ACTi I91 Manuel utilisateur

Indoor PTZ Camera

Hardware Manual

I91, I92, KCM-8111

Ver. 2014/01/14

www.acti.com

Hardware Manual

Table of Contents

Precautions 4

Safety Instructions ...........................................................................6

Introduction 8

List of Models....................................................................................8

Package Contents.............................................................................9

Physical Description ......................................................................10

Connectors View..........................................................................10

Internal View ................................................................................ 11

Before Installation 12

Unpacking the Camera...................................................................12

Preparing the Power Adapter ........................................................13

Preparing the DI/DO Connector.....................................................15

Installation Procedures 18

Mounting Solutions ........................................................................18

Other Mounting Accessories ........................................................20

Mounting on the Ceiling.................................................................21

Using the Bundled Surface Mount ...............................................21

Using the Flush Mount.................................................................24

Using the Pendant Mount.............................................................30

Mounting on Straight Wall .............................................................34

Using the L-Type Wall Mount.......................................................34

Other Straight Wall Mounting Solutions .......................................37

Other Accessories and Adjustments 38

How to Replace the Dome Cover................................................... 38

How to Reset the Camera...............................................................39

Resetting KCM-8111 Camera.......................................................39

www.acti.com

Hardware Manual

Resetting I92 / I93 Camera..........................................................39

Accessing Camera 40

Configure the IP Addresses...........................................................40

Access the Camera.........................................................................44

www.acti.com

Hardware Manual

Precautions

Read these instructions

You should read all the safety and operating instructions before using this product.

Heed all warnings

You must adhere to all the warnings on the product and in the instruction manual. Failure to

follow the safety instruction given may directly endanger people, cause damage to the system

or to other equipment.

Servicing

Do not attempt to service this video device yourself as opening or removing covers may expose

you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

Trademarks

All names used in this manual are probably registered trademarks of respective companies.

Liability

Every reasonable care has been taken during the writing of this manual. Please inform your

local office if you find any inaccuracies or omissions. We cannot be held responsible for any

typographical or technical errors and reserve the right to make changes to the product and

manuals without prior notice.

www.acti.com

Hardware Manual

Federal Communications Commission Statement

This equipment has been tested and found to comply with the limits for a class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications to the equipment that are not expressly approved by the

responsible party for compliance could void the user’s authority to operate the equipment.

European Community Compliance Statement

This product has been tested and found to comply with the limits for Class B

Information Technology Equipment according to European Standard EN 55022

and EN 55024. In a domestic environment, this product may cause radio interference in which

cause the user may be required to take adequate measures.

www.acti.com

Hardware Manual

Safety Instructions

Don’t use the power supply with other voltages

This device is likely to be damaged or damage other equipments / personnel, if you use a

power supply with different voltage than the one included with this device. All warranty of this

product will be voided in the situations above.

Don’t open the housing of the product

Cleaning

Disconnect this video product from the power supply before cleaning.

Attachments

Do not use attachments not recommended by the video product manufacturer as they may

cause hazards.

Water and Moisture

Do not use this video product near water, for example, near a bathtub, washbowl, kitchen sink,

or laundry tub, in a wet basement, or near a swimming pool and the like.

Don’t use accessories not recommended by the manufacturer

Only install this device and the power supply in a dry place protected from weather

Servicing

Do not attempt to service this video product yourself as opening or removing covers may

expose you to dangerous voltage or other hazards. Refer all servicing to qualified service

personnel.

Damage Requiring service

Disconnect this video product from the power supply immediately and refer servicing to

qualified service personnel under the following conditions.

1) When the power-supply cord or plug is damaged

2) If liquid has been spilled, or objects have fallen into the video product.

3) If the video product has been directly exposed to rain or water.

www.acti.com

Hardware Manual

4) If the video product does not operate normally by following the operating Instructions in this

manual. Adjust only those controls that are covered by the instruction manual, as an

improper adjustment of other controls may result in damage, and will often require

extensive work by a qualified technician to restore the video product to its normal operation.

Safety Check

Upon completion of any service or repairs to this video product, ask the service technician to

perform safety checks to determine if the video product is in proper operating condition.

www.acti.com

Hardware Manual

Introduction

List of Models

This hardware manual contains the following models:

KCM-8111

2MP Indoor PTZ with D/N, Advanced WDR, SLLS, 18x Zoom

lens

I91

1MP Indoor PTZ with D/N, Extreme WDR, SLLS, 30x Zoom lens

I92

2MP Indoor PTZ with D/N, Extreme WDR, SLLS, 30x Zoom lens

www.acti.com

Hardware Manual

Package Contents

Camera

Power Adapter

Universal Plug Converter

Surface Mount

Mounting Screw Kit

Fixing Bracket

Drill Template

Terminal Block

(for Power)

Terminal Block

(for DIO/DO)

Quick Installation Guide

Warranty Card

Drill Template

www.acti.com

Hardware Manual

Physical Description

Connectors View

1) Memory Card Slot

Insert a memory card (not included) into the slot for local recording purposes.

NOTE: Supports microSDHC and microSDXC cards.

2) Digital Input / Output (DI/DO)

This connector connects to digital input or output devices, such as an alarm trigger, panic

button, etc. Digital Input (DI) and Digital Output (DO) devices are used in applications like

motion detection, event triggering, alarm notifications, etc. Please refer to Preparing the

DI/DO Connector on page 15 for information on how to connect DI/DO devices to your

camera.

3) Audio IN

This jack connects to an audio input device, such as a microphone with built-in amplifier.

NOTE: Make sure that the connected audio input device has a built-in amplifier. Connecting an

ordinary microphone will dwarf sounds and will result in inaudible recording.

4) Audio OUT

This jack connects to an audio output device, such as a speaker.

5) DC 12V Power Input

Connect DC power source to the terminal block. The wire with white dashed lines is the live wire,

which should connect to the 12V pin.

6) Ethernet Port

The Ethernet port connects to a network using a standard Ethernet cable.
