ADLINK Technology NuIPC cPCI-3700 Manuel utilisateur

NuIPC

cPCI-3700

3U CompactPCI All-in-one

Socket 370 CPU Module

User’s Guide

Manual Rev. 1.10: 26 June 2000

The information in this document is subject to change without prior notice in

order to improve reliability, design and function and does not represent a

commitment on the part of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special, incidental,

orconsequentialdamagesarisingoutoftheuseor inability to use the product or

documentation, even if advised of the possibility of such damages.

This document contains proprietary information protected by copyright. All rights

are reserved. No part of this manual may be reproduced by any mechanical,

electronic, or other means in any form without prior written permission of the

manufacturer.

Trademarks

NuIPC is a registered trademark of ADLINK Technology Inc. Other product

names mentioned herein are used for identification purposes only and may be

trademarks and/or registered trademarks of their respective companies.

Getting service from ADLINK

Customer Satisfaction is always the most important thing for ADLINK

Technology Inc. If you need any help or service, please contact us and get it.

ADLINK Technology Inc.

Web Site http://www.adlink.comtw

Sales & Service [email protected]

Technical NuDAQ [email protected]

Support NuDAM [email protected]

NuIPC [email protected]

NuPRO [email protected]

Software [email protected]

TEL +886-2-82265877 FAX +886-2-82265717

Address 9F, No. 166, Jian Yi Road, Chungho City, Taipei, 235 Taiwan, R.O.C.

Please inform or FAX us of your detailed information for a prompt, satisfactory

and constant service. Detailed Company Information

Company/Organization

Contact Person

E-mail Address

Address

Country

TEL FAX

Web Site

Questions

Product Model

¨OS

¨Compute

Environment to Use ¨M/B : ¨CPU :

¨Chipset : ¨Bios :

¨Video Card :

¨Network Interface Card :

¨Other :

Challenge Description

SuggestionstoADLINK

Contents • i

Contents

Chapter 1 Introduction......................................1

1.1 Checklist..................................................................1

1.2 Description..............................................................1

1.3 Features...................................................................2

1.4 Specifications..........................................................2

1.5 Intelligence..............................................................4

Chapter 2 Installation........................................5

2.1 CPU Installation ......................................................5

2.2 Memory Installation ................................................6

2.3 Jumpers on the cPCI-3700.....................................6

2.4 Connectors on the cPCI-3700...............................8

2.4.1 The cPCI-3700 Processor Board........................................8

2.4.2 USB Connectors......................................................................9

2.4.3 Parallel Port Connector.........................................................9

2.4.4 COM1 Serial Ports..................................................................9

2.4.5 PS/2 Keyboard Connector...................................................10

2.4.6 PS/2 Mouse Connector........................................................10

2.4.7 VGA CRT Connector..............................................................10

2.4.8 JP4: IrDA Connector.............................................................12

2.4.9 EIDE Connector......................................................................12

2.4.10 J6:CPU Fan Power Connector............................................14

2.4.11 Floppy Drive Connector.......................................................14

2.4.12 CompactPCI Connectors.....................................................15

2.5 Watchdog Timer Configuration..........................17

Chapter 3 BIOS Configuration ......................19

3.1 BIOS Introduction.................................................19

3.2 BIOS Setup............................................................19

Chapter 4 Bus Master IDE Driver Installation

4.1 System Requirements..........................................21

4.2 Installing the Software.........................................21

ii •Contents

Chapter 5 VGA Driver Installation................ 24

5.1 Installing the Drivers for Windows 95............... 24

5.2 Installing the Drivers for Windows 98............... 25

5.3 Installing the Drivers for Windows NT 4.0........ 25

Chapter 6 System Monitor Utility ................. 26

Introduction •1

Introduction

Thismanualisdesignedtogiveyouinformation on the cPCI-3700 CPU module.

The topics covered in this chapter are as follows:

ØChecklist

ØDescription

ØFeatures

ØSpecifications

1.1 Checklist

Pleasecheckthatyourpackageiscompleteandcontainstheitemsbelow.Ifyou

discover damaged or missing items, please contact your dealer.

ØThe cPCI-3700 module

ØThis User’s Manual

ØADLINK All-in-one CD

1.2 Description

ThecPCI-3700isaSocket-370 processor board for 3U CompactPCI form factor.

The board is based on the Intel 440BX chipset and is fully designed for harsh

industrial environment. It features a Socket-370 processor connector that is

compatible with Intel Celeron processors.

2• Introduction

1.3 Features

ØCPU Speed 300~533MHz, Intel Celeron processors

ØBus Speed 66MHz

ØIntel 440BX AGPset

ØSODIMM socket support up to128 SDRAM system memory

ØC&T 69000 VGA chipset for CRT displays

ØTwoRS-232 serial ports, one is on the front I/O, the another is on the J2

rear I/O

Ø16 level programmable watchdog timer, from 0-30 seconds

ØHigh speed bi-directional SPP/ECP/EPP parallel port

ØHardware Monitoring

1.4 Specifications

ØProcessor Socket:Socket 370 connector

ØProcessor:Intel Celeron 300~533MHz

ØBus Speed: 66MHz

ØChipset:Intel 440BX AGPset with PCI EIDE and RTC built-in

ØSecondary Cache:CPU integrated

ØMemory Socket:

•One SO-DIMM socket

•Max. 128MB SDRAM

•Memory type: SDRAM (Synchronous DRAM)

ØBIOS: Award BIOS, PnP support

•FLASH EEPROM (256KB) for BIOS update

•Power management
