Advantech XR5i v2 Manuel utilisateur

Ethernet Industrial Router

XR5i v2

USER’S MANUAL

USED SYMBOLS

Used symbols

Danger – Information regarding user safety or potential damage to the router.

Attention – Problems that can arise in speciﬁc situations.

Information, notice – Useful tips or information of special interest.

GPL licence

Source codes under GPL licence are available free of charge by sending an email to:

cellularsales@advantech-bb.com.

Advantech B+B SmartWorx s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Manual Rev. 1 released in CZ, July 25, 2016

CONTENTS

Contents

1 Safety Instruction 2

2 WEEE directive 3

3 Router Description 4

4 Contents of Package 5

5 Router Design 6

5.1 Router versions .................................... 6

5.2 Delivery identiﬁcation ................................ 7

5.3 Order codes ...................................... 8

5.4 Basic dimensions of the router box ......................... 9

5.4.1 Plastic box .................................. 9

5.4.2 Metal box ................................... 9

5.5 Mounting recommendations ............................. 10

5.6 Removing from the DIN rail ............................. 12

5.7 Description of the front panel ............................ 13

5.7.1 Status indication ............................... 14

5.7.2 Power connector PWR ............................ 15

5.7.3 Ethernet Port ETH .............................. 16

5.7.4 PORT1 .................................... 17

5.7.5 PORT2 .................................... 17

5.7.6 USB Port ................................... 18

5.7.7 I/O Port .................................... 18

5.7.8 Reset ..................................... 20

6 First Use 21

6.1 Connecting the router before ﬁrst use ....................... 21

6.2 Start .......................................... 22

6.3 Conﬁguration ..................................... 22

6.3.1 Conﬁguration over web browser ....................... 22

6.3.2 Conﬁguration over Telnet .......................... 23

7 Technical Parameters 24

7.1 Basic parameters ................................... 24

7.2 Standards and regulations .............................. 24

7.3 Technical parameters of processor ......................... 25

CONTENTS

7.4 Technical parameters of I/O port .......................... 25

7.5 Technical parameters of expansion port ...................... 25

8 Recommended Literature 26

9 Troubleshooting 27

9.1 FAQ .......................................... 27

10 Customers Support 29

iii

LIST OF FIGURES

List of Figures

1 Contents of package ................................. 5

2 Front panel XR5i v2F ................................. 6

3 Front panel XR5i v2F with WiFi ........................... 6

4 Front panel XR5i v2F SL ............................... 6

5 Front panel XR5i v2F SL with WiFi ......................... 6

6 Label XR5i v2F .................................... 7

7 Label XR5i v2F SL .................................. 7

8 Basic dimensions of plastic box (bottom and front view) ............. 9

9 Basic dimensions of metal box (bottom and front view) .............. 9

10 Cable routing (plastic) ................................ 10

11 Cable routing (metal) ................................. 10

12 Space in front of connectors (plastic) ........................ 11

13 Space in front of connectors (metal) ........................ 11

14 Default position of DIN holder ............................ 12

15 Removing from the DIN rail ............................. 12

16 Front panel XR5i v2F ................................. 13

17 Power connector ................................... 15

18 Connection of power supply ............................. 15

19 Ethernet connector .................................. 16

20 Connection of ethernet cable ............................ 16

21 PORT1 cable connection .............................. 17

22 PORT2 cable connection .............................. 18

23 USB connector .................................... 18

24 I/O connector ..................................... 19

25 Connection of I/O cable ............................... 19

26 Connection of input and output to the router .................... 19

27 Router reset ...................................... 20

28 Router connection .................................. 21

29 Entering the IP address of the router ........................ 22

30 Entering login information .............................. 22

31 Router web interface ................................. 23

LIST OF TABLES

List of Tables

1 Router versions .................................... 6

2 Delivery identiﬁcation ................................ 7

3 Ordering codes .................................... 8

4 Front panel description ................................ 13

5 Status indication ................................... 14

6 Connection of power connector ........................... 15

7 Connection of Ethernet connector .......................... 16

8 Connection of USB connector ............................ 18

9 Connection of I/O port ................................ 18

10 Description of reset and restart router ....................... 20

11 Basic parameters ................................... 24

12 Standards and regulations .............................. 24

13 Technical parameters of processor ......................... 25

14 Technical parameters of I/O port .......................... 25

1. SAFETY INSTRUCTION

1. Safety Instruction

Please, observe the following instructions:

•The router must be used in compliance with all applicable international and national laws

and in compliance with any special restrictions regulating the utilization of the router in

prescribed applications and environments.

•To prevent possible injury to health and damage to appliances and to ensure that all the

relevant provisions have been complied with, use only the original accessories. Unau-

thorised modiﬁcations or utilization of accessories that have not been approved may

result in damage to the router and in a breach of applicable regulations. Unauthorized

modiﬁcations or utilization of accessories that have not been approved may result in the

termination of the validity of the guarantee.

•The router can not be opened.

•It must not be exceeded by the maximum voltage 36 V DC power connector on the router.

•Do not expose the router to extreme ambient conditions. Protect the router against dust,

moisture and high temperature.

•The router should not be used at petrol stations of ﬂammable and explosive materials.

We remind the users of the duty to observe the restrictions concerning the utilization of

radio devices at petrol stations, in chemical plants, or in the course of blasting works in

which explosives are used.

•When using the router in the close proximity of personal medical devices, such as cardiac

pacemakers or hearing aids, you must proceed with heightened caution.

•If it is in the proximity of TV sets, radio receivers and personal computers, the telephone

may cause interference.

•It is recommended that you should create an appropriate copy or backup of all the im-

portant settings that are stored in the memory of the device.

2. WEEE DIRECTIVE

2. Product Disposal Instructions

The WEEE (Waste Electrical and Electronic Equipment: 2002/96/EC) directive has been

introduced to ensure that electrical/electronic products are recycled using the best available

recovery techniques to minimize the impact on the environment. This product contains high

quality materials and components which can be recycled. At the end of it’s life this product

MUST NOT be mixed with other commercial waste for disposal. Check the terms and condi-

tions of your supplier for disposal information.

3. ROUTER DESCRIPTION

3. Router Description

Industrial router XR5i v2 is used to a secure connection between two local area networks

(LANs) via two ETHERNET interfaces 10/100 and secured tunnel (IPSec, OpenVPN or L2TP).

The second option is to use this router for connecting two devices with different serial interface

(RS232, RS485, MBUS) alternatively I/O to the local network (LAN). In this conﬁguration, the

communication device has an EHTERNET 10/100 and two interfaces that are equipped on

the user’s request.

XR5i v2 router is standardly equipped with one ETHERNET 10/100 port, one USB A (host)

port, one I/O port and two expansion ports. Users can select a second ETHERNET 10/100

port, serial interface RS232, RS485, RS422, MBUS, expansion port with SD card (SDH) or

other inputs/outputs (I/O). Industrial XR5i v2 router is supplied either in a plastic or metal

casing, based on the requirements of the customer.

Conﬁguration is performed via web interface and protected by password. The router sup-

ports creation of VPN tunnels using technologies IPsec, OpenVPN and L2TP to ensure safe

communication. Web interface provides detail statistics about the router activities.

Other diagnostic functions ensuring continuous communication include automatic function-

ality inspection, or hardware Watchdog which monitors the status of the router. With the help

of a special window (start up script window) you may insert Linux scripts for various actions.

For some applications the key option to create several different conﬁgurations for one wire-

less router, the so-called proﬁles (maximum of 4), and the option to switch between them (for

example via binary input status, web interface, etc.) is essential.

The industrial router XR5i v2 has implemented SNMP protocol for remote management.

It is also possible to conﬁgure the network in bulk and use any additional software – VPN

SmartCluster conﬁgurator to easily conﬁgure a VPN or a program for monitoring routers in

the network R-SeeNet. Industrial XR5i v2 router is enhanced by the ability to create custom

functions easy integration of custom software modules.

Examples of possible applications

•security system

•monitoring

•vending and dispatcher machines

4. CONTENTS OF PACKAGE

4. Contents of Package

Basic delivered set of router includes:

•router,

•power supply,

•crossover UTP cable,

•up to one external antenna,

•clip for the DIN rail,

•paper start guide.

Figure 1: Contents of package

Temperature range for power supply is reduced to 0 ◦C to +40 ◦C!

As optional accessories can also be supplied the following expansion ports (two boards for

Full version):

•RS232, RS485/422, MBUS, ETHERNET, CNT, SWITCH, WIFI, WMBUS or SDH.

•Separation columns for mounting expansion boards are included.
