Zte OPTUS MF920V Manuel utilisateur

MF920V

Quick Start Guide

Getting to Know Your Device

Appearance

The following gure is for your reference only.

1. *External antenna connectors (not all the devices

support)

2. Charging/micro-USB jack

3. Indicator light

4. Power key

• Press and hold for about 3 seconds to power on/off

your device.

• Press and hold for about 10 seconds to restart your

device.

5. WPS key

Press and hold for 3 seconds to activate the WPS

function.

6. micro-SIM card slot and reset hole

Getting to Know Your Device

Indicator lights

Indicator Status Description

Battery

Red solid /

blinking

The battery is low. Please

charge the battery.

Green

blinking

The battery is being

charged.

Green solid The battery level is middle

or high.

Light off Your device is not being

charged.

Wi-Fi

Blue solid Wi-Fi is active.

Blue

blinking WPS is active.

Light off Wi-Fi is off.

SMS

Blue solid You have unread mes-

sages.

Blue

blinking You have new messages.

Light off There is no unread mes-

sage or new message.

Indicator Status Description

Network

Red

Error status. Not registered

to the mobile network, no

micro-SIM card inserted or

no network service avail-

able.

Green solid Registered to the 2G/3G

mobile network.

Green

blinking

Connected to the 2G/3G

mobile network and data is

being transferred.

Blue solid Registered to the 4G LTE

network.

Blue

blinking

Connected to the 4G LTE

network and data is being

transferred.

Getting to Know Your Device

Connection Scenarios

The device allows multiple clients to surf on the Inter-

net at the same time. The following gure is for your

reference only.

4G Mode: A micro-SIM card can be used to access the

Internet.

Installing Your Device

1. Open the micro-SIM card cover.

NOTE:

Do not remove the cover roughly, because it is con-

nected with the device.

2. Install a micro-SIM card to the micro-SIM card slot.

WARNING!

Your device does not support SIM cards, nano-SIM

cards or any other non-standard micro-SIM cards. To

avoid damage to the device, do not use those cards or

any card holders.

3. Close the micro-SIM card cover.

Connecting to Your Device

Using Wi-Fi

1. Power on your device.

2. Ensure that your computer or other client devices

have enabled Wi-Fi, and search for available

wireless networks.

NOTE:

Refer to your Wi-Fi-enabled client device manual for

further details on how to search for wireless networks.

If you use a computer, you need to set your computer

to obtain an IP address automatically.

3. Select the Wi-Fi name (SSID) of your device, and

click Connect.

4. Enter the Wi-Fi password if necessary, and click

OK.

NOTE:

Refer to the chapter Getting to Know the Wi-Fi SSID

and Password to get the default Wi-Fi SSID and pass-

word.

5. Wait until the client device is connected to your

device successfully.

Connecting to Your Device

Using a USB Cable

1. Connect a computer to your device with a USB

cable.

2. Power on your device. The operating system

detects and identies new hardware, and

automatically installs the software.

NOTE:

If the system does not automatically launch installation,

you can double-click the device installation icon in My

Computer to install the software.

3. Wait until the computer is connected to your device

successfully.

Getting to Know the Wi-Fi SSID and

Password

You can view the label on the device to get the default

Wi-Fi SSID and password.

Logging in to the 4G Mobile Hotspot

Conguration Page

1. Ensure that the connection between your device

and the client device is correct.

2. Launch the Internet browser and enter

http://192.168.0.1 in the address bar.

3. Enter the password to log in to the 4G Mobile

Hotspot conguration page.

NOTE:

The default password is admin.

Changing the Wi-Fi SSID or Password

1. Log in to the 4G Mobile Hotspot conguration

page.

2. Select Wi-Fi Settings.

3. Change the Network Name (SSID) or the

Password in the Main SSID area.

4. Click Apply.

Accessing the Internet

After a client device is successfully connected to your

device, you can access the Internet in Automatic or

Manual mode. The default mode is Automatic.

Mode Operation

Automatic

Your device is automatically connected

to the Internet, and you can surf on the

Internet through the client.

Manual

1. Log in to the 4G Mobile Hotspot

conguration page.

2. In My router section, select LTE

(or other network type) Settings >

Connection Mode > Manual, and

then click Apply.

3. Click to return to the home page,

and then click or .

NOTE:

• To change current connection setting, please

disconnect from network.

• To modify the parameters of your device, log in to

the 4G Mobile Hotspot conguration page.
