ADMINISTRATIVE INFORMATION

SERVICE NOTE CLASSIFICATION:

MODIFICATION RECOMMENDED

ACTION

CATEGORY: X AGREEABLE TIME

STANDARDS

LABOR: 0.5 Hours

LOCATION

CATEGORY: X ON-SITE

X SERVICE CENTER

SERVICE

INVENTORY:N/A

USED

PARTS: N/A

AVAILABILITY: PRODUCT’S SUPPORT LIFE

NO CHARGE AVAILABLE UNTIL: 01-JAN-2011

AUTHOR: DYCS

PRODUCT LINE: WN

ADDITIONAL INFORMATION: This Service Note applies to the following PNA models: E8361A/C, E8362/3/4B/C and

E8362/3/4B/C-H85. Please refer to the Service Guide for troubleshooting procedure.

© AGILENT TECHNOLOGIES, INC. 2009

PRINTED IN U.S.A.

December 18, 2009

Rev. 16 Page 1 of 4

E8361C-07

S E R V I C E N O T E

Supersedes:

NONE

E8361C PNA Microwave Network Analyzers

Serial Numbers: "[US00000000 / US99999999] or ALL"

An enhancement added to absorb vibration when opening the swing deck

during hardware repair.

Parts Required:

P/N Description Qty.

E8361-40001 Bumper 1

Page 2 of 4 E8361C-07

Situation:

A bumper is available to enhance the serviceability and to protect nearby assembly from swing deck.

Solution/Action:

A rubber bumper –E8361-40001 is available to improve the serviceability of the instrument. This will

also ensure the swing deck well separated from other nearby assembly.

Refer to the PNA Service Guide for instruction on removing the PNA front panel. To view this

Service Guide information, use the following steps:

1. Go to http://na.tm.agilent.com/pna/documents.html.

2. Click on the appropriate Service Guide.

3. When the PDF of the Service Guide is displayed, look at the bookmarks in the left column. Expand

the Contents section by clicking on the plus sign next to its bookmark.

4. Scroll through the Contents section bookmarks to locate “Repair & Replacement Procedures.”

5. Click on the title/hyperlink for the section “Receiver Deck.”

6. Follow the instructions in the subsection “Raising and Lowering the Receiver Deck.”

7. Once the Receiver Deck has been lower, installed the Bumper as shown in Figure 2.

Figure 1

Bumper, E8361-40001

Page 3 of 4 E8361C-07

Figure 2

Figure 3

P

Pl

la

ac

ce

e

B

Bu

um

mp

pe

er

r

H

He

er

re

e

Page 4 of 4 E8361C-07

Figure 4

Figure 5
