................................................................... 1-2

Chapter 2 SCPI Device Message............... 2-1

2.1 Setting Frequency......................................................... 2-3

2.2 Setting Level ................................................................. 2-9

2.3 Controlling Waveform Patterns in Waveform Memory.. 2-26

2.4 Controlling Waveform Patterns in HDD/SSD................ 2-36

2.5 Modulation and AWGN Settings ................................... 2-44

2.6 External In/Output Settings........................................... 2-52

2.7 External output signal settings...................................... 2-66

2.8 Setting Trigger to Be Output to SG Marker

of SA/SPA ..................................................................... 2-77

2.9 Display Settings ............................................................ 2-79

2.10 Other Settings ............................................................... 2-81

Chapter 3 Native Device Message List..... 3-1

3.1 IEEE488.2 Common Device Messages........................ 3-2

3.2 Application Common Device Messages ....................... 3-4

3.3 Frequency Settings ....................................................... 3-7

3.4 Level Settings ............................................................... 3-8

3.5 Controlling Waveform Patterns in Waveform

Memory ......................................................................... 3-10

3.6 Controlling Waveform Patterns in HDD/SSD................ 3-12

3.7 Modulation and AWGN Settings ................................... 3-13

3.8 External Input Signal Settings....................................... 3-14

3.9 External Output Signal Settings.................................... 3-16

3.10 Setting Trigger to Be Output to SG Marker of

SA/SPA ......................................................................... 3-17

3.11 Display Settings ............................................................ 3-18

Chapter 4 Native Device Message Details 4-1

IV.

Chapter 1 Overview

1-1

Overview

This chapter provides an overview of the remote control of the Spectrum

Analyzer function (hereinafter, referred to as “this application”).

1.1 Overview .................................................................... 1-2

Chapter 1 Overview

1-2.

1.1 Overview

Automatic measurement can be performed by using this instrument in

connection with an external controller (PC). This instrument is

standardly equipped with GPIB, Ethernet, and USB interfaces. You can

also select a remote control command from the SCPI mode, which is a

command format defined by the SCPI Consortium, and Native mode,

which is our unique format.

See the

MS2690A/MS2691A/MS2692A and MS2830A/MS2840A Signal

Analyzer Operation Manual (Mainframe Remote Control)

for how to

switch the language mode.

You can use the Native mode by converting SCPI commands into Native

ones. See the

MS2690A/MS2691A/MS2692A and MS2830A/MS2840A

Signal Analyzer Operation Manual (Mainframe Remote Control)

for

details.
