ADLINK Technology AMSTX-CF Series Manuel utilisateur

Leading EDGE COMPUTING

AMSTX-CF Series

User’s Manual

Embedded Motherboard supporting MXM Graphics Module with

8th/9th Generation Intel® Core™ i7/i5/i3 in LGA1151 Socket

Manual Rev.: 1.1

Revision Date: April 20, 2021

Part Number: 50M-00020-1010

ii Preface

Preface

means in any form without prior written permission of the manufacturer.

Disclaimer

The information in this document is subject to change without prior notice in order to improve reliability, design, and

function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer

be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use

the product or documentation, even if advised of the possibility of such damages.

Environmental Responsibility

ADLINK is committed to fulfill its social responsibility to global environmental preservation

through compliance with the European Union's Restriction of Hazardous Substances (RoHS)

directive and Waste Electrical and Electronic Equipment (WEEE) directive. Environmental

protection is a top priority for ADLINK. We have enforced measures to ensure that our products,

manufacturing processes, components, and raw materials have as little impact on the

environment as possible. When products are at their end of life, our customers are encouraged

to dispose of them in accordance with the product disposal and/or recovery programs

prescribed by their nation or company.

Battery Labels (for products with battery)

廢電池請回收

California Proposition 65 Warning

WARNING: This product can expose you to chemicals including acrylamide, arsenic, benzene,

cadmium, Tris(1,3-dichloro-2-propyl)phosphate (TDCPP), 1,4-Dioxane, formaldehyde, lead, DEHP,

styrene, DINP, BBP, PVC, and vinyl materials, which are known to the State of California to cause

cancer, and acrylamide, benzene, cadmium, lead, mercury, phthalates, toluene, DEHP, DIDP, DnHP,

DBP, BBP, PVC, and vinyl materials, which are known to the State of California to cause birth defects or other

reproductive harm. For more information go to www.P65Warnings.ca.gov.

Trademarks

Product names mentioned herein are used for identification purposes only and may be trademarks and/or

registered trademarks of their respective companies.

AMSTX-CF Series

Preface iii

Revision History

Revision Description Date By

1.0 Initial release 2020-12-21 JC

1.1 Add new models (EGX-MXM-RTX3000 and EGX-MXM-RTX5000); add MXM

cooler for RTX5000 and 500W power supply; update specifications; update block

diagrams; add mating connector list; update DisplayPort BIOS settings

2021-04-20 JC

iv Preface

Table of Contents

Preface................................................................................................................................ii

List of Figures ...................................................................................................................vi

List of Tables....................................................................................................................vii

1Introduction................................................................................................................1

1.1 Packing List ................................................................................................................1

1.2 Available Models.........................................................................................................1

1.3 Optional Accessories ..................................................................................................1

2Specifications............................................................................................................3

2.1 Core System ...............................................................................................................3

2.2 I/O Interface ................................................................................................................3

2.3 Video...........................................................................................................................4

2.4 Audio...........................................................................................................................4

2.5 Power Supply..............................................................................................................4

2.6 Temperatures .............................................................................................................4

2.7 Humidity......................................................................................................................4

2.8 Certificate (EMC) ........................................................................................................5

2.9 Form Factor ................................................................................................................5

2.10 Operating Systems .....................................................................................................5

2.11 Functional Block Diagram...........................................................................................5

3Mechanical Layout ....................................................................................................7

3.1 Connector Locations...................................................................................................7

3.2 Mechanical Dimensions............................................................................................10

4Connector Pinouts ..................................................................................................11

4.1 LEDs .........................................................................................................................11

4.2 Internal Connectors ..................................................................................................12

4.3 Jumper and Switch Settings .....................................................................................21

5Driver Installation....................................................................................................25

6System Resources ..................................................................................................27

6.1 System Memory Map................................................................................................27

6.2 I/O Map .....................................................................................................................27

6.3 Interrupt Request (IRQ) Lines...................................................................................28

6.4 PCI/PCIe Device.......................................................................................................30

6.5 SMBus Slave Addresses ..........................................................................................31

AMSTX-CF Series

Preface v

7Digital Input/Output Function Library....................................................................33

7.1 DI/O with Windows API.............................................................................................33

8DisplayPort BIOS Settings......................................................................................35

8.1 MXM P1000/P2000/T1000/RTX3000/ RTX5000 ......................................................35

8.2 MXM P3000/P5000...................................................................................................35

9BIOS Setup...............................................................................................................37

9.1 Menu Structure .........................................................................................................38

9.2 Main ..........................................................................................................................39

9.3 Advanced..................................................................................................................42

9.4 Chipset......................................................................................................................56

9.5 Security.....................................................................................................................61

9.6 Boot ..........................................................................................................................62

9.7 Save & Exit ...............................................................................................................63

Safety Instructions...........................................................................................................64

Getting Service.................................................................................................................65

vi Preface

List of Figures

Figure 1: Functional Block Diagram .........................................................................................................5

Figure 2: IO Panel Connector Locations ..................................................................................................7

Figure 3: Onboard Connector Locations- Top Side .................................................................................8

Figure 4: Onboard Connector Locations - Bottom Side ...........................................................................9

Figure 5: Mechanical Dimensions - Top View ....................................................................................... 10

AMSTX-CF Series

Preface vii

List of Tables

Table 1: IO Panel Connector Definitions ..................................................................................................7

Table 2: Onboard Connector Definitions - Top Side ................................................................................8

Table 3: Onboard Connector Definitions - Bottom Side ...........................................................................9

Table 4: System Memory Map .............................................................................................................. 27

Table 5: IO Map..................................................................................................................................... 27

Table 6: IRQ Lines PIC Mode................................................................................................................ 28

Table 7 IRQ Lines APIC Mode .............................................................................................................. 28

Table 8 PCI Configuration Space Map.................................................................................................. 30

Table 9 PCI Interrupt Routing Map........................................................................................................ 31

Table 10 SMBus Slave Addresses........................................................................................................ 31

viii Preface

This page intentionally left blank.

AMSTX-CF Series

Introduction 1

1 Introduction

Embedded graphics enable system developers to boost the performance of a wide range of workloads, including

medical imaging, image analysis, compute acceleration, and artificial intelligence (AI). Leveraging graphics

processing units (GPUs), embedded graphics can be used to increase application speed and accuracy, as well as

decrease latency. Many embedded system developers use embedded graphics solutions in real-world applications

from the medical and manufacturing industries, to traffic management. System developers, OEMs, and system

integrators can more easily deploy embedded graphics with support from ADLINK’s large portfolio of computing

products designed in a wide range of form factors. The AMSTX-CF Series Micro-STX motherboard features a

socket-type CPU and support for Scalable Graphics Processing Ranging from Pascal to Turing GPUs in a compact

form factor. Combining its strong expertise serving embedded developers and its close relationship with NVIDIA,

ADLINK is delivering high-performance, long-life embedded graphics solutions for a variety of market segments.

1.1 Packing List

•AMSTX-CF embedded motherboard

•CPU cooler bracket (P/N: 32-50015-0100-A0)

•M3 screw, P-head, L4, Ni for M.2 E/B/M Key (P/N: 33-03013-0040) (3 for Q370, 2 for H310)

•2x M3 screw, I-head, L4, Nylok for MXM (P/N: 33-03306-0040)

1.2 Available Models

Model AMSTX-CFP12-Q370 AMSTX-CFP35-Q370 AMSTX-CFP12-H310 AMSTX-CFP35-H310

MXM

Support

EGX-MXM-P1000

EGX-MXM-P2000/

EGX-MXM-T1000

EGX-MXM-RTX3000

EGX-MXM-RTX5000

EGX-MXM-P3000

EGX-MXM-P5000

EGX-MXM-P1000

EGX-MXM-P2000

EGX-MXM-1000

EGX-MXM-RTX3000

EGX-MXM-RTX5000

EGX-MXM-P3000

EGX-MXM-P5000

Chipset Intel® Q370 Chipset Intel® H310 Chipset

1.3 Optional Accessories

•65W CPU cooler (P/N: 32-20495-0000)

•35W CPU cooler (P/N: 32-20378-0000-A0)

•MXM cooler for P1000/P2000 (P/N: 32-20797-0200-A0)

•MXM cooler for P3000/P5000 (P/N: 32-20823-0020-A0)

•MXM cooler for T1000 (P/N: 32-20830-0200-A0)

•MXM cooler for RTX3000 (P/N: 32-20823-1100-A0)

•MXM cooler for RTX5000 (P/N: 32-20839-1000-A0)

•12V/240W adaptor (P/N: 31-62164-0010-A0)

•500W power supply (12V/41.7A) (P/N: 91-95296-000E)

•Wi-Fi Kit Intel® Wireless-AC 9260 non-vPRO (P/N: 91-95266-0020)

•AMSTX/DLAP-3000 CPU cooler bracket (included by default) (PN: 32-50015-0100-A0)

2 Introduction

This page intentionally left blank.
