More and more people are relying on smart devices and cloud-based applications for business

communications. This means that high network availability is critical for business continuity, more

Wi-Fi is demanded in the workplace, and traditional regulatory measures for application usage

are obsolete. Without an eective solution to control, optimize and block social, productivity and

other Web applications, SMBs risk losing work productivity and exposing company networks to

new Web threats.

The new ZyXEL USG Advanced Series are Next Generation Firewalls

(NGFW) designed to meet the mobility, anti-malware and policy

enforcement challenges in SMBs. The integrated WLAN controller

oers easy WLAN scalability for the growing demand for Wi-Fi;

while WAN and VPN load balancing and failover ensures non-

stop business communications. ZyXEL USGs oer industry-

leading anti-virus, anti-spam, content ltering and application

intelligence technology for eective application optimization and

comprehensive network protection.

Benets

Always online

The ZyXEL USG Advanced Series oers SMBs high network availability for always online communications.

It features multi-WAN load balancing and failover, and a comprehensive mobile broadband USB modem

support list for WAN backup. On top of that, the Series supports IPSec load balancing and failover to

provide added resiliency for the most mission-critical VPN deployments.

Protection and optimization

The ZyXEL USG Advanced Series provides extensive anti-malware protection and eective control of

Web applications—like Facebook, Google Apps and Netix—with industry-leading rewall, anti-virus,

anti-spam, content ltering, IDP and application intelligence. These security measures are enhanced with

SSL inspection, which helps block threats that are hidden in SSL encrypted connections and facilitates

deeper policy enforcement.

• High-performance, high-value

Next Generation Firewall (NGFW)

for small and medium-sized

businesses

• Anti-malware protection

with rewall, anti-virus, anti-

spam, content ltering, IDP,

next-generation application

intelligence and SSL inspection

• Robust SSL, IPSec and L2TP over

IPSec VPN connectivity and VPN

high availability (HA)

• Built-in WLAN controller for

centralized AP management and

eortless WLAN scalability of up

to 18 APs

• Comprehensive mobile

broadband USB modem

compatibility and multi-WAN

load-balancing, failover and fall

back support

USG310/210/110

Unied Security Gateway—

Advanced Series

Secure and Always Online Networking for

Small- to Medium-sized Businesses

Streamlined management

Uni ed security policy streamlines the con guration of rewall and every security feature to o er faster, easier and more consistent policy management.

From a single interface, users can apply all policy criteria to every UTM feature with reduced complexity. The integrated WLAN controller also enables

users to management up to 18 APs from a centralized user interface.

More Wi-Fi

Addressing the trend of BYOD, the ZyXEL USG Advanced Series helps SMBs satisfy the Wi-Fi demand for an exploding amount of smart devices. The Series

is integrated with a WLAN controller that enables businesses to easily scale up the WLAN and provide Wi-Fi in multiple areas like meeting rooms and guest

reception areas.

Model List

USG310

Unied Security Gateway

USG110

Unied Security Gateway

USG210

Unied Security Gateway

• 8 x GbE RJ-45, 2 x USB (multi-WAN & mobile broadband)

• 5,000 Mbps rewall throughput

• 650 Mbps VPN throughput

• 450 Mbps IDP throughput

• 400 Mbps AV throughput

• 400 Mbps AV and IDP throughput

• 7 x GbE RJ-45, 2 x USB (multi-WAN & mobile broadband)

• 1,600 Mbps rewall throughput

• 400 Mbps VPN throughput

• 300 Mbps IDP throughput

• 250 Mbps AV throughput

• 250 Mbps AV and IDP throughput

• 7 x GbE RJ-45, 2 x USB (multi-WAN & mobile broadband)

• 1,900 Mbps rewall throughput

• 500 Mbps VPN throughput

• 350 Mbps IDP throughput

• 300 Mbps AV throughput

• 300 Mbps AV and IDP throughput

USG310/210/110

Uniﬁed Security Gateway—Advanced Series

Multi-WAN & Mobile Broadband

The ZyXEL USG Advanced Series provides non-stop

Internet uptime with multi-WAN and mobile broadband

support. Multi-WAN works with two or more Ethernet

WAN connections for active-active WAN load balancing

or active-passive failover. Comprehensive mobile

broadband USB modems are also supported for WAN

backup.

VPN High Availability (HA)

ZyXEL USGs feature VPN HA to satisfy the demands of

the most mission-critical VPN deployments. Supporting

advanced GRE over IPSec technology, users can deploy

two IPSec VPN tunnels for active-active VPN load

balancing or active-passive failover.

Unied Security Policy

Unied security policy oers object-based management

and a unied conguration interface for rewall and all

security-related policies. Users can easily apply all policy

criteria to every UTM feature, reduce conguration time,

and get more streamlined policy management.

Anti-Virus

ZyXEL USGs provide comprehensive and real-time

protection against malware threats before they enter the

network. ZyXEL USGs can identify and block over 650,000

viruses right at the gate and provide high-speed scanning

with stream-based virus scanning technology.

Anti-Spam

With a cloud-based IP reputation system, ZyXEL anti-

spam can deliver accurate, zero-hour spam outbreak

protection by analyzing up-to-the-minute sender

reputation data from highly diverse trac sources. It

can detect spam outbreaks in the rst few minutes of

emergence regardless of spam language or format.

Feature Introduction

Robust VPN

ZyXEL USGs support high-throughput IPSec, L2TP over

IPSec and SSL VPN for a wide range of site-to-client

and site-to-site VPN deployments. Reinforced with the

advanced SHA-2 encryption, the ZyXEL USGs provide the

most secure VPN for business communications.

Integrated WLAN Controller

The integrated WLAN controller supports CAPWAP,

and enables centralized authentication and access

management of multiple APs in the network. The ZyXEL

USG Advanced Series can manage 2 APs by default, and

up to 18 APs with license upgrade.

Application Intelligence

ZyXEL’s USG Advanced Series can identify, categorize

and control over 3,000 social, gaming, productivity, and

other Web applications and behaviors. Users can prioritize

productive applications, throttle acceptable ones, and

block unproductive applications to boost productivity

and prevent bandwidth abuse.

SSL Inspection

SSL inspection enables the ZyXEL Advanced Series to

provide not only comprehensive security, but also deeper

policy enforcement. It enables the USG’s application

intelligence, IDP, content ltering and anti-virus to inspect

trac in SSL encrypted connections and block threats

that usually go unseen.

Content Filtering

ZyXEL content ltering helps screen access to websites

that are not business related or malicious. With a massive,

cloud-based database of over 140 billion URLs that are

continuously analyzed and tracked, ZyXEL provides highly

accurate, broad and instant protection against malicious

Web content.

USG310/210/110

Unied Security Gateway—Advanced Series

USG310/210/110

Unied Security Gateway—Advanced Series

Application Diagram

Anti-malware protection and

application optimization

• Enabling anti-virus, anti-spam and

intrusion prevention, business

networks gain deep, extensive

protection against all types of

malware threats

• Content ltering enables businesses

to deny access to Websites that are

malicious or not business-related

• Application intelligence technology

not only enable businesses to block

or throttle non-productive Web

applications, but also optimize

Web applications that increase

productivity

VPN application

• Branch oces, partners and home

users can deploy ZyXEL USGs for

site-to-site IPSec VPN connections

• Branch oces can additionally

deploy IPSec VPN HA (load

balancing and failover) for always

online VPN connectivity

• Remote users can securely access

company resources with their

computers or smartphones via SSL,

IPSec and L2TP over IPSec VPN

• The headquarter USG can also

establish an IPSec VPN connection

with Microsoft Azure for secured

access to a variety of cloud-based

applications

Internet

Unied Security Gateway

Remote

Desktop Network

Extend

System Web

Apps

Inventory

Server File

Sharing

OA, ERP,

CRM System Email

Server

DMZ Resources

Remote

Desktop Network

Extend

System Web

Apps

Inventory

Server File

Sharing

OA, ERP,

CRM System Email

Server

DMZ Resources

Workgroup

Productive Web applications

Non-productive

Web applications

Viruses, intrusions,

malicious Websites,

email spam

SPAM

Anti-Virus Intrusion

Prevention

Anti-Spam Content

Filtering

Application Intelligence

& Optimization

Headquarters

Branch

Oce

Partner

Oce

SSL VPN

IPSec VPN

IPSec VPN HA

L2TP over

IPSec VPN

USG40W

Unied Security

Gateway

USG110

Unied Security

Gateway

USG1100

Unied Security

Gateway

USG1900

Unied Security

Gateway

Traveling

Employee

Traveling

Employee

Traveling

Employee

Home

User

Microsoft

Azure

Internet

Unied Security Gateway

Remote

Desktop Network

Extend

System Web

Apps

Inventory

Server File

Sharing

OA, ERP,

CRM System Email

Server

DMZ Resources

Remote

Desktop Network

Extend

System Web

Apps

Inventory

Server File

Sharing

OA, ERP,

CRM System Email

Server

DMZ Resources

Workgroup

Productive Web applications

Non-productive

Web applications

Viruses, intrusions,

malicious Websites,

email spam

SPAM

Anti-Virus Intrusion

Prevention

Anti-Spam Content

Filtering

Application Intelligence

& Optimization

Headquarters

Branch

Oce

Partner

Oce

SSL VPN

IPSec VPN

IPSec VPN HA

L2TP over

IPSec VPN

USG40W

Unied Security

Gateway

USG110

Unied Security

Gateway

USG1100

Unied Security

Gateway

USG1900

Unied Security

Gateway

Traveling

Employee

Traveling

Employee

Traveling

Employee

Home

User

Microsoft

Azure

USG310/210/110

Uniﬁed Security Gateway—Advanced Series

Specications

Model USG310 USG210 USG110

Hardware Specifications

10/100/1000 Mbps RJ-45 ports 8 (configurable) 4 x LAN/DMZ, 2 x WAN, 1 x OPT 4 x LAN/DMZ, 2 x WAN, 1 x OPT

USB ports 2 2 2

Console port Yes (DB9) Yes (DB9) Yes (DB9)

Rack-mountable Yes Yes Yes

System Capacity & Performance*1

SPI firewall throughput (Mbps)*2 5,000 1,900 1,600

VPN throughput (Mbps)*3 650 500 400

IDP throughput (Mbps)*4 450 350 300

AV throughput (Mbps)*4 400 300 250

UTM throughput (AV and IDP)

400 300 250

Unlimited user licenses Yes Yes Yes

Max. TCP concurrent sessions*5 100,000 80,000 60,000

New TCP session rate 12,000 3,500 3,500

Max. UTM (AV & IDP) concurrent sessions*5 100,000 80,000 60,000

Max. concurrent IPsec VPN tunnels 300 200 100

Max. concurrent SSL VPN users 105 50 25

Included SSL VPN user no. 25 10 5

Customizable zones Yes Yes Yes

IPv6 support Yes Yes Yes

VLAN interface 64 32 16

WLAN Management

AP Controller (APC) ver. 1.0 1.0 1.0

Managed AP number (default/max.) 2/18 2/18 2/18

Key Software Features

Virtual Private Network (VPN) Yes (IPSec, SSL, L2TP over IPSec) Yes (IPSec, SSL, L2TP over IPSec) Yes (IPSec, SSL, L2TP over IPSec)

Firewall Yes Yes Yes

Anti-Virus (AV) Yes Yes Yes

Anti-spam Yes Yes Yes

Content Filtering (CF) Yes Yes Yes

Application intelligence and optimization Yes Yes Yes

Intrusion Detection and Prevention (IDP) Yes Yes Yes

SSL inspection Yes Yes Yes

Single Sign-On (SSO) Yes Yes Yes

Power Requirements

Power input 100 - 240 V AC, 50/60 Hz, 1.3 A max. 12 V DC, 3.33 A max. 12 V DC, 3.33 A max.

Max. power consumption (watt) 58.5 37.0 37.0

Others

MTBF (hr) 560,811.5 787,109.3 787,109.3

Physical Specifications

Item dimensions (WxDxH)(mm/in.) 430 x 250 x 44/16.93 x 9.84 x 1.73 300 x 178 x 44/11.81 x 7 x 1.73 300 x 178 x 44/11.81 x 7 x 1.73

Item weight (kg/lb.) 3.3/7.28 2/4.4 2/4.4

*1: Actual performance may vary depending on network conditions and activated applications.

*2: Maximum throughput based on RFC 2544 (1,518-byte UDP packets).

*3: VPN throughput measured based on RFC 2544 (1,424-byte UDP packets).

*4: AV and IDP throughput measured using the industry standard HTTP performance test (1,460-byte HTTP packets). Testing done with multiple flows.

*5: Maximum sessions measured using the industry standard IXIA IxLoad testing tool.

USG310/210/110

Unied Security Gateway—Advanced Series

Features Set

Software Features

Firewall

• ICSA-certied rewall (certication in

progress)

• Routing and transparent (bridge) modes

• Stateful packet inspection

• User-aware policy enforcement

• SIP/H.323 NAT traversal

• ALG support for customized ports

• Protocol anomaly detection and protection

• Trac anomaly detection and protection

• Flooding detection and protection

• DoS/DDoS protection

IPv6 Support

• IPv6 Ready gold logo (certication in

progress)

• Dual stack

• IPv4 tunneling (6rd and 6to4 transition

tunnel)

• IPv6 addressing

• DNS

• DHCPv6

• Bridge

• VLAN

• PPPoE

• Static routing

• Policy routing

• Session control

• Firewall and ADP

• IPSec VPN

• Intrusion Detection and Prevention (IDP)

• Application intelligence and optimization

• Content ltering

• Anti-virus, anti-malware

• Anti-spam

IPSec VPN

• ICSA-certied IPSec VPN (certication in

progress)

• Encryption: AES (256-bit), 3DES and DES

• Authentication: SHA-2 (512-bit), SHA-1 and

MD5

• Key management: manual key, IKEv1 and

IKEv2 with EAP

• Perfect forward secrecy (DH groups) support

1, 2, 5

• IPSec NAT traversal

• Dead peer detection and relay detection

• PKI (X.509) certicate support

• VPN concentrator

• Simple wizard support

• VPN auto-reconnection

• VPN High Availability (HA): load-balancing

and failover

• L2TP over IPSec

• GRE and GRE over IPSec

• NAT over IPSec

• ZyXEL VPN client provisioning

SSL VPN

• Supports Windows and Mac OS X

• Supports full tunnel mode

• Supports 2-step authentication

• Customizable user portal

Intrusion Detection and Prevention (IDP)

• Routing and transparent (bridge) mode

• Signature-based and behavior-based

scanning

• Automatic signature updates

• Customizable protection prole

• Customized signatures supported

• SSL (HTTPS) inspection support

Application Intelligence and Optimization

• Granular control over the most important

applications

• Identies and controls over 3,000 applications

and behaviors

• Supports over 15 application categories

• Application bandwidth management

• Supports user authentication

• Real-time statistics and reports

• SSL (HTTPS) inspection support

Anti-Virus

• Supports Kaspersky anti-virus signatures

• Identies and blocks over 650,000 viruses

• Stream-based anti-virus engine

• HTTP, FTP, SMTP, POP3 and IMAP4 protocol

support

• Automatic signature updates

• No le size limitation

• SSL (HTTPS) inspection support

Anti-Spam

• Transparent mail interception via SMTP and

POP3 protocols

• Congurable POP3 and SMTP ports

• Sender-based IP reputation lter

• Recurrent Pattern Detection (RPD) technology

• Zero-hour virus outbreak protection

• X-Header support

• Blacklist and whitelist support

• Supports DNSBL checking

• Spam tag support

• Statistics report

Content Filtering

• Social media ltering

• Malicious Website ltering

• URL blocking and keyword blocking

• Blacklist and whitelist support

• Blocks java applets, cookies and ActiveX

• Dynamic, cloud-based URL ltering database

• Unlimited user license support

• Customizable warning messages and

redirection URL

• SSL (HTTPS) inspection support

Unied Security Policy

• Unied policy management interface

• Supported UTM features: anti-virus, anti-

spam, IDP, content ltering, application

intelligence, rewall (ACL)

• 3-tier conguration: object-based, prole-

based, policy-based

• Policy criteria: zone, source and destination IP

address, user, time

WLAN Management

• ZyXEL AP Controller (APC) 1.0 compliant

• Client RSSI threshold to prevent sticky clients

• IEEE 802.1x authentication

• Wireless Layer 2 isolation

• Captive portal Web authentication

• Customizable captive portal page

• Dynamic guest accounts

• RADIUS authentication

• Wi-Fi Multimedia (WMM) wireless QoS

• CAPWAP discovery protocol

• ZyXEL Wireless Optimizer (ZWO) AP planning

Mobile Broadband

• WAN connection failover via 3G and 4G* USB

modems

• Auto fallback when primary WAN recovers

* 4G USB modem support available in future rmware upgrades

Networking

• Routing mode, bridge mode and hybrid

mode

• Ethernet and PPPoE

• NAT and PAT

• VLAN tagging (802.1Q)

• Virtual interface (alias interface)

• Policy-based routing (user-aware)

• Policy-based NAT (SNAT)

• Dynamic routing (RIPv1/v2 and OSPF)

• DHCP client/server/relay

• Dynamic DNS support

• WAN trunk for more than 2 ports

• Per host session limit

• Guaranteed bandwidth

• Maximum bandwidth

• Priority-bandwidth utilization

Licenses

Security

Model Kaspersky Anti-Virus Application Intelligence

& IDP Content Filtering Anti-Spam

USG310 1 year

2 years

1 year

2 years

1 year

2 years

1 year

2 years

USG210 1 year

2 years

1 year

2 years

1 year

2 years

1 year

2 years

USG110 1 year

2 years

1 year

2 years

1 year

2 years

1 year

2 years

Notes:

1. ZyXEL USGs can be purchased with 13-month bundled licenses (anti-virus, anti-spam and content ltering), which include a 1-month trial.

2. Licenses can be easily activated, renewed and managed at myZyXEL.com (www.myzyxel.com)

3. License bundles may vary according to region. Please contact your local sales representative for more information.

VPN, Management and Reporting

Model SSL VPN Managed APs IPSec VPN Client Vantage Report

USG310 Add 10 tunnels Add 8 APs For 1 client

For 5 clients

For 10 clients

For 50 clients

For 1 device

For 5 devices

For 25 devices

For 100 devices

USG210 Add 10 tunnels Add 8 APs

USG110 Add 10 tunnels Add 8 APs

Authentication

• Local user database

• Microsoft Windows Active Directory

integration

• External LDAP/RADIUS user database

• XAUTH, IKEv2 with EAP VPN authentication

• Web-based authentication

• Forced user authentication (transparent

authentication)

• IP-MAC address binding

• SSO (Single Sign-On) support

Device High Availability (HA)

• Active-passive failover mode

• Device failure detection and notication

• Supports ICMP and TCP ping check

• Link monitoring

• Conguration auto-sync

System Management

• Role-based administration

• Multiple administrator logins

• Multi-lingual Web GUI (HTTPS and HTTP)

• Command line interface (console, Web

console, SSH and TELNET)

• SNMP v2c (MIB-II)

• System conguration rollback

• Firmware upgrade via FTP, FTP-TLS and Web

GUI

• Dual rmware images

Logging and Monitoring

• Comprehensive local logging

• Syslog (to up to 4 servers)

• Email alerts (to up to 2 servers)

• Real-time trac monitoring

• Built-in daily report

• Advanced reporting with Vantage Report

Access Point Compatibility List

Series

NWA3000-N Series NWA5000 Series NWA5120 Series

Unified Pro Access Point Managed Access Point Unified Access Point

Model

NWA3160-N

NWA3560-N

NWA3550-N

NWA5160N

NWA5560-N

NWA5550-N

NWA5121-NI

NWA5121-N

NWA5123-NI

Functions

Central management Yes Yes Yes

Auto provisioning Yes Yes Yes

Data forwarding Local bridge Local bridge Local bridge

USG310/210/110

Unied Security Gateway—Advanced Series

For more product information, visit us on the web at www.ZyXEL.com

of ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of

their respective owners. All specications are subject to change without notice.

5-100-00814001 05/14

Autres manuels pour USG310

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ZyXEL Communications Porte

ZyXEL Communications

ZyXEL Communications ZYAIR B-2000 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications Prestige 662H Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications UAG50 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications VMG1312-T20A Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZyXEL ZyWALL USG-1000 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications P870HNU-51B Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZyXEL ZyWALL 10W Manuel utilisateur

ZyXEL Communications

ZyXEL Communications P-870HW-51A V2 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications P-870HN-51B - V1.0 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZyXEL Prestige 310 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications USG310 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications nebula NSG Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications P-2302R-P1 Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZyWALL USG 100 Series Mode d’emploi

ZyXEL Communications

ZyXEL Communications P-660HW Series Instructions d'installation

ZyXEL Communications

ZyXEL Communications Broadband Security Gateway P-312 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications p-2302rl series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications P-660HU-T1 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications AMG1202-T10A Manuel de l'opérateur

ZyXEL Communications

ZyXEL Communications P-660HN-TxA Manuel utilisateur

ZyXEL Communications

ZyXEL Communications P-2302HWUDL-P1 Series Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZyWALL 10 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZyAIR G-4100 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZyXEL ZyWALL USG-1000 Manuel utilisateur

Manuels Porte populaires d'autres marques

LST

LST M500RFE-AS Manuel utilisateur

Kinnex

Kinnex Media Gateway Manuel utilisateur

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuel utilisateur

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuel utilisateur

Telsey

Telsey CPVA 500 - SIP Manuel utilisateur

RTA

RTA 460A-NNA4 Fiche technique

Shaw

Shaw Gateway HDPVR Manuel utilisateur

ABB

ABB VSN900 Guide de démarrage rapide

Commander

Commander Pulse Manuel utilisateur

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuel utilisateur

NETGEAR

NETGEAR C6300BD Manuel utilisateur

Amit

Amit CDW531AM Manuel utilisateur

HMS

HMS Netbiter EasyConnect EC150 Manuel utilisateur

Huawei

Huawei EchoLife HG620 Manuel utilisateur

AT&T

AT&T U-verse 3801 Manuel d'utilisation et d'entretien

Logic IO

Logic IO RTCU MX2 turbo Manuel utilisateur

Suttle

Suttle MediaMAX MXM-521 Manuel utilisateur

RTA

RTA 460MCBC-N2E Fiche technique
