PCA-6188

Socket 478 Pentium® 4/Cele-

ron® Full-sized Processor

Card with PCI-X/ DDR / VGA /

Dual GbE / 800 MHz FSB

User’s Manual

PCA-6188 User’s Manual ii

This document is copyrighted, 2004, by Advantech Co., Ltd. All rights

are reserved. Advantech Co., Ltd. reserves the right to make improve-

ments to the products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated or transmit-

ted in any form or by any means without the prior written permission of

Advantech Co., Ltd. Information provided in this manual is intended to

be accurate and reliable. However, Advantech Co., Ltd. assumes no

responsibility for its use, nor for any infringements upon the rights of

third parties which may result from its use.

Acknowledgements

•AWARD is a trademark of Phoenix Technologies Ltd.

•IBM and PC are trademarks of International Business Machines Corpo-

ration.

•Intel®, Pentium® 4, and Celeron™ are trademarks of Intel Corporation.

•WinBond is a trademark of Winbond Corporation.

All other product names or trademarks are the properties of their respec-

tive owners.

Part No. 2002618800 1st. Edition

Printed in Taiwan Aug 2004

iii

1.0.1 A Message to the Customer

Advantech customer services

Each and every Advantech product is built to the most exacting specifica-

tions to ensure reliable performance in the harsh and

demanding conditions typical of industrial environments. Whether your

new Advantech equipment is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and

ease of operation for which the name Advantech has come to be known.

Your satisfaction is our primary concern. Here is a guide to

Advantech’s customer services. To ensure you get the full benefit of our

services, please follow the instructions below carefully.

Technical support

We want you to get the maximum performance from your products. So if

you run into technical difficulties, we are here to help. For the most fre-

quently asked questions, you can easily find answers in your product doc-

umentation. These answers are normally a lot more detailed than the ones

we can give over the phone.

So please consult this manual first. If you still cannot find the answer,

gather all the information or questions that apply to your problem, and

with the product close at hand, call your dealer. Our dealers are well

trained and ready to give you the support you need to get the most from

your Advantech products. In fact, most problems reported are minor and

are able to be easily solved over the phone.

In addition, free technical support is available from Advantech engineers

every business day. We are always ready to give advice on application

requirements or specific information on the installation and operation of

any of our products.

PCA-6188 User’s Manual iv

Table 1.1: PCA-6188 comparison table

Model PCA-6188VG-00A1 PCA-6188G2-00A1

VGA:ATi Mobility Radeon

9600 Pro VGA controller

on board

Yes Yes

USB 2.0 port 4 4

LAN 1: Intel 82547

10/100/1000Base-T

Yes Yes

LAN 2: Intel 82541

10/100/1000Base-T

No Yes

Table 1-2: PCA-6188 DDR memory compatibility table

Brand Size Speed Type ECC Part Number Memory Full Load *

Apacer 256MB DDR266 DDR N/A 77.10603.112 Infineon HYB25D25680BT-7(32×8) N/A

Kingston 256MB DDR266 DDR N/A N/A Nanya NT5DS32MBAT-6 N/A

256MB DDR266 DDR N/A "KVR256X64C25/256 "Kingston D328DM-60(32×8) N/A

512MB DDR266 DDR N/A KVR266X64C25/512 Kingston D328DL-60(32×8) N/A

512MB DDR266 DDR N/A 9905006-30.A00 Kingston D328DP-75 N/A

Apacer 512MB DDR333 DDR N/A N/A SAMSUNG K4H560838C-TCB3(32×8) N/A

Transcend 256MB DDR333 DDR N/A TS32MLD64V3F5 SAMSUNG K4H560838D-TCB3(32×8) N/A

512MB DDR333 DDR N/A N/A SAMSUNG K4H560838C-TCB3(32×8) N/A

Samsung 256MB DDR333 DDR N/A N/A SAMSUNG K4H560838F-TCB3(32×8) V

Kingston 512MB DDR333 DDR N/A KVR333X64C25/512 Kingston D328DM-60(32×8) N/A

512MB DDR333 DDR N/A N/A Nanya NT5DS32MBAT-6 N/A

Apacer 256MB DDR400 DDR N/A 77.10639.535 PSC A2S56D30ATP -5(32×8) V

512MB DDR400 DDR N/A 77.10736.19G Infineon HYB25D256807BT-5(32×8) v

Transcend 256MB DDR400 DDR N/A TS32MLD64V4F3 MOSEL V58C2256804SAT5(32×8) v

Samsung 512MB DDR400 DDR N/A N/A SAMSUNG K4H560838F-TCCC(32×8) v

UG 1GB DDR266 DDR N/A N/A Hynix HY5DU128822AT-H v

Apacer 512MB DDR333 DDR N/A 77.10728.56G Mosel V58C2256804SAT5B v

DSL 512MB DDR333 DDR N/A N/A SAMSUNG K4H560838F-TCB3 v

1GB DDR333 DDR N/A N/A SAMSUNG K4H510838B-TCB3 v

Transcend 1GB DDR333 DDR N/A N/A SAMSUNG K4H560438E-TCB3 v

Apacer 256MB DDR400 DDR N/A 77.10636.115 Infineon HYB25D256800BT-5 v

256MB DDR400 DDR N/A 77.10636.465 SAMSUNG K4H560838E-TCCC v

512MB DDR400 DDR N/A 77.10736.114 Infineon HYB25D256800BT-5 v

512MB DDR400 DDR N/A 77.10736.56G Mosel V58C2256804SAT5B v

512MB DDR400 DDR N/A 77.10736.464 SAMSUNG K4H560838E-TCCC v

1GB DDR400 DDR N/A 77.11136.464 SAMSUNG K4H510838B-TCCC v

DSL 256MB DDR400 DDR N/A N/A Hynix HY5DU56822BT-D43 v

256MB DDR400 DDR N/A N/A SAMSUNG K4H560838E-TCCC v

Kingston 256MB DDR400 DDR N/A N/A Hynix HY5DU56822CT-D43 v

Transcend 1GB DDR400 DDR N/A N/A SAMSUNG K4H510838B-TCCC v

UG 512MB DDR400 DDR N/A N/A Hynix HY5DU56822CT-D43 v

Apacer 512MB DDR333 DDR v 77.10735.114 Infineon HYB25D256800BT-6 v

512MB DDR333 DDR v 77.10735.464 SAMSUNG K4H560838E-TCB3 v

1GB DDR333 DDR v 77.11135.464 SAMSUNG K4H510838B-TCB3 v

Apacer 512MB DDR400 DDR v 77.10738.114 Infineon HYB25D256800BT-5 v

1GB DDR400 DDR v 77.11138.464 SAMSUNG K4H510838B-TCCC v

Transcend 256MB DDR400 DDR v N/A Mosel V58C22568004SAT5 v

512MB DDR400 DDR v N/A Mosel V58C22568004SAT5 v

Full Load* : Supports 4 modules inserted in four slots as two pairs of Dual-channel memory configuration

PCA-6188 User’s Manual vi

1.0.1 Product warranty

Advantech warrants to you, the original purchaser, that each of its prod-

ucts will be free from defects in materials and workmanship for two years

from the date of purchase.

This warranty does not apply to any products which have been repaired or

altered by persons other than repair personnel authorized by Advantech,

or which have been subject to misuse, abuse, accident or improper instal-

lation. Advantech assumes no liability under the terms of this warranty as

a consequence of such events.

If an Advantech product is defective, it will be repaired or replaced at no

charge during the warranty period. For out-of-warranty repairs, you will

be billed according to the cost of replacement materials, service time and

freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

Step 1. Collect all the information about the problem encountered. (For

example, type of PC, CPU speed, Advantech products used,

other hardware and software used, etc.) Note anything abnormal

and list any on-screen messages you get when the problem

occurs.

Step 2. Call your dealer and describe the problem. Please have your man-

ual, product, and any helpful information readily available.

Step 3. If your product is diagnosed as defective, obtain an RMA (return

material authorization) number from your dealer. This allows us

to process your return more quickly.

Step 4. Carefully pack the defective product, a fully-completed Repair

and Replacement Order Card and a photocopy proof of purchase

date (such as your sales receipt) in a shippable container. A prod-

uct returned without proof of the purchase date is not eligible for

warranty service.

Step 5. Write the RMA number visibly on the outside of the package and

ship it prepaid to your dealer.

vii

1.0.2 Initial Inspection

Before you begin installing your single board computer, please make sure

that the following materials have been shipped:

If any of these items are missing or damaged, contact your distributor or

sales representative immediately.

We have carefully inspected the PCA-6188 mechanically and electrically

before shipment. It should be free of marks and scratches and in perfect

working order upon receipt.

As you unpack the PCA-6188, check it for signs of shipping damage.

(For example, damaged box, scratches, dents, etc.) If it is damaged or it

fails to meet the specifications, notify our service department or your

local sales representative immediately. Also notify the carrier. Retain the

shipping carton and packing material for inspection by the carrier. After

inspection, we will make arrangements to repair or replace the unit.

1.0.3 Release Note

1 PCA-6188 Pentium® 4/Celeron® processor-based single board computer

1 PCA-6188 Startup Manual

1 CD with driver utility and manual (in PDF format)

1 FDD cable P/N: 1700340640

2 Ultra ATA 66/100 HDD cables P/N: 1701400452

2 Serial ATA HDD data cable P/N: 1700071000

2 Serial ATA HDD power cable P/N: 1703150102

1 ATX 12V power converter cable P/N: 170304015K

1 Printer (parallel) port & COM port cable kit P/N: 1700060305

1 Dual COM port cable kit P/N: 1701092300

1 Y cable for PS/2 keyboard and PS/2 mouse P/N: 1700060202

2 Two USB ports cable P/N 1700100170

1 DVI cable P/N:1700000821

1 VGA cable p/n: P/N:1700000259

1 Video Cable( S / Composite terminal) P/N:1700000784

Warranty card

Date Revision Description

August 2004 1st. Edition Initial Release

PCA-6188 User’s Manual viii

Important Safety Information

SAFETY INSTRUCTIONS

This device complies with the requirements in part 15 of the FCC

rules: Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference

that may cause undesired operation

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide rea-

sonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio fre-

quency energy and, if not installed and used in accordance with the instruction manual,

may cause harmful interference to radio communications. Operation of this device in a

residential area is likely to cause harmful interference in which case the user will be

required to correct the interference at his/her own expense. The user is advised that any

equipment changes or modifications not expressly approved by the party responsible for

compliance would void the compliance to FCC regulations and therefore, the user's

authority to operate the equipment.

CAUTION!!

There is a danger of a new battery exploding if it is incorrectly installed. Do not

attempt to recharge, force open, or heat the battery. Replace the battery only with

the same or equivalent type recommended by the manufacturer. Discard used bat-

teries according to the manufacturer’s instructions.

Table 1.1:PCA-6188 comparison table.......................... iv

Chapter 1 Hardware Configuration .................................2

1.1 Introduction ....................................................................... 2

1.2 Features ............................................................................. 3

1.3 Specifications .................................................................... 4

1.3.1 System............................................................................. 4

1.3.2 Memory........................................................................... 4

1.3.3 Input/Output.................................................................... 4

1.3.4 VGA interface................................................................. 5

1.3.5 Ethernet LAN.................................................................. 5

1.3.6 Industrial features ........................................................... 5

1.3.7 Mechanical and environmental specifications................ 5

1.4 Jumpers and Connectors.................................................... 6

Table 1.1:Jumpers........................................................... 6

Table 1.2:Connectors ...................................................... 6

1.5 Board Layout: Jumper and Connector Locations.............. 8

Figure 1.1:Jumper and Connector locations ................... 8

1.6 PCA-6188 Block Diagram ............................................... 9

Figure 1.2: ..................................................................... 9

1.7 Safety Precautions .......................................................... 10

1.8 Jumper Settings ............................................................... 11

1.8.1 How to set jumpers ....................................................... 11

1.8.2 CMOS clear (J1) ........................................................... 11

Table 1.3:CMOS (J1).................................................... 11

1.8.3 Watchdog timer output (J2) .......................................... 11

Table 1.4:Watchdog timer output (J2).......................... 12

1.9 System Memory .............................................................. 12

1.9.1 CPU FSB and memory speed ....................................... 13

Table 1.5:CPU FSB and memory speed ....................... 13

1.9.2 Dual channel configuration........................................... 13

1.10 Memory Installation Procedures ..................................... 14

1.11 Processor Installation ...................................................... 14

Chapter 2 Connecting Peripherals .................................16

2.1 Introduction ..................................................................... 16

2.2 1st & 2nd (CN1, CN2) IDE Connectors ......................... 16

2.3 Floppy Drive Connector (CN3)....................................... 17

2.4 Parallel Port (CN4).......................................................... 17

2.5 USB Ports (CN6,CN63) .................................................. 18

2.6 VGA Connector CN7...................................................... 18

2.7 CRT-2 connector VCN2.................................................. 19

2.8 LVDS connector VCN4 .................................................. 19

2.9 DVI connector VCN5...................................................... 20

2.10 Ethernet Connector (CN24) ............................................ 20

PCA-6188 User’s Manual x

2.11 Serial Ports (COM1 : CN23; COM2 : CN10 ) ................ 21

2.12 PS/2 Keyboard/Mouse Connector (CN11)...................... 21

2.13 External Keyboard Connector (CN12)............................ 22

2.14 CPU Fan Connector (CN14) ........................................... 22

2.15 Front Panel Connectors (CN16, 17, 18, 19, 21&29)....... 23

2.15.1 Power LED (CN16) ...................................................... 23

2.15.2 External speaker (CN17) .............................................. 23

2.15.3 Reset (CN18) ................................................................ 23

2.15.4 HDD LED (CN19)........................................................ 24

2.15.5 ATX soft power switch (CN21).................................... 24

2.15.6 SM Bus Connector (CN29)........................................... 24

2.16 ATX feature connector (CN20)....................................... 24

2.17 AC-97 Audio interface (CN43)....................................... 25

2.18 Serial ATA interface (SA0 and SA1).............................. 25

2.19 Connecting to SNMP-1000 remote manager .................. 26

2.20 Auxiliary 4-pin power connector (ATX1) ...................... 26

Chapter 3 Award BIOS Setup.........................................28

3.1 Introduction ..................................................................... 28

3.1.1 CMOS RAM Auto-backup and Restore ....................... 28

3.2 Entering Setup ................................................................. 29

Figure 3.1:Award BIOS Setup initial screen ................ 29

3.3 Standard CMOS Setup .................................................... 29

Figure 3.2:Standard CMOS features screen ................. 29

3.4 Advanced BIOS Features ................................................ 30

Figure 3.3:Advanced BIOS features screen.................. 30

3.4.1 Hard Disk Boot Priority................................................ 30

3.4.2 Virus Warning............................................................... 30

3.4.3 CPU L1 & L2, L3 Cache .............................................. 30

3.4.4 Hyper-Threading Technology....................................... 30

3.4.5 Quick Power On Self Test ............................................ 31

3.4.6 First/Second/Third Boot Device .................................. 31

3.4.7 Boot Other Device ........................................................ 31

3.4.8 Swap Floppy Drive ...................................................... 31

3.4.9 Boot Up Floppy Seek.................................................... 31

3.4.10 Boot Up NumLock Status............................................. 31

3.4.11 Gate A20 Option........................................................... 31

3.4.12 Typematic Rate Setting................................................. 31

3.4.13 Typematic Rate (Chars/Sec) ......................................... 31

3.4.14 Typematic Delay (msec)............................................... 31

3.4.15 Security Option ............................................................. 32

3.4.16 APIC Mode................................................................... 32

3.4.17 MPS Version Control For OS....................................... 32

3.5 Advanced Chipset Features............................................. 33

Figure 3.4:Advanced chipset features screen ............... 33

Autres manuels pour PCA-6188

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Advantech Matériel informatique

Advantech

Advantech AIMC-3422 Manuel d'installation et d'exploitation

Advantech

Advantech FWA-6510 Manuel d'installation et d'exploitation

Advantech

Advantech FWA-1211 Manuel d'installation et d'exploitation

Advantech

Advantech EIS-D210 Manuel utilisateur

Advantech

Advantech SOM-2532 Series Manuel utilisateur

Advantech

Advantech PCIE-1158 Manuel d'installation et d'exploitation

Advantech

Advantech PCIe-1674 Manuel utilisateur

Advantech

Advantech MIC-7 Series Manuel d'installation et d'exploitation

Advantech

Advantech FWA-3050 Manuel utilisateur

Advantech

Advantech SOM-6883 Manuel utilisateur

Advantech

Advantech PCA-6004V-00A1 Manuel utilisateur

Advantech

Advantech PCA-6119P7 Manuel d'installation et d'exploitation

Advantech

Advantech MIO-5377 Manuel d'installation et d'exploitation

Advantech

Advantech PCL-848A/B Manuel utilisateur

Advantech

Advantech IPC-619 Manuel utilisateur

Advantech

Advantech ASMB-785 Manuel d'installation et d'exploitation

Advantech

Advantech PCM-4141 Series Manuel utilisateur

Advantech

Advantech ECU-P1628D Manuel d'installation et d'exploitation

Advantech

Advantech MIC-75M20 Manuel d'installation et d'exploitation

Advantech

Advantech RSB-4221 Manuel utilisateur

Advantech

Advantech PCE-5B09-06 Manuel d'installation et d'exploitation

Advantech

Advantech ASMB-815 Series Manuel utilisateur

Advantech

Advantech ARK-3202 Manuel utilisateur

Advantech

Advantech PCE-7214 Manuel d'installation et d'exploitation

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
