AJAX MotionProtect Manuel utilisateur
Posted on May 27, 2021
MotionProtect is a wireless motion detector designed for indoor use. It can
operate for up to 5 years from an in-built battery, and monitors the area within
12-meter radius. MotionProtect ignores animals, while recognizes a human from
the first step.
MotionProtect Plus uses radio frequency scanning along with a thermal sensor,
filtering interference from thermal radiation. Can operate up to 5 years from an
in-built battery.
MotionProtect (MotionProtect Plus) operates within the Ajax security system,
connected to the via the protected protocol. The communication
range is up to 1700 (MotionProtect Plus up to 1200) meters in the line of sight.
In addition, the detector can be used as a part of third-party security central
units via the or integration modules.
The detector is set up via the
for iOS Android macOS and Windows
Th
e
sys
t
em
no
tifi
es
user
o
f
a
ll
even
t
s
th
roug
h
pus
h
no
tifi
ca
ti
ons,
SMS
an
d
ca
ll
s
(if activated).
The Ajax security system is self-sustaining, but the user can connect it to the
central monitoring station of a security company.
Thermal PIR sensor of MotionProtect detects intrusion into protected room by
detecting moving objects whose temperature is close to the temperature of the
1. LED indicator
2. Motion detector lens
3. SmartBracket attachment panel (perforated part is required for actuating the
tamper in case of any attempt to dismantle the detector)
4. Tamper button
5. Device switch
6. QR code
sensitivity has been chosen in the settings
.
When the MotionProtect Plus detects motion, it will additionally carry out radio
frequency scanning of the room, preventing false actuation from thermal
interferences: air flows from sun-heated curtains and louvre shutters, operating
thermal air fans, fireplaces, air conditioning units, etc.
After actuation, the armed detector immediately transmits an alarm signal to the
hub, activating the sirens and notifying the user and security company.
If before arming the system, the detector has detected motion, it will not arm
immediately, but during the next inquiry by the hub.
Before starting connection:
Only users with administrator rights can add the device to the hub
How to connect the detector to the hub:
1. Following the hub manual recommendations, install the .
Create an account, add the hub to the application, and create at least one
room.
2. Switch on the hub and check the internet connection (via Ethernet and/or
GSM network).
3. Make sure that the hub is disarmed and does not update by checking its
status in the app.
1. Select theAdd Deviceoption in the Ajax application.
2. Name the device, scan/write manually the QR Code (located on the body
For detection and pairing to occur, the detector should be located within the
coverage of the wireless network of the hub (at a single protected object).
Request for connection to the hub is transmitted for a short time at the moment
of switching on the device.
If the detector failed to connect to the hub, switch off the detector for 5 seconds
3. Select Add — the countdown will begin.
4. Switch on the device.
of the detector statuses in the list depends on the device inquiry time set in the
hub settings(default value is 36 seconds).
To connect the detector to a third party security central unit with the
or integration module, follow the recommendations in the
manuals of these devices.
Parameter Value
Temperature Temperature of the Detector. Measured on the
processor and changes gradually
Jeweller Signal Strength Signal strength between the hub and the
detector
Connection Connection status between the hub and the
detector
Battery Charge
Battery level of the device. Displayed as a
percentage
Lid The tamper mode of the detector, which reacts
to the detachment of or damage of the body
Delay When Entering, sec Delay time when entering
Delay When Leaving, sec Delay time when exiting
ReX Displays the status of using the ReX range
extender
Sensitivity Sensitivity level of the motion sensor
1. Devices
2. MotionProtect | MotionProtect Plus
Temporary Deactivation
deactivation function:
Firmware Detector firmware version
Device ID Device identifier
Setting Value
First field Detector name, can be edited
Room Selecting the virtual room to which the device is
assigned
Delay When Entering, sec Selecting delay time when entering
Delay When Leaving, sec Selecting delay time on exit
Delays in night mode Delay turned on when using night mode
No — the device operates normally and
transmits all events.
Lid only — the hub administrator has
disabled notifications about triggering on
the device body.
Entirely — the device is completely excluded
from the system operation by the hub
administrator. The device does not follow
system commands and does not report
alarms or other events.
By number of alarms — the device is
automatically disabled when the number of
alarms is exceeded (specified in the settings
for Devices Auto Deactivation). The feature
is configured in the Ajax PRO app.
1. Devices
2. MotionProtect | MotionProtect Plus
3. Settings
Alarm LED indication
Sensitivity
Choosing the sensitivity level of the motion
sensor.
For MotionProtect:
For MotionProtect Plus:
Always active If active, the detector always registers motion
Alert with a siren if motion detected If active, added to the systemare
activated when the motion detected
Jeweller Signal Strength Test Switches the detector to the signal strength test
mode
Detection Zone Test Switches the detector to the detection area test
Attenuation Test
Switches the detector to the signal attenuation
test mode (available in detectors with firmware
version 3.50 and later)
Allows the user to disconnect the device
without removing it from the system.
High — for premises with a minimum
amount of obstacles, motion is detected as
quickly as possible
Medium — for premises with potential
obstacles (windows, air conditioner, heating
element, etc)
Low — ignore pets weighing up to 20 kg and
up to 50 cm tall
High — the detector disregards cats (under
25 cm)
Medium — disregards small dogs (under 35
cm)
Low — disregards animals under 50 cm.
Temporary Deactivation
The system can also automatically disable
devices when the set number of alarms is
exceeded.
User Guide Opens the User Guide
Unpair Device Disconnects the detector from the hub and
deletes its settings
Before using the detector as a part of the security system, set up the suitable
sensitivity level.
Switch the Always Active if the detector is located in a room requiring 24-hour
control. Regardless of whether the system is set in the armed mode, you will
receive notices of any detected motion.
If any motion is detected, the detector activates the LED for 1 second and
transmits an alarm signal to the hub and then to the user and central monitoring
station (if it is connected).
Event Indication Note
Turning on the detector Lights up green for about one
second
Detector connection to the
Lid only
—
the system will ignore only
notifications about the triggering of the
device tamper button
up and goes off green
manual
The Ajax security system allows conducting tests for checking the functionality
of connected devices.
The tests do not start immediately but within a period of 36 seconds when using
the standard settings. The time of the start depends on the settings of the
detector polling period (the paragraph on Jeweller settings in the hub settings).
The controlled area and the efficiency of the security system depends on the
location of the detector.
The device developed only for indoor use.
Location of MotionProtect depends on the remoteness from the hub and
presence of any obstacles between the devices hindering the radio signal
transmission: walls, inserted floors, large-size objects located within the room.
Check the signal level at the installation location
If the signal level is at one bar, we cannot guarantee stable operation of the
security system. Take all possible measures to improve the quality of the signal!
As a minimum, move the device – even 20 cm shift can significantly improve the
quality of reception.
If after moving the device still has a low or unstable signal strength, use the
.
The direction of the detector lens should be perpendicular to the probable way of
intrusion into the room
Make sure that any furniture, domestic plants, vases, decorative or glass
structures do not block the field of view of the detector.
We recommend installing the detector at the height of 2,4 meters.
If the detector is not installed at the recommended height, this will reduce the
area of the motion detection zone and impair the operation of the function of
ignoring animals.
