Encoder Firmware V4.06.09 User’s Manual

4”Indoor Dome Series

Hardware Manual

D61, D62, D64, D65, E61, E62, E63,

E64, E65, E66, E67, E68, E69

2013/03/05

www.acti.com

Hardware Manual

Table of Contents

Precautions .............................................................3

Introduction............................................................4

The List of Models ................................................................................... 4

Package Contents .................................................................................... 5

Safety Instructions ................................................................................... 6

Physical Description ................................................................................. 7

Installation and Access ...........................................8

Camera Installation ................................................................................. 8

Accessing Camera .................................................................................... 9

www.acti.com

Hardware Manual

Precautions

Read these instructions

You should read all the safety and operating instructions before using this product.

Heed all warnings

You must adhere to all the warnings on the product and in the instruction manual. Failure to follow

the safety instruction given may directly endanger people, cause damage to the system or to

other equipment.

Servicing

Do not attempt to service this video device yourself as opening or removing covers may expose

you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

Trademarks

All names used in this manual are probably registered trademarks of respective companies.

Liability

Every reasonable care has been taken during the writing of this manual. Please inform your local

office if you find any inaccuracies or omissions. We cannot be held responsible for any

typographical or technical errors and reserve the right to make changes to the product and

manuals without prior notice.

FCC/CE Regulation

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to

radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the users will be required to correct the interference at their own

expense.

www.acti.com

Hardware Manual

Introduction

The List of Models

This hardware manual contains the following models:

D61

1MP Indoor Dome with SLLS, Vari-focal lens, f2.8-12mm/F1.4, H.264,

720p/30fps, DNR, MicroSDHC, PoE

D62

2MP Indoor Dome with SLLS, Vari-focal lens, f2.8-12mm/F1.4, H.264,

1080p/30fps, DNR, MicroSDHC, PoE

D64

1MP Indoor Dome with D/N, IR, Vari-focal lens, f2.8-12mm/F1.4,

H.264, 720p/30fps, DNR, MicroSDHC, PoE

D65

3MP Indoor Dome with D/N, IR, Vari-focal lens, f2.8-12mm/F1.4,

H.264, 1080p/30fps, DNR, MicroSDHC, PoE

E61

1MP Indoor Dome with D/N, IR, Basic WDR, Vari-focal lens,

f2.8-12mm/F1.4, H.264, 720p/30fps, DNR, MicroSDHC, PoE

E62

3MP Indoor Dome with D/N, IR, Basic WDR, Vari-focal lens,
