Advantech EKI-4524I Manuel utilisateur

EKI-4524I

24-port 10/100TX Ethernet

Switch with AC/DC Power

Input

User Manual

The documentation and the software included with this product are copyrighted 2011 by

Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make

improvements in the products described in this manual at any time without notice. No part of

this manual may be reproduced, copied, translated or transmitted in any form or by any

means without the prior written permission of Advantech Co., Ltd. Information provided in this

manual is intended to be accurate and reliable. However, Advantech Co., Ltd. assumes no

responsibility for its use, nor for any infringements of the rights of third parties, which may

result from its use.

Acknowledgements

All other product names or trademarks are properties of their respective owners.

Part No.

Printed in China

2nd Edition

Feb 2011

EKI-4524I_User Manual ii

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its products will be free from

defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products which have been repaired or altered by persons

other than repair personnel authorized by Advantech, or which have been subject to misuse,

abuse, accident or improper installation. Advantech assumes no liability under the terms of

this warranty as a consequence of such events.

Because of Advantech′s high quality-control standards and rigorous testing, most of our

customers never need to use our repair service. If an Advantech product is defective, it will be

repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you

will be billed according to the cost of replacement materials, service time and freight. Please

consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, network speed,

Advantech products used, other hardware and software used, etc.) Note anything

abnormal and list any onscreen messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your manual, product, and any

helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandize

authorization) number from your dealer. This allows us to process your return more

quickly.

4. Carefully pack the defective product, a fully-completed Repair and Replacement Order

Card and a photocopy proof of purchase date (such as your sales receipt) in a shippable

container. A product returned without proof of the purchase date is not eligible for

warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid to your

dealer.

iii

Declaration of Conformity

This product has passed the CE test for environmental specifications. Test conditions for

passing included the equipment being operated within an industrial enclosure. In order to

protect the product from being damaged by ESD (Electrostatic Discharge) and EMI leakage,

we strongly recommend the use of CE-compliant industrial enclosure products.

FCC Class A

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the user will be required to correct

the interference at his own expense.

Technical Support and Assistance

Step 1. Visit the Advantech web site at www.advantech.com/support where you can find

the latest information about the product.

Step 2. Contact your distributor, sales representative, or Advantech’s customer service

center for technical support if you need additional assistance. Please have the

following information ready before you call:

- Product name and serial number

- Description of your peripheral attachments

- Description of your software (operating system, version, application software,

etc.)

- A complete description of the problem

- The exact wording of any error messages

EKI-4524I_User Manual iv

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User's Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not

use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the equipment and

must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may

cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment from

overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the equipment to

the power outlet.

9. Position the power cord so that people cannot step on it. Do not place anything over the

power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source to avoid

damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be opened only by

qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service personnel:

a. The power cord or plug is damaged.

b. Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

d. The equipment does not work well, or you cannot get it to work according to the user's

manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE

TEMPERATURE MAY GO BELOW -40℃(-40℉) OR ABOVE 85℃(185 ℉). THIS

COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN A

CONTROLLED ENVIRONMENT.

Safety Precaution - Static Electricity

Follow these simple precautions to protect yourself from harm and the products from damage.

1. To avoid electrical shock, always disconnect the power from your equipment chassis

before you work on it.

2. Disconnect power before making any configuration changes.

EKI-4524I_User Manual vi

vii Contents

Contents

Chapter 1 Overview...........................................2

1.1 Introduction ......................................................... 2

1.1.1 High-Speed Transmissions ....................... 2

1.1.2 19” Rack Mounting .................................... 2

1.1.3 Advanced Protection ................................. 2

1.1.4 Easy Troubleshooting................................ 2

1.2 Features.............................................................. 3

1.3 Specifications...................................................... 4

1.4 Packing List ........................................................ 6

1.5 Safety Precaution ............................................... 6

Chapter 2 Installation........................................8

2.1 LED Indicators .................................................... 8

Table 2.1: EKI-4524I LED Definition.......................................8

2.2 Dimensions (units: mm) ...................................... 9

Figure 2.1: EKI-4524I Mechanical Dimensions........................9

2.3 Mounting ........................................................... 10

2.3.1 Rack mounting......................................... 10

Figure 2.2: Attach mounting brackets with screws..................10

Figure 2.3: Mount the switch in the 19” rack ..........................10

2.4 Network Connection ......................................... 11

2.5 Wiring Power Input ........................................... 12

Table 2.2: Terminal Block Pinouts..........................................12

Figure 2.4: 10-position Cross Screw Terminal Block .............12

2.6 Wiring Relay Alarm Contacts............................ 13

Figure 2.5: Fail-Safe Relay Contacts.......................................13

Chapter 3 Troubleshooting ............................16

Appendix A Pin Assignments & Wiring.........18

Figure A.1: RJ-45 Pin Assignments.........................................18

Figure A.2: EIA/TIA-568B......................................................18

Figure A.2: EIA/TIA-568A .....................................................18

EKI-4524I_User Manual viii

1 Chapter1

Overview

Sections include:

zIntroduction

zFeatures

zSpecifications

zPacking List

zSafety Precaution

CHAPTER

Chapter 1 Overview

1.1 Introduction

The EKI-4524I is a cost-effective solution, which meets the high reliability requirements

demanded by industrial applications. The equipment supports both DC and AC power

inputs. Besides, the EKI-4524I is designed for the applications supposed to have

certain electric interference. Equipped with isolated power and isolated communication

ports, the device has high resistance toward electrical noise. It has been proved to

work well for any harsh applications.

1.1.1 High-Speed Transmissions

The EKI-4524I includes a switch controller that can automatically sense transmission

speeds (10/100 Mbps). The RJ-45 interface can also be auto-detected, so MDI or MDI-

X is automatically selected and a crossover cable is not required. All Ethernet ports

have memory buffers that support the store-and-forward mechanism. This assures that

data is properly transmitted.

1.1.2 19” Rack Mounting

The EKI-4524I comes with a rack-mounted kit and can be mounted in an EIA standard

size, 19-inch Rack. The Switch can be placed in a wiring closet with other equipment.

1.1.3 Advanced Protection

The power line of EKI-4524I supports up to 4,000 VDC EFT protection, which secures

equipment against unregulated voltage and makes systems safer and more reliable,

while 8,000 VDC ESD protection for Ethernet ports makes the equipment more suitable

for harsh environments.

1.1.4 Easy Troubleshooting

LED indicators make troubleshooting quick and easy. Each 10/100 Base-TX port has

LED indicators that display the link status, transmission speed and collision status.

EKI-4524I_User Manual 2
