Advantech UPOS-211 Manuel utilisateur

User Manual

UPOS-211

Intel® Celeron®J1900/Core™ i5

6300U/Core™ i3 6100U/Celeron®

3955U Processor-based

Ubiquitous POS with 15" TFT

LCD

UPOS-211 User Manual ii

The documentation and the software included with this product are copyrighted 2017

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to improve the products described in this manual at any time without notice. No part

of this manual may be reproduced, copied, translated, or transmitted in any form or

by any means without the prior written permission of Advantech Co., Ltd. The infor-

mation provided in this manual is intended to be accurate and reliable. However,

Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements

of the rights of third parties that may result from its use.

Acknowledgements

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows is registered trademark of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

Product Warranty (2 years)

Advantech warrants the original purchaser that all of its products will be free from

defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products that have been repaired or altered by

persons other than repair personnel authorized by Advantech, or products that have

been subject to misuse, abuse, accident, or improper installation. Under the terms of

this warranty, Advantech assumes no liability as a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most

customers never need to use our repair service. If an Advantech product is defective,

it will be repaired or replaced free of charge during the warranty period. For out-of-

warranty repairs, customers will be billed the cost of replacement materials, service

time, and freight. Please consult your dealer for more details.

If you suspect your product is defective, follow the steps outlined below.

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any onscreen messages that are displayed when the

problem occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any relevant information to hand.

3. If your product is diagnosed as defective, obtain a return merchandize authori-

zation (RMA) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a completed Repair and Replacement

Order Card, and a proof of purchase date (such as a photocopy of your sales

receipt) into a shippable container. Products returned without a proof of pur-

chase date are not eligible for warranty service.

5. Write the RMA number clearly on the outside and ship the package prepaid to

your dealer.

Part No. 2008211D10 Edition 1

Printed in China October 2017

iii UPOS-211 User Manual

Warnings, Cautions, and Notes

Document Feedback

To assist us in improving this manual, we welcome any comments and constructive

criticisms. Please send all feedback in writing to support@advantech.com

Technical Support and Assistance

1. Visit the Advantech website at http://support.advantech.com to obtain the latest

product information.

2. Contact your distributor, sales representative, or Advantech's customer service

center for technical support if you need additional assistance. Please have the

following information ready before calling:

–Product name and serial number

–Description of your peripheral attachments

–Description of your software (operating system, version, application software, etc.)

–Comprehensive description of the problem

–The exact wording of any error messages

Packing List

Before setting up the system, check that the items listed below are included in the

shipment and in good condition.

UPOS-211 Series

–Warranty card

–Adaptor

–User manual

–2 x COM Cable

–1 x HDD Bracket

If any of these items are missing or damaged, please contact your distributor or sales

representative immediately.

Warning! Warnings indicate conditions that if not observed, can cause personal

injury!

Caution! Cautions are included to help prevent hardware damage or data losses.

For example,

“New batteries are at risk of exploding if incorrectly installed. Do not

attempt to recharge, force open, or heat the battery. Replace the battery

only with the same or equivalent type recommended by the manufac-

turer. Discard used batteries according to the manufacturer's instruc-

tions.”

Note! Notes provide additional optional information.

UPOS-211 User Manual iv

Safety Instructions

1. Read these safety instructions carefully.

2. Retain this user manual for future reference.

3. Disconnect this equipment from all AC outlets before cleaning. Use only a damp

cloth to clean. Do not use liquid or spray detergents.

4. For pluggable equipment, the power outlet socket must be located near the

equipment and easily accessible.

5. Protect this equipment from humidity.

6. Place this equipment on a reliable surface during installation. Dropping or letting

the device fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment

from overheating. Do not cover the openings.

8. Ensure the voltage is correct before connecting the equipment to a power outlet.

9. Position the power cord away from high-traffic areas. Do not place anything over

the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If unused for a long time, disconnect the equipment from the power source to

avoid damage from transient overvoltage.

12. Never pour liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be

opened only by qualified service personnel.

14. If one of the following situations occurs, have the equipment checked by service

personnel:

The power cord or plug is damaged.

Liquid has penetrated the equipment.

The equipment has been exposed to moisture.

The equipment is malfunctioning, or does not operate according to the user

manual.

The equipment has been dropped and damaged.

The equipment has obvious signs of breakage.

15. Do not store this equipment in an environment where the temperature fluctuates

below -20 °C (-4 °F) or above 60 °C (140 °F) as this may cause damage. The

equipment should be stored in a controlled environment.

16. Batteries are at risk of exploding if incorrectly installed. Replace only with the

same or equivalent type recommended by the manufacturer. Discard used bat-

teries according to the manufacturer’s instructions.

The sound pressure level at the operator position does not exceed 70 dB (A) in

accordance with IEC 704-1:1982.

DISCLAIMER: These instructions are provided according to IEC 704-1. Advantech

disclaims all responsibility for the accuracy of any statements contained herein.

v UPOS-211 User Manual

Safety Precaution - Static Electricity

Follow these simple precautions to protect yourself from harm and the products from

damage.

To avoid electrical shock, always disconnect the power from your PC chassis

before you work on it. Don't touch any components on the CPU card or other

cards while the PC is on.

Disconnect power before making any configuration changes. The sudden rush

of power as you connect a jumper or install a card may damage sensitive elec-

tronic components.

UPOS-211 User Manual vi

vii UPOS-211 User Manual

Contents

Chapter 1 General Information ............................1

1.1 Introduction ............................................................................................... 2

1.2 Specifications ............................................................................................ 2

1.2.1 General Specifications .................................................................. 2

1.2.2 Environmental Specifications........................................................ 2

1.2.3 Touch Screen................................................................................ 2

1.2.4 LCD Specifications........................................................................ 3

1.3 Dimensions ............................................................................................... 3

Chapter 2 System Setup.......................................5

2.1 Quick Tour of the Device........................................................................... 6

Figure 2.1 Front view of UPOS-211............................................. 6

Figure 2.2 Rear view of UPOS-211 ............................................. 6

Figure 2.3 IO Connectors of UPOS-211 ...................................... 7

2.2 Installation Procedures.............................................................................. 7

2.2.1 Connecting the Power Cord.......................................................... 7

2.2.2 Connecting the Mouse and Keyboard........................................... 7

2.2.3 Activating the Power Source......................................................... 7

2.3 Installing System Software........................................................................ 8

2.4 Installing the HDD ..................................................................................... 9

2.5 Peripheral Cable Connection & Arrangement ......................................... 14

2.6 How to select Windows 7 ........................................................................ 18

2.7 Jumpers and Connectors ........................................................................ 19

Table 2.1: Jumpers.................................................................... 19

Table 2.2: Connectors ............................................................... 20

2.8 PenMount 6000 Multiple-Monitors set sop.............................................. 21

2.9 Capacitive touch extends display setup .................................................. 23

2.10 Peripheral and base ................................................................................ 25

2.10.1 MSR ............................................................................................ 25

2.10.2 VESA mount ............................................................................... 26

2.10.3 10-inch screen ............................................................................ 27

2.10.4 2nd display.................................................................................. 28

2.10.5 VDF............................................................................................. 31

2.10.6 Barcode scanner......................................................................... 33

2.10.7 Wall mount .................................................................................. 35

Chapter 3 BIOS Setup

(UPOS-211D)37

3.1 Introduction ............................................................................................. 38

3.2 BIOS Setup ............................................................................................. 38

3.2.1 Main Menu .................................................................................. 39

3.2.2 Advanced BIOS Features ........................................................... 40

3.2.3 Configuration Setting .................................................................. 53

3.2.4 Security Configuration Setting .................................................... 58

3.2.5 Boot Configuration ...................................................................... 59

3.2.6 Save & Exit Configuration Setting............................................... 60

Chapter 4 BIOS Setup

UPOS-211 User Manual viii

(UPOS-211F)61

4.1 Introduction ............................................................................................. 62

4.2 BIOS Setup ............................................................................................. 62

4.2.1 Main Menu .................................................................................. 62

4.2.2 Advanced BIOS Features ........................................................... 63

4.2.3 Chipset Configuration Setting ..................................................... 75

4.2.4 Security Configuration Setting .................................................... 79

4.2.5 Boot Configuration ...................................................................... 80

4.2.6 Save & Exit Configuration Setting............................................... 81

Chapter 1

1General Information

This chapter provides basic

information regarding UPOS-211.

Introduction

Specifications

Dimensions

UPOS-211 User Manual 2

1.1 Introduction

UPOS-211 is an all-in-one point-of-sale (POS) system that features a small footprint

and dual-hinge design, making it ideal for countertops and limited-space installations.

3955U processors, UPOS-211 ensures high-performance computing and reliable

data processing, while supporting flexible customization for diverse applications. The

IP65-rated front panel is water and dust resistance. UPOS-211 is a competitive cost,

and energy effective platform built for retail and hospitality.

1.2 Specifications

1.2.1 General Specifications

Dimensions (W x H x D): 354x327x237 mm, stand: 237 x 200 mm

Weight: 5.2 kg (Net Weight) / 6.9 kg (Gross Weight)

Power supply:

–60W (100-240Vac,50-60Hz,1.5A) power adapter

Storage: 1 x 2.5" SATA HDD/SSD connector

CPU: Intel® Celeron®J1900/Core™ i5 6300U/Core™ i3 6100U/Celeron®

3955U processors.

RAM: Support 1 x 204-pin DDR3L 1333 Mhz SO-DIMM, up to 8 GB/ 1 x 260-pin

DDR4 2333 Mhz SO-DIMM, up to 16GB

Serial ports:

–External: 2 x COM RS232 ports via RJ-48 connector,

–Internal: 4 x COM port, COM3 for touch, COM6 no power, COM4, 5 support

5V & 12V by order via box header

USB:

–UPOS-211F: 2xUSB3.0,3xUSB2.0

–UPOS-211D: 1xUSB3.0,4xUSB2.0

Front panel: IP65 sealed front panel with true flat touch screen

Cash drawer: 1 x RJ11

Ethernet: 1 x RJ-45 Gigabit LAN

Display port: 1 x VGA, 1 x DP

Expansion slot: 1 x Mini PCIe (for Wifi or 3G), shared with mini SATA

connector

Audio: 1 x Speaker

LPT port: 1 LPT port (optional)

1.2.2 Environmental Specifications

Operating Temperature: 0 ~ 40 °C (32 ~ 104 °F)

Relative humidity: 10 ~ 90% @ 40 °C (non-condensing)

Shock: 10 G peak acceleration (11 ms duration)

Vibration: 5 ~ 500 Hz 0.5 Grms, random

Certification: CCC, CE, UL, FCC, CB, BSMI

1.2.3 Touch Screen

Type: True Flat, 5-Wire Resistive Touch / Projected CAP Touch

Light Transmission: 80% +/-5% / 80%+/-3%
