Advantech UR5i v2 Libratum Manuel utilisateur

HSPA+ Industrial Router

UR5i v2 Libratum

USER MANUAL

UR5i v2 Libratum

Advantech B+B SmartWorx – Americas

Advantech B+B SmartWorx

707 Dayton Road

Ottawa, IL 61350 USA

Website

www.advantech-bb.com

Advantech B+B SmartWorx – Europe

Advantech B+B SmartWorx s.r.o.

Sokolska 71

562 04, Usti nad Orlici,

Czech Republic

Website

www.advantech-bb.com

2020 Advantech B+B SmartWorx s.r.o. No part of this publication may be reproduced or transmitted in any

form or by any means, electronic or mechanical, including photography, recording, or any information storage and

retrieval system without written consent. Information in this manual is subject to change without notice, and does

not represent a commitment on the part of Advantech B+B SmartWorx.

Advantech B+B SmartWorx s.r.o. shall not be liable for incidental or consequential damages resulting from

the furnishing, performance, or use of this manual.

All brand names used in this manual are the registered trademarks of their respective owners. The use of

trademarks or other designations in this publication is for reference purposes only and does not constitute an

endorsement by the trademark holder.

UR5i v2 Libratum

Used symbols

Danger – Information regarding user safety or potential damage to the router.

Attention – Problems that can arise in speciﬁc situations.

Information, notice – Useful tips or information of special interest.

GPL licence

Source codes under GPL licence are available free of charge by sending an email to:

[email protected].

Please see http://ep.advantech-bb.cz/devzone for more information.

Advantech B+B SmartWorx s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Document No. MAN-0017-EN, revision from January 9, 2020. Released in the Czech Republic.

UR5i v2 Libratum

Contents

1 Safety Instructions 2

2 WEEE directive 3

3 Router Description 4

4 Contents of Package 5

5 Router Design 6

5.1 Router versions .................................... 6

5.2 Delivery identiﬁcation ................................ 7

5.3 Order codes ...................................... 7

5.3.1 Order code structure ............................. 7

5.3.2 Order code examples ............................ 8

5.4 Basic dimensions of the router box ......................... 9

5.4.1 Plastic box .................................. 9

5.4.2 Metal box ................................... 9

5.5 Mounting recommendations ............................. 10

5.6 Removal from the DIN rail .............................. 12

5.7 Description of the front panel ............................ 13

5.7.1 Status indication ............................... 14

5.7.2 Power connector PWR ............................ 15

5.7.3 Antenna connector ANT, DIV (and WIFI) .................. 16

5.7.4 SIM card reader ............................... 17

5.7.5 Ethernet port (ETH0 and ETH1) ...................... 18

5.7.6 Reset ..................................... 19

6 First Use 20

6.1 Connecting the router before ﬁrst use ....................... 20

6.2 Start .......................................... 21

6.3 Conﬁguration ..................................... 21

6.3.1 Conﬁguration over web browser ....................... 21

6.3.2 Conﬁguration over Telnet .......................... 22

7 Technical Parameters 23

7.1 Basic parameters ................................... 23

7.2 Standards and regulations .............................. 23

7.3 Technical parameters of module .......................... 24

UR5i v2 Libratum

7.4 Technical Parameters of WiFi ............................ 25

7.5 Other Technical Parameters ............................. 25

8 Recommended Literature 26

9 Troubleshooting 27

9.1 FAQ .......................................... 27

10 Customers Support 30

10.1 Customer Support for NAM ............................. 30

10.2 Customer Support for Europe ............................ 30

10.3 Customer Support for Asia ............................. 30

iii

UR5i v2 Libratum

List of Figures

1 Contents of package ................................. 5

2 Front panel UR5i v2L ................................. 6

3 Front panel UR5i v2L with WiFi ........................... 6

4 Front panel UR5i v2L SL ............................... 6

5 Front panel UR5i v2L SL with WiFi ......................... 6

6 Label examples .................................... 7

7 Basic dimensions of plastic box (bottom and front view) ............. 9

8 Basic dimensions of metal box (bottom and front view) .............. 9

9 Space around antennas (plastic) .......................... 10

10 Space around antennas (metal) ........................... 10

11 Cable routing (plastic) ................................ 11

12 Cable routing (metal) ................................. 11

13 Space in front of connectors (plastic) ........................ 11

14 Space in front of connectors (metal) ........................ 11

15 Default position of plastic and metal DIN rail clip ................. 12

16 Removal from the DIN rail .............................. 12

17 Front panel UR5i v2 Libratum ............................ 13

18 Power connector ................................... 15

19 Connection of power supply ............................. 15

20 Connecting of the antenna .............................. 16

21 Ejected SIM holder .................................. 17

22 Ethernet connector .................................. 18

23 Connection of ethernet cable ............................ 18

24 Router reset ...................................... 19

25 Router connection .................................. 20

26 Entering the IP address of the router ........................ 21

27 Entering login information .............................. 21

28 Router web interface ................................. 22

UR5i v2 Libratum

List of Tables

1 Router versions .................................... 6

2 Delivery identiﬁcation ................................ 7

3 Type of port #2 .................................... 7

4 Type of router box .................................. 8

5 Type of power supply ................................. 8

6 Speciﬁc variation ................................... 8

7 Order code examples ................................ 8

8 Front panel description ................................ 13

9 Status indication ................................... 14

10 Value ranges of signal strength for different technologies. ............ 14

11 Connection of power connector ........................... 15

12 Connection of Ethernet connector .......................... 18

13 Description of reset and restart router ....................... 19

14 Basic parameters ................................... 23

15 Standards and regulations .............................. 24

16 Technical parameters of module .......................... 24

17 Technical parameters of WiFi ............................ 25

18 Other technical parameters ............................. 25

UR5i v2 Libratum

1. Safety Instructions

Please, observe the following instructions:

•The router must be used in compliance with all applicable international and national laws

and in compliance with any special restrictions regulating the utilization of the router in

prescribed applications and environments.

•The router can only be used in the ﬁxed location such as labs or computer facilities by

skilled person or engineer.

•To prevent possible injury and damage to appliances and to ensure compliance with

all relevant provisions, use only the original accessories. Unauthorized modiﬁcations or

the use of unapproved accessories may result in damage to the router and / or a breach

of applicable regulations. Unauthorized modiﬁcations or use of unapproved accessories

may void the warranty.

•The router can not be opened.

•Turn off the router and disconnect it from power supply before handling the SIM card.

•Caution! The SIM card could be swallowed by small children.

•Input voltage must not exceed 36 V DC max.

•Do not expose the router to extreme ambient conditions. Protect the router against dust,

moisture and high temperature.

•Only routers with appropriate certiﬁcation and labelling should be used in locations where

ﬂammable and explosive materials are present, including gas stations, chemical plants,

or locations in which explosives are used. We remind users of the duty to observe the

restrictions concerning the utilization of radio devices at such places.

•Switch off the router when traveling by plane. Utilization of the router on a plane may

endanger the operation of the plane or interfere with the mobile telephone network, and

may be unlawful. Failure to observe these instructions may result in the suspension or

cancellation of telephone services for the respective client and / or may result in legal

sanctions.

•When using the router in close proximity to personal medical devices, such as cardiac

pacemakers or hearing aids, you must proceed with heightened caution.

•The router may cause interference when used in close proximity to TV sets, radio re-

ceivers or personal computers.

•It is recommended that you create an appropriate copy or backup of all important settings

that are stored in the memory of the device.

UR5i v2 Libratum

2. Product Disposal Instructions

The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) directive was in-

troduced to ensure that electrical/electronic products are recycled using the best available

recovery techniques in order to minimize impact on the environment. This product contains

high quality materials and components which can be recycled. At the end of it’s life this pro-

duct MUST NOT be mixed with other commercial waste for disposal. The device contains the

battery. Remove the battery from the device before disposal. The battery in the device needs

to be disposed apart accordingly. Check the terms and conditions of your supplier for disposal

information.

UR5i v2 Libratum

3. Router Description

HSPA+ router UR5i v2 Libratum is used to wirelessly connect various equipments and

devices via Ethernet interface 10/100 to the internet or intranet. Thanks to high data transfer

speed of up to 14,4 Mbps (download) and 5,76 Mbps (upload) it is an ideal wireless solution

for trafﬁc and security camera systems, individual computers, LAN networks, automatic teller

machines (ATM) and other self-service terminals, etc.

As a standard, cellular router UR5i v2 Libratum is equipped with two Ethernet 10/100 and

two SIM cards. This wireless router is supplied either in a plastic or metal casing, based on

the requirements of the customer.

Conﬁguration is done via web interface protected by password. The UR5i v2 Libratum

router supports creation of VPN tunnels using technologies IPsec, OpenVPN and L2TP to

ensure safe communication. Web interface provides detail statistics about the 3G router activ-

ities, signal strength, detailed log, etc. Cellular router supports functions: DHCP, NAT, NAT-T,

DynDNS, NTP, VRRP, control by SMS and many other function.

Other diagnostic functions ensuring continuous communication include automatic inspec-

tion of PPP connection offering an automatic restart feature – in case of connection losses, or

hardware watchdog which monitors the status of the router. With the help of a special window

(start up script window) you may insert Linux scripts for various actions. For some applications

the key option to create several different conﬁgurations for one HSPA+ wireless router, the so-

called proﬁles (maximum of 4), and the option to switch between them (for example via SMS,

binary input status, etc.) is essential. Cellular routers UR5i v2 Libratum may automatically

upgrade conﬁguration and ﬁrmware from server. This allows mass reconﬁguration of many

routers in one time.

The router also supports additional software like R-SeeNet for permanent trafﬁc monitoring

of routers or communication VPN server Digicluster.

Examples of possible applications

•mobile ofﬁce

•ﬂeet management

•security system

•telematic

•telemetric

•remote monitoring

•vending and dispatcher machines

Autres manuels pour UR5i v2 Libratum

Table des matières

Autres manuels Advantech Routeur réseau

Advantech

Advantech MIC-3666 Manuel utilisateur

Advantech

Advantech ICR-2441 Manuel utilisateur

Advantech

Advantech B+B SmartWorx AirborneM2M BB-ABDN-ER-DP553 Manuel utilisateur

Advantech

Advantech EKI-7659C Manuel utilisateur

Advantech

Advantech SmartFlex SR304 Manuel utilisateur

Advantech

Advantech ICR-1601 Feuille d'instructions

Advantech

Advantech SmartFlex SR303 Manuel utilisateur

Advantech

Advantech SmartFlex SR300 Manuel utilisateur

Advantech

Advantech ICR-4453W Mode d’emploi

Advantech

Advantech SmartStart Series Mode d’emploi

Advantech

Advantech SmartFlex SR304 Manuel utilisateur

Advantech

Advantech ICR-1601G Feuille d'instructions

Advantech

Advantech B+B SmartWorx SE416 Manuel utilisateur

Advantech

Advantech EKI-7529MI Manuel utilisateur

Advantech

Advantech ICR-4453S Manuel utilisateur

Advantech

Advantech ICR-3211 Mode d’emploi

Advantech

Advantech ICR-2412 Manuel utilisateur

Advantech

Advantech SmartFlex SR305 Manuel utilisateur

Advantech

Advantech ICR-4434S Manuel utilisateur

Advantech

Advantech ER75s Manuel utilisateur

Advantech

Advantech SmartStart SL304 Manuel utilisateur

Advantech

Advantech SmartStart SL302 Manuel utilisateur

Advantech

Advantech ICR-2734 Manuel utilisateur

Advantech

Advantech SmartMotion ST352 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
