EDG-6528

8-Port Industrial 10/100 Mbps

Ethernet Switch

User Manual

EDG-6528 User Manual ii

The documentation and the software included with this product are copy-

righted 2005 by Advantech Co., Ltd. All rights are reserved. Advantech

Co., Ltd. reserves the right to make improvements in the products

described in this manual at any time without notice. No part of this man-

ual may be reproduced, copied, translated or transmitted in any form or

by any means without the prior written permission of Advantech Co., Ltd.

Information provided in this manual is intended to be accurate and reli-

able. However, Advantech Co., Ltd. assumes no responsibility for its use,

nor for any infringements of the rights of third parties, which may result

from its use.

Part No. 2003652803 4th Edition

Printed in Taiwan January 2006

iii

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its prod-

ucts will be free from defects in materials and workmanship for two years

from the date of purchase.

This warranty does not apply to any products which have been repaired or

altered by persons other than repair personnel authorized by Advantech,

or which have been subject to misuse, abuse, accident or improper instal-

lation. Advantech assumes no liability under the terms of this warranty as

a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous test-

ing, most of our customers never need to use our repair service. If an

Advantech product is defective, it will be repaired or replaced at no

charge during the warranty period. For out-of-warranty repairs, you will

be billed according to the cost of replacement materials, service time and

freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For

example, CPU speed, Advantech products used, other hardware

and software used, etc.) Note anything abnormal and list any

onscreen messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your man-

ual, product, and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return

merchandize authorization) number from your dealer. This allows

us to process your return more quickly.

4. Carefully pack the defective product, a fully-completed Repair and

Replacement Order Card and a photocopy proof of purchase date

(such as your sales receipt) in a shippable container. A product

returned without proof of the purchase date is not eligible for war-

ranty service.

5. Write the RMA number visibly on the outside of the package and

ship it prepaid to your dealer.

EDG-6528 User Manual iv

This product has passed the CE test for environmental specifications. Test

conditions for passing included the equipment being operated within an

industrial enclosure. In order to protect the product from being damaged

by ESD (Electrostatic Discharge) and EMI leakage, we strongly recom-

mend the use of CE-compliant industrial enclosure products.

FCC Class A

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interfer-

ence when the equipment is operated in a commercial environment. This

equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in

which case the user will be required to correct the interference at his own

expense.

Technical Support and Assistance

Step 1. Visit the Advantech web site at www.advantech.com/support

where you can find the latest information about the product.

Step 2. Contact your distributor, sales representative, or Advantech's cus-

tomer service center for technical support if you need additional

assistance. Please have the following information ready before

you call:

- Product name and serial number

- Description of your peripheral attachments

- Description of your software (operating system, version, appli-

cation software, etc.)

- A complete description of the problem

- The exact wording of any error messages

Document Feedback

To assist us in making improvements to this manual, we would welcome

comments and constructive criticism. Please send all such - in writing to:

[email protected]

Contents

Chapter 1 Introduction ..................................................... 2

1.1 Features ............................................................................. 2

1.2 Feature Summary .............................................................. 3

1.3 Specifications .................................................................... 4

1.4 Packing List....................................................................... 6

1.5 Ordering Information ........................................................ 6

1.6 Safety Precaution............................................................... 6

Chapter 2 Installation ....................................................... 8

2.1 LED Definitions ................................................................ 8

Table 2.1:EDG-6528 LED Definition ........................... 8

2.2 Dimensions........................................................................ 9

Figure 2.1:EDG-6528 Front Panel and Dimension ....... 9

2.3 Mounting ......................................................................... 10

2.3.1 Panel Mounting ............................................................ 10

Figure 2.2:Attaching the Bracket ................................. 10

Figure 2.3:Panel Mounting .......................................... 10

2.3.2 DIN-rail Mounting ....................................................... 11

Figure 2.4:Attaching the DIN-rail Mounting Kit ......... 11

Figure 2.5:DIN-rail Mounting. .................................... 11

2.3.3 DIN-rail Dismounting .................................................. 12

Figure 2.6:DIN-rail Dismounting ................................ 12

2.4 Network Connections...................................................... 13

2.4.1 Connection to Devices ................................................. 13

2.4.2 Connection to Other Hubs or Switches ........................ 13

2.5 Power Connections.......................................................... 14

Figure 2.7:Pin Assignment of the Power Connector ... 14

EDG-6528 User Manual vi

CHAPTER

Introduction

Sections include:

• Features

• Specifications

• Packing List

• Ordering Information

• Safety Precaution

EDG-6528 User Manual 2

Chapter 1 Introduction

1.1 Features

The EDG-6528 is an industrial-grade Ethernet switch for fast and cost-

effective expansion of industrial Ethernet networks. The EDG-6528 has

eight 10/100 Mbps Ethernet ports to connect up to eight Ethernet devices.

Moreover, EDG-6528 has industrial-grade design that assures high reli-

ability and stability. Therefore, EDG-6528 is an excellent solution for

industrial environments with Ethernet networking, such as: semi-conduc-

tor factories, inventory control environments, assembly lines and produc-

tion facilities.

High-Speed Transmission

The EDG-6528 includes a switch controller that can automatically sense

transmission speeds. (10/100 Mbps) The RJ-45 interface can also be auto-

detected, so MDI or MDI-X is automatically selected and a crossover

cable is not required. All Ethernet ports have memory buffers that support

the store-and-forward mechanism. This assures that data is properly

transmitted.

Dual Power Inputs (does not include EDG-6528L)

To reduce the risk of power failure, the EDG-6528 provides dual power

inputs. If there is a power failure, EDG-6528 will automatically switch to

the secondary power input.

Flexible Mounting

EDG-6528 is extremely compact and can be mounted on a DIN-rail or a

panel, so it is suitable for any space-constrained environment.

Advanced Protection for Power line and Ethernet Port

The power line of EDG-6528 supports up to 3000 VDC surge protection,

which secure equipment against unregulated voltage and make systems

safer and more reliable. Meanwhile, 4000 V DC ESD protection for

Ethernet ports (not including EDG-6528L) make EDG-6528 more suit-

able for harsh environments.

3 Chapter1

Wide Operating Temperature Range

The operating temperature of the EDG-6528 is between 0 and 70° C, and

the EDG-6528I can operate between -40 and 85° C. With such a wide

range you can use the EDG-6528 in some of the harshest industrial envi-

ronments that exist.

Easy to Trouble-Shoot

LED indicators make troubleshooting quick and easy. Each port has

LEDs that display the link status, power failure, and port activity for

immediate on-site diagnosis. (See 2.1)

1.2 Feature Summary

• Provides 8 x 10/100 Mbps Ethernet ports with RJ-45 connector

• Supports dual power inputs (not including EDG-6528L)

• Supports full/half duplex flow control

• Supports MDI/MDI-X auto crossover

• Provides broadcast storm protection

• Embedded with a switch controller, supports auto-negotiation

• Embedded with the memory buffer, supports store-and-forward trans-

mission

• Supports +12 ~ 48 VDC voltage

• Provides 3000 VDC surge protection for power line

• Provides 4000VDC ESD protection for Ethernet Ports

(not including EDG-6528L)

• Provides flexible mounting: DIN rail and panel mounting

• Supports wide-range operating temperature

• 128 KB of SRAM on chip for frame buffering

• Integrated address Look-Up Engine, supports 1K absolute MAC

addresses

EDG-6528 User Manual 4

1.3 Specifications

Communications

Standard IEEE 802.3, 802.3u,802.3x

LAN 10/100Base-TX

Transmission Distance 100 m (Ethernet)

Transmission Speed up to 100 Mbps

Interface

Connectors 8 x RJ-45

LED Indicators Power, Fault, Link, 10/100 Mbps

Power

Power Connectors 5-pin removable screw terminal

Power Consumption Max.3.1 W

Power Input EDG-6528/6528I: 2 x Unregulated 12~48 V DC

EDG-6528L: 1 x Unregualted 12~48 VDC

Fault Output Present

Mechanism

Dimensions (WxHxD) 56x134x114 mm

Enclosure Metal shell with PC side panel

(mounting kits included))

Mounting DIN 35 rail, wall

Table des matières

Autres manuels Advantech Routeur réseau

Advantech

Advantech B+B SMARTWORX SmartStart SL302 Manuel utilisateur

Advantech

Advantech SmartStart SL304 Manuel utilisateur

Advantech

Advantech SmartFlex SR304 Manuel utilisateur

Advantech

Advantech EKI2726FHPI Series Manuel d'installation et d'exploitation

Advantech

Advantech ICR-2701 Manuel utilisateur

Advantech

Advantech SmartFlex SR308 Manuel utilisateur

Advantech

Advantech SmartMotion ST352 Manuel utilisateur

Advantech

Advantech SmartFlex SR307 Manuel utilisateur

Advantech

Advantech ICR-2436 Manuel utilisateur

Advantech

Advantech EKI-4524I Manuel utilisateur

Advantech

Advantech SmartFlex SR307 Manuel utilisateur

Advantech

Advantech B+B SmartWorx AirborneM2M BB-ABDN-ER-DP553 Manuel utilisateur

Advantech

Advantech ICR-1601G Feuille d'instructions

Advantech

Advantech UR5i v2 Libratum Manuel utilisateur

Advantech

Advantech SmartStart Series Mode d’emploi

Advantech

Advantech ICR-4434 Manuel utilisateur

Advantech

Advantech B+B SmartWorx SE416 Manuel utilisateur

Advantech

Advantech SL305 Manuel utilisateur

Advantech

Advantech EKI-1222R-CE Manuel utilisateur

Advantech

Advantech EKI-7659C Manuel utilisateur

Advantech

Advantech LR77 v2 Series Manuel utilisateur

Advantech

Advantech B&B SmartWorx ESWGP506-2SFP-T Manuel utilisateur

Advantech

Advantech SmartMotion ST352 Manuel utilisateur

Advantech

Advantech ICR-2437 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
